IAC INDUSTRIES Quick Ship WORKMASTER User manual

INDUSTRIES
Quick Ship
WORKMASTER WORK BENCHES
IAC INDUSTRIES
3831 S BULLARD AVE., GOODYEAR, AZ 85338
Phone [phone] Fax [phone]
www.iacindustries.com
QS Workmaster
REV. (042318P65)Assembly Instructions

2
Table Of Contents
Page #
3 Attention Notes
4 Pre-assembly Check List
5 to 6 WM Workbench
7 to 8 Instrument Shelf / Riser Electrical
9 WM Undershelf Light
10 Footrest / Footpan
11 Electrical Strip
12 to14 Drawer / Double Drawer
15 Plate Caster Leg Extender Kit
16 ESD Grounding & Cleaning
PLEASE NOTE:
Quick Ship Accessories include assembly instructions
in their own packaging when packed by individually.
Please look for these instructions while unpacking.
If you are installing MTS posts to your 30” deep benches
only…make sure to install the “MTS T-nuts”, shown in the
QS MTS Assembly Instructions prior to installing and
securing the frame to the work surface. (Reference page 5)

3
ATTENTION NOTES:
IAC Industries takes great care in the packaging of its products, however damage
can occur during shipment. Check all packages and parts for any signs of damage. If
damage is evident STOP and contact the carrier that delivered your order. Request a
freight claim inspector to document the damage and begin the freight claim process.
Tools required to assemble your QS WM BENCH products are:
7/16” and 1/2” wrench or socket with ratchet.
Phillips screwdriver 8” long.
Utility knife.
Safety glasses and light duty protective gloves.
NOTE: Power tools are NOT recommended unless they are equipped with a torque
limiting device which can limit the torque to 10 foot lbs maximum at aluminum
attachment points, and 15 foot lbs maximum for all other attachment points.
Unpack your order and separate like parts into separate areas. Be careful not to
damage parts as they are being moved around and put into position. Also be sure all
parts are removed from the packing materials before these materials are thrown
away.
Locate the hardware kits and keep them in a central area. If the assembly is going to
take more than one day, all individual hardware pieces should be returned to a
central location.
Check all parts and hardware kits against the itemized packing list found with the
assembly instructions. If you believe there are parts missing from your order please
contact IAC Industries customer service HOTLINE at 800-989-1422.
If your order has ESD worksurfaces or accessories please review page 16 for helpful
instructions and cautions before you begin assembling the workstations.
WARNING:
ALL PARTICLE BOARD USED IN IAC INDUSTRIES PRODUCTS ARE SOURCED ONLY FROM VENDORS THAT
ARE CARB ATCM PHASE 2 AND TSCA TITLE VI COMPLIANT WITH VALID CERTIFICATES.Drilling, Sawing, Sanding
or Machining Wood products can expose you to wood dust, a substance known to the state of California to cause cancer. Avoid inhaling
dust generated from wood products or use a dust mask to other safeguards for personal protection. This product can expose you to
chemicals, including formaldehyde, which is known to the state of California to cause cancer, and methanol, which is known to the state
of California to cause birth defects or other reproductive harm. For more information please visit, www.P65WARNINGS.CA.GOV/WOOD.
COPY OF VENDOR CERTIFICATE AVAILABLE UPON REQUEST.

4
PRE ASSEMBLY CHECK LIST
Your bench has been carefully packed at the factory to prevent damage during shipment. Unpack all parts
and examine them for damage. Contact your freight carrier for freight claims information if your order was
shipped "freight collect" or "pre-pay and add". Contact IAC Industries at 800 989-1422 if parts are missing.
HARDWARE KIT QS-HWR0078:
1/4-20x3/4" Hex Head Bolt 1/4" Flat Washer 5/16-18x3/4" Hex Head Bolt Beam Connector Plate
HARDWARE KIT COMPONENTS:
Description Qty
1/4-20 x 3/4" Hex Head Bolt 16
1/4" Flat Washer 24
5/16-18 x 3/4" Hex Head Bolt 8
Beam Connector Plate 4
Floor Glides 4
WORKBENCH CONTENTS:
Description Qty
Worksurface 1
Pedestal Legs 2
Support Beams 2
Leg Extenders 4
TOOLS NEEDED: Power or hand held phillips head screwdriver with #2 tip, 7/16" and 1/2" combination
wrench or thin wall sockets.

5
QS Workmaster Bench Assembly:
Step 1:
Attach beam connector plates to the ends of the bench support beams using the 5/16-18 x .75 HH bolts and
1/4” flat washers supplied as shown. DO NOT TIGHTEN THE HARDWARE.
PLEASE NOTE: If you are installing MTS posts to your 30” deep benches only…make sure to install the MTS
T-nuts, shown in the QS MTS Assembly Instructions prior to installing and securing the frame support
beams to the work surface.
Step 2:
Place worksurface top side down on smooth flat surface being sure to protect it from damage by foreign
objects. IAC recommends the use of packing type blankets or clean cardboard. Place the support beams on
the worksurface with the open side toward the center of the worksurface and align the slots of the support
beams over the threaded inserts in the worksurface as shown. Thread 1/4-20 x .75 HH bolts and 1/4” flat
washers into the threaded inserts to attach the beams to the worksurface. DO NOT TIGHTEN THE
HARDWARE.

6
QS Workmaster Bench Assembly: (cont)
Step 3:
Align the workbench pedestals over the ends of the support beams and lower them down over the beam
connector plates so that the plates are on the inside of the pedestal tubing. Align the slots in the pedestal
support beam over the inserts in the worksurface and thread the 1/4-20 x .75 HH bolts with the 1/4 washers
into the inserts. Tighten the beam connector hardware. The frame should now be aligned on the worksurface
to even the overhangs on the right and left sides Tighten the beam attachment and the pedestal support
beam hardware. NOTE: Do not over tighten the hardware that goes into the threaded inserts in the
worksurface as this could cause the insert to pull out.
Step 4:
Slide the workbench leg extender into the pedestal tube making sure the plastic insert in the end of the leg
extender is exposed. Align the threads of the leg extender with the holes in the pedestal tube and select the
desired height of the bench. Thread the 1/4-20 x .75 HH bolts with the 1/4 washers into the threaded holes in
the leg extender and tighten. Thread the floor glide into the plastic insert of the leg extender. The floor glides
are used to level the bench when assembly is complete and it is put into position.
If you have ordered footrests, drawers or suspended cabinets for this bench please see pages 10 and 12 for
assembly instructions. If not the workbench can be turned over for assembly of above the worksurface
accessories or it can be put into place.

7
QS WM Instrument Shelf:
HARDWARE KIT QS-HWR045
Step 1:
Place the instrument top upside down on smooth flat surface being sure to protect it from damage by foreign
objects. IAC recommends the use of packing type blankets or clean cardboard. Place the riser boxes onto the
instrument shelf aligning the slots in the riser boxes with the threaded inserts in the instrument shelf as
shown. The side of the riser box that has holes in it, face the rear of the instrument shelf. Thread 1/4-20 x .75
hex head bolts and 1/4” flat washers into the threaded inserts in the instrument shelf. DO NOT TIGHTEN
THIS HARDWARE.
Step 2:
Connect the support beam to the riser boxes using the 1/4-20 x .75" hex head bolts 1/4" flat washers and 1/4-
20 keps nuts. Align support beam ends with holes in riser boxes and push bolts through the support beam
ends plates and holes in the riser boxes. Attach keps nuts to bolts on the inside of riser boxes and tighten.
Align the riser boxes to even the overhangs and then tighten riser box attachment hardware. Install all plastic
cap plugs that apply. If you have Riser Electrical Panels do not install the 1.5” cap plug.
Note: If you are assembling a 96” instrument shelf you will have a second beam that is mounting in rear of the
shelf the same as in the front.
Note: If you are installing a WM Undershelf Light please see page 9 at this time.

8
Step 3:
Install the riser covers or optional Riser Electrical Panels using (8) # 8 x .375 self-threading
screws. Align the riser covers holes with the holes in the riser box and thread #8 x .375
screws into each hole. Tighten at this time. For optional Riser Electrical Panels install 1.5”
plastic bushing into the holes located in the rear of the riser boxes. Then run the power
cord(s) from the inside of the riser box through the 1.5” plastic bushing. Align the Riser
Electrical Panel holes with the holes in the riser box and thread #8 x .375 screws into each
hole. Tighten at this time. Install plastic caps where needed.
Note: For SESIS Panels CAUTION: Risk of Electric Shock. Do NOT plug into another
Relocatable power tap.
STEP 4
Carefully turn instrument shelf over and from the backside of the bench align the U shaped flanges at the
bottom of the riser boxes with the bench worksurface. Carefully slide the U shaped flanges over the
worksurface until the back of the riser box is approximately 1/8” from the back of the worksurface. Look under
the worksurface to align the slots in the U shaped flanges with the inserts in the worksurface. When both riser
boxes are aligned with the inserts attach them with 1/4-20 x .75 hex head bolts and 1/4” flat washers as
shown. Tighten hardware at this time.

9
QS WM Under shelf Light
HARDWARE KIT QS-HWR048
Step 1
Carefully remove the plastic diffuser to expose the inside of the light housing. Align the slots in the light
housing over the inserts in the underside of the instrument shelf. Thread 2 each 1/4-20 x 5/8” phillips screws
with 1/4" washers in the inserts in the shelf and tighten. Install the appropriate light tube. It is a good idea to
test the light at this time by plugging it in and turning it on and off. If the light tube does not light please double
check that the power is on and the tube is good. Once the light tube works carefully replace the plastic
diffuser taking care not to force it into place as this could cause it to break.
Note: This SIL UNDERSHELF light fixtures are designed to run with high efficiency T8 Tubes
A F32T8 SP41 is shown for reference only. Brand name is also reference only.

10
Q.S. Footrest Tube
1. Push and twist the rectangular spring nut into the bottom cross brace of the pedestal
legs with the spring pointed towards the closed top of the brace. Make sure the nut is
securely seated on the inside lips of the cross brace.
2. Position the footrail tube so that the drain holes point down when bench is upright.
3. Hold the unistrut nut against the inside of the cross brace and attach the footrail
tube with a 1/4-20 x 1.00 hex bolt, split washer, and flat washer on each end. The footrail
can be adjusted forward or backward along the cross brace.
Q.S. Ergo Footrest Pan
Attach foot pan to the footrest tube using (4) black plastic "U" shaped clamps and (4)
1/4-20 x 1.125 Socket Head screws. Position the U-clamps around the footrest tube
as shown in the diagram and secure to the bottom
of the footpan.

11
QS Electrical Strip
HARDWARE KIT QS-HWR047
Step 1
Attach the TE2 mounting brackets to the back side of the SEC Electrical Channel using the 1/4-20 x .50 self-
threading phillips screws being sure to fit the power cord through the large hole in the bracket. DO NOT
TIGHTEN these screws. From the backside of the bench carefully fit the SEC Electrical Channel over the top
of the worksurface while fitting the lower flange of the TE2 mounting brackets under the worksurface. Looking
under the worksurface align the slots in the TE2 mounting brackets with the inserts in the worksurface.
Thread the 1/4-20 x .75 hex head bolts into the inserts and while applying pressure to the backside of the
SEC Electrical Channel to force it against the back of the worksurface tighten the bolts. Next tighten the 1/4-
20 x .50 self-threading phillips screws.
Note: CAUTION: Risk of Electric Shock. Do NOT plug into another Relocatable power tap.

12
Q.S. Single Drawer
Note: Applies to all QS drawer and door cabinet options.
HARDWARE KIT QS-HWR015
For easier installation, it is best to install drawer bracket and drawer(s) while bench in upside down.
Step 1: Install rear mounting bracket as shown on below drawings using hardware listed above.
Note: The position of your bracket will be determined by the size of your front beam.
Step 2: Install captive retainer nut to drawer mounting bracket and bench front beam as shown below.

13
Step 3: Remove drawer from drawer case by pulling the drawer body out of the case. Locate the slide
release tabs. Lift up on the left side tab and press down on the right side tab and pull on drawer body.
Step 4: With the drawer removed from the case, place the case over the front beam and the drawer
mounting bracket as shown. Use supplied hardware to fasten.
Note: For double stacking drawers use bolts washer and nuts supplied in hardware kit to attach the stacked
drawer case to the first case.

14
Before Installing the Drawer Body back into the Drawer Case:
Once bench is complete and is in the right side up position you can install your drawer bodies back into the
single drawer or cabinets, but before installing the two parts (Drawer body/Drawer Case) of the drawer
assembly together you much do the following:
1. Make sure the Red locking mechanism in in the closed position: Using the switch of the Red locking
mechanism, close the spring loaded Red locking mechanism by turning the switch up or down
(depend on what side your setting) position until the Red locking mechanism closes.
Switch
Before installing the drawer body slide into the Drawer Housing slide please make sure that both of the
“Ball bearing tracks” on the outside left and right pieces are all the way forward. Install drawer body
part of slide to drawer housing part of slide making sure the slide are aligned with each other. Insert
the drawer body all the way in then all the way out making sure the two part work OK.
Ball bearing tracks
Outer piece
Inner piece

15
Q.S. Plate Caster Leg Extender Kit
HARDWARE KIT QS-HWR0135
For easier installation, it is best to install the plate caster leg extenders while bench in upside down.
Note: If this kit is for an excising bench the leg extenders in that bench will have to be removed.
Slide the plate caster leg extender into the pedestal tube making sure the threaded holes on the plate caster
leg extender tube are on the same side as the holes in the pedestal tube. Align the threads of the leg
extender with the holes in the pedestal tube and select the desired height of the bench. Thread the 1/4-20 x
.75 HHW bolts with the 1/4 flat washers into the threaded holes, two per plate caster leg extender, and
tighten. Install a caster wheel per plate caster leg extender, using four 1/4-20 x 75 HH bolts and eight of the
1/4 flat washers with four 1/4-20 hex keps nuts then tighten.

16
ESD GROUNDING
HARDWARE KIT QS-HWR 014 and QS-HWR 122
Step 1 Note: do not use power tools for this installation
For ESD worksurfaces and instrument shelves to dissipate static electricity they require the connection of a
ground cord to an earth ground. IAC install grounding studs on each rear corner of all ESD worksurfaces and
instrument shelves. Thread the 1/4-20 coupler nut onto one of these ground studs and tighten it being careful not
to over tighten. Over tightening this coupler nut can cause damage to the connection between the ground stud
and the laminate. Place the eyelet of the ground cord (or cords if you are also grounding an instrument shelf to
the same ground stud) over the 1/4-20 x 1/2" bolt and thread the bolt into the coupler nut. The alligator clip must
attach to an earth ground.
ESD Laminate Testing:
Although IAC conducts connectivity and surface resistance tests at the factory on all ESD worksurfaces and
instrument shelves, IAC recommends that customers conduct their own tests on all ESD worksurfaces and
instrument shelves to ensure that the ground cord installation has been completed correctly and that the ESD
material is working properly.
Cleaning ESD Materials:
ESD laminates are designed to resist abrasion, scuffing, scorching, and most solvents. Intense exposure to
any of these conditions can damage the ESD properties of the laminate and will require the replacement of
the worksurface or instrument shelf. ESD laminate worksurfaces and instrument shelves are cleaned much
the same as non ESD laminated surfaces with a damp cloth and light soapy cleanser. A mild chemical
cleaner can also be used as long as the laminate is not exposed to the chemical for long periods of time.
Stains can be removed with a two minute exposure to a 5% hypo chloride bleach solution immediately
followed by a light soapy cleanser.
ESD Ground Precautions:
1) Connect each workbench worksurface individually to the earth ground.
2) The green wire in a standard wall duplex can be used if it has been absolutely determined that it is
attached to an earth ground.
3) Do not use power tools to install grounding hardware and components.
4) If benches are relocated IAC recommends the ground cords connections be re-tested.
5) Never use abrasive pads or cleansers to clean ESD surfaces.
6) Never wax ESD surfaces and avoid cleaners with wax-based properties.
7) Test ESD worksurfaces and instrument shelves frequently to ensure it is working properly.
