IAdea XDS-1072 User manual

IAD_DGS_X7S_30EP
XDS-1072 / XDS-1078
Quick Start Guide
This is a quick walkthrough of the set up process. For complete documentations
and quick start guides, please visit http://support.IAdea.com.
Box Content
Smart
signboard
AC adapter
(with selected power plug)
Power and micro
SD card brackets
Table stand
Mounting and Installation
Mounting option 1: VESA mount
- VESA standard: VESA MIS-D75 (75 mm x 75 mm)
- Screw: M4 x 4 mm (excluding the mounting plate thickness)
Mounting option 2: using back cover
- Power / SD card brackets MUST NOT be connected when mounting cover
-plate
Mounting option 3: glass mount
- 3M VHB™ Industrial Heavy Duty Mounting Tape (90 mm x 70 mm)
Mounting back cover
1) Release the cover
plate screw to
release cover plate
2) Install cover plate
(thread head height
not to exceed 3 mm)
3) Run power and network
cable from the bottom
and connect to signboard
before mounting
Reseting smart signboard to factory default
Factory reseting the smart signboard will result in the removal of all saved con-
tents, passwords, and congurations in settings. Please refer to the steps below
to complete the smart signboard factory reseting process:
Use a pen to press and hold the reset button - do not release until Step 4.1
Insert the power cord.2
Wait 30 seconds for the system reboot indicating your data is erased.3
Release the reset button and your smart signboard will initialize in factory
default state.
4
Content Management
Please consult the software documentation for information specic to your
content management solution.
How do I interrupt playback and enter setup menu?
Use USB mouse to click and hold one corner of the screen for 10 seconds to exit
playback and enter setup menu.
How do I provide a DEBUG log for a misbehaving signboard to the support team?
Please follow the instructions below to collect the player's DEBUG log:
Troubleshooting
Prepare a blank USB stick in FAT-32 format.1
Create a folder named "DEBUG" (case insensitive) in the root of USB stick.2
Make sure the player is operating (see welcome screen or playing content).3
Insert the USB stick into player and wait for yellow
dot on upper right corner to stop blinking.
4
Within the "DEBUG" folder, is a folder with a string of number as its name. If
the string of numbers are all zero's, the debug log has not been collected
properly. Repeat step 1-4 again and make sure to wait until stop blinking.
5
6 Zip the"DEBUG" folder and send to IAdea Support Team.

IAD_DGS_X7S_30EP
Securing power and network cable Securing SD card
1) Insert both
cables
2) Fasten bracket
onto the socket
1) Insert SD
card bracket
2) Fasten SD
card bracket
Securing table stand
Screw the table stand
into stand screw hole.
Supports landscape
and portrait setup.
Glass mount
Landscape
Portrait
1) Order your glass mount kit
2) Scan QR code for user manual
3) Mount your signboard
4) Impress your visitors
Port Connections
QR: http://www.iadea.com/wp-content/uploads/2018/10/PGM-001_User-Manual_2018OCT_web.pdf
Boot up1
System Setup
4 Set content
3 Make configurations
Users can set content by clicking "Set Content" to enter
the URL or use the desired content manage-ment
system to upload the contents onto the smart signboard.
To change smart signboard system language, se-
lect “(Current Language) ....” For system configu-
rations, select “Advanced.”
Important recommended con igurations:
2
1
2
Set correct time, date, and time zone for
properly scheduled playback.
Set password to prevent unauthorized
access during setup menu.
Set network for establishing network
connection.
3
Plug in the AC adapter and Ethernet cable to the media
player and it will power on automatically. Once the user
has exited the boot up screen, users can go through
system configurations in both landscape and portrait
orientations.
Autoplay content
When boot up is complete, if the system detects
preloaded content, the loading circle will appear. Once
the loading circle completes, content will be played. To
stop autoplay and enter "Basic settings," users need to
select the pause button in the center of the loading
circle.
Basic settings
When boot up is complete and there is no preloaded
contents, the user will see the “Basic settings” which
allows the user to make configurations or autoplay pre-
loaded content.
3
