iAIRE EC-CHAS5-VBA0 Series User manual

CARRIER CHAS5
VERTICAL
ECONOMIZERS
I/O/M MANUAL
PD 11/04/2021 - v 1.00
PN IOM-0038-CHAS5V

iAIRE, LLC iAIRE Carrier Economizers I/O/M
2
Table of Contents
Carrier Economizer Description..........................................................3
Chassis 5 Vertical Submittal............................................................... 4
Chassis 5 Vertical Install......................................................................5
Additional Install Notes........................................................................6
For information on iAIRE’s Economizer Controls Package,
please refer to IOM-0014

iAIRE Carrier Economizers I/O/MiAIRE, LLC
3
Carrier Economizer Description
Economizer Part Numbering Scheme
EC - 1 - 2 3 4 5 - 6
EC - ECONOMIZER
type unit/ton (1)
0 - NO ECON
C - CONVERTIBLE
H - HORIZONTAL
V - VERTICAL
0 - NO ACTUATOR
A - 20 IN-LB
B - 62 IN-LB
C - 160 IN-LB
actuator (3)
0 - ECON ONLY
A - IAQ
B - IAQ (NO IONIZATION)
D - DCV
controls (4)
configuration (2)
PNS-0021 PD 10/20/21 - v.02.03
iAIRE, LLC | 2100 Consulate Drive, Suite 102, Orlando, FL 32837
www.myiaire.com | Toll Free 844-348-9168
CHAS12
CHAS34
CHAS5
CHAS69
26
712
1525
3050
6075
100
125
150
A-BOX
B-BOX
C-BOX
D-BOX
E-BOX
F-BOX
FND35
PACK13
PREC35
PREC48
PREC610
PREC810
VOY12
VOY12HE
VOY1525HE
AFF
LXS
LXL
SCS12
SCS34
SCSHE12
SCSHE34
SCL12
SCL34
SCLHE12
SCLHE34
PRED
PREDS
SL
SLL
SLU
Controls Only Carrier
Lennox
Trane
York
0 - NO POWER EXHAUST
A - 208/230V 1ΦFIXED PE
B - 208/230V 3ΦFIXED PE
C - 460V 3ΦFIXED PE
power exhaust (5)
0 - NONE
B - HUMIDITY
C - BACNET
D - BLDG PRESSURE*
R - RTU OPEN
U - ULTRA LOW LEAK
options (6)
Note: By adding option “D” any
powered exhaust will be modulating.
SUB-0024 iAIRE LLC | 2100 Consulate Drive Suite 102, Orlando, FL 32837
www.myultrapure.com | Toll Free 844-348-9168 PD 09/25/21 V.01.00
CHAS5:
48/50TC 16; 50TCQ 14;
48/50HC 14; 50HCQ 12;
48/50LC 08-12
CHAS5
CHAS to RTU Conversion
PLEASE NOTE: Our economizer is a low leak, eld installed economizer with the iAIRE patented con-
trols packages and actuator, allowing you to reduce the amount of outside air needed from your rooftop
HVAC system by up to 2/3 and will improve indoor air quality.
This reduction in system operation creates on-going utility savings. Payback on capital equipment costs
with an iAIRE economizer can be realized in fewer than three years. These packages are designed to
work directly on existing rooftop HVAC systems.
These economizers are all low leak and meet the IECC 2015 requirement and are Title 24 compliant by
meeting section 120.2(i) for the required controls and the e󰀩ciency requirements in 140.4(e).
Product Data
EC-CHAS5-***0-* | Carrier Economizer
Part Number
Description

iAIRE, LLC iAIRE Carrier Economizers I/O/M
4
Chassis 5 Vertical Submittal
EC - CHAS5 - VBA0 - * | Carrier Economizer
Product Data
100% BAROMETRIC RELIEF DOWN DISCHARGE ECONOMIZER
RELIEF DISCHARGE
DAMPERS
\OUTSIDE AIR
INTAKE HOOD
ENTRAINMENT FILTER
PART # A B C WEIGHT
EC-CHAS5-VBA0-* 53” 25” 33.625” 175 lbs
Dimensions
Economizers with Indoor Air Quality control are Title 24 compliant by meeting section 120.2(i) for the required controls and
the e󰀩ciency requirements in 140.4(e). They also meet California ozone emissions requirements to be CARB certied.
0 - No Options
B - Humidity/Enthalpic
C - BACNet
*OPTIONS
PART AMPS PART AMPS TOTAL
ACTUATOR .29A CONTROLS .44A .73A
Electrical Data
·iAIRE Patented Controls Scheme Included
· Low Leak Damper Included
· VOC, CO2 and Ionization included
· Heavy Gauge Galvanized Steel Construction
·American Sterling Grey Paint Finish
· One Piece Assembly
· Gear Driven Dampers
· Uses HVAC Unit Filter Access Door
· Capable of Relieving up to 100% of the Outside Air Intake
Features
SUB-0024-CHAS5V iAIRE, LLC | 2100 Consulate Drive, Suite 102, Orlando, FL 32837
www.myultrapure.com | Toll Free 844-348-9168 PD 09/15/2021 - v 1.00

iAIRE Carrier Economizers I/O/MiAIRE, LLC
5
Chassis 5 - Vertical Install
1. Remove return air compartment lter access panel and lower economizer panel of HVAC unit.
Save the screws and the lter access panel, but discard the economizer panel.
2. Slide the economizer up to the HVAC unit and tilt the top of the economizer toward the HVAC unit.
Slide it into the compartment as shown below.
3. At the back of the bottom return opening, under the lter rack on the HVAC unit, there are three
tabs. The front ange of the economizer must slide under these tabs.
4. Once the front ange is under the tabs, lower the economizer until it sits down into the slot on the
back of the economizer and down onto the base rail of the HVAC unit.
5. Be sure the side anges of the power exhaust cabinet are sitting in the slots of the corner posts of
the HVAC unit.
6. Fasten the economizer to the HVAC unit through the holes provided. Use the screws that were
removed from the economizer panel in step 1.
7. At the lter access door opening, reach in and plug the economizer harness into the corresponding
economizer harness in the HVAC unit.
8. Refer to page 5 in IOM-0014 Economizer Controls Installation Manual for installation of the various
sensors and actuators. Connect wires according to the wiring diagram on page 8.
9. Slide the lter access door back into the place above the economizer.

iAIRE, LLC iAIRE Carrier Economizers I/O/M
6
Carrier Economizer Install Notes
Additional Notes
1. Motor Spring-Returns closed when unit is not running.
2. Ensure that equipment transformer is sized to handle the extra load of the economizer and
actuator.
3. When using a heat with defrost feedback, add an isolation relay between O and C. (Field provided
and installed).
