REMOVING THE VOICE AND DATA COVER
Use a flathead screwdriver as a lever by placing
it between the voice and data cover and the
profile joint, as shown in diagram 03.
INSTALLING PDC WITH ELECTRIC
SOCKETS ONLY
You will see the base where you are going to
place it. Mark and use a drill to make the
necessary holes. Then, insert the rawlplugs and
screw the base to the floor, as shown in diagram
07.
CONNECTING THE POWER SUPPLY
Connect the power cable to the GST 18 connector
incorporated at the end of rail B. Finally, put the
top cover back on.
user manual
01
02
04
03
INSTALLING PDC WITH DATA AND
ELECTRIC POWER SUPPLY
Use a crosshead screwdriver to remove the top
cover, as shown in diagram 1.
Once you have removed the cable tray cover,
insert the data cables, the cover is designed for
inserting cables with or without a connector, as
it has slots at the ends of the cover in order to
insert cables with connectors.
REMOVE THE CABLE TRAY COVER
Use a flathead screwdriver as a lever by placing
it between the cover and the profile joint, as
shown in diagram 03.
You will see the base where you are going to
place it. Mark and use a drill to make the
necessary holes. Then, insert the rawlplugs and
screw the base to the floor, as shown in diagram
2.
For any queries related to the product, contact:
08
CONNECTING THE POWER SUPPLY
Connect the power cable to the GST 18
connector incorporated at the end of rail B. If it
has a regulated power supply and a normal
power supply, there will be two different coloured
GST connectors:
Red: Regulated, Black: Normal
CONNECTING THE DATA CABLES
Thread the V/D cables through the bottom part.
Place the RJ45 connectors in the cover and
connect them, as shown in detail A.
Place the cover on the rail with the connectors
and collect any excess cable. For data cables
with a connector, a female I/O connector can
be inserted in the board.
.
