Ormazabal cgm.3 system Series Instruction manual

LIB
cgm.3 system
medium voltage SF
6
gas-insulated cubicles up to 38 kV
according to IEEE and CSA standards
General instructions
IG-183-EN, version 06, 31/03/2020

In view of the constant evolution in standards and design, the characteristics of the elements contained in this manual are subject
to change without prior notice. These characteristics, as well as the availability of components, are subject to confirmation by
Ormazabal.
CAUTION!
When medium-voltage equipment is operating, certain components are live, other parts may be in movement and some may
reach high temperatures. Therefore, the use of this equipment poses electrical, mechanical and thermal risks.
In order to ensure an acceptable level of protection for people and property, and in compliance with applicable environmental
recommendations, Ormazabal designs and manufactures its products according to the principle of integrated safety, based on
the following criteria:
• Elimination of hazards wherever possible.
• Where elimination of hazards is neither technically nor economically feasible, appropriate protection functions are
incorporated in the equipment.
• Communication about remaining risks to facilitate the design of operating procedures which prevent such risks,
training for the personnel in charge of the equipment, and the use of suitable personal protective equipment.
• Use of recyclable materials and establishment of procedures for the disposal of equipment and components so
that once the end of their service lives is reached, they are duly processed in accordance, as far as possible, with the
environmental restrictions established by the competent authorities.
Consequently, the equipment to which the present manual refers complies with the requirements of section 11.2 of Standard
IEC 62271-1. It must therefore only be operated by appropriately qualified and supervised personnel, in accordance with the
requirements of standard EN 50110-1 on the safety of electrical installations and standard EN 50110-2 on activities in or near
electrical installations. Personnel must be fully familiar with the instructions and warnings contained in this manual and in other
recommendations of a more general nature which are applicable to the situation according to current legislation[1].
The above must be carefully observed, as the correct and safe operation of this equipment depends not only on its design but also
on general circumstances which are in general beyond the control and responsibility of the manufacturer. More specifically:
• The equipment must be handled and transported appropriately from the factory to the place of installation.
• All intermediate storage should occur in conditions which do not alter or damage the characteristics of the equipment
or its essential components.
• Service conditions must be compatible with the equipment rating.
• The equipment must be operated strictly in accordance with the instructions given in the manual, and the applicable
operating and safety principles must be clearly understood.
• Maintenance should be performed properly, taking into account the actual service and environmental conditions in
the place of installation.
The manufacturer declines all liability for any significant indirect damages resulting from violation of the guarantee, under any
jurisdiction, including loss of income, stoppages and costs resulting from repair or replacement of parts.
Warranty
The manufacturer guarantees this product against any defect in materials and operation during the contractual period. In the
event that defects are detected, the manufacturer may opt either to repair or replace the equipment. Improper handling of this
equipment and its repair by the user shall constitute a violation of the guarantee.
Registered Trademarks and Copyrights
All registered trademarks cited in this document are the property of their respective owners. The intellectual property of this manual
belongs to Ormazabal.
[1] For example, in Spain the “Regulation on technical conditions and guarantees for safety in high-voltage electrical installations” – Royal Decree
337/2014 is obligatory.

IG-183-EN version 06; 31/03/2020 3
General instructions
cgm.3 system: medium voltage SF6gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
Contents
In view of the constant evolution in standards and design, the characteristics of the elements contained in this manual are subject
to change without prior notice. These characteristics, as well as the availability of components, are subject to confirmation by
Ormazabal.
CAUTION!
When medium-voltage equipment is operating, certain components are live, other parts may be in movement and some may
reach high temperatures. Therefore, the use of this equipment poses electrical, mechanical and thermal risks.
In order to ensure an acceptable level of protection for people and property, and in compliance with applicable environmental
recommendations, Ormazabal designs and manufactures its products according to the principle of integrated safety, based on
the following criteria:
• Elimination of hazards wherever possible.
• Where elimination of hazards is neither technically nor economically feasible, appropriate protection functions are
incorporated in the equipment.
• Communication about remaining risks to facilitate the design of operating procedures which prevent such risks,
training for the personnel in charge of the equipment, and the use of suitable personal protective equipment.
• Use of recyclable materials and establishment of procedures for the disposal of equipment and components so
that once the end of their service lives is reached, they are duly processed in accordance, as far as possible, with the
environmental restrictions established by the competent authorities.
Consequently, the equipment to which the present manual refers complies with the requirements of section 11.2 of Standard
IEC 62271-1. It must therefore only be operated by appropriately qualified and supervised personnel, in accordance with the
requirements of standard EN 50110-1 on the safety of electrical installations and standard EN 50110-2 on activities in or near
electrical installations. Personnel must be fully familiar with the instructions and warnings contained in this manual and in other
recommendations of a more general nature which are applicable to the situation according to current legislation[1].
The above must be carefully observed, as the correct and safe operation of this equipment depends not only on its design but also
on general circumstances which are in general beyond the control and responsibility of the manufacturer. More specifically:
• The equipment must be handled and transported appropriately from the factory to the place of installation.
• All intermediate storage should occur in conditions which do not alter or damage the characteristics of the equipment
or its essential components.
• Service conditions must be compatible with the equipment rating.
• The equipment must be operated strictly in accordance with the instructions given in the manual, and the applicable
operating and safety principles must be clearly understood.
• Maintenance should be performed properly, taking into account the actual service and environmental conditions in
the place of installation.
The manufacturer declines all liability for any significant indirect damages resulting from violation of the guarantee, under any
jurisdiction, including loss of income, stoppages and costs resulting from repair or replacement of parts.
Warranty
The manufacturer guarantees this product against any defect in materials and operation during the contractual period. In the
event that defects are detected, the manufacturer may opt either to repair or replace the equipment. Improper handling of this
equipment and its repair by the user shall constitute a violation of the guarantee.
Registered Trademarks and Copyrights
All registered trademarks cited in this document are the property of their respective owners. The intellectual property of this manual
belongs to Ormazabal.
[1] For example, in Spain the “Regulation on technical conditions and guarantees for safety in high-voltage electrical installations” – Royal Decree
337/2014 is obligatory.
Contents
1. Description and main characteristics.......................5
1.1. Cubicle elements ............................6
1.1.1. Voltage presence indication unit ............13
1.1.2. ekor.sas - acoustic grounding
prevention alarm unit .......................14
1.1.3. Nameplate..................................14
1.2. Mechanical characteristics ..................16
2. Transport ..................................................................17
2.1. Lifting methods.............................17
2.2. Location of documentation and
accessories during transport ................19
2.2.1. p modules ..................................19
2.2.2. l and v modules .............................20
3. Storage......................................................................21
4. Installation ...............................................................22
4.1. Unpacking the equipment ..................22
4.2. Civil engineering works .....................23
4.3. Recomended cable trenchs..................24
4.3.1. Cubicles with gas tank internal arc up
to 20 kA - 0,5 s ..............................24
4.3.2. Cubicles with IAC internal arc up
to 25 kA – 1 s................................28
4.4. Fastening to the floor .......................31
4.4.1. Floor fastening on a profile ..................31
4.4.2. Fastening to the floor by anchoring..........31
4.5. Connecting the cubicles.....................36
4.6. Grounding the equipment ..................36
4.7. Cable connection ...........................37
5. Recommended sequence of operations.................38
5.1. Checking voltage presence and
phase balance ..............................38
5.2. Operating levers ............................40
5.2.1. Lever for B, BR-A, AV and RAV driving
mechanisms ................................40
5.2.2. Spring charging lever for cgm.3-v ...........40
5.3. cgm.3-l cubicle .............................41
5.3.1. Opening operation from
the grounded position ......................41
5.3.2. Switch closing operation from
the open position ...........................42
5.3.3. Opening operation from the
switch-disconnector closed position.........43
5.3.4. Grounding operation from
the open position ...........................44
5.3.5. Cable test...................................44
5.4. cgm.3-s cubicle .............................45
5.4.1. Switch-disconnector closing operation ......45
5.4.2. Switch-disconnector opening operation .....46
5.5. cgm.3-s-ptd cubicle.........................47
5.5.1. Opening operation from
the grounded position ......................47
5.5.2. Closing operation from the open position ...48
5.5.3. Opening operation from the
switch-disconnector closed position.........49
5.5.4. Grounding operation from
the open position ...........................50
5.6. cgm.3-s-pti cubicle..........................51
5.6.1. Opening operation from
the grounded position ......................51
5.6.2. Closing operation from the open position ...52
5.6.3. Opening operation from the
switch-disconnector closed position.........53
5.6.4. Grounding operation from
the open position ...........................54
5.7. cgm.3-p cubicle.............................55
5.7.1. Opening operation from the grounded
position ....................................55
5.7.2. Switch-disconnector closing
operation from the open position
(using the BR-A driving mechanism) .........56
5.7.3. Opening operation from the
switch-disconnector closed position.........57
5.7.4. Grounding operation from
the open position ...........................58
5.8. Fuse replacement sequence .................59
5.8.1. Selection of recommended fuses ............63
5.9. cgm.3-rb with grounding ...................64
5.9.1. Opening operation from
the grounded position ......................64
5.9.2. Grounding operation from
the open position ...........................65
5.10. cgm.3-v cubicle with driving
mechanism A(M)V or RA(M)V ................66
5.10.1. Opening operation from
the grounding position .....................66
5.10.2. Closing operation from the open position ...68
5.10.3. Opening operation from
the closed position..........................71
5.10.4. Grounding operation from
the open position ...........................73
6. Safety elements........................................................75
6.1. Earthing prevention acoustic alarm unit .....75
6.2. Interlocks ...................................75
6.2.1. Locking with a padlock......................76
6.2.2. Locking with a key lock (optional) ...........76

IG-183-EN version 06; 31/03/2020
4
Contents
General instructions
cgm.3 system: medium voltage SF6gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
7. Maintenance.............................................................77
7.1. Voltage presence indicator test..............77
7.2. Acoustic grounding prevention alarm test ...78
7.2.1. Connecting the ekor.sas unit................79
7.3. Specific maintenance for
the cgm.3-v cubicle .........................79
7.4. Replacement of contact
inspection camera ..........................80
8. Spares and accessories ............................................85
9. Environmental information ....................................87

IG-183-EN version 06; 31/03/2020 5
General instructions
cgm.3 system: medium voltage SF6gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
Description and main characteristics
1. Description and main characteristics
The cgm.3 system is made up of a range of fully insulated
modular SF6cubicles, which allow the conguration of
dierent medium voltage secondary electrical distribution
diagrams up to 38 kV.
This cubicle system has been designed to meet the
requirements of the following standards:
Standard Description
CAN CSA C22.2
No.31-04 Switchgear assemblies
IEEE C37.74
IEEE Standard requirements for subsurface, vault,
and pad-mounted load-interrupter switchgear
and fused load-interrupter switchgear for
alternating current systems up to 38 kV
IEEE C37.20.3 IEEE Standard for metal-enclosed interrupter
switchgear
IEEE 1247 IEEE Standard for interrupter switches for
alternating current, rated above 1000 volts
IEEE C37.123 IEEE Guide to specications for gas-insulated,
electric power substation equipment
IEEE C37.20.4 IEEE Standard for indoor ac switches (1 kv - 38 kv)
for use in metal-enclosed switchgear
IEEE C37.04 IEEE Standard rating structure for ac high-voltage
circuit breakers
IEEE C37.06
AC high-voltage circuit breakers rated on a
symmetrical current basis: preferential ratings and
related capacities required
IEEE C37.09
IEEE Standard test procedure for ac high-voltage
circuit breakers rated on a symmetrical current
basis
IEEE C37.20.7 IEEE Guide for testing medium voltage metal-
enclosed switchgear for internal arcing faults
IEC 60529 Degrees of protection provided by enclosures
(IP Code)
IEC 62271-206/
IEC 61243-5 Voltage presence indicating systems
Table 1.1. Requirements
The cgm.3 system comprises the following functional units:
Models
cgm.3-l Feeder cubicle
cgm.3-s Busbar switch cubicle
cgm.3-s-pt Busbar switch cubicle with ground connection on
the right (-ptd) or on the left (-pti)
cgm.3-p Fuse protection cubicle
cgm.3-v Circuit-breaker cubicle
cgm.3-rb Busbar rise cubicle
cgm.3-rc Cable rise cubicle
cgm.3-r2c Double cable rise cubicle
cgm.3-m Metering cubicle
Table 1.2. Unifunctional switchgear
Models
cgm.3-2lp 2 feeder and 1 fuse protection functions
cgm.3-2lv 2 feeder and 1 vacuum circuit breaker functions
cgm.3-rlv 1 busbar rise, 1 feeder and 1 vacuum circuit
breaker function
Table 1.3. Multifunctional switchgear

IG-183-EN version 06; 31/03/2020
6
Description and main characteristics
General instructions
cgm.3 system: medium voltage SF6gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
1.1. Cubicle elements
Each cubicle is made up of a series of independent
compartments:
1Gas tank
1.1 Side connection female bushings
2Driving mechanism area
2.1 Name plate
2.2 Operating sequence plate
2.3 Actuating shafts (see mimic diagram of each model)
2.4 ekor.vpis/ekor.ivds voltage presence detection unit*
2.5 ekor.sas acoustic earthing prevention alarm unit*
3Base
3.1 Cable compartment access cover
3.2 Medium voltage cable xing support
3.3 Gas relief compartment
3.4 Earth collector
3.5 Front cable connection bushings
Figure 1.1. Main components of cgm.3 cubicles
1. Gas tank: Sealed compartment which houses the
busbar and the switching and breaking elements,
where the insulating medium is SF6.
The gas tank has a membrane to allow gases to escape
in the event of an internal arc.
Do not rell the switchgear.
Figure 1.2. Gas tank

IG-183-EN version 06; 31/03/2020 7
General instructions
cgm.3 system: medium voltage SF6gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
Description and main characteristics
Each tank has a manometer for checking the gas
pressure, which can easily be seen from outside the
cubicle. The manometer scale is divided into dierent
colors: red, grey and green. For safe operation, the
needle must be in the green zone of the corresponding
temperature band.
Pressure gauge is not intended to be used for telemetry
purposes.
Figure 1.3. Manometer
Includes a padlockable coupling device which allows
the driving mechanism to be replaced regardless of the
position of the switch-disconnector: closed, open or
grounded.
Figure 1.4. Device for coupling the switch
Optionally, the gas tank includes a contact inspection
camera that allow to see on-live through a tablet the
position of the switch - disconnector contacts.
Figure 1.5. Position of the USB connector for contacts inspection camera
Figure 1.6. Position contacts inspection camera

IG-183-EN version 06; 31/03/2020
8
Description and main characteristics
General instructions
cgm.3 system: medium voltage SF6gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
Switch-disconnector and grounding switch: This has
three positions: closed, open or grounded.
This switch is operated using driving mechanisms with two
dierent shafts: one for the switch (switching between the
closed and open positions); and the other for the grounding
switch (which switches between the open and grounded
positions) on the feeder cables, and in the case of fused
protection cubicles, on the six fuse holder clamps.
These elements are operated independently so that their
actuation speed does not depend on the speed of the
manual operation.
Vacuum circuit-breaker: The cgm.3-v cubicle’s circuit-
breaker uses vacuum switching technology.
The circuit-breaker is actuated by means of the push-
button on the front of the cubicle. For manual operation,
springs must be charged with the corresponding lever.
To ensure that the isolating distance is adequate, the
cgm.3-v cubicle’s circuit-breaker comes standard with a
switch-disconnector and a grounding switch. This element
is operated using a specic lever.
The cgm.3-v circuit-breaker cubicles can be equipped with
an electromechanical safety device called an undervoltage
coil. Its function is to ensure that the cubicle switch opens
in the event of an unexpected drop of more than 30% in the
auxiliary voltage.
2. Driving mechanism compartment: this is the
compartment in which the switch-disconnector,
grounding switch or the circuit-breaker is actuated,
depending on the type of cubicle. The mimic diagram
for the main medium voltage circuit is displayed on the
cover of this compartment.
The mimic diagram includes all the position indicators
for the actuators.
Elements in the driving mechanism area of modular
cubicles:
cgm.3-l
aekor.sas, acoustic grounding prevention alarm
bManometer window
cVoltage presence indicator ekor.vpis / ekor.ivds
d
Operation area:
• GREY for switch-disconnector
• YELLOW for grounding switch
e
Status indicators:
• GREEN open
• RED closed
fActuation shaft access handle
Figure 1.7. Mimic diagram of cgm.3-l cubicle

IG-183-EN version 06; 31/03/2020 9
General instructions
cgm.3 system: medium voltage SF6gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
Description and main characteristics
cgm.3-s
aPressure gauge window
bSwitch-disconnector actuation zone (B and BM driving
mechanisms)
c
Status Indicator:
• GREEN open
• RED closed
dActuation shaft access handle
Figure 1.8. Mimic diagram of cgm.3-s cubicle
cgm.3-s-ptd
aekor.sas, acoustic grounding prevention alarm
bPressure gauge window
cekor.sas, acoustic grounding prevention alarm
d
Operation area:
• GREY for switch-disconnector
• YELLOW for grounding switch
e
Status indicators:
• GREEN open
• RED closed
fActuation shaft access handle
Figure 1.9. Mimic diagram of cgm.3-s-ptd cubicle

IG-183-EN version 06; 31/03/2020
10
Description and main characteristics
General instructions
cgm.3 system: medium voltage SF6gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
cgm.3-s-pti
aekor.sas, acoustic grounding prevention alarm
bManometer window
cekor.vpis / ekor.ivds voltage presence indication unit
d
Operation area:
• GREY for switch-disconnector
• YELLOW for grounding switch
e
Status indicators:
• GREEN open
• RED closed
fActuation shaft access handle
Figure 1.10. Mimic diagram of cgm.3-s-pti cubicle
cgm.3-p
aekor.sas, acoustic grounding prevention alarm
bPressure gauge window
cVoltage indicator ekor.vpis or ekor.ivds
d
Operation area:
• GREY for switch-disconnector
• YELLOW for grounding switch
e
Status indicator:
• BLACK for switch-disconnector
• RED for earthing switch
fActuation shaft access handle
gManual trip operation
h
Fuse status indicator:
• GREEN: normal
• RED: fuse blown
iSpring charge indicator
Figure 1.11. Mimic diagram of cgm.3-p cubicle

IG-183-EN version 06; 31/03/2020 11
General instructions
cgm.3 system: medium voltage SF6gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
Description and main characteristics
cgm.3-v
bPressure gauge window
cVoltage presence indicator ekor.vpis / ekor.ivds
d
Operation area:
• YELLOW for earthing switch
• GREY for switch-disconnector
eekor.rpg protection unit
fStatus indicators
gEarthing switch actuating shaft access handle
jSpring change indicator
kCircuit-breaker manual spring change
mOperation counter
nSwitch-disconnector actuating shaft access handle
o
Circuit-breaker operation area
• RED pushbutton for opening
• GREEN pushbotton for closing
Figure 1.12. Mimic diagram of cgm.3-v cubicles
cgm.3-rb-pt
bPressure gauge window
cekor.vpis / ekor.ivds voltage presence indication unit
dOperation area:
• YELLOW for earthing switch
e
Status Indicators
• GREEN open
• RED closed
fActuation shaft access handle
Figure 1.13. Mimic diagram of cgm.3-rb

IG-183-EN version 06; 31/03/2020
12
Description and main characteristics
General instructions
cgm.3 system: medium voltage SF6gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
cgm.3-rb
fekor.vpis / ekor.ivds voltage presence indicator
Figure 1.14. Mimic diagram of cgm.3-rb
cgm.3-rc / cgm.3-r2c
Figure 1.15. Mimic diagram of cgm.3-rc / -r2c cubicle

IG-183-EN version 06; 31/03/2020 13
General instructions
cgm.3 system: medium voltage SF6gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
Description and main characteristics
3. Base: made up of the cable compartment (3a) and the
gas relief compartment (3b), see Figures 1.1 and 1.2.
The rst is located in the lower front part of the cubicle
and has a cover interlocked with the unit’s ground
connection, which allows front access to the medium
voltage cables.
The gas relief compartment is located in the lower rear
section of the cubicle. In the event of an internal arc,
the gases produced are deected downwards and to
the rear, and in no way aecting any persons, cables, or
the rest of the installation switchgear.
For cubicles with 1 s internal arc, the gases are diverted
to the trench.
Figure 1.16. Cable compartment
1.1.1. Voltage presence indication unit
Ormazabal has two voltage presence indication options:
• The ekor.vpis unit for detecting voltage, designed in
accordance with standard IEC 62271-206.
• The ekor.ivds unit for detecting voltage, designed in
accordance with standard IEC 61243-5.
Both units provide a clear visual indication for the user,
without needing an auxiliary power supply for its operation.
For each of the three phases, the presence of voltage is
indicated by intermittent ashing of the indicators.
The test points for the ground and the three phases make
it easier to check the phase balance between cubicles. Any
universal comparator which complies with specications of
standard IEC 62271-206 can be used for this purpose.
If the indicators do not light up, use other means to
check that there is no voltage. 1
The numbering corresponds to the order of the phases, from
left to right, seen from the front of the cubicle. Each phase has a
test point for checking the phase balance between cubicles.
2Display each of the indicator phases
3Voltage presence indicator
A ashing light indicates the presence of voltage in that phase.
4Ground test point
This is only used for comparing the phases.
Figure 1.17. Voltage presence indication unit

IG-183-EN version 06; 31/03/2020
14
Description and main characteristics
General instructions
cgm.3 system: medium voltage SF6gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
1.1.2. ekor.sas - acoustic grounding prevention alarm unit
The ekor.sas grounding prevention alarm is an acoustic
indicator which works in association with the grounding
shaft handle and the ekor.vpis voltage presence indicator.
Both operate within the same range. The alarm is activated
when there is voltage in the cubicle’s medium voltage
feeder and the lever is inserted in the grounding switch
shaft. A sound then warns the operator that if he performs
the operation, a short-circuit in the network might occur.
This unit is standard on cgm.3 system feeder functional
units and supplied to order in the rest of the functional
units.
Figure 1.18. Location of ekor.sas unit
1.1.3. Nameplate
Every cubicle has a name plate indicating some of the
following values:
Figure 1.19. Example of nameplate

IG-183-EN version 06; 31/03/2020 15
General instructions
cgm.3 system: medium voltage SF6gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
Description and main characteristics
Nameplate
General instr. Manual of General Instructions (IG) corresponding to the system
No. Cubicle serial number*
Identier Cubicle model
Type Type of circuit-breaker (if applicable)
UrEquipment rated voltage (kV)
BIL (Up)Lightning impulse withstand voltage (kV)
UdPower frequency withstand voltage (kV)
frEquipment rated frequency (Hz)
Ir/Iload Equipment rated continuous current and load switching current (A)
Icc Equipment rated cable-charging switching current (A)
Iut Equipment rated unloaded transformer switching current (A) (if applicable)
M1 or M2 Number of mechanical operations (switch: 1000 or 5000 operations; circuit-breaker 2000 or 10000 operations)
Ik/IpShort-time withstand current/ Short-time withstand peak value - Fault making current (kA)
tkShort-time withstand current time (s)
Pre/Pme Rated lling pressure for insulation / Rated lling pressure for operation (kPa)
Pme/Pmm Minimum functional pressure for insulation / Minimum functional pressure for operation (kPa)
UaRated auxiliary voltage (V)
SF6Weight of insulating uid (g)
Weight Total weight of cubicle (kg)
Date Month and year of manufacture
TcThermal class (°C)
DC Percentage of Direct Current component in circuit- breaker cubicle
Int.time Rated interrupting time in circuit-breaker cubicle
Duty Cycle Rated operating duty cycle in circuit-breaker cubicle
Isc Rated short-circuit switching current in circuit- breaker cubicle
Address Factory address
* In the event of a problem or non-conformity, note down this number and send it to Ormazabal.
Table 1.4. Nameplate

IG-183-EN version 06; 31/03/2020
16
Description and main characteristics
General instructions
cgm.3 system: medium voltage SF6gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
1.2. Mechanical characteristics
The dimensions and weights of the cgm.3 cubicle system
are represented in the following table.
Figure 1.20. cgm.3 system dimensions
Module Width (a)
(inches) [mm]
Depth (f)
(inches) [mm]
Height (h)
(inches) [mm]
Bushings height (g)
(inches) [mm]
Weight (pounds)
[kg]
-l (16)
[418]
(33[1])
[850[1]]
(69)
[1745]
(41)
[1042]
(357)
[162]
-s (16)
[418]
(33)
[850]
(69)
[1745] -(315)
[143]
-s-pt (24)
[600]
(33)
[850]
(69)
[1745] -(408)
[185]
-p (19)
[480]
(40)
[1010]
(69)
[1745]
(21)
[525]
(507)
[230]
-v (24)
[600][2]
(33)
[850]
(69)
[1745]
(27)
[695]
(562)
[255]
-rci / -rcd (14)
[367]
(33)
[831]
(69)
[1745] -(93)
[42]
-r2c (21.6)
[550]
(33.46)
[831]
(68.7)
[1740] -(132.4)
[60]
-rb / -rb-pt (16)
[418]
(33)
[850]
(69)
[1745]
(41)
[1042]
(348)
[158]
-m (43)
[1100]
(46)
[1160]
(71)
[1800] -(661)
[300]
-2lp (52)
[1316]
(40)
[1010](1)
(55)
[1400]
-l -p (460)
[1014]
(28)
[697]
(7)
[180]
(69)
[1745]
(41)
[1042]
(21)
[525]
(490)
[1080]
-2lv (56)
[1436]
(33)
[850]
(69)
[1745]
-l -v (547)
[1205]
(41)
[1042]
(27)
[695]
-rlv (56)
[1436]
(33)
[850]
(69)
[1745]
(41)
[1042]
(27)
[695]
(547)
[1205]
[1] Cubicle with double cable: 36.69 inches (930 mm).
[2] As an option, there is also available a 23 inches (595 mm) wide model of the cgm.3-v cubicle. Contact Ormazabal.
Table 1.5. Dimensions and weights

IG-183-EN version 06; 31/03/2020 17
General instructions
cgm.3 system: medium voltage SF6gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
Transport
2. Transport
2.1. Lifting methods
The cubicles must always be kept upright, directly on the
ground or on a pallet depending on the type of handling
involved.
To handle cgm.3 assemblies with up to 4 functional units,
one of the following methods should be used:
1. Using a forklift truck or hand-operated pallet truck.
Position the rear of the cubicle facing the driver, to
avoid damaging the front.
Figure 2.1. Lifting a cgm.3 modular cubicle using a fork- lift truck
2. Raising it using slings xed to the lifting supports on
the sides of the top of the cubicle. The angle of pull
should be as vertical as possible (with an angle of more
than 60° from the horizontal).
Figure 2.2. Lifting a cgm.3 modular cubicle with slings
3. if it is not possible to use the aforementioned methods,
rollers may be used underneath the cubicles. Another
option is to slide the cubicles over rods (these same
rods can be used to get over the trench).

IG-183-EN version 06; 31/03/2020
18
Transport
General instructions
cgm.3 system: medium voltage SF6gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
4. To handle 5 functional unit cgm.3 assemblies use lifting
systems (slings, lifting beam, etc.) with a pull angle
greater than 65° and less than 115° in order to prevent
possible damage to the cubicles during hoisting.
The use of lifting beams is required for cubicle
assemblies with control boxes As the sole exception,
slings may be used if the cubicles of the assembly have
identical height control boxes installed.
Figure 2.3. Lifting a cgm.3 assembly with 5 functional units
Figure 2.4. Lifting a cgm.3 assembly with a forklift truck

IG-183-EN version 06; 31/03/2020 19
General instructions
cgm.3 system: medium voltage SF6gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
Transport
2.2. Location of documentation and accessories during transport
During transport, the cubicle must be perfectly seated and
xed so that it cannot move about and possibly damage the
equipment.
The corresponding documentation (General Instructions,
electrical diagrams, etc.) is supplied with the cubicles, as
well as a set of accessories located at the rear of the cubicles,
as indicated in the gures below:
The cubicle models with internal arc for 1 s have the
accessories box located on the roof of the tank.
2.2.1. pmodules
Figure 2.5. Location of documentation and accessories

IG-183-EN version 06; 31/03/2020
20
Transport
General instructions
cgm.3 system: medium voltage SF6gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
2.2.2. land vmodules
Depending on the medium voltage cubicle model, the
accessory box contains some of the following items:
• Ormazabal’s IG-183 General Instructions document
• Actuating lever
• Spring charging lever
• Cubicle connecting kit:
- ormalink
- Springs
- Syntheso grease
- Grounding bar
• End plug kit:
- Cubicle end assembly
- Nylon thread
- Plastic plugs
- Side cover
Figure 2.6. Location of documentation and accessories
