Huawei New Main Way 2.0 User manual

New Main Way 2.0
User Manual
Issue 05
Date 2020-10-15
HUAWEI TECHNOLOGIES CO., LTD.
Part Number: 31500ACJ

Copyright © Huawei Technologies Co., Ltd. 2020. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and
the customer. All or part of the products, services and features described in this document may not be
within the purchase scope or the usage scope. Unless otherwise specied in the contract, all statements,
information, and recommendations in this document are provided "AS IS" without warranties, guarantees
or representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every eort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address:
Website:
Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
https://e.huawei.com
Issue 05 (2020-10-15) Copyright © Huawei Technologies Co., Ltd. i

About This Document
Purpose
This document describes the New Main Way (NMW) 2.0 in terms of its features,
performance, appearance as well as instructions for installation, and operation
and maintenance (O&M).
Intended Audience
This document is intended for:
● Sales engineers
● Technical support engineers
● System engineers
● Hardware installation engineers
● Commissioning engineers
● Data conguration engineers
● Maintenance engineers
Symbol Conventions
The symbols that may be found in this document are dened as follows.
Symbol Description
Indicates a hazard with a high level of risk which,
if not avoided, will result in death or serious
injury.
Indicates a hazard with a medium level of risk
which, if not avoided, could result in death or
serious injury.
New Main Way 2.0
User Manual About This Document
Issue 05 (2020-10-15) Copyright © Huawei Technologies Co., Ltd. ii

Symbol Description
Indicates a hazard with a low level of risk which,
if not avoided, could result in minor or moderate
injury.
Indicates a potentially hazardous situation which,
if not avoided, could result in equipment damage,
data loss, performance deterioration, or
unanticipated results.
NOTICE is used to address practices not related to
personal injury.
Supplements the important information in the
main text.
NOTE is used to address information not related
to personal injury, equipment damage, and
environment deterioration.
Change History
Changes between document issues are cumulative. The latest document issue
contains all the changes made in earlier issues.
Issue 05 (2020-10-15)
Optimized the support installation diagrams.
Issue 04 (2020-05-15)
Added "Preparing Load Cables."
New Main Way 2.0
User Manual About This Document
Issue 05 (2020-10-15) Copyright © Huawei Technologies Co., Ltd. iii

Contents
About This Document................................................................................................................ ii
1 Safety Precautions...................................................................................................................1
1.1 General Safety Precautions.................................................................................................................................................. 1
1.2 Electrical Safety........................................................................................................................................................................2
1.3 Environmental Safety............................................................................................................................................................. 3
1.4 Mechanical Safety................................................................................................................................................................... 3
1.5 Routing Cables......................................................................................................................................................................... 4
1.6 Information About Foreign Objects Near the Installation Position of the NMW............................................. 5
2 Overview....................................................................................................................................6
2.1 General Input Unit.................................................................................................................................................................. 7
2.2 Power Distribution Unit...................................................................................................................................................... 12
2.3 Busbar Trunking Unit...........................................................................................................................................................13
3 Installation..............................................................................................................................15
3.1 Installation Preparations.................................................................................................................................................... 15
3.1.1 Preparing Power Cables.................................................................................................................................................. 15
3.1.2 Unpacking and Acceptance............................................................................................................................................17
3.2 NMW Layout and Cable Routing Principles................................................................................................................ 17
3.2.1 Layout and Cable Routing Principles: Single-Row Aisle Containment (2N Scenario)...............................17
3.2.2 Layout and Cable Routing Principles: Dual-Row Aisle Containment, Crossing Rows (2N Scenario)
............................................................................................................................................................................................................ 18
3.2.3 Layout and Cable Routing Principles: Dual-Row Aisle Containment (2N Scenario)..................................19
3.2.4 Layout and Cable Routing Principles: Single-Row Aisle Containment (N+1 Scenario)............................ 20
3.2.5 Layout and Cable Routing Principles: Dual-Row Aisle Containment, Crossing Rows (N+1 Scenario)
............................................................................................................................................................................................................ 21
3.2.6 Layout and Cable Routing Principles: Dual-Row Aisle Containment (N+1 Scenario)............................... 22
3.3 Installing the NMW.............................................................................................................................................................. 23
3.3.1 Support-Mounting Scenario...........................................................................................................................................24
3.3.1.1 Determining the Support Installation Positions.................................................................................................. 25
3.3.1.2 Installing the NMW....................................................................................................................................................... 27
3.3.2 Hoisting Scenario...............................................................................................................................................................35
3.4 Installing Cables.................................................................................................................................................................... 35
3.4.1 Cable Routes....................................................................................................................................................................... 35
3.4.2 Installing Cables................................................................................................................................................................. 37
New Main Way 2.0
User Manual Contents
Issue 05 (2020-10-15) Copyright © Huawei Technologies Co., Ltd. iv

3.5 Verifying the Installation.................................................................................................................................................... 42
4 Power-On Commissioning................................................................................................... 43
4.1 Insulation Test........................................................................................................................................................................ 43
4.2 Power-On................................................................................................................................................................................. 44
4.3 Commissioning...................................................................................................................................................................... 45
5 Routine Maintenance........................................................................................................... 48
6 Troubleshooting.....................................................................................................................50
7 Alarm List................................................................................................................................ 51
8 Parts Replacement................................................................................................................ 55
8.1 Replacing a General Input Unit........................................................................................................................................55
8.2 Replacing a Power Distribution Unit..............................................................................................................................57
8.3 Replacing an SPD.................................................................................................................................................................. 59
8.4 Replacing an SPD Circuit Breaker....................................................................................................................................60
8.5 Replacing the Auxiliary Contact of an SPD Circuit Breaker................................................................................... 61
8.6 Replacing an Integrated Management Card............................................................................................................... 63
8.7 Replacing the Monitoring Board of the General Input Unit.................................................................................. 63
8.8 Replacing an Alarm Indicator........................................................................................................................................... 66
8.9 Replacing the Output Circuit Breaker of the Power Distribution Unit............................................................... 67
9 Technical Specications....................................................................................................... 71
A Preparing Load Cables......................................................................................................... 73
B Acronyms and Abbreviations..............................................................................................75
New Main Way 2.0
User Manual Contents
Issue 05 (2020-10-15) Copyright © Huawei Technologies Co., Ltd. v

1 Safety Precautions
1.1 General Safety Precautions
General Safety Principles
To ensure safety of humans and the equipment, pay attention to the safety
symbols on the equipment and all the safety instructions in this document.
The "Note", "CAUTION", "WARNING", and "DANGER" statements in this
document do not represent all the safety instructions. They are only supplemental
to the safety instructions.
Local Safety Regulations
When operating Huawei equipment, you must follow the local laws and
regulations. The safety instructions in this document are only supplemental to the
local laws and regulations.
Personnel Requirements
Personnel who plan to install, operate, and maintain Huawei equipment must be
thoroughly trained, understand all necessary safety precautions, and master
correct operation methods.
● Only trained and qualied personnel are allowed to install, operate, and
maintain the equipment.
● Only personnel certied or authorized by Huawei are allowed to replace or
change the equipment or components (including software).
● Any fault or error that might cause safety problems must be reported
immediately to a supervisor.
Grounding Requirements
Equipment to be grounded must meet the following requirements:
New Main Way 2.0
User Manual 1 Safety Precautions
Issue 05 (2020-10-15) Copyright © Huawei Technologies Co., Ltd. 1

● When installing the device, always make the ground connection rst.
● When removing the device, disconnect the ground cable at the end.
● Do not damage the ground conductor.
● Do not operate the device in the absence of a properly installed ground
conductor.
● The device (or system) must be connected permanently to the protection
ground before operation. Before operating the device, check its electrical
connection to ensure that it is securely grounded.
Human Safety
● Do not operate the device or cables during thunderstorms.
● In the case of a thunderstorm, disconnect the AC power supply, and do not
use xed terminals or touch the terminals or antenna connectors.
● Before operating the device, put on electrostatic discharge (ESD) clothes, ESD
gloves, and an ESD wrist strap. Do not wear conductive articles such as
jewelry or watches when you operate the device.
● In the case of a re, immediately leave the building or the equipment room,
and turn on the re alarm bell or make an emergency call. Never enter a
building or equipment zone that is on re.
Equipment Safety
● The device must be xed securely on the oor or to other immovable objects
such as walls or mounting racks before operation.
● Do not block the ventilation vents while the device is operating.
● Tighten the screws using tools when installing panels.
● After the installation, remove packing materials from the equipment area.
1.2 Electrical Safety
High Voltage
D ANGER
● The high voltage power supply provides power for the equipment operation.
Direct or indirect contact (especially with a damp object) with the high voltage
power supply may result in fatal injury.
● Non-standard and improper high-voltage operations may result in accidents
such as re or electric shock.
New Main Way 2.0
User Manual 1 Safety Precautions
Issue 05 (2020-10-15) Copyright © Huawei Technologies Co., Ltd. 2

High Electricity Leakage
CA UTION
Ground the equipment before powering it on. Otherwise, personal injury or
equipment damage may be caused by high electricity leakage.
If a "high electricity leakage" label is attached near the power terminal of the
equipment, you need to ground the protective ground terminal on the enclosure
before connecting the AC power supply; otherwise, electric shock as a result of
electricity leakage may occur.
Power Cable
D ANGER
Do not connect or disconnect power cables with power on. Transient contact
between the core of a power cable and a conductor may generate electric arcs or
sparks, which may cause re or hurt human eyes.
● Before installing or removing a power cable, turn o the power switch.
● Before connecting a power cable, check that the label on the power cable is
correct.
Fuse
CA UTION
To ensure that the equipment runs safely, if a fuse is blown, replace it with a new
fuse of the same type and specications.
1.3 Environmental Safety
D ANGER
Do not place or operate a device in a ammable, explosive, or smoky
environment.
Operating any electronic device in a ammable environment can be fatal.
1.4 Mechanical Safety
New Main Way 2.0
User Manual 1 Safety Precautions
Issue 05 (2020-10-15) Copyright © Huawei Technologies Co., Ltd. 3

Moving Sharp Objects
CA UTION
Wear protective gloves when moving sharp objects.
Moving Heavy Objects
Wear protective gloves to protect hands when moving heavy objects.
CA UTION
Be careful to prevent injury when moving heavy objects.
1.5 Routing Cables
Binding Signal Cables
NO TICE
Signal cables must be bound separately from strong-current cables and high-
voltage cables.
Laying Out Power Cables
When the temperature is very low, violent impact or vibration may damage the
power cable sheathing. To ensure safety, comply with the following requirements:
● Power cables should be laid out or installed only when the temperature is
higher than 0°C.
● Cables stored at subzero temperatures must be stored at room temperature
for at least 24 hours before they are laid out.
● Handle power cables with caution, especially at a low temperature. Do not
drop the power cables directly from the vehicle.
Pictu
re
Desc
riptio
n
Internal
equipotenti
al
connection
label.
General
ground
point.
Copper bar
or cable of
phase L1.
Copper bar
or cable of
phase L2.
Copper bar
or cable of
phase L3.
New Main Way 2.0
User Manual 1 Safety Precautions
Issue 05 (2020-10-15) Copyright © Huawei Technologies Co., Ltd. 4

Sym
bol
QF FU L QFS FS
Nam
e
Circuit
breaker
Fuse Indicator or
phase
sequence
SPD circuit
breaker
SPD
1.6 Information About Foreign Objects Near the
Installation Position of the NMW
The purpose of this note is to provide information and warnings about the
potential risks of the operational integrity of an installed NMW system. These risks
are caused by foreign objects in or near the NMW, relevant auxiliary equipment, or
components.
WARNING
● If conductive materials have entered the channel in the NMW, relevant
auxiliary equipment, or components, equipment faults may occur.
● Potential risks include damage to the installed NMW and subsequent power
derating and power failure of loads at critical positions.
● Huawei uses the IP30 standard in NMW design to ensure that live parts are not
in contact with the exterior and that no foreign objects will enter the
equipment during operation.
● When the NMW bae plate and cover are open and electrical wiring terminals
are exposed by the electrical contractor or installation personnel who are
setting up a power line connection, it cannot be ensured that no foreign object
will enter the NMW during onsite installation.
● It is common to have someone working in the same room as the NMW during
onsite installation. Sometimes some people may be working above the NMW,
relevant auxiliary equipment, or components.
● To avoid serious damage to the onsite operation, property hazards, and
personal injury including fatal injury, it is the responsibility of each equipment
manager or construction manager to ensure that no foreign object enters the
NMW, relevant auxiliary equipment, or components.
New Main Way 2.0
User Manual 1 Safety Precautions
Issue 05 (2020-10-15) Copyright © Huawei Technologies Co., Ltd. 5

2 Overview
NO TICE
● Use professional insulated tools when installing or operating the equipment.
● Only engineers certied by the manufacturer or its agents are allowed to
install, commission, and maintain the NMW. Otherwise, personal injury or
device damage may occur, and the resulting faults of the NMW are beyond the
warranty scope of Huawei.
● The gures provided in this document are for reference only. The actual product
prevails.
Appearance
Figure 2-1 Single-route installation scenario
(1) General input unit (2) Connective kit (3) Power distribution
unit
(4) Busbar trunking
unit
(5) Column (6) Around-column
busbar trunking unit
and elbow (used in the
scenario with columns)
(7) End plug (8) Low support
New Main Way 2.0
User Manual 2 Overview
Issue 05 (2020-10-15) Copyright © Huawei Technologies Co., Ltd. 6

Figure 2-2 Dual-route installation scenario
(1) General input unit (2) Connective kit (3) Power distribution
unit
(4) Busbar trunking
unit
(5) Column (6) Around-column
busbar trunking unit
and elbow (used in the
scenario with columns)
(7) End plug (8) High support
2.1 General Input Unit
It is used as a cable entry unit.
Model Number Description
Figure 2-3 General input unit
No. Meaning
1 New main way
2 Input MCCB current level:
0250: 250 A (derated to 187 A at 40°C)
0400: 400 A (derated to 300 A at 40°C)
3 AC
4 Rated 380–415 V, three-phase
5 General input unit
6 Monitoring type
7 01 right-mounted
02: left-mounted
New Main Way 2.0
User Manual 2 Overview
Issue 05 (2020-10-15) Copyright © Huawei Technologies Co., Ltd. 7

Appearance
Figure 2-4 General input unit
(1) Alarm indicator (2) Monitoring panel (3) Integrated
management card
(4) PWR_2 port
(5) PWR_1 port (6) FE port (7) SPD (8) Input switch
(9) SPD circuit breaker (10) Cable inlet (11) Cable outlet
Table 2-1 Alarm indicator description (with an integrated management card)
Status Description
Steady on An alarm is generated. If the PWR indicator on the monitoring
panel is on, the general input unit is powered by the mains, 48 V,
or both.
O No alarm is generated. If the PWR indicator on the monitoring
panel is on, the general input unit is powered by the mains, 48 V,
or both. If the PWR indicator on the monitoring panel is o, the
power supply is disconnected.
Table 2-2 Alarm indicator description (without an integrated management card)
Status Description
Steady on An alarm is generated, the general input unit is powered by the
mains, and the 48 V power supply is not involved.
O No alarm is generated. If the PWR indicator on the monitoring
panel is on, the general input unit is powered by the mains. If the
PWR indicator on the monitoring panel is o, the power supply is
disconnected.
New Main Way 2.0
User Manual 2 Overview
Issue 05 (2020-10-15) Copyright © Huawei Technologies Co., Ltd. 8

Figure 2-5 Monitoring panel
The monitoring panel displays the running status of the NMW system by
indicators, implements the blink function with the ECC800-Pro by the Blink button,
and provides USB, RS485, FE, and AIDI ports.
(1) Indicators (2) Blink button (3) USB port (4) RS485 port
(5) AIDI_1 port (6) FE port (7) AIDI_2 port
Table 2-3 Indicator description
Indicator Color Status Description
RUN Green Blinking at 0.5 Hz, on for 1s
and then o for 1s.
The equipment is
running properly.
Blinking at 10 Hz, on for
0.05s and then o for 0.05s.
The RUN indicator
blinks.
PWR Green Steady on The power supply to
the CPU of the
monitoring board is
normal.
O The power supply to
the CPU of the
monitoring board is
abnormal.
ALM Red Steady on There is an alarm.
O There is no alarm.
New Main Way 2.0
User Manual 2 Overview
Issue 05 (2020-10-15) Copyright © Huawei Technologies Co., Ltd. 9

Figure 2-6 USB pins
Table 2-4 USB pin denition
Pin Description
1 5V
2 DM
3 DP
4 GND
Figure 2-7 RS485, FE, and AIDI pins
Table 2-5 RS485, FE, and AIDI pin denition
Pin RS485 FE AIDI
1 RS485+ TRX0+ -
2 RS485– TRX0- -
3 - TRX1+ GND
4 RS485+ TRX2+ -
5 RS485– TRX2- -
6 - TRX1- GND
New Main Way 2.0
User Manual 2 Overview
Issue 05 (2020-10-15) Copyright © Huawei Technologies Co., Ltd. 10

Pin RS485 FE AIDI
7 - TRX3+ AIDI_1+
8 - TRX3- -
Figure 2-8 Integrated management card (optional)
The card supports 48 V DC power supply and FE communication extension. It is
hot-swappable.
(1) PWR indicator (2) POE port (3) 48 V output port
Figure 2-9 POE pins
Table 2-6 POE pin denition
Pin Description
1 TRX0+_RTN
2 TRX0-_RTN
3 TRX1+_-48V
4 TRX2+_RTN
5 TRX2-_RTN
6 TRX1-_-48V
New Main Way 2.0
User Manual 2 Overview
Issue 05 (2020-10-15) Copyright © Huawei Technologies Co., Ltd. 11

Pin Description
7 TRX3+_-48V
8 TRX3-_-48V
Specications
● When the input switch is 400 A, the dimensions (H x W x D) of the general
input unit are 300 mm x 600 mm x 220 mm.
● When the input switch is 250 A, the dimensions (H x W x D) of the general
input unit are 270 mm x 600 mm x 220 mm.
2.2 Power Distribution Unit
The power distribution unit is a cable outlet unit from which power is led out from
the busbar trunking unit.
Model Number Description
Figure 2-10 Power distribution unit model
No. Meaning
1 New main way
2 Current level: 125 A (derated to 88 A at 40°C)
3 AC
4 Rated 380–415 V, three-phase
5 Number of single-phase circuit breakers
6 Number of three-phase circuit breakers
7 Monitoring type
8 01: 16 A output circuit breaker (derated to 12 A at 40°C)
02: 40 A output circuit breaker (derated to 30 A at 40°C)
03: 63 A output circuit breaker (derated to 44 A at 40°C)
04: 40 A output circuit breaker (hot-swappable, derated to 30 A
at 40°C)
New Main Way 2.0
User Manual 2 Overview
Issue 05 (2020-10-15) Copyright © Huawei Technologies Co., Ltd. 12

Appearance
Figure 2-11 Power distribution unit
(1) Load wiring port (2) PWR_1 port (3) FE1 port (4) Monitoring panel
(5) Integrated
management card
(6) FE2 port (7) PWR_2 port (8) Output circuit
breaker (behind the
cover)
NO TICE
The monitoring panel, integrated management card model, and FE port
denitions of the power distribution unit and general input unit are the same.
Specications
Dimensions (H x W x D): 255 mm x 250 mm x 220 mm
2.3 Busbar Trunking Unit
The busbar trunking unit consists of buses, bus supports, insulation parts, the
housing, fasteners, and connective kits connected to other units.
Model Number Description
Figure 2-12 Busbar trunking unit
New Main Way 2.0
User Manual 2 Overview
Issue 05 (2020-10-15) Copyright © Huawei Technologies Co., Ltd. 13

No. Meaning
1 New main way
2 Current level:
0250: 250 A (derated to 187 A at 40°C)
0400: 400 A (derated to 300 A at 40°C)
3 AC
4 Rated 380–415 V, three-phase
5 Busbar trunking unit
6 01: 1200 mm long busbar trunking unit
02: 407 mm long busbar trunking unit
Appearance
Figure 2-13 Busbar trunking unit
New Main Way 2.0
User Manual 2 Overview
Issue 05 (2020-10-15) Copyright © Huawei Technologies Co., Ltd. 14
