iB COLUMBO User manual

USER MANUAL

2
CONTENTS
Welcome 3
Connecting 4
Cleaning 4
Resources 5
Support/Software
SDK Download Link
Scanning 6
Finger Conditions
Hand Orientation 7
Correct Placement – Top View
Finger Contact 8
Correct Placement – Side View
Flat Scanning 9
Finger Placement
Warranty 10
Compliance 10
© 2021 Integrated Biometrics, Inc. All rights reserved.

3
WELCOME!
Thank you for purchasing Columbo, Integrated Biometrics’
patented Light Emitting Sensor (LES) fingerprint scanning solution.
Columbo is the most durable, highest performance FAP 60 FBI
Appendix F-certified single-print live scanning solution.
Please read this manual thoroughly before using your Columbo
to review proper steps for unit operation and capture processes.
Your Integrated Biometrics reseller and the IB team are ready to
answer any questions you may have!

4
CONNECTING
CONNECT USB TO THE DEVICE
Connecting Columbo is easy!
1. Download and install the latest IBScanUltimate SDK
2. Integrated Biometrics provides a variety of test applications for
demonstration. IBScanUltimate SDK includes demonstration
applications for supported platforms and source code for ease
of deployment.
For proper cleaning and disinfection of IB products, visit:
https://integratedbiometrics.com/cleaning
CLEANING AND
DISINFECTION

5
RESOURCES
SUPPORT/SOFTWARE DEVELOPMENT
The IBScanUltimate Software Development Kit (SDK) is a set of robust
tools that empower solution providers with the ability to deploy
compelling LES biometric acquisition applications. The SDK includes
support for a variety of operating systems and exceeds the needs of
the most challenging environments.
The SDK includes Application Programming Interface (API)
documentation, IB software components, demonstration applications
and source code for each platform. Demonstration source code is a
simple reference for integrators to rapidly develop solutions using
Integrated Biometrics’ LES technologies. We encourage you to review
the included materials and explore the limits of creativity when
designing custom biometric solutions.
If you have any questions, please contact your Integrated Biometrics
reseller or the IB team. We’ll be glad to provide assistance during
solution development.
DOWNLOAD SDK
www.integratedbiometrics.com/sdk-downloads
Download Software Development Kit (SDK)
Technical Documentation and Product Support

6
SCANNING
FINGER CONDITIONS
VERY MOIST FINGERS
• Result: Images too dark, poorly defined. Indicates too much
moisture on the fingers.
• Solution: Dry the fingers with a towel or cloth before
fingerprint capture.
• The resultant images will be lighter and the NFIQ quality scores
will improve.
VERY DRY FINGERS
• Result: Images take several seconds to appear or contrast appears
lighter than desired.
• Solution: Rub a small amount of moisturizer on the fingertips.
(Do not slather.)
• The resultant images will be darker and the NFIQ quality scores
will improve.
• Gentle or light contact with the plate is recommended in scanning.
Placing extra pressure on the hand is not recommended.
• Avoid using hand sanitizers, alcohol based lotions, and baby wipes
prior to scanning.
BEST PRACTICES
• Never put a wet hand on the scanner i.e., just washed and not
thoroughly dried, holding a bottle of liquid that leaves condensation
on your hand. Hands should be wiped dry.
Dry FingerprintsNormal Fingerprints Wet Fingerprints

7
HAND ORIENTATION
CORRECT PLACEMENT – TOP VIEW
Your finger should be facing the cable.
It should be firmly placed on the platen
and bezel.
Bezel
Platen

8
FINGER CONTACT
CORRECT PLACEMENT – SIDE VIEW
Your finger should be
facing the cable. It
should be firmly placed
on the platen and bezel.
Bezel
Platen

9
FLAT SCANNING
FINGER POSITION
Ready to scan
Scan finished.
Put your finger firmly on the bezel for proper contact.
Bezel
Platen

10
All products are guaranteed for 12 months from the date of delivery.
Additional year warranties available. Check with your dealer.
See the warranty here: https://integratedbiometrics.com/warranty
WARRANTY
COMPLIANCE
FCC
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by
Integrated Biometrics could void the user’s authority to operate this
equipment legally under FCC regulations.
