iBaby M7 User manual

iBaby Labs, Inc.

iBaby Monitor User Manual
2
Contents
1 PRODUCT OVERVIEW .......................................................................................................... 2
1.1 Package List ....................................................................................................................... 2
1.2 Interface Introduction .......................................................................................................3
1.3 Product Specifications....................................................................................................... 4
2 INSTALLATION GUIDE .......................................................................................................... 5
2.1 App Download................................................................................................................... 5
2.2 Getting Started..................................................................................................................5
2.3 Register and Login ............................................................................................................. 5
2.4 Device Activation............................................................................................................... 5
2.4.1 Apple Users Activation ......................................................................................................5
2.4.2 Android Users Activation................................................................................................... 6
3 APP OPERATION AND FUNCTION...................................................................................... 8
3.1 The Main Viewing Screen.................................................................................................. 8
3.2 App Function Menu......................................................................................................... 10
3.3 Frequently Used Function ............................................................................................... 11
4 FREQUENTLY ASKED QUESTIONS.................................................................................. 15
4.1 LED Status Light............................................................................................................... 15
4.2 Installation FAQ ............................................................................................................... 16
4.3 Loading Wheel................................................................................................................. 19
4.4 Features FAQ ................................................................................................................... 22
5 CONTACT INFORMATION................................................................................................... 23
6 FCC CAUTION ...................................................................................................................... 23
1 Product Overview
1.1 Package List
 iBaby Monitor
 Base
 Power Adapter
 User Manual

iBaby Monitor User Manual
3
1.2 Interface Introduction
Figure 1
1) Photosensitive Sensor：Changes to night vision automatically
2) Microphone
3) Camera Lens
4) Monitor Serial Number：Uniquely identifies monitor, such as “6039aahs”
5) USB Interface：iPhone users，used for first installation or changing Wi-Fi
6) Reset Button：Long press, for 30 seconds, to restore factory settings
7) Base
8) LED Status Light：Shows status of monitor. Refer to Table 1 of Section 4.1
9) Power Interface: Supplies power to the monitor
10) Temperature/Humidity Sensor Interface：Connected with base, transfers data of
temperature and humidity
11) Metal Prongs

iBaby Monitor User Manual
4
1.3 Product Specifications
Model:M7 Lite
Compression H.264
Frame rate 1~12 frame
Resolution Ultra (1920*1080),HD(1280*720),VGA(640*480)
Camera Standard：4.2mm F=2.0fixed aperture (3 million camera
lens) view angle 85°
Video
Online users Support 4 users online simultaneously
Compression G711
Sampling frequency 8Kpbs
Input Audio input/built-in microphone
Output Audio output/built-in speaker
Audio
Intercom Full duplex ：two-way voice intercom simultaneously
Night vision control
Photo resistance control infrared opening
automatically (Lowest Illumination 0LUX) Night vision
Night vision effect 9 12ML LED night vision 8 meters
Control Built-in motor
Platform Rotate angle Horizontal direction 360°Vertical direction 110°
Network protocol TCP/IP，HTTP， UDP， DHCP， UPNP, NTP,P2P
Network Protocol Support IP address Dynamic IP address
Wireless protocol Support Wi-Fi 802.11 a/b/g/n
Wi-Fi module Support 2.4GHz and 5GHz Wi-Fi
Encryption Support WPA/WPA2encryption
Temperature/Humidity
module
Built-in 1
Reset 1
Wireless
Power adapter
interface DC5V 2A
Shape material Plastic
Use environment Indoor
Power consumption Nobody view within 2.5W in the day，Infrared opening
within 3W in the evening
Work environment Temperature ：-10~40 °C，Humidity ：40℃ ≤75%
Storage environment Temperature ：-40℃～55℃， Humidity：55℃ ≤90%
Size Monitor size: 132*142*110MM (W x D x H )
Package size: 165*165*165MM (W x D x H)
Others
Weight Gross weight ：380g
System Requirement Mobile phone Above iOS 8.0;Above Android 4.0

iBaby Monitor User Manual
5
2 Installation Guide
2.1 App Download
Apple Users：Search on the App Store for“iBaby Care App”
Android Users：Search on the Google Play Store for“iBaby Care App”
The icon of the app is as follows:
2.2 Getting Started
Connect your device to power adapter and wait for a jingle tone to sound. The LED
status light on the back will turn into a blinking red light after about 30s. The LED light
and jingle tone indicates that the device is started and active.
Note: If the device has been previously activated, it will not jingle when connected to the
power adapter.
For the meanings of the LED status light, please refer to Table 1 of section 4.1.
2.3 Register and Login
1.New users
Follow the prompt on the app to register an account. Use an active email address and
use a password must contain letters (case sensitive) and numbers. The length of it must
be over 6 characters. It can login automatically after registering.
Note: Active email can support users to find their password if they forget.
2.Users with account
Login with email and password they have used to register. If they forget their password,
click“Forgot Password”to reset password according to the prompt.
2.4 Device Activation
Please confirm that your mobile phone used for activating the device has a connection to
your Wi-Fi network. And then login with the registered account after the device has been
started.
2.4.1 Apple Users Activation
1.Open the USB cover on the bottom of the device, then connect your iPhone or iPad to
the device with the original iPhone USB cable.
2.You will see a “Share Wi-Fi Settings?”prompt on your screen. Once this window
operation system
Certification Certificate FCC CE ROSH RCM KC

iBaby Monitor User Manual
6
shows, click “Allow”. The LED status light will then turn into a blinking green light.
Figure 2
Note:
1) If the prompt does not show, unplug and re-plug the USB cable.
2) If the LED status light does not turn a blinking green, please contact Customer Service
or refer to the FAQ of section 4.2 for help.
3.It will show a scene as shown below on the app after selecting the corresponding
monitor, then click “Next”to activate the device.
Figure 3
4.Once the device is activated, unplug the USB cable. Put the USB cover back on and
place the device on its base.
Note: If you still cannot activate the device, please refer to the “Installation Issues”in
section 4.2.
2.4.2 Android Users Activation
1.From the “Add a Device”menu, select the device you want to install.

iBaby Monitor User Manual
7
Figure 4
2.Connect your Android device to a Wi-Fi network. Then, connect the power adapter to
the monitor. Click “Next”once these steps are completed.
3.The screen will appear as shown below. Click“Next”after entering the correct Wi-Fi
password.
Figure 5

iBaby Monitor User Manual
8
4. A progress bar will indicate the progression of your device installation.
Note: If you are unable to activate the device, please refer to“Installation Issues”in
section 4.2.
3 APP Operation and Function
3.1 The Main Viewing Screen

iBaby Monitor User Manual
9
收听：
Figure 6
1.Function Guide Section
： Function Menu Guide Button: A menu will appear to the left containing device
settings and functions.
： Devices List: Toggle between different devices using the downward
arrow.
： Media Gallery: View all of your saved photos and videos here.
2.Information Display Section
：Current environment’s temperature
：Current environment’s humidity
：The signal of the Wi-Fi network on the device

iBaby Monitor User Manual
10
3.Function Button Section
： Listen button
： Speak button
： Record button: Captures videos which are saved in the Media Gallery.
： Play button: Plays music from your music library.
： Capture button: Captures photos which are saved in the Media Gallery.
： Air quality icon: It shows the current air quality rating. View previous air quality
statistics by clicking on the icon.
3.2 App Function Menu
Figure 7
Switch Products:Users can switch between other iBaby devices.

iBaby Monitor User Manual
11
Home:Users can return to the main viewing screen.
Add a Device:Install a new iBaby device.
Alert Settings:Set the alert notification, alert tone and the specific alert types.
Invite & View Users:Invite multiple users to view your monitor and distribute viewing
rights to them.
Help Center:Answer the frequently asked questions.
My Account:Set and display the personal information.
Settings:Set the parameters and functions on the device.
Contact iBaby:Contact iBaby for support or just send your feedback.
Logout:Exit the current account.
3.3 Frequently Used Function
3.3.1 Alert Settings
Figure 8
Feeding Alert: You can set to remind your feeding for your child. It will remind you when
times up.
Diaper Alert: You can set to remind your diaper change for your child. It will remind you
when times up.
Motion Alerts:The device will give an alert when something moves by it. The higher the
sensitivity rating, the more sensitive the monitor will be.
Sound Alerts:The device will give an alert when it picks up a sound in the room. The
higher the sensitivity, the more sensitive the monitor will be.

iBaby Monitor User Manual
12
Temperature Alerts:The device will give an alert when the temperature around the device
is below the minimum value (eg.32℉) or above the maximum value (eg.86℉).
Humidity Alerts:The device will give an alert when the humidity around the device is
below the minimum value (eg.50%) or above the maximum value (eg.60%).
Alerts Tone:Select a tone for the alerts.
Notification:If this setting is on, you will get notifications when the app is closed or
running in the background.
Alerts display types:
Photo:When there is an alert the device will capture 3 photos and save them in the
Media Gallery.
Video:When there is an alert, the device will capture a 15 second video and save it in the
Media Gallery.
Alert Only:There is only notification without any media file saved.
3.3.2 Invite & View Users
You can invite unlimited number of family and friends to have access to the monitor. The
users can operate the monitor under the usage rights given by the owner. As for specific
steps, please refer to “Q2”of section 4.4.
3.3.3 Settings =》 Display Settings

iBaby Monitor User Manual
13
Figure 9
Night Vision:
Auto:The image on the screen will turn into colored/black and white according to the light
intensity automatically. This is the default setting.
On:Night vision will always be on and the image on the screen will be in black and white.
Off:Night vision will always be off and the image on the screen will be in colored.
Video Resolution:
Fair 640P :The image quality is poor. It produces less than 128kbps’ data per second
with low bandwidth occupied.
Good 720P:The image quality is good (it corresponds with 720P). It produces less than
256kbps’ data per second with medium bandwidth occupied.
Excellent1080P:The image quality is excellent (it corresponds with 1080P).It produces
less than 512kbps’ data per second with high bandwidth occupied.
Auto Video Adjustment:Video resolution automatically gets adjusted based on your

iBaby Monitor User Manual
14
network connection.
Hide Connection Bar: Hide the Wi-Fi network signal on the main viewing screen.
Hide Humidity & Temperature:Hide the humidity & temperature on the main viewing
screen.
3.3.4 Settings =》Sleep Mode
When the Sleep Mode is on, other users cannot access or view the monitor.
Figure 10
3.3.5 Play Music
A collection of pre-loaded music. Simply select any of the media files to play through the
iBaby device speakers.
Note:Because the music is downloaded from the Internet, they might not be played (or
delayed) when the network connection is poor. Please check your network settings.
Figure 11

iBaby Monitor User Manual
15
3.3.6 Camera & App Information
It shows the camera and app information, including firmware version, app version, S/N,
etc. If there is a updated firmware version, you can upgrade the firmware by clicking the
“Firmware Upgrade”button.
Figure 12
4 Frequently Asked Questions
4.1 LED Light Status
LED status Meaning
A blinking red light Device is not connected to Wi-Fi and
not activated
A blinking green light Device is connected to Wi-Fi, but not
activated
A steady red light Device is not connected to Wi-Fi, but
has been activated
A steady green light Device is working properly
Red and green blinking
alternately
Device is starting

iBaby Monitor User Manual
16
Not bright The power adapter is not plugged or
there is an issue on the device
Table 1
4.2 Installation FAQ
Q1.iOS Device:
Click “Cancel”when you see a prompted message“If You Do Not See Any
Progress”as below(the LED status light on the back of the monitor is a blinking
red light).
Figure 13
If this prompt shows, it may be that the monitor is not connected to your Wi-Fi network.
Please follow the steps as below:
1)Please use the phone’s original USB cable to enable a great connection.
2)Place the monitor near the router as close as possible while installation. If your router
supports 5GHz, we recommend that your phone connects 5GHz Wi-Fi before
installation.
3)The best Wi-Fi name & password should be 8-32 characters comprised of upper and
lower-case letters, numbers, and underscores. And they should not contain symbols or
special characters such as Chinese, Japanese, Korean, etc.
4)Enable your router’s SSID broadcasting.
5)Select WPA2-PSK as the Wi-Fi authentication type and select AES as the encryption

iBaby Monitor User Manual
17
type on the router.
Q2.Android Device:
There is a prompted message indicates installation failed.Why? (the LED status
light on the back of the monitor is a blinking red light)
Figure 14
It indicates that your monitor has not connected to your Wi-Fi network. Please follow the
steps as below:
1)Verify that the Wi-Fi password you enter is correct. Unplug the power adapter, and
then plug back it to reinstall.
2) Place the monitor as close to the router as possible during installation. If your router
supports 5GHz, we recommend connecting to the 5GHz Wi-Fi.
3) The best Wi-Fi name & password will be 8-32 characters comprised of upper and
lower-case letters, numbers, and underscores. And they should not contain symbols or
special characters such as Chinese, Japanese, Korean, etc.
4) Enable your router’s SSID broadcasting.
5) Select WPA2-PSK as the Wi-Fi authentication type and select AES as the encryption
type on the router.
Note:
Installation starts immediately after you enter the password. The monitor will jingle when
the installation progress bar reaches around 5%. There is a steady green light after the
installation is completed.
You’d better place the monitor near the router as close as possible if the monitor does

iBaby Monitor User Manual
18
not jingle. Restart the router to reinstall the monitor. You can reinstall the monitor at
another time if available.
Q3.Click “Cancel”when you see a prompted message“If You Do Not See Any
Progress”(the LED status light on the back of the monitor is a blinking green
light).
It indicates that your monitor has connected to your Wi-Fi network, but it is not activated
on the server. Please exit the app in the background and then reopen it. Both the monitor
and the router need to restart. If the installation fails again, please reinstall the monitor at
another time, but do not reset the monitor.
Q4.Cannot go to the next step while adding a device. Why?
Figure 15
There are some tips to follow:
1)Please use the iPhone’s original USB cable.
2)Verify that your phone has connected to your Wi-Fi network.
3)The power adapter has been plugged and the device has started (the LED status light
on the back of the monitor is a blinking red light).
4)Unplug the power adapter and then plug back it.
Q5.How to install the monitor when the Wi-Fi settings have been changed?

iBaby Monitor User Manual
19
iOS Device:Please use the USB cable to connect your iOS device and the monitor. And
then click“Allow”when you see a prompted message “Share Wi-Fi Settings?”.
Android Device:Reset the monitor and then reinstall it. As for the specific steps about
reset, please refer to “Q6” of section 4.4.
Q6.What should you do if you forget the password?
When you forget your login password, please enter the email address you used at
registration, and then click “Send”. There will be a link sent to your mailbox which is
used for resetting your login password. Please click the link to reset the login password
within 1 hour.
Figure 16
4.3 Loading Wheel
Q1.It is very slow on the main viewing screen when viewing at home(the LED
status light on the back of the monitor sometimes is a steady green light, and
sometimes it is a steady red light).
When the LED status light is a steady red or green light, it indicates an unstable Wi-Fi
connection. You should optimize the Wi-Fi settings by following the tips as below:
1)If you have a dual band router, we recommend that your monitor connects 5GHz
Wi-Fi .
2)If you use a regular router on 2.4GHz,you can login to the router to optimize the Wi-Fi
settings. Select 20M as the bandwidth if it is a TP-Link router(if it is a NETGEAR router,
enable 20/40MHz coexistence).
3)If the router is far away from the monitor(or there are multiple walls between the router
and the monitor),please place the monitor near the router as close as possible to have a
try.
4)The router might have a heavy load, please unplug the power cord of the router and
then plug back it to restart.
Q2.If it gets stuck on a loading screen while viewing at home and the LED status
light on the back of the monitor is a steady red light.

iBaby Monitor User Manual
20
Figure 17
It indicates that your monitor has not connected to your Wi-Fi network. Please follow the
steps below:
1)Unplug the power adapter of the monitor and then restart to check whether the LED
status light turns into a steady green light.
2)The router might have heavy load, please unplug the power cord of the router and then
plug back it to restart.
3)If the router is far away from the monitor( or there are multiple walls between the router
and the monitor),please place the monitor near the router as close as possible to have a
try.
4)If the LED status light is still a steady red light, it indicates that the Wi-Fi password
might have been changed. Please reinstall the monitor.
Q3.You can control the 360° pan’s movement and hear the sounds while viewing at
home.But the main viewing screen shows a black screen at this moment(the LED
status light on the back of the monitor is a steady green light).
