IBM ThinkPad 240 User manual

The purpose of this spreadsheet is to provide a guide to the compatibility within and between the ThinkPad 240 models.
The spreadsheet contains information that can be used to highlight the compatibilities and differences between ThinkPad models when
doing transition planning and/or to build an initial software image.
This package is NOT intended to be a list of the latest levels of the software drivers needed to build an image. Although it is current as
it is being created, it will become out of date over time.
For the current list of the levels of the latest software drivers, see the support page on the IBM ThinkPad web site at:
240 240 240 240X
21U 31U 41U 51U, 61U
Supported OS Version
PC-DOS 7.0 Minimum Support Minimum Support Minimum Support Minimum Support
PC DOS 2000 Minimum Support Minimum Support Minimum Support Minimum Support
MS-DOS 6.22 Minimum Support Minimum Support Minimum Support Minimum Support
Windows 3.11 No No No No
Windows for WG 3.11 No No No No
Windows 95 (OSR1 - Win95 Retail + Service Pack 1) Yes Yes Yes Yes
Windows 95 (OSR2/2.1 - adds USB and new IE browser) Yes Yes Yes Yes
Windows 98 Yes Yes Yes Yes
Windows 98 ME No No No No
Windows NT Workstation 3.51 No No No No
Windows NT Workstation 4.0 Service Pack 3 No No No No
Windows NT Workstation 4.0 Service Pack 4 Yes Yes Yes No
Windows NT Workstation 4.0 Service Pack 5 Yes Yes Yes No
Windows NT Workstation 4.0 Service Pack 6a No No No Yes
WIndows 2000 Professional Yes Yes Yes Yes
OS/2 Warp 4.0 No No No No
System Utility (ThinkPad Features / Configuration)
Utility Diskette for DOS,Personalization N/A N/A IRU202US Ver 1.01 KSU204US Ver 1.03
Utility Diskette for Win3.1
Utility Diskette for Win95
Utility Diskette for Win95/98 IRU108US ver 2.07 IRU503US ver 3.02.00 IRU506US ver 3.05 KSU517US Ver 3.16
Utility Driver Disk for Win95
Win95 Supplement File Disk II
Win98 Supplement File Disk II IRO105US ver 1.00 IRO105US ver 1.00 IRO105US ver 1.00 IRO110US ver 1.03
Utility Diskette for Win98 Disk I
Utility Diskette for Win98 Disk II
Utility Diskette for OS/2 Warp
Utility Diskette for WinNT
Utility Data Diskette I
Utility Data Diskette II
Utility Data Diskette II
Utility Data Diskette I for Win95/98
Utility Data Diskette I for Win 98
Utility Data Diskette II for Win 98
Utility Data Diskette III for Win 98
IDE Driver Diskette
OS/2 Warp Install Diskette I
OS/2 Warp Install Diskette II
Personalization Data Update Disk
System Board Intel MMO No (BGA) No (BGA) No (BGA) No (BGA)
System Bus PCI PCI PCI PCI
HDD Interface Enhanced IDE Enhanced IDE Enhanced IDE Enhanced IDE
I/O Port Serial 16550 Compatible 16550 Compatible 16550 Compatible 16550 Compatible
Parallel ECP/EPP ECP/EPP ECP/EPP ECP/EPP
USB Controller Intel 430TX (PIIX4E) Intel 430TX (PIIX4M) Intel 430TX (PIIX4M) Intel 82443MX(Banister
)
BIOS All BIOS are AT-compatible AT Compatible AT Compatible AT Compatible AT Compatible
System BIOS Updates
Model/Sub-model
fixed with FC/01 for all systems
Memory Map
F0000-FFFFF
E0000-EFFFF
D0000-DFFFF
C7FFF-CFFFF Video C8000-CBFFF Video C8000-CBFFF Video C8000-CBFFF Video C8000-CBFFF
C0000-C7FFF Video BIOS Video BIOS Video BIOS Video BIOS
A0000-BFFFF Video RAM Video RAM Video RAM Video RAM
Memory Data Path 64-bit 64-bit 64-bit 64-bit
Voltage 3.3V 3.3V 3.3V 3.3V
Technology SDRAM SDRAM SDRAM SDRAM
Battery Type Li-Ion Li-Ion Li-Ion Li-Ion
Battery Installation Check Utility
LCD 10.4" TFT 800x600 10.4" TFT 800x600 10.4" TFT 800x600 10.4" TFT 800x600

Docking SelectaDock I / II /III Diagnostic Diskette N/A N/A N/A N/A
Graphics Chipset NM2160C NM2160C NM2160C SMI Lynx EM+
VRAM/DRAM 2.0MB 2.0MB 2.0MB 2.0MB
Graphics Data Path 128b 128b 128b 64b
H/W Expansion Yes Yes Yes Yes
DPMS Yes Yes Yes Yes
Video BIOS
LCD Display Modes (See below for VESA display modes.)
VGA 10.4" 10.4" 10.4" 10.4"
Vesa101 60Hz 60Hz 60Hz 60Hz
Vesa111 60Hz 60Hz 60Hz 60Hz
*1 Vesa112 60Hz 60Hz 60Hz 60Hz
Vesa102 60Hz 60Hz 60Hz 60Hz
Vesa103 60Hz 60Hz 60Hz 60Hz
Vesa114 60Hz 60Hz 60Hz 60Hz
*1 Vesa115 60Hz 60Hz 60Hz 60Hz
Vesa104 60Hz 60Hz 60Hz 60Hz
Vesa105 60Hz 60Hz 60Hz 60Hz
Vesa117 60Hz 60Hz 60Hz 60Hz
Vesa118 No No No No
Vesa106 No No No No
Vesa107 No No No No
CRT Display Modes (See below for VESA display modes.)
VGA 60 / 70 Hz 60 / 70 Hz 60 / 70 Hz 60 / 70 Hz
Vesa101 60 / 75 / 85 Hz 60 / 75 / 85 Hz 60 / 75 / 85 Hz 60 / 75 / 85 Hz
Vesa111 60 / 75 / 85 Hz 60 / 75 / 85 Hz 60 / 75 / 85 Hz 60 / 75 / 85 Hz
*1 Vesa112 60 / 75 / 85 Hz 60 / 75 / 85 Hz 60 / 75 / 85 Hz 60 / 75 / 85 Hz
Vesa102 60 / 75 / 85 Hz 60 / 75 / 85 Hz 60 / 75 / 85 Hz 60 / 75 / 85 Hz
Vesa103 60 / 75 / 85 Hz 60 / 75 / 85 Hz 60 / 75 / 85 Hz 60 / 75 / 85 Hz
Vesa114 60 / 75 / 85 Hz 60 / 75 / 85 Hz 60 / 75 / 85 Hz 60 / 75 / 85 Hz
*1 Vesa115 60 / 75 / 85 Hz 60 / 75 / 85 Hz 60 / 75 / 85 Hz 60 / 75 / 85 Hz
Vesa104 60Hz 60Hz 60Hz 60Hz
Vesa105 60 / 70 / 75 Hz 60 / 70 / 75 Hz 60 / 70 / 75 Hz 60 / 75 / 85 Hz
Vesa117 60 / 70 / 75 Hz 60 / 70 / 75 Hz 60 / 70 / 75 Hz 60 / 75 / 85 Hz
Vesa118 No No No No
Vesa106 No No No No
Vesa107 No No No No
*1 Win 3.11 Video Features
*1 Win 95 Video Features
Win 95/98 Video Features IRD104WW ver 6.23.
00
IRD108WW ver 6.25.
00Q
IRD111WW ver. 6.28.
00Q
KSD114WW ver 4.11.01.0062
*1 OS/2 Warp 4.0 Video Features
*1 WinNT3.51 Video Features
*1 WinNT4.0 Video Features IRD203WW ver 3.28Q IRD210WW ver. 3.33.
00Q
IRD210WW ver. 3.33.
00Q
KSD209WW ver 4.00.1381.0089
LCD 640x480 256/64K/16M 640x480 256/64K/16M 640x480 256/64K/16M 640x480 256/64K/16M
800x600 256/64K/16M 800x600 256/64K/16M 800x600 256/64K/16M 800x600 256/64K/16M
CRT 640x480 256/64K/16M 640x480 256/64K/16M 640x480 256/64K/16M 640x480 256/64K/16M
800x600 256/64K/16M 800x600 256/64K/16M 800x600 256/64K/16M 800x600 256/64K/16M
1024x768 256/64K 1024x768 256/64K 1024x768 256/64K 1024x768 256/64K
No High Resolution No High Resolution No High Resolution No High Resolution
PCMCIA IBM PC Card Director utility N/A N/A N/A N/A
Dos/Win
Win95
OS/2
WinNT *3
SystemSoft CardSoft for DOS
CardWizard for Win3.1
CardWorks for Win95
CardWizard for WinNT
Slot
CardBus
ZV Port Enabled
Audio ES1946 ES1946 ES1946 CS4281
Driver DOS/Win3.11
Win95
KSA106WW ver 4.12.5018
Win95/Win98 IRA107US ver 1113 IRA110US ver 4.06.00 IRA110US ver 4.06.00
KSA401WW ver 5.12.5017 (Only W98)

Warp
WinNT IRA303US ver 4.05.18 IRA303US ver 4.05.18 IRA303US ver 4.05.18
KSA207WW ver 4.01.5017
Voyetra AudioStation Disk for Win31
MIDI I/F
Driver DOS/Win
Win95
Warp
WinNT
Wave Table Audio
DOS/Win
Win95
Warp
WinNT
Integrated Modem WS-5614BMDG WS-5614BMDG WS-5614BMDG WS-5614BMDG
Drivers *2 DOS/Win3.11
Win95 IRM102WW ver 5.37
Win95 / 98
Win95 / 98 / NT IRM102US ver 5.37 IRM402WW ver 5.48 IRM402WW ver 5.48 KSM501WW ver 5.62
Warp
WinNT
Speed Up to 56Kbps Up to 56Kbps Up to 56Kbps Up to 56Kbps
VOD
IR Win3.11/95/Warp Driver
HP Mode (115Kbps) Yes Yes Yes Yes
Sharp Mode (9600) No No No No
IBM Mode (1.15Mbps) Yes Yes Yes Yes
4Mbps Yes Yes Yes Yes
WinNT
Infrared Features Disk II
CD-ROM Driver N/A N/A N/A N/A
Dos/Win
Win95
Warp
WinNT
Speed
DVD ROM Driver N/A N/A N/A N/A
DVD-Video Player for Win 95/98
Speed
MPEG 2 Support
Features N/A N/A N/A N/A
DOS
Win3.11
Microsoft Win32s Setup
Win95
Warp
WinNT
MMPM/2 MPEG Update for OS/2
Video CD Player
DOS
Win3.11
Win95
Warp
WinNT
Video Capture Driver
Win95
Win98
WinNT 4.0
DVD Player DOS
Win3.11
Win95
Warp
WinNT
DVD Movie for Win95
DVD Movie Region for Win95
MPEG-1 (Hrdware assisted)
MPEG-2 HHR NTSC
MPEG-2 HHR PAL

MPEG-2 (Full)
Dolby digital audio with AC-3 support
Enhanced Video Driver N/A N/A N/A N/A
DOS
Win3.11
Win95
Warp
WinNT
Overlay
Accelaration
TV Out (NTSC/PAL)
TrackPoint Driver Win95/WinNT
Warp
Win98/ Win95/ WinNT IEG107US ver 1.02 IEG107US ver 1.02 IEG107US ver 1.02 IEG110US ver 2.01.00
Systems Mgmt LANDesk Client Manager Driver N/A N/A N/A N/A
Disk II for OS/2
Win95
WinNT
Disk II for Win95/98/NT
Notes: *1 Applications will recognize video mode as 16M color modes. However, 256K color will show on the
panel due to TFT LCD panel design.
*2 National Language versions available outside US
*3 WinNT provides native support. WinNT 4.0 PC Card Director Version 1.00 available for download
from the Internet.
