IBM ThinkPad 390X Owner's manual

i

Before using this information and the product it supports,
be sure to read the general information under “Read This
First” on page 19.
First Edition (November 1999)
The following paragraph does not apply to the United
Kingdom or any country where such provisions are
inconsistent with local law:
INTERNATIONAL BUSINESS MACHINES CORPO-
RATION PROVIDES THIS PUBLICATION "AS IS"
WITHOUT ANY WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED
TO, THE LIMITED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. Some states do not allow disclaimers or
express or implied warranties in certain transactions; there-
fore, this statement may not apply to you.
This publication could include technical inaccuracies or
typographical errors. Changes are periodically made to the
information herein; these changes will be incorporated in
new editions of the publication. IBM may make improve-
ments or changes in the products or the programs
described in this publication at any time.
It is possible that this publication may contain references
to, or information about, IBM products (machines and pro-
grams), programming, or services that are not announced
in your country. Such references or information must not
be construed to mean that IBM intends to announce such
IBM products, programming, or services in your country.
Requests for technical information about IBM products
should be made to your IBM Authorized Dealer or your
IBM Marketing Representative.
 Copyright International Business Machines Corpo-
ration 1999. All rights reserved. Note to US Government
Users — Documentation related to restricted rights — Use,
duplication, or disclosure is subject to restrictions set forth
in GSA ADP Schedule Contract with IBM Corp.

Contents
ThinkPad 390X / i Series 1700 Hardware
Maintenance Manual . . . . . . . . . . . . . . 1
Introduction . . . . . . . . . . . . . . . . . . . . 2
Important Service Information .......... 2
How to Use Error Messages .......... 3
How to Read POST Error Messages ...... 3
Drive and Diskette Compatibility Matrix ....... 4
Safety Notices (Multi-lingual Translations) ..... 5
Safety Information . . . . . . . . . . . . . . . . 12
General Safety . . . . . . . . . . . . . . . . 12
Electrical Safety . . . . . . . . . . . . . . . . 13
Safety Inspection Guide ............ 14
Handling Electrostatic Discharge-Sensitive Devices 15
Grounding Requirements . . . . . . . . . . . . 16
Laser Compliance Statement ........... 17
Read This First .................. 19
What to Do First ................ 19
How to Disable the Password ......... 20
Service Web site ............... 21
Product Overview . . . . . . . . . . . . . . . . . 22
Fn Key Combinations ............. 23
Status Indicators . . . . . . . . . . . . . . . . 24
Checkout Guide . . . . . . . . . . . . . . . . . 26
Audio Checkout . . . . . . . . . . . . . . . . 27
Diskette Drive Checkout ............ 27
CD-ROM Checkout . . . . . . . . . . . . . . 28
Fan Checkout . . . . . . . . . . . . . . . . . 28
Keyboard and Auxiliary Input Device Checkout . 29
Memory Checkout . . . . . . . . . . . . . . . 30
Modem Board Checkout ............ 31
Power System Checkout ............ 32
TrackPoint Checkout . . . . . . . . . . . . . . 34
Power Management Features ......... 35
Symptom-to-FRU Index . . . . . . . . . . . . . . 38
Numeric Error Codes .............. 39
Error Messages . . . . . . . . . . . . . . . . 41
No Beep Symptoms .............. 41
LCD-Related Symptoms . . . . . . . . . . . . 42
Keyboard-Related Symptoms . . . . . . . . . . 42
Indicator-Related Symptoms . . . . . . . . . . 42
Power-Related Symptoms . . . . . . . . . . . 43
PC Card (PCMCIA)-Related Symptoms ..... 43
Speaker-Related Symptoms . . . . . . . . . . 43
Power Management-Related Symptoms ..... 43
Peripheral-Device-Related Symptom . . . . . . 44
Intermittent Problems . . . . . . . . . . . . . 44
Undetermined Problems . . . . . . . . . . . . 45
CE Utility Program Diskette ............ 46
Setting the LCD Panel ID ........... 46
Setting the Thermal Sensor .......... 46
Contents iii

Writing the RFID Data ............. 47
Flash UUID . . . . . . . . . . . . . . . . . . 47
Running the Diagnostics .............. 48
PC-Doctor DOS System Diagnostics ...... 48
FRU Removals and Replacements ......... 58
FRU Service Procedures ............ 59
Battery . . . . . . . . . . . . . . . . . . . . 61
Hard Disk Drive ................ 62
Combo Bay . . . . . . . . . . . . . . . . . . 63
Diskette Drive . . . . . . . . . . . . . . . . . 64
CD-ROM . . . . . . . . . . . . . . . . . . . 65
Combo Bay FPC ............... 66
Hard Disk Adapter Combo Bay ......... 67
Modem Card . . . . . . . . . . . . . . . . . 68
Backup Battery (RTC) ............. 69
Keyboard . . . . . . . . . . . . . . . . . . . 70
LED Board . . . . . . . . . . . . . . . . . . 72
Upper Heatsink . . . . . . . . . . . . . . . . 73
PCMCIA Slots . . . . . . . . . . . . . . . . . 74
CPU Board . . . . . . . . . . . . . . . . . . 76
LCD Panel . . . . . . . . . . . . . . . . . . 77
Upper Cover . . . . . . . . . . . . . . . . . 79
IMM Lower Heatsink .............. 81
Fan . . . . . . . . . . . . . . . . . . . . . . 82
Speakers . . . . . . . . . . . . . . . . . . . 83
Power Latch, IR Board, and DC-DC & BATT Board 85
System Board . . . . . . . . . . . . . . . . . 86
Combo Bay Interposer Board .......... 87
LCD Bezel 15.0" ................ 88
LCD Inverter 15.0" ............... 89
Microphone 15.0" . . . . . . . . . . . . . . . 90
LCD Panel 15.0" ................ 91
LCD Bezel 14.1" ................ 93
Speaker 14.1" . . . . . . . . . . . . . . . . . 94
VR Board 14.1" ................ 95
Microphone 14.1" . . . . . . . . . . . . . . . 96
LCD Panel 14.1" ................ 97
LCD Inverter 14.1" ............... 98
LCD FPC 14.1" ................ 99
LCD Bezel 12.1" ............... 100
Speaker 12.1" . . . . . . . . . . . . . . . . 101
VR Board 12.1" ............... 102
LCD Inverter 12.1" .............. 103
Microphone 12.1" . . . . . . . . . . . . . . 104
LCD Panel 12.1" ............... 105
LCD FPC 12.1" ............... 106
Switch Location . . . . . . . . . . . . . . . 106
System Unit Parts Listing ............ 107
LCD Unit Parts Listing .............. 112
12.1" LCD Parts Listing ........... 113
14.1" LCD Parts Listing ........... 115
15.0" LCD Parts Listing ........... 117
Service Tools . . . . . . . . . . . . . . . . 118
iv ThinkPad 390X / i 1700 HMM

Notices . . . . . . . . . . . . . . . . . . . . . 119
Trademarks . . . . . . . . . . . . . . . . . . 119
Contents v

vi ThinkPad 390X / i 1700 HMM

ThinkPad 390X / i Series 1700
Hardware Maintenance Manual
About This Manual
This manual contains service and reference information for
the IBM ThinkPad 390X / i Series 1700 products. Use this
manual along with the advanced diagnostics tests to trou-
bleshoot problems effectively.
The manual is divided into sections as follows:
The introduction section provides general information,
guidelines, and safety information required to service
computers.
The product-specific section includes service, refer-
ence, and product-specific parts information.
Important
This manual is intended for trained servicers who are
familiar with ThinkPad products. Use this manual
along with the advanced diagnostic tests to trouble-
shoot problems effectively. Before servicing an IBM
ThinkPad product, be sure to review the safety infor-
mation under “Safety Notices (Multi-lingual
Translations)” on page 5 and “Safety Information” on
page 12.
ThinkPad 390X / i 1700 HMM 1

Introduction
Important Service Information
Important
Diskette fixes are customer installable.
Advise customers to contact the PC Company
HelpCenter at 800-772-2227 if they need assistance in
obtaining or installing any diskette fixes.
Customers in Canada should call IBM HelpPC at
800-565-3344 for assistance or down-load information.
The Canadian BBS phone numbers are:
Montreal 514-938-3022
Toronto 905-316-4255
Vancouver 604-664-6464
Winnipeg 204-934-2735
FRU Replacement Strategy
Before Replacing Parts
Ensure that all diskette fixes are installed prior to
replacing any FRUs listed in this manual.
Use the following strategy to prevent unnecessary FRU
replacement and service expense:
If you are instructed to replace a FRU and that
does not correct the problem, reinstall the original
FRU before you continue.
Some computers have both a processor board and a
system board. If you are instructed to replace either
the processor board or the system board, and the first
board that you replaced does not correct the problem,
reinstall the original board, then replace the other
(processor or system) board.
If an adapter or device consists of more than one
FRU, an error code may be caused by any of the
FRUs. Before replacing the adapter or device,
remove the FRUs, one by one, to see if the symp-
toms change. Replace only the FRU that changed
the symptoms.
Attention
A customized setup configuration (other than default
settings) may exist on the computer you are servicing.
Running Automatic Configuration may alter those set-
tings. Note the current configuration settings (using
the View Configuration option) and verify that the set-
tings are in place when service is complete.
2ThinkPad 390X / i 1700 HMM

Hard Disk Drive Replacement Strategy:
Always try to run a low-level format before replacing a hard
disk drive.
Attention
The drive startup sequence in the computer you are
servicing might have been changed. Be extremely
careful during write operations such as copying,
saving, or formatting. Data or programs can be over-
written if you select an incorrect drive.
How to Use Error Messages
Use the error codes displayed on the screen to diagnose
failures. If more than one error code is displayed, begin
the diagnosis with the first error code. The cause of the
first error code can result in false error codes being dis-
played. If no error code is displayed, see if the error
symptom is listed in the Symptom-to-FRU Index for the
computer you are servicing.
How to Read POST Error Messages
POST error messages are displayed on the screen as
three, four, five, or eight digits. The error messages that
can be displayed as shorter POST messages are high-
lighted in this index. Some digits will represent different
information for SCSI errors versus non-SCSI errors.
The following example shows which digits display the
shorter POST error messages and also defines the SCSI
information in an eight-digit error message.
Shorter POST Messages
┌────┬────┬────┬────┐
│ │ │ │ │
┌────┬────┬────┬────┬────┬────┬────┬────┐
│ ð│ ð│ ð│ ð│ ð│ ð│ ð│ ð│
└────┴────┴────┴────┴────┴────┴────┴────┘
│ │ │ │ │ │ │ │
Reserved ││││││Size (SCSI)
└────┴────┘ │ │ Slot Number (SCSI)
Device Code │ Logical Unit Number (SCSI)
ID (SCSI)
All SCSI devices are set to a different SCSI ID.
Duplicate SCSI ID settings can generate a false error
message. Use the SCSI ID to determine whether the error
message is coming from an internal or an external device.
ThinkPad 390X / i 1700 HMM 3

Drive and Diskette Compatibility Matrix
The following table provides identification information for
3.5-inch drives.
Diskette
Drive Identifying Mark
3.5-Inch - 1.44MB 1.44 on the eject button
3.5-Inch - 2.88MB 2.88 on the eject button
The following table provides compatibility information for
3.5-inch diskettes and 3.5-inch diskette drives.
The following table provides identification information for
5.25-inch diskette drives.
Diskette
Capacity 1.44MB Drive 2.88MB Drive
1.0MB Read/Write Read/Write
2.0MB Read/Write Read/Write
4.0MB Not Compatible Read/Write
Diskette
Drive Identifying Mark
5.25-Inch - 360KB (External) Asterisk on bezel
5.25-Inch - 1.2MB (Internal) 1.2 on the eject button
The following table provides compatibility information for
5.25-inch diskettes and 5.25-inch diskette drives.
Note: A 360KB diskette written to or formatted on a
1.2MB drive can be read reliably only on a 1.2MB
drive.
Diskette
Capacity 360KB Drive 1.2MB Drive
360KB Read/Write Read/Write
1.2MB Not Compatible Read/Write
4ThinkPad 390X / i 1700 HMM
