IBM ThinkPad 770X User manual

Parts Number: 27L3404
ThinkPad 770X
Quick Reference and Service Information
Your Name:
Company Name:
Model Number:
Serial Number:
Company or Reseller Service:
IBM Service Web Site:
IBM Service Number:
Locations
Indicator panel
TrackPoint
Click buttons
Latch
Latch with
UltraBay
indicator
Bay eject levers UltraBay II
PC Card slots
Telephone
jack
External diskette
drive
connector
Parallel
connector
Rear infrared port
Serial connector
Power jack
Power switch
Headphone jack
Battery pack
Microphone/
line-in jack
System-expansion
connector
Universal serial bus
connector
Attaching Options
Function Keys
You want to... You need to...
Swap the device in
the UltraBay II Release the bay eject levers; then a message appears. Make sure the
LED stays green and there is no
beep; then swap the device.
Attach the diskette
drive externally Power off your computer; then attach the external diskette drive.
Note:
Some devices or configurations might not support hot
plugging or unplugging.
If the LED is blinking orange, do not attempt to swap the
device.
Fn+Result
F2 Displays the battery power status indicator or
erases it if it is displayed. (The Fuel-Gauge
program must first be activated.)
F3 Places the computer in standby mode.
F4 Places the computer in suspend mode.
F7 Changes computer display output locations.
Notes: F8 Displays computer output in XGA (full-screen)
mode. If the computer is equipped with a
13.7-inch SXGA display and used in standard
VGA mode, you cannot use this function.
F11 Changes the power mode.
F12 Places the computer in hibernation mode.
Copyright IBM Corp.1998

Getting Service
Always read the “Solving Computer Problems”
chapter of your User's Reference before calling
IBM.
During the warranty period, you can get help and
information from International Warranty Service
(IWS) in your country. Before you call, fill out the
front of this card. Also have:
The exact wording of any error messages
Hardware and software configuration information
A description of the problem
Information and serial numbers of any options
installed on your system
International Warranty Service
Information
This IBM product is eligible for IWS wherever your
machine type is sold by IBM. Your computer must
be registered to receive international service. To reg-
ister, call one of the following IWS offices:
Help through a ThinkPad Web Site
The latest information about ThinkPad
computers:
http://www.ibm.com/thinkpad
Technical support information:
http://www.ibm.com/support
ThinkPad Configuration
Program
You can customize your hardware system settings
with the ThinkPad Configuration program. To start
the ThinkPad Configuration program, click on Start,
move the cursor to Settings, and click on Control
Panel; then double-click on the ThinkPad Config-
uration icon.
For more information, click on the Help button
( ).
Battery Status
You can monitor the battery status with the Fuel-
Gauge program. To start the Fuel-Gauge program,
click on Start and move the cursor to Programs and
ThinkPad; then click on Fuel-Gauge.
If you are using the secondary battery, you can also
see its status with the Fuel-Gauge program.
For Further Information
You can find the following information in your
ThinkPad user's manuals.
User's Reference
Getting familiar with your computer
Extending the features of your computer
Protecting your computer
Solving computer problems
Features and specifications
Online User's Guide
Using your computer outside your home
country
Using audio, modem, and DVD features
Protecting your computer
Using your computer with a battery pack
Using your computer with a PC Card
Getting service
Resolving system resource conflicts
Frequently asked questions
Installing software
Using system management
Using PS2 commands
Handling tips
Southeast Asia, Australia, New Zealand,
and Hong Kong: 61-2-9354-4171
Canada, Latin America, and the U.S.: 1-800-497-7426
Europe, Middle East, and Africa: 44-1475-893638
Japan, Korea, China (except Hong Kong),
and Taiwan: 81-462-73-7598 Note: To start the Online User's Guide, click on
Start and move the cursor to Programs and
ThinkPad 770; then click on ThinkPad 770
User's Guide.
