IBM 72H9623 User manual

These user’s setup instructions cover typical user environments. The on-screen
messages may differ depending on the level of your hardware and software. In some
cases you may need to vary the setup procedures.
For more information, refer to your computer or operating system manuals or consult
your system administrator or dealer.
Ces instructions de configuration d’exploitation s’appliquent aux environnements
d’utilisation types. Les messages affichés à l’écran peuvent varier en fonction du niveau
de votre matériel et de vos logiciels informatiques. Dans certains cas, vous pouvez être
amenés à changer de procédures de configuration.
Pour de plus amples informations à ce sujet, veuillez vous reporter aux manuels de
votre ordinateur et de votre système d’exploitation, ou consultez l’administrateur de
votre système ou votre revendeur.
Diese Einstellungsanweisungen durch den Benutzer gelten für typische
Betriebsumgebungen. Die Bildschirmmeldungen können je nach Art der verwendeten
Hardware und Software auch anders lauten. In einigen Fällen müssen die
Einstellungsschritte unter Umständen abgeändert werden.
Weitere Informationen finden Sie im Computer- oder Betriebssystemhandbuch, oder
wenden Sie sich an Ihren Systemadministrator oder Fachhändler.
En estas instrucciones de configuración se describen entornos de usuarios típicos. Los
mensajes en pantalla, pueden diferir según sea el nivel del hardware y del software. En
algunos casos, necesitará seguir otros procedimientos para la configuración.
Para obtener más información, puede consultar los manuales del ordenador o del
sistema operativo o ponerse en contacto con el administrador del sistema o con el
distribuidor.
Queste istruzioni di configurazione per l’utente coprono gli ambienti operativi comuni. I
messaggi che appaiono sul video possono differire a seconda dell’hardware e del
software utilizzati. In alcuni casi potrebbe essere necessario variare le procedure di
configurazione.
Per ulteriori informazioni, fare riferimento ai manuali del computer o del sistema
operativo, o consultare il proprio amministratore di sistema o il concessionario.
Inside cover

i
DANGER
To avoid electric shock hazard:
• The product is supplied with a grounded plug and power cord which should be used to
connect to the AC supply.
• The power cord should only be used with a properly wired and grounded power outlet.
• Any equipment to which this product is attached must also be connected to a properly wired
and grounded outlet.
• Do not remove the covers.
• The product does not incorporate an AC power switch. To isolate the monitor from the
electrical supply, you must remove the plug from the power outlet. The power outlet should
be easily accessible.
• Do not connect or disconnect this product during an electrical storm.
• Always use the AC adapter supplied with the monitor.
Handing:
• Handle this product with care when moving it.
• The panel should not be operated in a horizontal position.
• The fluorescent lamp used in the Liquid Crystal Display assembly contains a small quantity
of mercury (less than 50 milligrams). For environmental reasons this product should not be
disposed of into landfill. It must be disposed of as required by local ordinances or
regulations.
• The Liquid Crystal Display assembly is made of glass and can break as a result of rough
handling or dropping. This may lead under some circumstances to a small quantity of the
liquid crystal material being exposed. Avoid contact with this material as it is an irritant.
Should this material come into contact with eyes, hands, etc., the area should be washed
with water for at least 15 minutes; medical care should be obtained if any symptoms are
present after washing.
