IBM iDataPlex User manual

Taiwan Systems & Technology Lab
2010/7/29
Installation of nVIDIA M1060
at the Side Bay of Expension Tray
iDataPlex Service Guide

Taiwan Systems and Technology Lab
22010/7/29
Slide M1060 halfway into side bay
Check Points
M1060 extender in the
groove of blue retainer
bracket.
Power cable for M1060 is
not tangled (not yet
connected to M1060).

Taiwan Systems and Technology Lab
32010/7/29
Connect power cable

Taiwan Systems and Technology Lab
42010/7/29
Push the heatsink down and move the card forward until
the gold fingers stop at the slot on the riser card
Check Points
While forwarding the card,
ensure the edge of I/O
bracket meets chassis
bottom. Do not lift M1060
during this step.

Taiwan Systems and Technology Lab
52010/7/29
Push M1060 gently into slot
Check Points
Do not lift M1060 during
this step.
Check if screw holes on
M1060 and chassis aligned.
Or,
EMI shield (blue line) is not
higher than I/O bracket (red
line). More illustrations on
the next page for the
definitions of the lines.

Taiwan Systems and Technology Lab
62010/7/29
Red line: Bottom surface of
I/O bracket.
Blue line: as shown. Same
level as the edge of I/O
aperture.

Taiwan Systems and Technology Lab
72010/7/29
… another picture of correct installation

Taiwan Systems and Technology Lab
82010/7/29
Screw side cover on
