IBM Power System 9009-42A User manual

Power Systems
PCIe adapter placement for the
9009-41A, 9009-42A, or 9223-42H
IBM

Note
Before using this information and the product it supports, read the information in “Safety notices” on
page v, “Notices” on page 17, the IBM Systems Safety Notices manual, G229-9054, and the IBM
Environmental Notices and User Guide, Z125–5823.
This edition applies to IBM® Power Systems servers that contain the POWER9™ processor and to all associated models.
© Copyright International Business Machines Corporation 2018, 2019.
US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract with
IBM Corp.

Contents
Safety notices........................................................................................................v
PCIe adapter placement........................................................................................ 1
PCIe adapter placement rules and slot priorities for the 9009-41A, 9009-42A, and 9223-42H ........... 1
PCIe adapter placement rules and slot priorities for the EMX0 PCIe Gen3 I/O expansion drawer..........8
Related procedures for PCIe adapter placement.....................................................................................15
Finding the current system conguration in IBM i.............................................................................. 15
Notices................................................................................................................17
Accessibility features for IBM Power Systems servers............................................................................ 18
Privacy policy considerations ................................................................................................................... 19
Trademarks................................................................................................................................................ 19
Electronic emission notices.......................................................................................................................19
Class A Notices.....................................................................................................................................20
Class B Notices.....................................................................................................................................23
Terms and conditions................................................................................................................................ 25
iii

iv

Safety notices
Safety notices may be printed throughout this guide:
•DANGER notices call attention to a situation that is potentially lethal or extremely hazardous to people.
•CAUTION notices call attention to a situation that is potentially hazardous to people because of some
existing condition.
•Attention notices call attention to the possibility of damage to a program, device, system, or data.
World Trade safety information
Several countries require the safety information contained in product publications to be presented in their
national languages. If this requirement applies to your country, safety information documentation is
included in the publications package (such as in printed documentation, on DVD, or as part of the product)
shipped with the product. The documentation contains the safety information in your national language
with references to the U.S. English source. Before using a U.S. English publication to install, operate, or
service this product, you must rst become familiar with the related safety information documentation.
You should also refer to the safety information documentation any time you do not clearly understand any
safety information in the U.S. English publications.
Replacement or additional copies of safety information documentation can be obtained by calling the IBM
Hotline at 1-800-300-8751.
German safety information
Das Produkt ist nicht für den Einsatz an Bildschirmarbeitsplätzen im Sinne § 2 der
Bildschirmarbeitsverordnung geeignet.
Laser safety information
IBM servers can use I/O cards or features that are ber-optic based and that utilize lasers or LEDs.
Laser compliance
IBM servers may be installed inside or outside of an IT equipment rack.
DANGER: When working on or around the system, observe the following precautions:
Electrical voltage and current from power, telephone, and communication cables are hazardous.
To avoid a shock hazard:
• If IBM supplied the power cord(s), connect power to this unit only with the IBM provided power
cord. Do not use the IBM provided power cord for any other product.
• Do not open or service any power supply assembly.
• Do not connect or disconnect any cables or perform installation, maintenance, or reconguration
of this product during an electrical storm.
• The product might be equipped with multiple power cords. To remove all hazardous voltages,
disconnect all power cords.
– For AC power, disconnect all power cords from their AC power source.
– For racks with a DC power distribution panel (PDP), disconnect the customer’s DC power
source to the PDP.
• When connecting power to the product ensure all power cables are properly connected.
– For racks with AC power, connect all power cords to a properly wired and grounded electrical
outlet. Ensure that the outlet supplies proper voltage and phase rotation according to the
system rating plate.
© Copyright IBM Corp. 2018, 2019 v

– For racks with a DC power distribution panel (PDP), connect the customer’s DC power source
to the PDP. Ensure that the proper polarity is used when attaching the DC power and DC power
return wiring.
• Connect any equipment that will be attached to this product to properly wired outlets.
• When possible, use one hand only to connect or disconnect signal cables.
• Never turn on any equipment when there is evidence of re, water, or structural damage.
• Do not attempt to switch on power to the machine until all possible unsafe conditions are
corrected.
• Assume that an electrical safety hazard is present. Perform all continuity, grounding, and power
checks specied during the subsystem installation procedures to ensure that the machine meets
safety requirements.
• Do not continue with the inspection if any unsafe conditions are present.
• Before you open the device covers, unless instructed otherwise in the installation and
conguration procedures: Disconnect the attached AC power cords, turn off the applicable
circuit breakers located in the rack power distribution panel (PDP), and disconnect any
telecommunications systems, networks, and modems.
DANGER:
• Connect and disconnect cables as described in the following procedures when installing,
moving, or opening covers on this product or attached devices.
To Disconnect:
1. Turn off everything (unless instructed otherwise).
2. For AC power, remove the power cords from the outlets.
3. For racks with a DC power distribution panel (PDP), turn off the circuit breakers located in the
PDP and remove the power from the Customer's DC power source.
4. Remove the signal cables from the connectors.
5. Remove all cables from the devices.
To Connect:
1. Turn off everything (unless instructed otherwise).
2. Attach all cables to the devices.
3. Attach the signal cables to the connectors.
4. For AC power, attach the power cords to the outlets.
5. For racks with a DC power distribution panel (PDP), restore the power from the Customer's
DC power source and turn on the circuit breakers located in the PDP.
6. Turn on the devices.
Sharp edges, corners and joints may be present in and around the system. Use care when
handling equipment to avoid cuts, scrapes and pinching. (D005)
(R001 part 1 of 2):
DANGER: Observe the following precautions when working on or around your IT rack system:
• Heavy equipment–personal injury or equipment damage might result if mishandled.
• Always lower the leveling pads on the rack cabinet.
• Always install stabilizer brackets on the rack cabinet unless the earthquake option is to be
installed.
• To avoid hazardous conditions due to uneven mechanical loading, always install the heaviest
devices in the bottom of the rack cabinet. Always install servers and optional devices starting
from the bottom of the rack cabinet.
vi Power Systems: PCIe adapter placement for the 9009-41A, 9009-42A, or 9223-42H

• Rack-mounted devices are not to be used as shelves or work spaces. Do not place objects on top
of rack-mounted devices. In addition, do not lean on rack mounted devices and do not use them
to stabilize your body position (for example, when working from a ladder).
• Each rack cabinet might have more than one power cord.
– For AC powered racks, be sure to disconnect all power cords in the rack cabinet when directed
to disconnect power during servicing.
– For racks with a DC power distribution panel (PDP), turn off the circuit breaker that controls
the power to the system unit(s), or disconnect the customer’s DC power source, when
directed to disconnect power during servicing.
• Connect all devices installed in a rack cabinet to power devices installed in the same rack
cabinet. Do not plug a power cord from a device installed in one rack cabinet into a power device
installed in a different rack cabinet.
• An electrical outlet that is not correctly wired could place hazardous voltage on the metal parts
of the system or the devices that attach to the system. It is the responsibility of the customer to
ensure that the outlet is correctly wired and grounded to prevent an electrical shock. (R001 part
1 of 2)
(R001 part 2 of 2):
CAUTION:
• Do not install a unit in a rack where the internal rack ambient temperatures will exceed the
manufacturer's recommended ambient temperature for all your rack-mounted devices.
• Do not install a unit in a rack where the air flow is compromised. Ensure that air flow is not
blocked or reduced on any side, front, or back of a unit used for air flow through the unit.
• Consideration should be given to the connection of the equipment to the supply circuit so that
overloading of the circuits does not compromise the supply wiring or overcurrent protection. To
provide the correct power connection to a rack, refer to the rating labels located on the
equipment in the rack to determine the total power requirement of the supply circuit.
•(For sliding drawers.) Do not pull out or install any drawer or feature if the rack stabilizer
brackets are not attached to the rack or if the rack is not bolted to the floor. Do not pull out more
than one drawer at a time. The rack might become unstable if you pull out more than one drawer
at a time.
•(For xed drawers.) This drawer is a xed drawer and must not be moved for servicing unless
specied by the manufacturer. Attempting to move the drawer partially or completely out of the
rack might cause the rack to become unstable or cause the drawer to fall out of the rack. (R001
part 2 of 2)
CAUTION: Removing components from the upper positions in the rack cabinet improves rack
stability during relocation. Follow these general guidelines whenever you relocate a populated
rack cabinet within a room or building.
• Reduce the weight of the rack cabinet by removing equipment starting at the top of the rack
cabinet. When possible, restore the rack cabinet to the conguration of the rack cabinet as you
received it. If this conguration is not known, you must observe the following precautions:
Safety notices vii

– Remove all devices in the 32U position (compliance ID RACK-001 or 22U (compliance ID
RR001) and above.
– Ensure that the heaviest devices are installed in the bottom of the rack cabinet.
– Ensure that there are little-to-no empty U-levels between devices installed in the rack cabinet
below the 32U (compliance ID RACK-001 or 22U (compliance ID RR001) level, unless the
received conguration specically allowed it.
• If the rack cabinet you are relocating is part of a suite of rack cabinets, detach the rack cabinet
from the suite.
• If the rack cabinet you are relocating was supplied with removable outriggers they must be
reinstalled before the cabinet is relocated.
• Inspect the route that you plan to take to eliminate potential hazards.
• Verify that the route that you choose can support the weight of the loaded rack cabinet. Refer to
the documentation that comes with your rack cabinet for the weight of a loaded rack cabinet.
• Verify that all door openings are at least 760 x 230 mm (30 x 80 in.).
• Ensure that all devices, shelves, drawers, doors, and cables are secure.
• Ensure that the four leveling pads are raised to their highest position.
• Ensure that there is no stabilizer bracket installed on the rack cabinet during movement.
• Do not use a ramp inclined at more than 10 degrees.
• When the rack cabinet is in the new location, complete the following steps:
– Lower the four leveling pads.
– Install stabilizer brackets on the rack cabinet or in an earthquake environment bolt the rack to
the floor.
– If you removed any devices from the rack cabinet, repopulate the rack cabinet from the
lowest position to the highest position.
• If a long-distance relocation is required, restore the rack cabinet to the conguration of the rack
cabinet as you received it. Pack the rack cabinet in the original packaging material, or equivalent.
Also lower the leveling pads to raise the casters off of the pallet and bolt the rack cabinet to the
pallet.
(R002)
(L001)
DANGER: Hazardous voltage, current, or energy levels are present inside any component that has
this label attached. Do not open any cover or barrier that contains this label. (L001)
(L002)
viii Power Systems: PCIe adapter placement for the 9009-41A, 9009-42A, or 9223-42H

DANGER: Rack-mounted devices are not to be used as shelves or work spaces. Do not place
objects on top of rack-mounted devices. In addition, do not lean on rack-mounted devices and do
not use them to stabilize your body position (for example, when working from a ladder). (L002)
(L003)
or
or
or
or
Safety notices ix

DANGER: Multiple power cords. The product might be equipped with multiple AC power cords or
multiple DC power cables. To remove all hazardous voltages, disconnect all power cords and
power cables. (L003)
(L007)
CAUTION: A hot surface nearby. (L007)
(L008)
CAUTION: Hazardous moving parts nearby. (L008)
All lasers are certied in the U.S. to conform to the requirements of DHHS 21 CFR Subchapter J for class 1
laser products. Outside the U.S., they are certied to be in compliance with IEC 60825 as a class 1 laser
product. Consult the label on each part for laser certication numbers and approval information.
CAUTION: This product might contain one or more of the following devices: CD-ROM drive, DVD-
ROM drive, DVD-RAM drive, or laser module, which are Class 1 laser products. Note the following
information:
• Do not remove the covers. Removing the covers of the laser product could result in exposure to
hazardous laser radiation. There are no serviceable parts inside the device.
• Use of the controls or adjustments or performance of procedures other than those specied
herein might result in hazardous radiation exposure.
(C026)
x Power Systems: PCIe adapter placement for the 9009-41A, 9009-42A, or 9223-42H

CAUTION: Data processing environments can contain equipment transmitting on system links
with laser modules that operate at greater than Class 1 power levels. For this reason, never look
into the end of an optical ber cable or open receptacle. Although shining light into one end and
looking into the other end of a disconnected optical ber to verify the continuity of optic bers may
not injure the eye, this procedure is potentially dangerous. Therefore, verifying the continuity of
optical bers by shining light into one end and looking at the other end is not recommended. To
verify continuity of a ber optic cable, use an optical light source and power meter. (C027)
CAUTION: This product contains a Class 1M laser. Do not view directly with optical instruments.
(C028)
CAUTION: Some laser products contain an embedded Class 3A or Class 3B laser diode. Note the
following information:
• Laser radiation when open.
• Do not stare into the beam, do not view directly with optical instruments, and avoid direct
exposure to the beam. (C030)
(C030)
CAUTION: The battery contains lithium. To avoid possible explosion, do not burn or charge the
battery.
Do Not:
• Throw or immerse into water
• Heat to more than 100 degrees C (212 degrees F)
• Repair or disassemble
Exchange only with the IBM-approved part. Recycle or discard the battery as instructed by local
regulations. In the United States, IBM has a process for the collection of this battery. For
information, call 1-800-426-4333. Have the IBM part number for the battery unit available when
you call. (C003)
CAUTION: Regarding IBM provided VENDOR LIFT TOOL:
• Operation of LIFT TOOL by authorized personnel only.
• LIFT TOOL intended for use to assist, lift, install, remove units (load) up into rack elevations. It is
not to be used loaded transporting over major ramps nor as a replacement for such designated
tools like pallet jacks, walkies, fork trucks and such related relocation practices. When this is not
practicable, specially trained persons or services must be used (for instance, riggers or movers).
• Read and completely understand the contents of LIFT TOOL operator's manual before using.
Failure to read, understand, obey safety rules, and follow instructions may result in property
damage and/or personal injury. If there are questions, contact the vendor's service and support.
Local paper manual must remain with machine in provided storage sleeve area. Latest revision
manual available on vendor's web site.
• Test verify stabilizer brake function before each use. Do not over-force moving or rolling the LIFT
TOOL with stabilizer brake engaged.
• Do not raise, lower or slide platform load shelf unless stabilizer (brake pedal jack) is fully
engaged. Keep stabilizer brake engaged when not in use or motion.
• Do not move LIFT TOOL while platform is raised, except for minor positioning.
• Do not exceed rated load capacity. See LOAD CAPACITY CHART regarding maximum loads at
center versus edge of extended platform.
• Only raise load if properly centered on platform. Do not place more than 200 lb (91 kg) on edge
of sliding platform shelf also considering the load's center of mass/gravity (CoG).
• Do not corner load the platforms, tilt riser, angled unit install wedge or other such accessory
options. Secure such platforms -- riser tilt, wedge, etc options to main lift shelf or forks in all four
(4x or all other provisioned mounting) locations with provided hardware only, prior to use. Load
objects are designed to slide on/off smooth platforms without appreciable force, so take care
Safety notices xi

not to push or lean. Keep riser tilt [adjustable angling platform] option flat at all times except for
nal minor angle adjustment when needed.
• Do not stand under overhanging load.
• Do not use on uneven surface, incline or decline (major ramps).
• Do not stack loads.
• Do not operate while under the influence of drugs or alcohol.
• Do not support ladder against LIFT TOOL (unless the specic allowance is provided for one
following qualied procedures for working at elevations with this TOOL).
• Tipping hazard. Do not push or lean against load with raised platform.
• Do not use as a personnel lifting platform or step. No riders.
• Do not stand on any part of lift. Not a step.
• Do not climb on mast.
• Do not operate a damaged or malfunctioning LIFT TOOL machine.
• Crush and pinch point hazard below platform. Only lower load in areas clear of personnel and
obstructions. Keep hands and feet clear during operation.
• No Forks. Never lift or move bare LIFT TOOL MACHINE with pallet truck, jack or fork lift.
• Mast extends higher than platform. Be aware of ceiling height, cable trays, sprinklers, lights, and
other overhead objects.
• Do not leave LIFT TOOL machine unattended with an elevated load.
• Watch and keep hands, ngers, and clothing clear when equipment is in motion.
• Turn Winch with hand power only. If winch handle cannot be cranked easily with one hand, it is
probably over-loaded. Do not continue to turn winch past top or bottom of platform travel.
Excessive unwinding will detach handle and damage cable. Always hold handle when lowering,
unwinding. Always assure self that winch is holding load before releasing winch handle.
• A winch accident could cause serious injury. Not for moving humans. Make certain clicking sound
is heard as the equipment is being raised. Be sure winch is locked in position before releasing
handle. Read instruction page before operating this winch. Never allow winch to unwind freely.
Freewheeling will cause uneven cable wrapping around winch drum, damage cable, and may
cause serious injury.
• This TOOL must be maintained correctly for IBM Service personnel to use it. IBM shall inspect
condition and verify maintenance history before operation. Personnel reserve the right not to use
TOOL if inadequate. (C048)
Power and cabling information for NEBS (Network Equipment-Building System) GR-1089-CORE
The following comments apply to the IBM servers that have been designated as conforming to NEBS
(Network Equipment-Building System) GR-1089-CORE:
The equipment is suitable for installation in the following:
• Network telecommunications facilities
• Locations where the NEC (National Electrical Code) applies
The intrabuilding ports of this equipment are suitable for connection to intrabuilding or unexposed wiring
or cabling only. The intrabuilding ports of this equipment must not be metallically connected to the
interfaces that connect to the OSP (outside plant) or its wiring. These interfaces are designed for use as
intrabuilding interfaces only (Type 2 or Type 4 ports as described in GR-1089-CORE) and require isolation
from the exposed OSP cabling. The addition of primary protectors is not sufcient protection to connect
these interfaces metallically to OSP wiring.
Note: All Ethernet cables must be shielded and grounded at both ends.
The ac-powered system does not require the use of an external surge protection device (SPD).
xii Power Systems: PCIe adapter placement for the 9009-41A, 9009-42A, or 9223-42H

The dc-powered system employs an isolated DC return (DC-I) design. The DC battery return terminal shall
not be connected to the chassis or frame ground.
The dc-powered system is intended to be installed in a common bonding network (CBN) as described in
GR-1089-CORE.
Safety notices xiii

xiv Power Systems: PCIe adapter placement for the 9009-41A, 9009-42A, or 9223-42H

PCIe adapter placement for the 9009-41A,
9009-42A, or 9223-42H
Find information about the placement rules and slot priorities of Peripheral Component Interconnect
Express (PCIe) adapters.
The following features are electromagnetic compatibility (EMC) Class B features. See the Class B Notices
in the Hardware Notices section.
Table 1. Electromagnetic compatibility (EMC) Class B features
Feature Description
5748 POWER® GXT145 PCI Express Graphics Accelerator
5785 4-port Async EIA-232 PCIe Adapter
EN0W PCIe2 2-port 10 GbE BaseT RJ45 Adapter
PCIe adapter placement rules and slot priorities for the 9009-41A,
9009-42A, and 9223-42H
Find information about the placement rules and slot priorities for the Peripheral Component Interconnect
Express (PCIe) adapters that are supported for the 9009-41A, 9009-42A, and 9223-42H systems.
PCIe slot descriptions for the 9009-41A, 9009-42A, and 9223-42H
The 9009-41A, 9009-42A, and 9223-42H systems provide PCIe3 and PCIe4 slots. Table 2 on page 1
provides information about the PCIe slots in the 9009-41A, 9009-42A, and 9223-42H systems. The
9009-41A system offers one POWER9 processor module. The 9009-42A and 9223-42H systems offer
two POWER9 processor modules. The PCIe slots are enabled to support the PCIe3 cable adapter (FC
EJ08 or EJ20) that is used to attach the EMX0 PCIe Gen3 I/O expansion drawer.
Table 2. PCIe slot locations and descriptions for the 9009-41A, 9009-42A, and 9223-42H systems
Slot availability Description Adapter size
9009-41A
(one processor)
9009-42A and
9223-42H
(one processor)
9009-42A and
9223-42H
(two processors)
Two slots (P1-C6,
P1-C12)
Two slots (P1-C6,
P1-C12)
Two slots (P1-C6,
P1-C12)
PCIe3 x8 with x16
connector
Full-height, half-
length
Four slots (P1-C5,
P1-C7, P1-C10, P1-
C11)
Four slots (P1-C5,
P1-C7, P1-C10, P1-
C11)
Four slots (P1-C5,
P1-C7, P1-C10, P1-
C11)
PCIe3 x8 Full-height, half-
length
One slot (P1-C9) One slot (P1-C9) Three slots (P1-C3®,
P1-C4, P1-C9)
PCIe4 x16 Full-height, half-
length
One slot (P1-C8) One slot (P1-C8) Two slots (P1-C2,
P1-C8)
PCIe4 x8 with x16
connector
Full-height, half-
length
© Copyright IBM Corp. 2018, 2019 1

Two PCIe3 switches in the system backplane provide PCIe3 buses from the system processor modules
that provide connectivity to the following features:
Note: PCIe3 switch 1 and switch 2 provide PCIe buses from processor module SCM0.
• PCIe slots
• PCIe local area network (LAN) controller
• PCIe3 internal SAS controller
The two PCIe3 switches are as follows:
Table 3 on page 2 lists the features provided by the PCIe3 switches.
Table 3. PCIe3 switches in the system.
Features provided Switch 1 and switch 2
Lanes and ports 48-lane, 12-ports, PCIe3
With integrated 8.0 gigatransfers per second (GT/s)
Serializer/Deserializer (SerDes) speed negotiation for
each port
Lane and polarity reversal Supported
All ports support concurrent maintenance through I2C
bus.
Yes
End-to-end cyclic redundancy check (CRC) and poison
bit error checking
Supported
Data path parity Supported
Memory error correction Supported
Advanced error reporting Supported
Aggregate full duplex bandwidth 768 GT/s
Designate any port as the upstream port Yes
27x27 mm, 676-pin FCBGA package Yes
Power consumption • Nominal: 8 watts
• Maximum: 12 watts
Notes:
• Up to three adapters can be in SR-IOV shared mode.
• Of the three adapters in SR-IOV shared mode, a maximum of two adapters can be either FC EC2S or EC2U.
Figure 1 on page 3 shows the rear view of the system with the location codes for the PCIe adapter
slots.
Table 4 on page 3 lists the PCIe adapter slot locations and details for the 9009-41A, 9009-42A, and
9223-42H systems.
2 Power Systems: PCIe adapter placement for the 9009-41A, 9009-42A, or 9223-42H

Figure 1. Rear view of a rack-mounted 9009-41A, 9009-42A, or 9223-42H system with PCIe slots location
codes
Table 4. PCIe slot locations and descriptions for system
Location
code
Description Processor
module
Adapter
size
Slot capabilities Slot availability
CAPI SR-IOV 32-bit
dynamic
direct
memory
access
(DMA) GB
I/O adapter
enlarged
capacity
enablemen
t order5
(9009-41A)
I/O adapter
enlarged
capacity
enablemen
t order
5(9009-42
A and
9223-42H)
9009-41A,
9009-42A,
and
9223-42H
(one
processor)
9009-42A
and
9223-42H
(two
processors)
P1-C21, 3 PCIe4 x8 or
NVLink slot
Processor
module
SCM1
Full-height,
half-length
No Yes 2 N/A 5 No Yes
P1-C31PCIe4 x16 Processor
module
SCM1
Full-height,
half-length
Yes Yes 2 N/A 2 No Yes
P1-C41PCIe4 x16 Processor
module
SCM1
Full-height,
half-length
Yes Yes 2 N/A 3 No Yes
P1-C54PCIe3 x8 PCIe3
switch,
S2P16
Full-height,
half-length
No Yes 2 5 8 Yes Yes
P1-C62, 4 PCIe3 x8
with x16
connector
PCIe3
switch,
S1P8
Full-height,
half-length
No Yes 2 3 6 Yes Yes
P1-C74PCIe3 x8 PCIe3
switch,
S2P17
Full-height,
half-length
No Yes 2 7 10 Yes Yes
PCIe adapter placement for the 9009-41A, 9009-42A, or 9223-42H 3

Table 4. PCIe slot locations and descriptions for system (continued)
Location
code
Description Processor
module
Adapter
size
Slot capabilities Slot availability
CAPI SR-IOV 32-bit
dynamic
direct
memory
access
(DMA) GB
I/O adapter
enlarged
capacity
enablemen
t order5
(9009-41A)
I/O adapter
enlarged
capacity
enablemen
t order
5(9009-42
A and
9223-42H)
9009-41A,
9009-42A,
and
9223-42H
(one
processor)
9009-42A
and
9223-42H
(two
processors)
P1-C81, 3 PCIe4 x8 Processor
module
SCM0
Full-height,
half-length
Yes Yes 2 2 4 Yes Yes
P1-C91PCIe4 x16 Processor
module
SCM0
Full-height,
half-length
Yes Yes 2 1 1 Yes Yes
P1-C104PCIe3 x8 PCIe3
switch,
S2P16
Full-height,
half-length
No Yes 2 6 9 Yes Yes
P1-C114PCIe3 x8
(default
LAN slot)
PCIe3
switch,
S2P17
Full-height,
half-length
No Yes 2 8 11 Yes Yes
P1-C122, 4 PCIe3 x8
with x16
connector
PCIe3
switch,
S1P8
Full-height,
half-length
No Yes 2 4 7 Yes Yes
1High-performance slot that is directly connected to the processor module. The connectors in these slots are differently colored than the slots from the PCIe3
switches.
2Slots P1-C6 and P1-C12 have Gen3 x16 connectors, but will only function as Gen3 x8.
3Slots P1-C2 and P1-C8 have Gen4 x16 connectors, but will only function as Gen4 x8.
4Slot connected by PCIe3 switches.
5Enabling the I/O adapter enlarged capacity option will only affect Linux partitions. If your system doesn’t have Linux partitions, the I/O Adapter Enlarged
Capacity setting should be disabled.
Notes:
• The peak bandwidths supported by the x16 slots are 32 gigabytes per second (GBps) in simplex mode and 64 GBps in duplex mode.
• The peak bandwidths supported by P1-C5, P1-C6, P1-C7, P1-C10, P1-C11, and P1-C12 x8 slots are 8 GBps in simplex mode and 16 GBps in duplex mode.
• The peak bandwidths supported by P1-C2 and P1-C8 x8 slots are 16 GBps in simplex mode and 32 GBps in duplex mode.
• All slots support enhanced error handling (EEH).
• All PCIe slots are hot swappable and support concurrent maintenance.
Firmware slot capabilities
System PCIe slots are allocated direct memory access (DMA) space using the following algorithm:
• All slots are allocated a 2 GB default DMA window.
• All I/O adapter slots (except the embedded USB) are allocated Dynamic DMA Window (DDW) capability
based on installed platform memory. DDW capability is calculated assuming 4 K I/O mappings:
– For systems with less than 64 GB of memory, slots are allocated 16 GB of DDW capability.
– For systems with at least 64 GB of memory, but less than 128 GB of memory, slots are allocated 32
GB of DDW capability.
– For systems with 128 GB or more of memory, slots are allocated 64 GB of DDW capability.
– Slots can be enabled with Huge Dynamic DMA Window capability (HDDW) using the I/O Adapter
Enlarged Capacity setting in the Advanced System Management Interface (ASMI).
– HDDW enabled slots are allocated enough DDW capability to map all of installed platform memory
using 64 K I/O mappings.
– Minimum DMA window size for HDDW enabled slots is 32 GB.
– Slots that are HDDW enabled are allocated the larger of the calculated DDW capability and HDDW
capability.
4 Power Systems: PCIe adapter placement for the 9009-41A, 9009-42A, or 9223-42H

PCIe adapter placement rules
Use this information while selecting slots for installing PCIe adapters in the 9009-41A, 9009-42A, and
9223-42H. Use Table 5 on page 5 to identify slot placement priorities in the system and the maximum
number of adapters that can be installed in the system.
1. The slot P1-C11 must be used to install the local area network (LAN) adapter feature codes (FCs). Any
other PCIe adapter feature isn’t supported in this slot.
2. The PCIe3 cable adapter for the PCIe3 EMX0 expansion drawer (FC EJ08 or EJ20) is supported in P1-
C9 for the 9009-41A, 9009-42A, and 9223-42H single processor systems. It is supported in P1-C9,
P1-C3, and P1-C4 in the 9009-42A and 9223-42H double processor systems.
3. CAPI accelerator adapters are supported in slots P1-C3, P1-C4, P1-C8, and P1-C9.
4. Slots P1-C2 and P1-C8 are x8 slots with busses direct from the processor modules and can be used to
install high-performance PCIe adapters. The adapter priority for this slot is for the high-performance
adapters followed by any other adapter.
5. Slots P1-C3, P1-C4, and P1-C9 are slots with x16 busses direct from the processor modules and can
be used to install high-performance PCIe adapters. The adapter priority for these slots is for CAPI
accelerator adapters, PCI accelerator adapters, high-performance adapters, followed by any other
adapter.
6. PCIe internal slots are used to install high-performance internal SAS RAID adapters.
7. There’s no Fibre Channel over Ethernet (FCoE) support for FC EN0H, EN0K, FC EN0M, FC EL56, and FC
EL57.
8. Conguring an SR-IOV adapter into SR-IOV shared mode may require more hypervisor memory. If
sufcient hypervisor memory isn't available, the request to move to SR-IOV shared mode will fail. The
user will be instructed to free up extra memory and try the operation again.
Verify whether the adapter is supported for your system. The feature code (FC) column in the table below
lists all of the supported adapters for these systems. You can select the FC for more details. To view all
the POWER9 processor-based systems and EMX0 PCIe3 expansion drawer that a specic adapter is
supported on, see PCI adapter information by feature type for the 9008-22L, 9009-22A, 9009-41A,
9009-42A, 9040-MR9, 9080-M9S, 9223-22H, 9223-42H system and the EMX0 PCIe3 expansion
drawer (http://www.ibm.com/support/knowledgecenter/POWER9/p9hcd/p9hcd_pcibyfeature.htm).
The 9009-42A and 9223-42H systems can have one or two system processor modules. The PCIe slot
conguration in the 9009-42A and 9223-42H systems with a single processor module is the same as in
the 9009-41A system.
Note: In the following table, the slot priority numbers 2 - 12 correspond to slot locations P1-C2 through
P1-C12.
Table 5. PCIe adapter slot priorities and maximum adapters supported in the 9009-41A, 9009-42A, or 9223-42H
Feature
code
Description 9009-41A, 9009-42A, or 9223-42H
(one processor)
9009-42A or 9223-42H
(two processors)
Slot priorities Maximum number
of adapters
supported
Slot priorities Maximum number
of adapters
supported
2893 or
2894
PCIe 2-line WAN with modem (FC 2893, 2894,
EN13, EN14; CCIN 576C); Part number:
44V5323
8, 9 2 8, 2, 9, 4, 3 5
5729 PCIe2 FH 4-port 8 Gb Fibre Channel adapter
(FC 5729; CCIN 5729); Adapter part number:
74Y3467
8, 9, 5, 10, 6, 12, 7 7 8, 2, 4, 9, 3, 5, 10,
6, 12, 7
10
5735 8 Gb PCI Express dual-port Fibre Channel
adapter (FC 5273, 5735, EL2N, and EL58);
CCIN 577D); Adapter part number: 10N9824
8, 9, 5, 10, 6, 12, 7 7 8, 2, 4, 9, 3, 5, 10,
6, 12, 7
10
5748 POWER GXT145 PCI Express Graphics
Accelerator (FC 5748; CCIN 5269); Adapter
part number: 10N7756
10, 7, 8, 9 4 10, 7, 8, 2, 9, 4, 3 7
PCIe adapter placement for the 9009-41A, 9009-42A, or 9223-42H 5

Table 5. PCIe adapter slot priorities and maximum adapters supported in the 9009-41A, 9009-42A, or 9223-42H (continued)
Feature
code
Description 9009-41A, 9009-42A, or 9223-42H
(one processor)
9009-42A or 9223-42H
(two processors)
Slot priorities Maximum number
of adapters
supported
Slot priorities Maximum number
of adapters
supported
5785 4-port Async EIA-232 PCIe 1X adapter (FC
5277 and 5785; CCIN 57D2); Adapter part
number: 46K6734
8, 9 2 8, 2, 9, 4, 3 5
5899 PCIe2 4-port 1 GbE adapter (FC 5260, 5899,
EL4L, and EL4M; CCIN 576F); Adapter part
number: 74Y4064
11, 5, 10, 12, 6, 7,
8, 9
8 11, 5, 10, 12, 6, 7,
8, 2, 9, 4, 3
11
EC2N PCIe3 2-port 10 GbE NIC & RoCE SR adapter
(FC EC2M, EC2N, EL40, and EL54; CCIN 57BE);
Adapter part number: full-height tailstock:
00RX875, low-prole tailstock: 00RX872
11, 5, 10, 12, 6, 7,
8, 9
8 5, 10, 12, 6, 7, 8,
2, 9, 4, 3
10
EC2S PCIe3 2-port 10 Gb NIC & RoCE SR/Cu adapter
(FC EC2R and EC2S; CCIN 58FA); Adapter part
number: 01FT759
5, 10, 12, 6, 7, 8, 9 7 5, 10, 12, 6, 7, 8,
2, 9, 4, 3
10
EC2U PCIe3 2-port 25/10 Gb NIC & RoCE SFP28
adapter (FC EC2U; CCIN 58FB); Adapter FRU
number: 01FT756
8, 9, 5, 10, 6, 12, 7 7 8, 2, 4, 9, 3, 5, 10,
6, 12, 7
10
EC3B PCIe3 2-Port 40 GbE NIC RoCE QSFP+ adapter
(FC EC3A and EC3B; CCIN 57BD); Adapter part
number: 00FW105
8, 9, 5, 10, 6, 12, 7 7 8, 2, 4, 9, 3, 5, 10,
6, 12, 7
10
EC3F PCIe3 2-port 100 Gb EDR InniBand adapter
x16 (FC EC3E and EC3F; CCIN 2CEA); Adapter
part number: 00WT075
9 1 4, 9, 3 3
EC3M PCIe3 2-port 100 GbE NIC & RoCE QSFP28
adapter (FC EC3M; CCIN 2CEC); Adapter FRU
number: 00WT078
9 1 4, 9, 3 3
EC3U PCIe3 1-port 100 Gb EDR InniBand adapter
x16 (FC EC3U; CCIN 2CEB) Adapter part
number: 00WT013
9 1 4, 9, 3 3
EC38 PCIe3 2-port 10 GbE NIC & RoCE SFP+ Copper
adapter (FC EC37, EC38, EL3X, and EL53; CCIN
57BC); Adapter part number: 00RX859
11, 5, 10, 12, 6, 7,
8, 9
8 8, 2, 4, 9, 3, 5, 10,
6, 12, 7
10
EC42 PCIe2 3D Graphics adapter x1 (FC EC42);
Adapter part number: 00E3980
8, 9, 5, 10, 6, 12, 7 7 8, 2, 4, 9, 3, 5, 10,
6, 12, 7
10
EC46 PCIe2 4-port USB 3.0 adapter (FC EC45 and
EC46; CCIN 58F9); Adapter part number:
00E2932
8 1 8, 2, 4, 3 4
EC5B PCIe3 x8 Non-Volatile Memory 1.6 TB SSD
NVMe adapter (FC EC5A and EC5B; CCIN
58FC); Adapter part number: 01DH570
8, 9, 5 3 2, 8, 3, 9, 4 5
EC63 PCIe4 x16 1-Port EDR 100 GB IB ConnectX-5
CAPI Capable adapter (FC EC63; CCIN 2CF1);
Adapter FRU number: 00WT179
9 1 9, 3, 4 3
EC65 PCIe4 x16 2-Port EDR 100 GB IB ConnectX-5
CAPI Capable adapter (FC EC65; CCIN 2CF2)
9 1 9, 3, 4 3
EC66 PCIe4 x16, 2-port 100 GB RoCE En
ConnectX-5 adapter (FC EC66 and EC67; CCIN
2CF3); Adapter part number: 01FT742
9 1 9, 3, 4 3
EJ08 PCIe3 cable adapter for the EMX0 PCIe3
expansion drawer (FC EJ08; CCIN 2CE2);
Adapter part number: 41T9901
9 1 9, 3, 4 3
EJ0J PCIe3 SAS RAID quad-port 6 Gb adapter (FC
EJ0J and EL59); CCIN 57B4); Adapter part
number: 00FX846
8, 9, 5, 10, 6, 12, 7 7 8, 2, 4, 9, 3, 5, 10,
6, 12, 7
10
EJ0L PCIe3 12 GB Cache SAS RAID quad-port 6 Gb
adapter (FC EJ0L; CCIN 57CE); Adapter part
number: 00FX840
8, 9, 5, 10, 6, 12, 7 7 8, 2, 4, 9, 3, 5, 10,
6, 12, 7
10
6 Power Systems: PCIe adapter placement for the 9009-41A, 9009-42A, or 9223-42H
