Part 1: Installation Guide
Product description
The IBM SR9 AGP 4X DVI-I Graphics Adapter uses an S3 Savage 4 graphics
engine to help your monitor provide superior performance with digital video and 3D
graphics. The graphics adapter provides 128-bit graphics processing for 2D graphics
acceleration, 32-bit rendering, and 3D texture compression. Additionally, the graphics
adapter MPEG2/DVD motion compensation feature enhances full-motion video
playback.
The graphics adapter contains Accelerated Graphics Port (or AGP) 4X technology,
which has data transfer rates of more than 1,000MB1 per second, allowing for
enhanced 3D graphics performance. The graphics adapter also supports the DVI-I
interface on both analog and digital monitors.
In addition to this supplement, your option package contains:
graphics adapter
DVI-A 15-way dongle, blue
Installation CD for SR9 AGP 4X DVI-I Adapter with S3 SAVAGE4 Xtreme
Adapter Option User's Guide
Preparing for installation
Before you install a graphics adapter, you must take the following precautions in order
to prevent static electricity from damaging electronic parts.
Before touching any electronic parts, drain the static electricity from your body.
You can do this by touching the metal frame of your computer.
Do not remove the graphics adapter from the antistatic shipping container until
you are ready to install it. When you remove an adapter from your computer,
place it back in its original container.
When handling the graphics adapter, hold it by its edges, and avoid touching its
circuitry.
1MB means approximately 1000000 bytes of data.
Copyright IBM Corp. 1999 1-1

Installing the SR9 AGP 4X DVI-I Graphics
Adapter
To install the SR9 AGP 4X DVI-I Graphics Adapter:
1. Turn off all attached devices; then turn off your computer. Unplug the power
cords of all attached devices and your computer. Remove the cover from your
computer. For instructions on how to remove your computer’s cover, refer to the
documentation that comes with your computer.
For IBM computers, refer to About Installing Options for instructions on opening
the computer cover, removing existing adapter cards, and installing adapter cards
in expansion slots.
2. Remove any previously installed graphics adapter cards. If you have no other
graphics adapter cards, but your computer system board has built-in VGA
graphics capability, make sure the VGA graphics capability is disabled. For
information on disabling the VGA graphics capability on your computer, see the
documentation that comes with your computer.
3. Choose an AGP expansion slot.
Note: Inserting a graphics adapter into the wrong type of slot might damage
your adapter, your computer, or both.
To identify the location of each type of expansion slot in your computer, refer to
the documentation that comes with your computer.
Note: Do not insert the plastic tab next to the connector pins into the expansion
slot.
4. Remove the expansion slot cover for the expansion slot you intend to use. Save
the screw to use with the mounting bracket.
5. Position the graphics adapter over the expansion slot you have chosen. Push the
graphics adapter in firmly and evenly until it is fully seated in the slot.
1-2 User's Guide Supplement

6. Using the screw from the expansion slot cover, secure the mounting bracket of
the graphics adapter to the computer frame.
This graphics adapter comes with a bracket for the ATX-type computer already
attached. To attach the bracket for an NLX-type computer to the graphics
adapter, follow the diagram below.
7. Replace the cover on your computer.
8. If you have a standard analog monitor, attach the included blue dongle to the
monitor connector on the graphics adapter; then plug your monitor cable into the
dongle. If you have a digital or analog monitor with DVI-I connectors, plug your
monitor cable directly into the blue connector on the graphics adapter. Plug the
other end of the monitor cable into your monitor.
Refer to the documentation that comes with your monitor to make sure that the
monitor is properly set up.
9. Plug the cables for any other attached devices into your computer. Plug the
power cables for the computer, monitor, and other attached devices into a power
outlet; then turn on your computer and all attached devices.
Part 1: Installation Guide 1-3

Installing the software
This section has instructions for installing the software and device drivers for the SR9
AGP 4X DVI-I Graphics Adapter. Instructions are for installing the software with
Microsoft Windows 95, Microsoft Windows 98 or Microsoft Windows NT
Workstation 4.0. Refer to the section for the operating system that you use.
Installing the software for Windows 95
Windows 95 automatically detects the graphics adapter when it is installed, but you
must also install the device drivers and utility software. To do so, follow these
instructions.
1. After you install the graphics adapter and restart your computer, Windows 95
automatically detects the graphics adapter. If appropriate display drivers have not
been previously installed, Windows 95 reports finding a PCI adapter (even if you
have an AGP card). When the New Hardware Wizard opens, click Next.
2. When prompted to choose device drivers, click to check the box next to Driver
from disk provided by hardware manufacturer.
Note: The installation messages might vary depending on which version of
Windows 95 is installed on your computer. If the message you see is different
than the one in these instructions, choose the message which is closest in meaning
to the one used here.
3. Locate the installation CD included with this option. Insert the CD into your
CD-ROM or DVD-ROM drive.
4. Click Browse and locate the Win95 directory on the installation CD. If prompted
for a specific file, select SR9.INF.
5. Follow the instructions on your screen to complete the installation; then restart
your computer if it does not do so automatically.
Installing the software for Windows 98
Windows 98 automatically detects the graphics adapter when it is installed, but you
must also install the device drivers and utility software. To do so, follow these
instructions.
1. After you install the graphics adapter and restart your computer, Windows 95
automatically detects the graphics adapter. When the New Hardware Wizard
opens, click Next.
2. On the next window, click to check the box next to Search for the best
driver for your device; then click Next.
3. Locate the installation CD included with this option. Insert the CD into your
CD-ROM or DVD-ROM drive.
4. Choose CD-ROM and then click Next.
5. Enable the Specify a Location option; then click the Browse button and locate
the Win98 directory on the installation CD.
1-4 User's Guide Supplement

6. The Add New Hardware Wizard detects the device driver. Click Next.
7. Follow the instructions on your screen to complete the installation; then restart
your computer if it does not do so automatically.
Installing the software for Windows NT Workstation
Follow these instructions to install the device drivers and utility software for Windows
NT Workstation.
1. After installing the graphics adapter, start up your computer in VGA mode.
During the start up process, Windows NT Workstation will prompt you to choose
between VGA mode and normal mode; select VGA mode.
2. Log in as a user who is able to change system settings.
3. A warning message might appear which says Invalid display settings...;
click OK to continue.
4. With the right mouse button, click on the desktop; then click Properties.
5. Click the Settings tab; then click Display Type....
6. The Display Type window opens. In the Adapter Type section, click Change....
7. Locate the installation CD included with this option. Insert the CD into your
CD-ROM or DVD-ROM drive.
8. Click Have Disk...; then click Browse and locate the WinNT40 directory on the
installation CD.
9. Click to select the SR9.INF file; then click Open.
10. Follow the instructions on your screen to complete the installation. When
prompted to do so, restart your computer.
11. When your computer restarts, you will see a warning message which says
Invalid display settings: A new display driver has been installed.
The default resolution is being used by the system. Click OK and
select a new resolution setting.
12. Test the new resolution setting before accepting it. If your monitor displays a
blank or distorted screen, your monitor does not support the resolution setting you
chose; select a different setting.
Note: If you accidently accept a resolution setting not supported by your
monitor, you must restart your computer in VGA mode and select a
different setting.
Part 1: Installation Guide 1-5

Utility software setup and adjustment
The graphics adapter software that you installed includes the Number Nine Hawkeye
utility. To open Hawkeye, double-click the Number Nine icon on the taskbar. The
Hawkeye Properties Control Panel opens. The property sheets are listed below, along
with a description of the settings or information available on each sheet.
Information
This sheet contains information about the manufacturer of the Hawkeye utility,
Number Nine Visual Technology. The information includes the mailing address and
Web site address for the company.
Monitor adjustment
On this sheet you can adjust the refresh rate setting for your monitor. Select the new
refresh rate setting from the drop-down list.
Status
This sheet lists the software version you have, as well as listing hardware
configuration information for your graphics adapter.
Resolution exchange
On this property sheet you can change the settings for your monitor resolution, the
resolution for your virtual workspace, and change the number of colors displayed on
your monitor screen.
Change your monitor resolution setting in the Monitor section of this property sheet.
In the list of available resolution settings, click the setting you want. Once you choose
a new setting and click OK, the monitor screen will blank out for a few seconds, then
return at the new resolution setting.
Change the number of colors displayed on your monitor screen in the Colors section
of this property sheet. Click to check the circle next to the color setting you want.
Restart Windows to enable the new color setting.
Note: The number of available monitor resolutions may change depending on how
many colors you want to have displayed on your monitor screen.
Change your virtual resolution setting in the Virtual section of this property sheet.
Expanded virtual resolutions can increase the size of your Windows desktop. Display
the expanded desktop area by moving your mouse cursor past the border of the area
displayed on your monitor. This is also called panning to another section of the
expanded desktop area. In the list of available resolution settings, click the setting you
want. Once you choose a new setting and click OK, the monitor screen will blank out
for a few seconds, then return at the new resolution setting.
1-6 User's Guide Supplement

Note: The number of available virtual resolution settings depends on the amount of
memory on your graphics adapter and the active monitor resolution.
Click Apply to save your changes and continue. Click OK to save your changes and
close Hawkeye. Click Cancel to discard your changes and close Hawkeye.
Chameleon Cursor
On this property sheet you can adjust the color and size settings for your mouse
cursor. There are three slider bars the Color section of this property sheet. To change
the color of your cursor, click on each of the slider bars and move the slider up or
down until you have the color adjusted the way you want it. In the Cursor size
section of this property sheet, click on the size you want. Click Apply to save your
changes and continue. Click OK to save your changes and close Hawkeye. Click
Cancel to discard your changes and close Hawkeye.
Color perfect
On this property sheet you can adjust the appearance of colors on your monitor screen.
To change the appearance of the colors, click the slider bars next to each color and
move it up or down until the color appearance is the way you want it. Click Apply to
save your changes and continue. Click OK to save your changes and close Hawkeye.
Click Cancel to discard your changes and close Hawkeye.
Part 1: Installation Guide 1-7

Installation Guide (Translate)
Product description
The IBM SR9 AGP 4X DVI-I Graphics Adapter uses an S3 Savage 4 graphics
engine to help your monitor provide superior performance with digital video and 3D
graphics. The graphics adapter provides 128-bit graphics processing for 2D graphics
acceleration, 32-bit rendering, and 3D texture compression. Additionally, the graphics
adapter MPEG2/DVD motion compensation feature enhances full-motion video
playback.
The graphics adapter contains Accelerated Graphics Port (or AGP) 4X technology,
which has data transfer rates of more than 1,000MB1 per second, allowing for
enhanced 3D graphics performance. The graphics adapter also supports the DVI-I
interface on both analog and digital monitors.
In addition to this supplement, your option package contains:
graphics adapter
DVI-A 15-way dongle, blue
Installation CD for SR9 AGP 4X DVI-I Adapter with S3 SAVAGE4 Xtreme
Adapter Option User's Guide
Preparing for installation
Before you install a graphics accelerator adapter, you must take the following
precautions in order to prevent static electricity from damaging electronic parts.
Before touching any electronic parts, drain the static electricity from your body.
You can do this by touching the metal frame of your computer.
Do not remove the graphics adapter from the antistatic shipping container until
you are ready to install it. When you remove the graphics adapter from your
computer, place it back in its container.
When handling the graphics adapter, hold it by its edges, and avoid touching its
circuitry.
1-8 User's Guide Supplement

Installing the SR9 AGP 4X DVI-I Graphics
Adapter
To install the SR9 AGP 4X DVI-I Graphics Adapter:
1. Turn off all attached devices; then turn off your computer. Unplug the power
cords of all attached devices and your computer. Remove the cover from your
computer. For instructions on how to remove your computer’s cover, refer to the
documentation that comes with your computer.
For IBM computers, refer to About Installing Options for instructions on opening
the computer cover, removing existing adapter cards, and installing adapter cards
in expansion slots.
2. Remove any previously installed graphics adapter cards. If you have no other
graphics adapter cards, but your computer system board has built-in VGA
graphics capability, make sure the VGA graphics capability is disabled. For
information on disabling the VGA graphics capability on your computer, see the
documentation that comes with your computer.
3. Choose an AGP expansion slot.
Note: Inserting a graphics adapter into the wrong type of slot might damage
your adapter, your computer, or both.
To identify the location of each type of expansion slot in your computer, refer to
the documentation that comes with your computer.
Note: Do not insert the plastic tab next to the connector pins into the expansion
slot.
4. Remove the expansion slot cover for the expansion slot you intend to use. Save
the screw to use with the mounting bracket.
5. Position the graphics adapter over the expansion slot you have chosen. Push the
graphics adapter in firmly and evenly until it is fully seated in the slot.
Part 1: Installation Guide 1-9

6. Using the screw from the expansion slot cover, secure the mounting bracket of
the graphics adapter to the computer frame.
This graphics adapter comes with a bracket for the ATX-type computer already
attached. To attach the bracket for an NLX-type computer to the graphics
adapter, follow the diagram below.
7. Replace the cover on your computer.
8. If you have a standard analog monitor, attach the included blue dongle to the
monitor connector on the graphics adapter; then plug your monitor cable into the
dongle. If you have a digital or analog monitor with DVI-I connectors, plug your
monitor cable directly into the blue connector on the graphics adapter. Plug the
other end of the monitor cable into your monitor.
Refer to the documentation that comes with your monitor to make sure that the
monitor is properly set up.
9. Plug the cables for any other attached devices into your computer. Plug the
power cables for the computer, monitor, and other attached devices into a power
outlet; then turn on your computer and all attached devices.
1-10 User's Guide Supplement

Installing the software
This section has instructions for installing the software and device drivers for the SR9
AGP 4X DVI-I Graphics Adapter. Instructions are for installing the software with
Microsoft Windows 95, Microsoft Windows 98 or Microsoft Windows NT
Workstation 4.0. Refer to the section for the operating system that you use.
Installing the software for Windows 95
Windows 95 automatically detects the graphics adapter when it is installed, but you
must also install the device drivers and utility software. To do so, follow these
instructions.
1. After you install the graphics adapter and restart your computer, Windows 95
automatically detects the graphics adapter. If appropriate display drivers have not
been previously installed, Windows 95 reports finding a PCI adapter (even if you
have an AGP card). When the New Hardware Wizard opens, click Next.
2. When prompted to choose device drivers, click to check the box next to Driver
from disk provided by hardware manufacturer.
Note: The installation messages might vary depending on which version of
Windows 95 is installed on your computer. If the message you see is different
than the one in these instructions, choose the message which is closest in meaning
to the one used here.
3. Locate the installation CD included with this option. Insert the CD into your
CD-ROM or DVD-ROM drive.
4. Click Browse and locate the Win95 directory on the installation CD. If prompted
for a specific file, select SR9.INF.
5. Follow the instructions on your screen to complete the installation; then restart
your computer if it does not do so automatically.
Installing the software for Windows 98
Windows 98 automatically detects the graphics adapter when it is installed, but you
must also install the device drivers and utility software. To do so, follow these
instructions.
1. After you install the graphics adapter and restart your computer, Windows 95
automatically detects the graphics adapter. When the New Hardware Wizard
opens, click Next.
2. On the next window, click to check the box next to Search for the best
driver for your device; then click Next.
3. Locate the installation CD included with this option. Insert the CD into your
CD-ROM or DVD-ROM drive.
4. Choose CD-ROM and then click Next.
5. Enable the Specify a Location option; then click the Browse button and locate
the Win98 directory on the installation CD.
Part 1: Installation Guide 1-11

6. The Add New Hardware Wizard detects the device driver. Click Next.
7. Follow the instructions on your screen to complete the installation; then restart
your computer if it does not do so automatically.
Installing the software for Windows NT Workstation
Follow these instructions to install the device drivers and utility software for Windows
NT Workstation.
1. After installing the graphics adapter, start up your computer in VGA mode.
During the start up process, Windows NT Workstation will prompt you to choose
between VGA mode and normal mode; select VGA mode.
2. Log in as a user who is able to change system settings.
3. A warning message might appear which says Invalid display settings...;
click OK to continue.
4. With the right mouse button, click on the desktop; then click Properties.
5. Click the Settings tab; then click Display Type....
6. The Display Type window opens. In the Adapter Type section, click Change....
7. Locate the installation CD included with this option. Insert the CD into your
CD-ROM or DVD-ROM drive.
8. Click Have Disk...; then click Browse and locate the WinNT40 directory on
the installation CD.
9. Click to select the SR9.INF file; then click Open.
10. Follow the instructions on your screen to complete the installation. When
prompted to do so, restart your computer.
11. When your computer restarts, you will see a warning message which says
Invalid display settings: A new display driver has been
installed. The default resolution is being used by the
system. Click OK and select a new resolution setting.
12. Test the new resolution setting before accepting it. If your monitor
displays a blank or distorted screen, your monitor does not support the
resolution setting you chose; select a different setting.
Note: If you accidently accept a resolution setting not supported by your
monitor, you must restart your computer in VGA mode and select
a different setting.
1-12 User's Guide Supplement

Utility software setup and adjustment
The graphics adapter software that you installed includes the Number Nine
Hawkeye utility. To open Hawkeye, double-click the Number Nine icon on
the taskbar. The Hawkeye Properties Control Panel opens. The property
sheets are listed below, along with a description of the settings or information
available on each sheet.
Information
This sheet contains information about the manufacturer of the Hawkeye
utility, Number Nine Visual Technology. The information includes the
mailing address and Web site address for the company.
Monitor adjustment
On this sheet you can adjust the refresh rate setting for your monitor. Select
the new refresh rate setting from the drop-down list.
Status
This sheet lists the software version you have, as well as listing hardware
configuration information for your graphics adapter.
Resolution exchange
On this property sheet you can change the settings for your monitor
resolution, the resolution for your virtual workspace, and change the number
of colors displayed on your monitor screen.
Change your monitor resolution setting in the Monitor section of this
property sheet. In the list of available resolution settings, click the setting you
want. Once you choose a new setting and click OK, the monitor screen will
blank out for a few seconds, then return at the new resolution setting.
Change the number of colors displayed on your monitor screen in the Colors
section of this property sheet. Click to check the circle next to the color
setting you want. Restart Windows to enable the new color setting.
Note: The number of available monitor resolutions may change depending
on how many colors you want to have displayed on your monitor
screen.
Part 1: Installation Guide 1-13

Change your virtual resolution setting in the Virtual section of this property
sheet. Expanded virtual resolutions can increase the size of your Windows
desktop. Display the expanded desktop area by moving your mouse cursor
past the border of the area displayed on your monitor. This is also called
panning to another section of the expanded desktop area. In the list of
available resolution settings, click the setting you want. Once you choose a
new setting and click OK, the monitor screen will blank out for a few
seconds, then return at the new resolution setting.
Note: The number of available virtual resolution settings depends on the
amount of memory on your graphics adapter and the active monitor
resolution.
Click Apply to save your changes and continue. Click OK to save your
changes and close Hawkeye. Click Cancel to discard your changes and close
Hawkeye.
Chameleon Cursor
On this property sheet you can adjust the color and size settings for your
mouse cursor. There are three slider bars the Color section of this property
sheet. To change the color of your cursor, click on each of the slider bars
and move the slider up or down until you have the color adjusted the way you
want it. In the Cursor size section of this property sheet, click on the size
you want. Click Apply to save your changes and continue. Click OK to
save your changes and close Hawkeye. Click Cancel to discard your changes
and close Hawkeye.
Color perfect
On this property sheet you can adjust the appearance of colors on your
monitor screen. To change the appearance of the colors, click the slider bars
next to each color and move it up or down until the color appearance is the
way you want it. Click Apply to save your changes and continue. Click OK
to save your changes and close Hawkeye. Click Cancel to discard your
changes and close Hawkeye.
1-14 User's Guide Supplement
