IBT IB700 User manual

IB700
Full-Size Socket 370 CPU Card
With Optional VGA/LAN/SCSI
USER’S MANUAL
Version 1.0 B

ii IB700 User’s Manual
Acknowledgments
Award is a registered trademark of Award Software International,
Inc.
PS/2 is a trademark of International Business Machines
Corporation.
Intel and Celeron are registered trademarks of Intel Corporation.
Microsoft Windows is a registered trademark of Microsoft
Corporation.
Winbond is a registered trademark of Winbond Electronics
Corporation.
All other product names or trademarks are properties of their
respective owners.

IB700 User’s Manual iii
Table of Contents
Introduction.....................................................................1
Product Description ........................................................1
Checklist........................................................................2
Specifications .................................................................3
Board Dimensions...........................................................4
Installations......................................................................5
Installing the CPU...........................................................6
MicroPCI Daughter Card Installation...............................6
Installing the Memory (DIMM)........................................7
Setting the Jumpers.........................................................8
Connectors on IB700 ....................................................14
Watchdog Timer Configuration......................................28

iv IB700 User’s Manual
This page was intentionally left blank.

INTRODUCTION
IB700 User’s Manual 1
Introduction
Product Description
IB700 is a high-performance flexible CPU card that comes with two built-
in MicroPCI Sockets that supports MicroPCI daughter cards with VGA,
VGA/LAN, Ethernet (LAN), and SCSI functions. It is based on the Intel
440BX AGPset and features a Socket 370 architecture that supports Intel
Celeron andCoppermineprocessorsusing 66MHzand100MHz frontside
bus respectively.
System memory is provided by three DIMM sockets that accommodate
up to 768MB SDRAM. The Award BIOS facilitates easy system
configuration and peripheral setup. Other advanced features include
DiskOnChipflashdisk support,watchdog timer,USB andIrDAinterface.
DiskOnChip flashdisksarestoragedevicesthathasnomovingpartsand
emulates FDD/HDD with Flash/RAM/ROM offering reliable
data/programstorage and longlife span.Theyare reliableand suitable for
industrial or other harsh environments characterized by motion, shock,
vibration, adverse temperature, dust and humidity. Other features include
faster data access, longer MTBF, lower power consumption, cost
effective for small capacity and small form factor.
The IB700 CPU card is designed with all components placed on a single
side, thus, offering stable performance in a harsh industrial environment.

INTRODUCTION
2IB700 User’s Manual
Checklist
Your IB700 package should include the items listed below.
• The IB700 Industrial CPU Card
• This User’s Manual
• 1 IDE Ribbon Cable
• 1 Floppy Ribbon Connector
• 2 Serial Port Ribbon Cable and 1 Parallel Port Attached to a
Mounting Bracket
• 1 CD containing the following:
• Intel PCI IDE Driver and Flash Memory Utility
• CHIPS C&T 69000 VGA Drivers
• Ethernet Drivers
• Initio Inic1060 Ultra2 SCSI Drivers

INTRODUCTION
IB700 User’s Manual 3
Specifications
Processor
Supported
Socket 370 support Intel Celeron / Coppermine,
300MHz~850MHz, 66MHz/100MHz Bus Speed
Chipset Intel 440BX AGPset
BIOS Award BIOS
Supports ACPI, DMI, PnP
System Memory 3x DIMM sockets support up to 768MB capacity
ECC supported
Multi I/O Chipset Winbond W83977TF (keyboard controller is built-in)
I/O Features 1x FDD (up to 2.88MB, 3 Mode, LS120)
1x Parallel Port (EPP, ECP Port)
2x Serial Ports (1x RS232 and 1x RS232/422/485)
1x IrDA TX/RX Headers
Bus Master IDE 2x IDE interfaces for up to 4 devices; supports PIO Mode 3/4
or Ultra DMA/33 IDE HDD, and ATAPI CD-ROM
VGA (option) Using IBD69 MicroPCI VGA card or IBD99 MicroPCI
VGA/LAN Combo card that features:
CHIPS 69000 PCI VGA accelerator
CRT & LCD panel support
2MB integrated memory
Ethernet (option) Using IBD59 MicroPCI LAN card or IBD99 MicroPCI
VGA/LAN Combo card that features:
Intel 82559 Fast Ethernet controller
10/100Mbps data transfer speeds
WakeOnLAN support
SCSI (option) Using IBD60 MicroPCI LAN SCSI card featuring:
Initio Inic1060 Ultra 2 SCSI controller
Built-in Ultra2 SCSI connector
Hardware
Monitoring
Winbond W83781D IC
Monitors CPU/system temperature and voltages
SSD Interface Support M-Systems 2MB~144MB DiskOnChip flash disk
Other Features Watchdog timer, ISA high drive, PICMG compliance
Form Factor Full Size
Dimensions 338mm x 122mm (13.3”x 4.8”)
Power
Requirements
+5V : 12A (max)
+/-12V : 200mA (max)

INTRODUCTION
4IB700 User’s Manual
Board Dimensions

INSTALLATIONS
IB700 User’s Manual 5
Installations
This section provides information on how to use the jumpers and
connectors on the IB700 in order to set up a workable system. The topics
covered are:
Installing the CPU...........................................................6
MicroPCI Daughter Card Installation...............................6
Installing the Memory (DIMM)........................................7
Setting the Jumpers.........................................................8
Connectors on IB700 ....................................................14
Watchdog Timer Configuration......................................28

INSTALLATIONS
6IB700 User’s Manual
Installing the CPU
The IB700 CPU card supports a Socket 370 processor socket for Intel
Celeron/Coppermine processors.
The Socket 370 processor socket comes with a lever to secure the
processor.Raisethislevertoabouta90°angletoallowtheinsertionofthe
processor. Place the processor into the socket by making sure the notch
on the corner of the CPU corresponds with the notch on the inside of the
socket. Once the processor has slide into the socket, return the lever to
the lock position. After you have installed the processor into the socket,
check if the jumpers for the CPU type and speed are correct.
NOTE:Ensure that the CPU heat sink and the CPU top surface are in
total contact to avoid CPU overheating problem that would
cause your system to hang or be unstable.
MicroPCI Daughter Card Installation
The IB700 CPU card is integrated with twoMicroPCI sockets that use
SO-DIMM 144-pin connectors. These sockets can accommodate the
VGA, Ethernet or SCSI MicroPCI daughter cards.
To insert a MicroPCI daughter card, position it at about 30°(Figure 1)
to the PCB and gently push it into the MicroPCI socket. Once inserted,
slowly press the card towards the PCB until it locks on both sides to the
clips of the connector (Figure 2). Screw the card to the PCB to secure the
installation.
Figure 2.
Figure 1.
Figure 1. Figure 2.

INSTALLATIONS
IB700 User’s Manual 7
Installing the Memory (DIMM)
The IB700 CPU Card supports three 168-pin DIMM socket for a maximum
total memory of 768MB in SDRAM type. The memory module capacities
supported are 32MB, 64MB, 128MB and 256MB.
Installing and RemovingDIMMs
Toinstall the DIMM, locatethe memory sloton the CPU cardand perform
the following steps:
1. Hold the DIMM so that the two keys of the DIMM align with those on
the memory slot.
2. Gently push the DIMM in an upright position until the clips of the slot
close to hold the DIMM in place when the DIMM touches the bottom
of the slot.
3. To remove the DIMM, press the clips with both hands.
Top View of DIMM Socket
DIMM Lock
Lock
Lock Lock

INSTALLATIONS
8IB700 User’s Manual
Setting the Jumpers
Jumpers are used on IB700 to select various settings and features
according to your needs and applications. Contact your supplier if you
have doubts about the best configuration for your needs. The following
lists the connectors on IB700 and their respective functions.
Jumper Locations on IB700......................................................................9
DSW1 (3): CPU Bus Speed Selector.....................................................10
DSW1 (5-8): CPU Frequency Selector..................................................10
JP3: Onboard LAN Enable/Disable (IBD99)........................................11
JP4: Onboard C&T VGA Enable/Disable (IBD99)..............................11
JP5: Watchdog Selection.......................................................................11
JP6: DiskOnChip Address Select..........................................................11
JP8: Clear CMOS Content......................................................................12
JP9: External Battery Connector............................................................12
JP10, JP11, JP12: RS232/422/485 (COM2) Selection...........................12
JP2: LCD Power Setting (IBD99/69)......................................................13
The following conventions are used in this section:
off off on on
↓↓↑↑
Pin 1-2
Short/Closed

INSTALLATIONS
IB700 User’s Manual 9
Jumper Locations on IB700
DISK ON CHIP
DSW1 (3): CPU Bus Speed Selector
DSW1 (5-8): CPU Frequency Selector
JP10, JP11, JP12: RS232/422/485
(COM2) Selection
JP9: External Battery Connector
JP8: Clear CMOS Content
JP5: Watchdog Selection
JP6: DiskOnChip Address Select

INSTALLATIONS
10 IB700 User’s Manual
DSW1 (3): CPU Bus Speed Selector
Bus Speed SW1 (3) Switch
Setting
100MHz off
66MHz on
DSW1 (5-8): CPU Frequency Selector
The table below shows the correct setting to match the CPU frequency.
Frequency
Multiplier
CPU
Frequency
(66MHz)
CPU
Frequency
(100MHz) SW1(5-8)
4.5X 300MHz 450MHz
xx xx xx xx off on off on
5X 333MHz 500MHz
xx xx xx xx off off on on
5.5X 366MHz 550MHz
xx xx xx xx off off off on
6X 400MHz 600MHz
xx xx xx xx on on on off
6.5X 433MHz 650MHz
xx xx xx xx on on off off
7X 466MHz 700MHz
xx xx xx xx on off on off
7.5X 500MHz 750MHz
xx xx xx xx on off off off
8X 533MHz 800MHz
xx xx xx xx off on on off
*IB700 BIOS can detect 850MHz CPU and no switch setting is required.

INSTALLATIONS
IB700 User’s Manual 11
JP3: Onboard LAN Enable/Disable (IBD99)
JP3 Setting LAN Function
Pin 1-2
Short/Closed Enabled
Pin 2-3
Short/Closed Disabled
JP4: Onboard C&T VGA Enable/Disable (IBD99)
JP4 Setting VGA Function
Pin 1-2
Short/Closed Enabled
Pin 2-3
Short/Closed Disabled
JP5: Watchdog Selection
JP5 Setting Function
Pin 1-2
Short/Closed Reset
Pin 2-3
Short/Closed NMI
JP6: DiskOnChip Address Select
JP6 Address
D0000-D7FFF
D8000-DFFFF (default)

INSTALLATIONS
12 IB700 User’s Manual
JP8: Clear CMOS Content
JP8 Setting Function
Pin 1-2
Short/Closed Normal Operation
Pin 2-3
Short/Closed Clear CMOS Content
JP9: External Battery Connector
This 4-pin connector allows the user to connect an external battery to
maintain the information stored in the CMOS RAM in case the built-in
battery malfunctions.
Pin # Signal Name
1Vcc
2N.C.
3Battery GND
4Ground
JP10, JP11, JP12 : RS232/422/485 (COM2) Selection
COM1 is fixed for RS-232 use only.
COM2 is selectable for RS232, RS-422 and RS-485.
The following table describes the jumper settings for COM2 selection.
COM2
Function RS-232 RS-422 RS-485
Jumper
Setting
(pin closed)
JP10:
1-2
JP11:
3-5 & 4-6
JP12:
3-5 & 4-6
JP10:
3-4
JP11:
1-3 & 2-4
JP12:
1-3 & 2-4
JP10:
5-6
JP11:
1-3 & 2-4
JP12:
1-3 & 2-4

INSTALLATIONS
IB700 User’s Manual 13
JP2: LCD Power Setting (IBD99/69)
The IBD99/69 C&T 69000 VGA MicroPCI daughter card supports 5V and
3.3V power. Use JP2 to select the power setting.
3.3V Setting 5V Setting

INSTALLATIONS
14 IB700 User’s Manual
[
Connectors on IB700
The connectors on IB700 allows you to connect external devices such as
keyboard,floppy diskdrives, harddiskdrives,printers,etc. Thefollowing
table lists the connectors on IB700 and their respective functions.
Connector Locations on IB700..............................................................15
J1: System Function Connector............................................................16
J2: External Keyboard Connector..........................................................18
J3: CPU Fan Power Connector...............................................................18
J4, J5: EIDE Connectors..........................................................................19
JP4: IrDA Connector...............................................................................20
J6, J7: USB Connectors...........................................................................20
JP7: Wake On LAN Connector..............................................................20
J8: System Fan Power Connector..........................................................20
J9: Floppy Drive Connector...................................................................21
J10: External ATX Power Connector....................................................21
J11: P8 AT Power Connector.................................................................22
J12: Parallel Port Connector...................................................................22
J13, J14: COM1, COM2 Serial Port........................................................23
J15: PS/2 Keyboard Connector..............................................................23
J16: PS/2 Mouse Connector...................................................................23
J17: PS/2 Mouse External Connector....................................................24
J18: VGA CRT Connector.......................................................................24
J19: RJ45 Connector................................................................................24
J20, J21: MicroPCI Connectors..............................................................24
J1: LCD Panel Connector (IBD69).........................................................25
Flat Panel Display Interface Pin Descriptions.....................................26
JP1: WakeOnLAN Connector (IBD59).................................................26
J1: Ultra2 SCSI Connector (IBD60).......................................................27

INSTALLATIONS
IB700 User’s Manual 15
Connector Locations on IB700
J9: Floppy Drive Connector
JP7: Wake On LAN Connector
J11: P8 AT Power Connector
J12: Parallel Port Connector
J13: COM1 Serial Port Connector
J14: COM2 Serial Port Connector
JP4: IrDA Connector
J4, J5: EIDE Connector
J8: System Fan Power Connector
J10: External ATX Power Connector
J21: MicroPCI Connector
DISK ON CHIP
J19: RJ45 Connector
J15: PS/2 Keyboard Connector
J17: PS/2 Mouse External Connector
J16: PS/2 Mouse Connector
J18: VGA CRT Connector
J1: System Function Connector
J2: External Keyboard Connector
J3: CPU Fan Power Connector
J20: MicroPCI Connector
J6, J7: USB Connectors

INSTALLATIONS
16 IB700 User’s Manual
J1: System Function Connector
J1 provides connectors for system indicators that provides light
indicationofthecomputer activitiesandswitchesto changethecomputer
status. J1 is a 20-pin header that provides interfaces for the following
functions.
Hard Disk Drive LED Reset Switch
Turbo LED Connector ATX Power On Switch
SMI / Hardware Switch
Power LED andKeylock
Speaker
Speaker: Pins 1 - 4
This connector provides an interface to a speaker for audio
tone generation. An 8-ohm speaker is recommended.
Pin # Signal Name
1Speaker out
2No connect
3Ground
4+5V
Power LED and Keylock: Pins 11 - 15
The power LED indicates the status of the main power
switch. The keylock switch, when closed, will disable the
keyboard function.
Pin # Signal Name
11 Power LED
12 No connect
13 Ground
14 Keylock
15 Ground
