MFI0800/0806/0805 - Flake Ice Maker
®
Rev: A-01/09
Part: 7011
MFI0800/0806/0805 Flake Ice Maker
MFI0800/0806/0805 - Flake Ice Maker
MFI0800 on B55
Features
•Only 21" (533 mm) wide.
•Produces up to 810 lbs (368 kg) of ice perday.
• Load Monitoring System constantly checks workload on gearbox — shutting
down system before a problem develops and preventing costly repairs.
•Water sensor eliminates low or no water failures and cannot
be affected by adverse water conditions.
•Rugged stainless steel evaporator and auger ensures reliability.
•Industrial-grade roller bearings and heavy duty gearbox
provide years of trouble free service.
Options & Accessories
Water Filters
Ice Machine
Model
Manifold Inline
System Replacement System
MFI0800 IFQ1 IOMQ (1) IFI4C / IFI8C
Ice Maker Warranty
Every Ice-O-Matic ice maker is backed by a warranty that provides
both parts and laborcoverage.
Parts & Labor
•Three years Parts and Labor.
•Five years Parts coverage on the compressor.
Ice Form
FLAKED ICE
Bin Chart
Kits for Combining Wider Bins with Smaller Models
Ice Storage Bins
ModelNo.
Capacity
Width
B25
255lbs(116kg)
30in(762mm).
B40
365lbs(165kg)
30in(762mm)
B42
374lbs(170kg)
22in(559mm)
B55
556lbs(252kg)
30in(762mm)
B100
927lbs(420kg)
48in(1219mm)
B120
1193lbs(541kg)
48in(1219mm)
B150
1499lbs(679kg)
60in(1524mm)
B170
1866lbs(846kg)
60in(1524mm)
Kits
MFI0800 KBT8 KBT8 KBT14 KBT8 KBT7 KBT41* KBT61* KBT61*
MFI0800 (2) N/A N/A N/A N/A KBT22 KBT22 N/A N/A
*MFI Flakers are available internationally only.
*See Ice-O-Matic Price List for Adapter Kits to combine ice makers with most available ice/beverage dispensers.
ISO 9001 Certied
MFI0800/0806/0805 Flake Ice Maker

11100 E. 45th Avenue
Denver, CO 80239
Phone: 1. 866. PURE. ICE
Fax: [phone]
www.iceomatic.com
®
Rev: A-01/09
Part: 7011
MFI0800/0806/0805 Flake Ice Maker
MFI0800/0806/0805 Flake Ice Maker
Air Cooled
Please note: air-cooled units require 6" (152 mm) clearance
for air intake and exhaust. Please note: air-cooled units
require 6" (152 mm) clearance for air intake and exhaust.
A. Ice maker potable water in, ⁄" Male Flare.
B. Drain, ¾" FPT.
C. Hole for electricalconnection.
D. Condenser drain (water cooled only)
½" FPT.
E. Condenser inlet (water cooled only)
⁄" FPT
Air-Out
Back
21"
(533 mm)
24"
(610 mm)
27" (686 mm)
Air
In-Front
27"
(686 mm)
18.80"
(478 mm)
9.43"
(240 mm)
21.66"
(550 mm)
20.84"
(529 mm)
5.25"
(133 mm)
3.00"
(76 mm)
12.43"
(316 mm)
15.53"
(394 mm)
17.80"
(452 mm) A. C.
B.
D. E.
Air/Water Cooled
Operating Requirements
Minimum Maximum
60 Hz
AmbientTemp. Range Air 50˚F (10˚C) 100˚F (38˚C)
WaterTemp. 40˚F (4.4˚C) 80˚F (26.7˚C)
Water Pressure 20 PSIG (1.4 BAR) 60 PSIG (4.1 BAR)
Dimensions
All Models
W x D x H (inches) 21 x 24 x 27
W x D x H (mm) 533 x 610 x 686
Specifications
Model Number Cond. Unit
Ice Production
per 24hrs
Water Usage
gallons per 100 lbs of Ice
90°F air/70°F water kWH Used
per 100 lbs
of ice @
90°F air/
70°F water
Voltage
Characteristics
Min.
Circuit
Ampacity
Fuse
Size
Approx.
BTUs
per hour
70°F air/
50°F water
lbs (kg)
90°F air/
70°F water
lbs (kg)
Potable Condenser
MFI0800AS Air 760 (342) 595 (270) 12.0 - 4.9 115/60/1 19.5 30 7,400
MFI0805AS Air 760 (342) 595 (270) 12.0 - 4.1 230/50/1 10.1 15 7,400
MFI0806AS Air 760 (342) 520 (236) 12.0 - 4.9 208-230/60/1 10.2 15 5,600
MFI0806WS Water 810 (368) 585 (265) 12.0 82.3 3.8 208-230/60/1 10.2 15 4,400
NOTES:
Number of Wires: 3 (including ground)
Approx. Shipping Weight lbs (kg): MFI0800AS205(93) • MFI0805AS205(93) • MFI0806205(93)
Refrigerant Type: R404A
