Iceking CF300W User manual

CF300W

Introduction
Thank you for choosing this appliance. It has been
designed to give years of trouble-free use provided it is installed and
maintained correctly.
Please read these instructions carefully before installing or using your
appliance. It is advisable to keep your purchase and installation receipts
with these instructions in a safe place for future reference. Included is
some important safety information in addition to guidelines and
recommendations that will enable you to take full advantage of all the
functions available.
This quality appliance has been tested and certified to meet all applicable
UK electrical and safety standards.
This appliance must be installed and connected in accordance with
Current regulations by a qualified electrician.
After unpacking the appliance ensure that there is no visible damage.
If the appliance has been damaged during transit, do not use it, contact your
retailer immediately.
Registered Office Address:
Iceking.
The Courtyard,
Harris Business Park,
Hanbury Road
Stoke Prior,
Bromsgrove,
B60 4DJ
Email: [email protected]
Web: ice-king.co.uk
Tel: [phone]

Your 2 year Manufacturer's guarantee
THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.
Your new Iceking appliance carries a free guarantee which protects you against
the cost of repairs during the first 24 months from date of purchase provided
that:
Any claim is accompanied by evidence of the model reference, model serial
number and proof of purchase, such as a Sales Receipt, showing that the
appliance was purchased within the 24 months prior to the date of claim.
What is not covered under the Guarantee:
 Any appliance not correctly installed and operated in accordance with
the manufacturer's instructions.
 Any appliance that is used for anything other than domestic purposes.
 Any defect caused by accident, misuse, unauthorized modification or
inexpert repair.
 Cost of Call-out where a fault cannot be found with the appliance.
 Cost of Call-out for work covering routine maintenance, such as, but not
exclusively, cleaning of filters or defrosting.
 Cost of Call-out for work required to correct the alignment of doors
following door reversal procedures carried out by you.
 Use of the appliance by anyone other than the Householder.
 Use in any commercial environment.
 Consumable items, such as, but not exclusively, fuses in plugs, bulbs and
breakable items which require routine replacement.
 Repair costs incurred that have not been authorised by Repairtech
and/or carried out by a non-approved Repairtech engineer.
YOUR GUARANTEE IS VALID ONLY IN THE UK.
To Register your Appliance simply complete the card in your appliance pack and return it
with a stamp affixed or Alternatively you can Register online at www.repairtechuk.com
SERVICE HELP-LINE
Should your appliance develop a fault, please call the
Repairtech Service Helpline on:
01527-888133
Please remember to have all your product details available, including the model number,
serial number, date of purchase and your retailer’s details before registering a fault. Your
service call cannot progress without this information.

NAMES OF THE PARTS
WARNING: Never touch the interior of the Freezer Chamber or frozen foods in the
compartment with wet hands as this could result in frost bite.
KEEP THE KEY OUT OF REACH OF CHILDREN AND NOT IN THE VICINITY OF THE FREEZER.
Diagram of Circuit Principles
CF300/CF400:

TRANSPORTATION INSTRUCTIONS
The appliance should be transported only in a vertical upright position. The packing as
supplied must be intact during transportation.
If during the course of transport the product has been transported horizontally, it must
only be laid on its left hand side (when facing the door front) and it must not be operated
for at least 4 hours to allow the system to settle after the appliance is brought back to
upright position.
1. Failure to comply with the above instructions could result in damage occuring to the
appliance. The manufacturer will not be held responsible if these instructions are
disregarded.
2. The appliance must be protected against rain, moisture and other atmospheric
influences.
IMPORTANT: Care must be taken while cleaning / carrying the appliance to avoid
touching the condenser metal wires at the back of the appliance, as you might injure your
fingers and hands or damage your product.
IMPORTANT: This appliance is not designed for stacking with any other appliance. Do
not attempt to sit or stand on top of your appliance as it is not designed for such use. You
could injure yourself or damage the appliance.
IMPORTANT: Make sure that mains cable is not caught under the appliance during and
after carrying / moving the appliance, to avoid the mains cable becoming cut or
damaged.”
When positioning your appliance take care not to damage your flooring, pipes, wall
coverings etc. Do not move the appliance by pulling by the lid or handle. Do not allow
children to play with the appliance or tamper with the controls. Our company declines to
accept any liability should the instructions not be followed.
INSTALLATION INSTRUCTIONS
1. If possible avoid placing the appliance near cookers, radiators or in direct sunlight as
this will cause the compressor to run for long periods. If installed next to a source of
heat or refrigerator, maintain the following minimum side clearances:
From Cookers 4" (100 mm)
From Radiators 12" (300 mm)
From Fridges 4" (100 mm)
2. Make sure that sufficient room is provided around the appliance to ensure free air
circulation. Ideally, A space of no less than 10cm must be left around the freezer, and
ensure you allow gaps as shown in the below diagram.

3. The appliance should be located on a smooth surface.
4. It is forbidden to use the refrigerator outdoors.
5. Protection from moisture. Do not locate the freezer in moist space to avoid the metal
parts rusty. And do not spray water to the freezer, otherwise it will weaken the
insulation and causes current leakage.
6. Refer to "Cleaning and Care" section to prepare your appliance for use.
7. If the freezer is installed in unheated areas, garages etc., in cold weather
condensation may form on the outer surfaces. This is quite normal and is not a fault.
Remove the condensation by wiping with a dry cloth.
STARTING
Final Check
Before you starting to use the freezer, please check that:
1. The interior is dry and air can circulate freely at the rear.
2. Clean the interior as recommended under "CLEANING AND CARE".
3. Insert the plug into the wall socket and switch on the electricity supply，then the
Red light is on. Avoid accidental disconnection by taping over the switch. Green
light will glow and the compressor will start running (see Freezer Operation page
7).
4. You will hear a noise as the compressor starts up. The liquid and gases sealed
within the refrigeration system may also give rise to noise, whether the
compressor is running or not which is quite normal.
5. If you going to store already frozen food open the freezer lid and check that the
freezer has reached the correct temperature. Then you can put in your already
frozen food. (See Storing Frozen Food page 8).
6. Do not load the appliance immediately after it is switched on. Wait until the correct
storage temperature has been reached. We recommend that you check the
temperature with an accurate thermometer (see Freezer Operation page 7).

Important Notes:
• If there is a power failure do not open the lid. Frozen food should not be affected if
the failure lasts for less than 20 hours. If the failure is longer, then the food should be
checked and eaten immediately or cooked and then refrozen.
• If you find that the lid of the chest freezer is difficult to open just after you have
closed it, don’t worry. This is due to the pressure difference which will equalize and
allow the lid to be opened normally after a few minutes.
FREEZER OPERATION
Temperature adjustment
The temperature of the freezer is adjusted by means of the knob assembled on the
thermostat. ”1、2、3、4、5” do not represent a specific temperature. The smaller the No.
the higher the temperature, whereas. So, position “5” is being the lowest temperature.
Figures mean:
“OFF”：Forced Shutdown Point
1—5：Frozen Interval （from -12 ℃ to -30 ℃）
The achieved temperatures can vary according to the conditions of use of the appliance,
such as: place of the appliance, ambient temperature, and frequency of lid opening,
extent of filling with food of the freezer. The position of the thermostat knob will change
according to these factors. Normally, for an ambient temperature of approx. 25℃, the
thermostat should be adjusted to the mild position.
We recommended that you check the temperature with a thermometer to ensure that the
Freezer is kept to the desired temperature. Remember you must take your reading very
quickly since the thermometer temperature will rise very rapidly after you remove it from
the freezer.
Please remember each time the lid is opened cold air escapes and the internal
temperature rises. Therefore never leave the lid open and ensure it is closed:
immediately after Food is put in or removed.

Indicator lights
The indicator light set is placed on the front side of the freezer for easy visibility.
Indicator lights mean the following:
Green - Indicate the freezer is plugged.
Red - Indicate high temperature inside cabinet.
STORING FROZEN FOOD
Prepackaged commercially frozen food should be stored in accordance with the frozen
food manufacturer’s instructions for a freezer compartment.
To ensure that the high quality achieved by the frozen food manufacturer and the food
retailer is maintained the following should be remembered:
1．Put packets in the freezer as quickly as possible after purchase.
2．Do not exceed “Use By”, “Best Before” dates on the packaging.
FREEZING FRESH FOOD
Place fresh food to be frozen near the side walls to ensure fast freezing and away from
already frozen food, if possible.
Freezing capacity of your appliance in a 24 hours period is 5 kg (10lb).
Never exceed this maximum capacity. Do not freeze too large a quantity at any one time.
The quality of the food is best preserved when it is frozen right through to the centre as
quickly as possible.
Take special care not to mix already frozen food and fresh food.
DEFROSTING
Defrost twice a year or when a frost layer of around 7 mm (1/4”) has formed.
Alternatively you may switch off the freezer at the socket outlet and pull out the mains
plug.
Extract the water conduit and put in a water container.
6 hours before the defrosting, please set the thermostat knob at “MAX” position to make
sure the food is at the lowest temperature when you get it out. All food should be
wrapped in several layers of newspaper and stored in a cool place (e.g. fridge or larder).
Remove the freezer basket. Leave the lid open. Containers of warm water may be placed
carefully in the freezer to speed up the defrosting.
Never use hairdryers, electrical heaters or other such electrical appliances for defrosting.
When defrosting has finished flow out defrost water which collects at the bottom of the
freezer as the below diagram and dry the interior thoroughly. Switch on the Fast Freeze
and leave it on for about three hours.

1. There is a water conduit at the bottom of the freezer, when defrosting, extract the
rubber cover, defrosted water will drip into the hole and flow out. (NOTES: PLEASE
KEEP THE RUBBER COVER WELL DURING THE DEFROSTING AND PUT IT
BACK AFTER DEFROSTING IS DONE )
2. Extract the water conduit by 20-25mm until the water hole can be seen.
3. Twist the water conduit until the arrow points downward.
4. After defrosting is done, make sure there is no more water coming out before out the
water conduit in place and make the arrow point upward.
Important Notes:
• Do not use pointed or sharp-edged objects such as knives or forks to remove the frost.
• Never use hairdryers, electrical heaters or other such electrical appliances for
defrosting.
CLEANING AND CARE
** We recommend that you switch off the freezer at the socket outlet and pull out the
mains plug before cleaning.
** Never use any sharp abrasive instrument, soap, household cleaner, detergent and
wax polish for cleaning.
** Use lukewarm water to clean the cabinet of the freezer and wipe it dry.
** Use a damp cloth wrung out in a solution of one teaspoon of bicarbonate of soda to
one pint of water to clean the interior and wipe it dry.
** Excess deposit of ice should be removed on a regular basis using a plastic ice scraper
available from your local store. Large accumulation of ice will impair the performance of
the freezer.
** If the freezer is not going to be used for a long period of time switch it off, remove all
food, clean it and leave the lid ajar.
** Check lid seals regularly to ensure they are clean and free from food particles.
Important Notes:
Never use water wash the compressor position, wipe it with a dry cloth thoroughly
after cleaning to prevent rust.
DO’S AND DON’TS
Do – Defrost food from the freezer thoroughly in a fridge or in a microwave oven following
defrosting and cooking instructions.
Do – Ensure that chest freezer lid is completely closed after each use.
Do – Defrost frozen meat completely before cooking.
Do – Close the lid gently.
Do – Check contents of the freezer at regular intervals.
Do – Clean and defrost your freezer regularly (See “Defrosting”)
Do – Keep food for as short a time as possible and adhere to “Best Before”, “Use By” dates.
Do – Store commercially frozen food in accordance with the instructions given on the packets

that you buy.
Do – Always choose high quality fresh food and be sure it is thoroughly clean before you
freeze it.
Do – Prepare fresh food for freezing in small portions to ensure rapid freezing.
Do – Wrap all foods in aluminum foil or freezer quality plastic bags and make sure any air is
excluded.
Do – Wrap frozen food when you buy it and put it in to the freezer as soon as possible.
Do – Store small items in the basket provided.
Do – Remove ice cream from the freezer 10-20 minutes before serving.
Don’t – Leave the lid open for long periods as this will make the freezer more costly to run
and cause excessive ice formation.
Don’t – Use pointed sharp edged objects such as knives, forks to remove the ice.
Don’t – Put hot food in the freezer. Let it cool down first.
Don’t – Put liquid-filled bottles or sealed cans containing carbonated liquids into the freezer
as they may burst.
Don’t – Store poisonous or dangerous substances in the freezer. Your freezer has been
designed for the storage of edible foodstuffs only.
Don’t – Exceed the maximum freezing capacity ( 5 kg in any 24 hours) when freezing fresh
food.
Don’t – Consume ice-cream and water ices direct from the freezer. The low temperature may
cause ‘freezer burns’ on lips.
Don’t – Freeze fizzy drinks.
Don’t – Try to keep frozen food which has thawed, it should be eaten within 24 hours or
cooked and refrozen.
Don’t – Remove items from the freezer with wet hands.
Don’t – Shut the lid with force. You will damage the appliance.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensoryor mental capabilities, or lack of experience andknowledge, unless they have been
given
supervision or instruction concerning use of theappliance by a person responsible for their
safety.
• Children should be supervised to ensure that theydo not play with the appliance.
• Do not store explosive substances such as aerosolcans with a flammable propellant in this
appliance.
• This appliance is intended to be used in householdand similar applications such as staff
kitchen areas in shops, offices and other working environment farm houses and by clients in
hotels, motels and other residential type environments; bed and breakfast type
environments catering and similar not-retail applications.
• If the supply cord is damaged, it must be replaced by manufacture, its service agent or
similarly qualified persons in order to avoid a hazard.

The manufacturers of the product(s) described herein, to which this description refers,
declares on its sole responsibility that the product(s) meet the relevant fundamental
safety, health and protection requirements of the relevant UK, ROI & EU laws and that
the corresponding test reports are available for examination by the relevant authorities
and can be requested from the seller of the appliance, especially with regard to CE
Declaration of Conformity issued by the manufacturers approval.
Moreover, the manufacturer declares that the parts of the appliance described in this
instruction manual, which comes into contact with fresh or frozen food, do not contain
any toxic substances.
The manufacturer works constantly at the further development of all products. Please
therefore bear this in mind as the form, set up and technology are subject to change,
without prior notice.
After Sales Service, Guarantee and Points of Contact:
1. Resolving faults by yourself:
If you suspect any fault, before contacting Iceking Product Support directly or via your
retailer, make sure you have observed all instructions and advice in this instruction manual.
If you have, please follow the next steps…..
2. After sales service:
Consult the enclosed warranty card within your appliance for further details or turn to pages
2 & 3 of this manual for contact numbers and procedures.
In order to receive immediate help, make sure you have ready the following essential date to
identify your appliance.
 Brand and Model Number
 Serial Number (Located on the rating plate of your appliance – Normally on the
back)
 Details of Fault
 Date of Purchase
 Place of Purchase
Precautions:
If the appliance is to be discard/recycled, you must remove the lid. This will
reduce the possibility of danger to children. The flammable foaming needs to
be disposed of by a professional company/person or your local council.
Declaration of Conformity:

! Insurance ! Any warranty provided with this product does not cover loss of
fridge/freezer content.
Any claim for loss, damage, costs or expenses of an indirect or consequential nature
including any economic loss or damage to foodstuffs or any other goods is excluded.
We recommend that you inspect your fridge/freezer regularly to check that it is working
correctly, losses can result from deterioration following breakdown or accidental failure of
the appliance, fuses, plugs or public electricity supply, these can be covered by your standard
home insurance or might require extra cover. Check with your insurance provider.
Important Note:
This appliance is marked according to the European directive 2002/96/EC on Waste Electrical
and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the environment and human health, which
could otherwise be caused by inappropriate waste handling of this product.
The symbol on the product, or on the documents accompanying the product, the Crossed
Out Wheelie Bin, indicates that this appliance may not be treated as household waste.
Instead it shall be handed over to the applicable collection point for the recycling of
electrical and electronic equipment. Disposal must be carried out in accordance with local
environmental regulations for waste disposal. For more detailed information about
treatment, recovery and recycling of this product, please contact your local authority, your
household waste disposal service or the retailer where you purchased the product.
We continuously try to improve our products for the benefit of our customers. For this
reason we reserve the right to make changes to any product at any time, without notice.
Issue: 02/12/06/2017
Model No: Specification Dimensions (mm)
CF300W
292ltr Chest Freezer, A+ Energy
,
FST
–
Freezer Safe Technology (-15°c)
Unpacked: H: 885 W: 1090 D: 780mm
Packed: H: 835 W: 1055 D: 735mm
