Iceking Rz204w.e User manual

204W.E

Wide Upright

Freezer

White

InstallationandOperating

Manual

Please read these instructions carefully before attempting to install

or use this appliance. It is advisable to keep these instructions

in a safe place for future reference.

Iceking: Henry John House

Northway Industrial Estate, Northway Lane, Ashchurch , Tewkesbury, Gloucestershire

GL20 8JH

01527

888133 | enquiries@ice-king.co.uk

| www.ice

king.co.uk

Introduction

Thank you for choosing this I

ICEKING

appliance. It has been

designed to give years of trouble-free use provided it is installed

and maintained correctly.

Please read these instructions carefully before installing or using your

appliance. It is advisable to keep your purchase and installation

receipts with these instructions in a safe place for future reference.

Included is some important safety information in addition to guidelines

and recommendations that will enable you to take full advantage of all

the functions available.

This quality appliance has been tested and certified to meet all

applicable UK electrical and safety standards.

This appliance must be installed and connected in accordance

with current regulations by a qualified electrician.

After unpacking the appliance ensure that there is no visible damage.

If the appliance has been damaged during transit, do not use it,

contact your retailer immediately.

Safety information

In the interest of your safety and to ensure the correct use, before

installing and first using the appliance, read this user manual carefully,

including its hints and warnings. To avoid unnecessary mistakes and

accidents, it is important to ensure that all people using the appliance

are thoroughly familiar with its operation and safety features. Save

these instructions and make sure that they remain with the appliance if

it is moved or sold, so that everyone using it through its life will be

properly informed on appliance use and safety.

For the safety of life and property keep the precautions of these user’s

instructions as the manufacturer is not responsible for damages

caused by omission.

Children and vulnerable people safety

yThis appliance can be used by children aged from 8 years and above

and persons with reduced physical, sensory or mental capabilities or

lack of experience and knowledge if they have been given super

vision or instruction concerning use of the appliance in a safe way

and understand the hazards involved.

yChildren aged from 3 to 8 years are allowed to load and unload this

appliance.

yChildren should be supervised to ensure that they do not play with

the appliance.

yCleaning and user maintenance shall not be made by children unless

they are aged from 8 years and above and supervised.

yKeep all packaging well away from children. There is risk of

suffocation.

yIf you are discarding the appliance pull the plug out of the socket, cut

the connection cable (as close to the appliance as you can) and

remove the door to prevent playing children to suffer electric shock or

to close themselves into it.

yIf this appliance featuring magnetic door seals is to replace an older

appliance having a spring lock (latch) on the door or lid, be sure to

make that spring lack unusable before you discard the old appliance.

This will prevent it from becoming a death trap for a child.

General safety

WARNING! Keep ventilation openings, in the appliance enclosure

or in the built-in structure, clear of obstruction.

WARNING! Do not use mechanical devices or other means to

accelerate the defrosting process, other than those recommended

by the manufacturer.

WARNING! Do not damage the refrigerant circuit.

Safety information

WARNING! Do not use other electrical appliances (such as ice

cream makers) inside of refrigerating appliances, unless they are

approved for this purpose by the manufacture.

WARNING! Do not touch the light bulb if it has been on for a long

period of time because it could be very hot.1 )

yDo not store explosive substances such as aerosol cans with a

flammable propellant in this appliance.

yThe refrigerant isobutane (R-600a) is contained within the refrigerant

circuit of the appliance, a natural gas with a high level of

environmental compatibility, which is nevertheless flammable.

yDuring transportation and installation of the appliance, be certain that

none of the components of the refrigerant circuit become damaged.

- avoid open flames and sources of ignition

-thoroughly ventilate the room in which the appliance is situated

yIt is dangerous to alter the specifications or modify this product in

any way. Any damage to the cord may cause a short circuit, fire and/

or electric shock.

yThis appliance is intended to be used in household and domestic

applications only.

WARNING! Any electrical components(plug, power cord,

compressor and etc.) must be replaced by a certified service agent

or qualified service personnel.

WARNING! The light bulb supplied with this appliance is a “special

use lamp bulb” usable only with the appliance supplied. This “special

use lamp” is not usable for domestic lighting.1 )

1) If there is a light in the compartment.

WARNING! When positioning the appliance, ensure the supply

cord is not trapped or damaged.

WARNING! Do not locate multiple portable socket-outlets or

portable power suppliers at the rear of the appliance.

Safety information

1) If there is a freezer compartment.

2) If there is a fresh-food storage compartment.

yPower cord must not be lengthened.

yMake sure that the power plug is not squashed or damaged by the

back of the appliance. A squashed or damaged power plug may

overheat and cause a fire.

yMake sure that you can come to the mains plug of the appliance.

yDo not pull the mains cable.

yIf the power plug socket is loose, do not insert the power plug. There

is a risk of electric shock or fire.

yYou must not operate the appliance without the lamp.

yThis appliance is heavy. Care should be taken when moving it.

yDo not remove nor touch items from the freezer compartment if you

hands are damp/wet, as this could cause skin abrasions or

frost/freezer burns.

yAvoid prolonged exposure of the appliance to direct sunlight.

'DLO\XVH

yDo not put hot on the plastic parts in the appliance.

yDo not place food products directly against the rear wall.

yFrozen food must not be re-frozen once it has been thawed out.1 )

yStore pre-packed frozen food in accordance with the frozen food

manufacture,

s instructions.1 )

yAppliance,

s manufactures storage recommendations should be

strictly adhered to. Refer to relevant instructions.

yDo not place carbonated of fizzy drinks in the freezer compartment as

it creates pressure on the container, which may cause it to explode,

resulting in damage to the appliance.1 )

yIce lollies can cause frost burns if consumed straight from the

appliance.1 )

To avoid contamination of food, please respect the following

instructions

yOpening the door for long periods can cause a significant increase of

the temperature in the compartments of the appliance.

yClean regularly surfaces that can come in contact with food and

accessible drainage systems.

yClean water tanks if they have not been used for 48h; flush the water

system connected to a water supply if water has not been drawn for 5

days.

yStore raw meat and fish in suitable containers in the refrigerator, so

that it is not in contact with or drip onto other food.

yTwo-star frozen-food compartments (if they are presented in the

appliance) are suitable for storing pre-frozen food, storing or making

ice-cream and making ice cubes.

Safety information

1) If there is a freezer compartment.

2) If there is a fresh-food storage compartment.

&DUHDQGFOHDQLQJ



Before maintenance, switch off the appliance and disconnect the

mains plug from the mains socket.

Do not clean the appliance with metal objects.

Do not use sharp objects to remove frost from the appliance. Use a

plastic scraper.1 )

Regularly examine the drain in the refrigerator for defrosted water. If

necessary, clean the drain. If the drain is blocked, water will collect in

the bottom of the appliance.2 )

Installation

Important! For electrical connection carefully follow the instructions

given in specific paragraphs.

Unpack the appliance and check if there are damages on it. Do not

connect the appliance if it is damaged. Report possible damages

immediately to the place you bought it. In that case retain packing.

It is advisable to wait at least four hours before connecting the

appliance to allow the oil to flow back in the compressor.

Adequate air circulation should be around the appliance, lacking this

leads to overheating. To achieve sufficient ventilation, follow the

instructions relevant to installation.

Wherever possible the spacers of the product should be against a

wall to avoid touching or catching warm parts (compressor, con-

denser) to prevent possible burn.

The appliance must not be located close to radiators or cookers.

Make sure that the mains plug is accessible after the installation of

the appliance.

6HUYLFH

Any electrical work required to do the servicing of the appliance

should be carried out by a qualified electrician or competent person.

This product must be serviced by an authorized Service Center, and

only genuine spare parts must be used.

(QHUJ\VDYLQJ

Don’t put hot food in the appliance;

Don’t pack food close together as this prevents air circulating;

Make sure food don’t touch the back of the compartment(s);

yOne-, two- and three -star compartments (if they are presented in the

appliance) are not suitable for the freezing of fresh food.

yIf the appliance is left empty for long periods, switch off, defrost,

clean, dry and leave the door open to prevent mount developing

within the appliance.



This refrigerating appliance is not intended to be used as a built-in

appliance

Safety information



If electricity goes off, don’t open the door(s);

Don’t open the door(s) frequently;

Don’t keep the door(s) open for too long time;

Don’t set the thermostat on exceeding cold temperatures;

All accessories, such as drawers, shelves and balconies, should be kept

there for lower energy consumption.

(QYLURQPHQW3URWHFWLRQ

This appliance does not contain gasses which could damage the

ozone layer, in either its refrigerant circuit or insulation materials. The

appliance shall not be discarded

together with the urban

refuse and

rubbish. The insulation foam contains flammable gases: the appliance

shall be disposed according to the appliance regulations to obtain from

your local authorities. Avoid damaging the cooling unit, especially the

heat exchanger. The materials used on this appliance marked by the

symbol

are recyclable.

The symbol on the product or on its packaging indicates that this

product may not be treated as household waste. Instead it

should be taken to the appropriate collection point for the

recycling of electrical and electronic equipment. By ensuring this

product is disposed of correctly, you will help prevent potential

negative consequences for the environment and human health, which

could otherwise be caused by inappropriate waste handling of this

product. For more detailed information about recycling of this product,

please contact your local council, your household waste disposal

service or the shop where you purchased the product.

Packaging materials

The materials with the symbol are recyclable. Dispose the packaging in

a suitable collection container to recycle it.

Disposal of the appliance

Disconnect the mains plug from the mains socket.

Cut off the mains cable and discard it.

WARNING!

During using, service and disposal the

appliance, please pay attention to symbol as left side, which is

located on rear of appliance (rear panel or compressor.

It’s risk of fire warning symbol. There are flammable materials in

refrigerant pipes and compressor.

Please be far away fire source during using, service and

disposal.

Description of the Appliance

Temperature Control Knob

Storage Drawers x

Levelling Feet

Please note that your appliance may be supplied with the door left or

right hand hinged. To reverse the door please refer to section 4.5.

(Picture shown for indicative purposes only, model supplied may differ).

CONTENTS:

Section 1. Installation

Section 2. Safety Advice

Section 3. Operating the Appliance

Section 4. Maintenance

Section 1. Installation

-IMPORTANT! This appliance must be left to stand in an upright position for

at least 4 hours before being switched on for the first time.

-Remove all packaging and securing tape from the appliance.

-Wash the interior of the appliance with luke warm water containing a small

amount of bicarbonate soda (5ml to 0.5 litres of water).

-Position the appliance in a dry atmosphere and out of direct sunlight.

-This appliance should not be sited in a cold atmosphere, i.e. cellar, garage

or shed. Doing so may cause condensation to form on the exterior of the

unit. N.B. Condensation or related problems such as rust on exterior

panels are not covered under the manufacturers guarantee.

-Do not position next to a cooker or other sources of heat, i.e. radiator.

-If positioned next to another fridge or freezer, leave a minimum gap of

2cm between the appliances in order to avoid condensation.

-A clearance of 50mm should be left above the appliance. If this cannot be

achieved you should ensure a clearance of 25mm is maintained on each

side of the appliance.

-Please ensure that there is a small ‘air-gap’ between the condenser on the

rear of the appliance and the rear wall.

-Do not place or store heavy items on the top of this appliance.

-Ensure that the appliance is positioned on a firm flat floor.

-This appliance must be level. Adjust the level by screwing the adjustable

feet up or down (use your fingers or a suitable spanner).

-Ensure that the appliance is upright and both feet are in firm contact with

the floor so that the cabinet is stable.

-Connect the plug to an adjacent 13amp socket outlet and ensure that the

appliance is not standing on the supply cable.

N.B. If you site this appliance in a garage, out-building or a cold

room where the ambient temperature may fall below 6 to 8 degrees

C, condensation may form on the outer cabinet and ‘pool’ under the

appliance. This is quite normal and does not indicate that there is a

fault with the appliance.

To prevent condensation building up on the outer cabinet ensure that

the ambient temperature is above 8 degrees C.

- Install this appliance at a location where the ambient temperature

corresponds to the climate class indicated on the rating plate of the

appliance:

extended temperate (SN) :"this refrigerating appliance is intended to be

used at ambient temperature ranging from 10 °C to 32 °C;

temperate (N): this refrigerating appliance is intended to be used at ambient

temperatures ranging from 16 °C to 32 °C;

subtropical (ST): this refrigerating appliance is intended to be used at

ambient temperatures ranging from 16 °C to 38 °C;

tropical (T): this refrigerating appliance is intended to be used at ambient

temperatures ranging from 16 °C to 43 °C

Section 2. Safety Advice

-Please read this booklet thoroughly before installing and switching on the

appliance. The manufacturer accepts no responsibility for incorrect

installation and usage.

-If this appliance is to replace an old refrigerator with a lock, as a safety

measure break or remove the lock and/or door before disposal.

-Your old appliances contain insulation gases and refrigerant that must be

disposed of correctly. Please ensure that the refrigerant circuit is not

damaged before the appliance is taken away for correct disposal in line

with current legislation. If there is any doubt contact your Local Authority

for instructions.

-This appliance may contain the refrigerant isobutene (R600a). This is a

natural gas with a high level of environmental compatibility; however,

caution is required as isobutene is a flammable gas. It is essential to

ensure that refrigerant tubes are not damaged during transportation and the

installation of the appliance. In the event that the refrigerant circuit is

damaged, avoid naked flames or sources of ignition and ventilate the room

in which the appliance is situated.

-Do not damage the refrigerant circuit.

-Do not allow children to play with plastic bags – tear the bag(s)

immediately and ensure that they are placed in a dust-bin out of reach.

-This appliance shall not be used by children aged from 8 years and above

and persons with reduced physical, sensory or mental capabilities, or lack

of experience and knowledge, unless they have been given supervision or

instruction on how to use of the appliance in a safe way and understand the

hazards involved. Children shall not play with the appliance. Cleaning and

user maintenance shall not be made by children without supervision.

-If using an adaptor, this must be used in accordance with the

manufacturers instructions and ensure that the electrical circuit is not

overloaded as this could cause overheating.

-Do not twist or bend the cables, and keep them away from hot surfaces.

-Do not plug ın or unplug this appliance with wet hands.

-Following installation make sure that the power cable is not trapped

underneath the appliance.

-If the power supply cord is damaged, it must be replaced by the

manufacturer, it’s service agent or similarly qualified persons in order to

avoid a hazard.

Section 3. Operating the Appliance

3.1. Switching on the Appliance

-Allow the appliance to stand for a minimum of 4 hours after installation.

-Plug in the appliance and switch on at the mains supply.

-Set the thermostat control to the required setting as detailed in the

Temperature Control section (3.2.).

-Leave the appliance for approximately 4 hours for the correct temperature

to be reached.

3.2. Temperature Control

The temperature control knob is located just above the door on the front of

the appliance (See ‘Description of the Appliance’ on page 3). Set the control

as follows:

-Setting “Min”: Warmest Temperature

-Setting “Normal”: Normal Operation (adequate for most situations)

-Setting “Max”: Coldest Temperature

Important!

During high ambient temperatures e.g. on hot summer days, it may be necessary to

set the control to the coldest setting (Max). This may cause the compressor to run

continuously in order to maintain a low temperature in the cabinet.

N.B. If you site this appliance in a garage, out-building or a cold room where

the ambient temperature may fall below 6 to 8 degrees C, condensation may

form on the outer cabinet and ‘pool’ under the appliance. This is quite normal

and does not indicate that there is a fault with the appliance.

To prevent condensation building up on the outer cabinet ensure that

the ambient temperature is above 8 degrees C.

3.3. Storing & Freezing Food in the Freezer

This appliance is a four star freezer and is suitable for the long-term storage of

frozen food items. It can also be used for freezing and storing fresh food items.

You should always follow the storage guidelines printed on each food producers

packaging, however the following information is provided as a general guide for

the maximum storage life of frozen items:

-Fresh Meat and Poultry – up to 12 months

-Cooker Meats – up to 2 months

-Fresh Fish – up to 6 months

-Fruit and Vegetables – up to 12 months

-Bread and Cakes – up to 6 months

When adding large quantities of fresh food to your freezer you are advised to turn the

temperature to the ‘Max’ setting for a maximum of 4 hours. This will help to fast freeze

the food. Remember to turn the temperature back to the ‘Mid’ setting after the 4 hour

period!

3.4. Normal Operating Sounds

You may hear faint gurgling or bubbling sounds when the refrigerant is pumped to

the cooling system and through the coils or tubing at the rear of the appliance.

When the compressor is in operation you may hear a slight whirring sound or

pulsating noise. The thermostat controls the operation of the compressor, and

you may hear a slight click as it cycles in and out.

3.5. Energy Saving Advice

- Do not install the appliance close to sources of heat, such as a

cooker, dishwasher or radiator.

-Locate the appliance in a cool well-ventilated room and make sure

that the air vents are clear.

-Try to avoid keeping the door open for a long time, warm air will enter the

cabinet and may cause a build up of ice as well as affecting the energy

consumption. Ensure there are no obstructions preventing the door from

closing properly.

-Ensure that the door seal is clean and there are no tears or splits.

-Do not put hot food into the freezer – let it cool down first.

3.6. In the Event of a Power Failure

If there is a power failure, keep the door closed. When the power has been

restored the appliance will start to operate but it may take some time to achieve

the pre-set operating temperature. Check the condition of your stored food items

and liquids.

C 

Freezer drawer(s)/shelf Foods for long-term storage.

Bottom drawer/shelf for raw meat, poultry, fish.

Middle drawer/shelf for frozen vegetables, chips.

Top drawer/shelf for ice cream, frozen fruit, frozen

baked goods.

3.7 Food Storage Advice

To avoid food waste, please refer to the recommended setting and storage times found in

the user manual.

Load limits are determined by baskets, flaps, drawers, shelves etc. Make sure that these

components can still close easily after loading.

3.8 Temperature Setting Recommendation

Environment Temperature Freezer Compartment

Summer

Normal

Winter

Impact on food storage

- Under recommended setting, the best storage time of freezer is no more than 1 month.

- The best storage time may reduce under other settings.

Section 4. Maintenance

Before any maintenance or cleaning work is carried out, DISCONNECT

the appliance from the ELECTRICITY supply.

4.1. Internal Cleaning

Clean the interior and accessories with warm water and bicarbonate of soda

(5ml to 0.5 litre of water). Rinse and dry thoroughly. Do not use detergents,

abrasive powders, highly perfumed cleaning products, wax polishes or cleaning

products containing bleach or alcohol.

4.2. External Cleaning

Wash the outer cabinet with warm soapy water. Do NOT use abrasive products.

There may be sharp edges on the underside of the product, so care should be

taken when cleaning. Once or twice a year dust the rear of the appliance and the

compressor at the back of the appliance, with a brush or vacuum cleaner, as an

accumulation of dust will affect the performance of the appliance and cause

increased energy consumption.

4.3. Defrosting

It is advisable to carry out de-frosting when your frozen food stocks are minimal.

Any frozen food that you do have inside the appliance should be wrapped in

thick newspaper or stored in a cool bag whilst carrying out the defrost operation.

If ice build up in the appliance exceeds 3-5mm, empty the contents and switch off

the appliance, leave the door open and allow the ice to melt. Do not use sharp

objects to scrape the ice away. Clean and dry the interior, close the door and

turn on the power to the appliance. When the power has been restored the

appliance will start to operate but it may take some time to achieve the pre-set

operating temperature.

4.4. When the appliance is not in use

When the appliance is not in use for long periods, remove the contents,

disconnect from the electricity supply and clean the appliance, leaving the door

ajar until you wish to use the appliance again.

4.5. Reversing the Door

The door opening can be reversed from “right hand hinged” to “left hand hinged” if

required. If your appliance is supplied “left hand hinged” simply reverse the

following procedure.

Warning!

When reversing the door, the appliance must not be connected to the mains.

Remove the plug from the mains beforehand.

Remove the top hinge cover

Lean the appliance back and prop it up securely at the front

Remove the top door hinge screws and remove the hinge bracket

Remove the door from the lower hinge

Now remove the lower hinge bracket and unscrew/remove the central

hinge pin. Turn the hinge over and refit the hinge pin as shown below

Secure the lower door hinge into place on the opposite side of the

appliance

Now ensure both levelling feet are in place and secure

Now position the door onto the lower hinge bracket

Now refit the upper hinge bracket on the opposite side of the appliance

Do not fully tighten the screws until you have tested that the door closes

correctly and that the door seal is tight

Now secure all the screws

Refit the top hinge cover.

N.B. Service calls relating to door problems and/or cooling issues will be

chargeable if the fault is found to be due to an incorrect door

reversal procedure carried out by the consumer!

4.6. What to do if something goes wrong

There is no power to the appliance:

-Check there is not a power cut

-Check there is power to the electric socket/appliance

-Check the fuse in the plug (Must be 13

amp) The compressor runs continuously:

-Is the door closed correctly?

-Have large quantities of food recently been added to the appliance? – if

yes, allow the interior temperature to recover

-Has the appliance door been opened frequently? – if yes, allow the interior

temperature to recover

-Is the t/stat control set to maximum? – if yes, adjust the control to a lower

setting

There is excessive frost/ice build-up:

-Ensure that the door has been closed correctly

-Ensure that the door seal is clean and sealing correctly

-Ensure the temperature control is not set on Max

The appliance is making a noise:

-Refer to Normal Operating Sounds, section 3.4.

-Ensure that the appliance has been installed correctly (see section 1).

Guarantee

YOUR 2 YEAR MANUFACTURER'S GUARANTEE

THIS DOES NOT AFFECT YOUR STATUTORY

RIGHTS

Your new ICEKING appliance carries a free guarantee which protects you

against the cost of

repairs during the first 24 months from date of purchase

provided that any claim is accompanied by evidence of the model reference,

model serial number and proof of purchase, such as a Sales Receipt,

showing that the appliance was purchased within the 24 months prior to the

date of

claim.

YOUR GUARANTEE IS VALID ONLY IN THE UK &

REPUBLIC OF IRELAND

To register your appliance, simply complete the card in your appliance pack

and return it with a stamp affixed or alternatively you can register online at

www.repairtechuk.com

Service Helpline

Should your appliance develop a fault, please call the

Iceking Service

Helpline on:

01527 888133

Please remember to

have all

your product details available, including the

model number, serial number, date of purchase and your retailer’s details

before registering a fault.

Your service call cannot progress without this information.

WHAT IS NOT COVERED UNDER THE GUARANTEE:

•

Any appliance not correctly installed and operated in accordance with the

manufacturer’s instructions

•

Any appliance that is used for anything other than domestic purposes.

•

Any defect caused by accident, misuse, unauthorised modification or

inexpert repair.

Guarantee

•Cost of callout where a fault cannot be found with the appliance.

•Cost of callout for work covering routine maintenance, such as, but not

exclusively, cleaning of filters or defrosting.

•Cost of callout for work required to correct the alignment of doors following

door reversal procedures carried out by you.

•Use of the appliance by anyone other than the Householder.

•Use in any commercial environment.

•Consumable items, such as, but not exclusively, fuses in plugs, bulbs and

breakable items which require routine replacement.

•Repair costs incurred that have not been authorised by the Repairtech and/or

carried out by a non-approved Repairtech engineer.

Insurance

!! Any warranty provided with this prod

uct

does

not

cover

loss

fridge/freezer content !!

Any claim for loss, damage, costs or expenses of an indirect or

consequential nature including any economic loss or damage to

foodstuffs or any other goods is excluded. We recommend that you

inspect your fridge/freezer regularly to check that it is working correctly,

losses can result from deterioration following breakdown or accidental

failure of the appliance, fuses, plugs or public electricity supply, these

can be covered by your standard home insurance or might require extra

cover. Check with your insurance provider.

Special

for new European standard

The ordered parts in the following table can be acquired from customer services.

Ordered Parted

Provided By

Minimum Time Required For

provision.

Professional maintenance
