Icemobile BLIZZARD III User manual

1
1.1 Phone overview
1.Technical specifications
Dimensions (W×D×H): 106.3X46X13.5MM
Weight:with out battery 67 Grams
Lithium battery:NOkia 5C
Rated capacity:1000Mah
Continuous standby duration: (Relates to network status)
100 Hours
Continuous conversation duration: (Relates to network
status) 130 Mins
Please refer to their labels for other data related to the
battery and the charger.
2Getting started
2.1InstallingtheSIMcards
Remove the back cover and lift battery away. Insert SIM
card into the SIM card slot lightly.
2.2 Installing T-Flash Card
To install the T-Flash card, open its latch, place its
indented side downward, insert the card into the card slot,

2
and then close the latch.
To remove the T-flash card, open its latch and
slightly press the card inward. The card will automatically
pop out. Close the latch.
2.1 Charging the Battery
The lithium battery delivered with the mobile phone
can be put into use immediately after being unpacked. A
new battery will have maximum performance after the first
three full charge/discharge cycles.
2.2 Linking to the Network
The mobile phone automatically searches for an available
network.
Dialing a call to a number in the phonebook
Enter the phonebook and use the upward and/or
downward direction keys to find the telephone number you
want to call.
Press the Dial key. The mobile phone automatically dials
the chosen telephone number.
Redialing the last number
In the standby interface, press the dial key to show the
dialed calls.
Press the upward and/or downward direction keys to select
a number you want to dial and then press the Dial key.
Adapting volume
During a conversation, you can press the Up and/or Down
direction keys to tune the sound volume.
Answering incoming calls

3
Press the Dial key or the Left soft key to answer an
incoming call.
Press the End key to end the current conversation.
To reject an incoming call, press the End key or the Right
soft key.
Using options during a conversation
Select Options during a conversation to pause, end the
ongoing call, originate a new call, browse the phonebook,
view information, set the mute, set the DTMF, or perform
other operations. For details, refer to the menu guide.
2.3 Using the Headset
It would enter headset mode automatically when you
insert headset to the slot. Make sure of inserting it at the
bottom of the slot, or you can’t use it normally.
3Input method
This mobile phone provides multiple input methods,
including English input in both upper and lower case, and
numeric input method.
3.1 To Shift Entry Methods
Press the #key to switch between input methods.
3.2 Numeric Input
You can input numbers with the numeric input method.
Press a number key to input the corresponding number.
3.3 Inserting a Symbol
Press the *key to enter the Select symbol interface,
use direction keys to select a symbol you want.

4
4Using the Menus
4.1 Call center
Missed Calls: You can view a list of the latest missed
calls.
Dialed Calls:You can view the latest dialed calls. Choose
dialed calls and then select a dialed call to delete, save,
dial, or edit (or send a short message to it).
Received Calls:You can view the latest received calls.
Choose received calls and then select a received call to
delete, save, dial, or edit (or send a short message to it).
Rejected calls:A list of calls you’ve rejected.
Delete all :You can delete the latest call records.
Call Timers
GPRS flow rate
Last sent: Viewing the rate of last session sent
Last received: Viewing the rate of last session received
All sent: Viewing all of the rate of sessions sent
All received: Viewing all of the rate of sessions
received
Reset counter: Clearing all rates.
4.2 Multimedia
Camera
This function enables you take a picture you want. Roll the
phone to align the camera to the picture and then press OK
key, which the picture will be stored in the album.
Select “option”and you can set some paramount of photo
and camera, and scan the pictures you’ve taken in gallery
and view the storage status.

5
Analog TV
Video recorder
This function enables you to record dynamic pictures.
Adapt the VCR to the scene or the figure, the press OK to
start or pause recording. Press STOP to end recording, and
the phone would save the file automatically.
Video player
This function enables you play, send, rename, delete, delete
all files, rank or save your video and movies.
Image viewer
This function enables you view, edit, slide show, use as,
send, rename, delete, delete all files, rank and save about
your pictures.
Audio Player
The audio player provides four buttons: Play or Pause, Stop,
Back, and Forward which are corresponding to the up
direction key, down direction key, left direction key and
right direction key. The audio player supports MP3,
formats. Press # key and * key to increase or decrease
volume.
Recorder
The phone support WAV. The recording file you stopped
would be stored in file list automatically. You can select
storage location as needed. The path is
Multimedia>recorder>option>storage location>Udisk/
Memory card.
FM Radio
Your phone is equipped with an FM radio. You can use the

6
application as a traditional FM radio with automatic tuning
and saved channels. Press # key and * key to increase or
decrease volume.
File manager
The phone provides a certain space for users to manage
files and supports the T-Flash card. The capacity of the
T-Flash card is selectable. You can use the file manager to
conveniently manage various directories and files on the
phone and the T-Flash card.
Choose File manager to enter the root directory of the
memory. The root directory will list the default folders,
new folders and user files. When the mobile phone is
powered on for the first time or when you have not changed
the directory, the root directory contains the default folders
only.
You can use this function to format all the data in the
memory. The system will re-create a default folder. The
formatted data cannot be recovered. Therefore, think twice
before using the formatting function.
4.3 Phonebook
The mobile phone can store up to 500 telephone numbers.
4.4 User profiles
The mobile phone provides multiple user profiles, so that
you can customize some settings to adapt to the specific
events and environments.
Customize the user profiles according to your preference
and then activate the user profiles. The user profiles fall
into five scenarios: General, Meeting, Outdoor, Indoor

7
and Silent.
Select option, and you can perform the following
operations: Activate, Settings and Rename.
Note: In standby state, hold the # key to switch to the mute
mode. To switch back to the original mode, hold the # key
again.
4.5 Messages
If the short message memory is full, a blinking SMS icon
appears on the top of the screen. To normally receive short
messages, you need to delete some of the existing short
messages.
4.6 Tools
Alarm
Three alarm clocks are set but deactivated by default. You
can activate one, multiple or all of them as needed. For
each alarm clock, the ringing date and the ringing time can
be set. When the preset alert time is up, the mobile phone
gives off an alert tone whereas the current date and time
blinks on the screen. Select Stop to stop the ring or Snooze
to temporarily stop the ring. If you select Snooze, the alarm
clock will ring four minutes later.
Calendar
Once you enter this menu, there is a monthly-view calendar
for you to keep track of important appointments, etc. Days
with events entered will be marked

8
Bluetooth
E-Book reader
Calculator
Hold down the ‘*’key to get the decimal point. Confirm
with the OK key or the left soft key.
Note: This calculator provides limited precision and is only
applicable to simple arithmetic calculation.
World clock
Torch
STK
4.7Settings
Dual SIM Settings
Dual-SIM: Dual-SIM refers to two SIM card slots, and
the two cards can standby at the same time or set
one of them to display on the idle screen.
Call Setup
◆Network selection: Set Network selection mode to
Automatic or Manual. Automatic is recommended. When
Network selection mode is set to Automatic, the mobile
phone will prefer the network where the SIM card is
registered. When Network selection mode is set to Manual,
you need to select the network operator's network where
the SIM card is registered.
Call waiting
Activate: After you choose Activate, the mobile phone
will contact the network. A moment later, the
network will make a response and send a message

9
to acknowledge your operation. If the call waiting
function is activated, the network will alert you and
the mobile phone screen will display the incoming
call number if others are calling you while you are
already in a conversation.
Deactivate: If you choose Deactivate, the network will
not alert you when others are calling you while you
are already in a conversation.
Query status: Query the network to obtain the current
call waiting status.
Hide ID:When you call someone, he or she can’t find
out your number if you enable this function.
Line selection: Switch to Line 1 or Line 2. By default,
Line 1 is used.
Note: If you choose Line 2, dialing may fail. This depends
on the implementation of the network operator.
Phone Settings
Time and date: Set time, date, time format and
date display type.
Language: Select the display language for the
mobile phone.
Display
Select images and set them as wallpaper and idle display.
You can set duration of backlight and keypad light.
Security Settings
This function provides you with related settings about
safety use. To set the SIM1 lock, you need to input the PIN.
You can set the SIM lock only after inputting the correct

10
PIN. If you set SIM1 lock to On, you need to input the PIN
each time you power on the mobile phone. In the case you
input a wrong PIN for three consecutive times, you need to
input the PIN Unblocking Key (PUK). The PUK is used to
unlock and change the locked PIN. To obtain the PUK,
contact the network operator. Fixed dial requires the SIM
card's support and the network operator's support. When
the fixed dial function is activated, you can dial only the
numbers in the fixed dial list. To activate the fixed dial
function, you need to input the PIN2. Barred dial requires
SIM card’s support, you can activate or deactivate barring
of some or all calls. Phone lock enables you to lock/unlock
the phone. Input password to switch on or off the phone.
Password is required when the phone is locked. The
password is 4 to 8 digits. Keypad lock enables you to
lock/unlock the keypad. Setting the auto locking time that
5s, 30s, 1min or 5mins is available. The keypad will be
auto locked with no operation during the period.
Restore factory settings
Restore settings: Choose Phone Settings > Restore settings
to restore the factory settings. Input the phone lock code
and then select OK or press the Left soft key.
Note: The initial phone lock code is 1234.
4.7 ICE SMART ZONE
Face book,
Box man,
MSN
Yahoo

11
Twitter
google
A game named Box man is embedded in the phone, you
can refer to ‘Help’option embedded in the phone for
operation.
Games settings: You can turn on or turn off Audio or
Vibration and modify volume as needed.
4.8 Service
This function enables you to view the internet. Your phone
will ask you with existed way. You can start to view only
by starting corresponding way. You can store a website of
home page in each way. The home page will be first
viewed when using WAP explore. And you can add, edit,
delete or send bookmarks. The websites you’ve visited are
usually stored in Histories. Moreover, you are able to set
some paramount of WAP settings as needed.
