Icom UX-R9000 User manual

INSTRUCTIONS
LCD UNIT
UX-R9000 Thank you for purchasing the UX-R9000 LCD UNIT.
Please read these instructions before installing and
using this product.
qRemove the rack mounting handles, top/bottom cov-
ers and front panel as shown in the diagram below.
wRemove the speaker cable as shown in the diagram
below.
eRemove the 4 screws and open the RFA/TV units
as shown in the diagram below.
rRemove the 4 screws and remove the SW-D unit as
shown in the diagram below.
tRemove the 6 screws from the DISPLAY unit (CRT)
and remove the cover as shown in the diagram
below.
yRemove the 4 screws and 2 connectors from the
DISPLAY unit (CRT) and remove the unit as shown
in the diagram below.
INSTALLATION
Speaker cable
DISPLAY unit cover
DISPLAY unit
RF A/TV unit SW-D unit
RWARNING: DISCONNECT the AC power
cable and wait several minutes before opening the
receiver.
