iCON Pro Audio C1 Pro User manual

User manual
Large-diaphragm condenser handheld microphone

Important Safety Instructions
1. Read this manual thoroughly before using this unit.
2. Keep this manual for future reference.
3. Take notice of and comply with all warnings included in the user's manual or indicated on the
appliance.
4. Follow all instructions included in this manual.
5. Do not expose this unit to rain or moisture. Avoid having water or other liquids spilled on this
unit.
6. When cleaning the cabinet or other parts of this appliance, use only a dry or slightly damp soft
cloth.
7. Do not block any ventilation openings or interfere with the proper ventilation of this unit. Install
in accordance with the manufacturer's instructions.
8. Do not use or store near any heat sources such as radiators, heat registers, stoves, or other heat-
producing appliances.
9. Do not interfere with the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding-type plug has two blades and a third
grounding prong. These are designated for your safety. If the provided plug does not fit into your
outlet, consult an electrician.
10. Protect the power cord from being walked on or otherwise damaged by items placed on or
against them. Particular attention should be given to the plugs, receptacles, and the point where
the cord exits the appliance.
11. To avoid the risk of electrical shock, do not touch any exposed wiring while the unit is in
operation.
12. Only use attachments/accessories specified by the manufacturer.
13. Unplug this unit and all connected electrical equipment during lightning storms or when left
unused a long period of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the appliance has
been damaged in any way or fails to operate normally.
WARNING: To reduce the risk of fire or electric shock, do not expose this unit to rain or moisture

Introduction...............................................................................................4
What’s in the package? ............................................................................4
Register your ICON ProAudio product to your personal account ...........5
Features ...................................................................................................6
Operating the C1 Pro...............................................................................7
Specications ...........................................................................................9
Services..................................................................................................10
Contents

4
Introduction
What’s in the package?
●C1 Pro large diaphragm condenser microphone
●Shock - Mount Clip
●Storage Pouch
●Hallow foam Windscreen
Thank you for purchasing the ICON ProAudio C1 Pro large diaphragm condenser
microphone. We sincerely trust this product will provide years of satisfactory service,
but if anything is not to your complete satisfaction, we will endeavor to make things
right.
In these pages, you'll nd a detailed description of the features of the C1 Pro large
diaphragm condenser microphone, step-by-step instructions for their setup and use,
and full specications.
Please register the product on our website at the below link
www. iconproaudio.com/registration:
Please follow the step by step procedures. Start by inputing the device’s serial
number as well as your personal information, etc. By registering your product online,
you will be entitled to service and after-sales support at our Help Center by visiting
our website at www.iconproaudio.com. Also, all the registered products under your
account will be listed on your personal product page where you will nd updated
information such as rmware/driver upgrades, software bundles, user manual
downloads, etc. for your device.
As with most electronic devices, we strongly recommend you retain the original
packaging. In the unlikely event the product must be returned for servicing, the
original packaging (or reasonable equivalent) is required.
With proper care and adequate air circulation, your C1 Pro large diaphragm
condenser microphone will operate without any trouble for many years.

5
Register your ICON ProAudio product to your
personal account
1. Check serial number of your device
Please go to http:// iconproaudio.com/registration or scan the QR code
below.

Input your device’s serial number and the other information on the screen. Click
“Submit”.

A message will pop up showing your device information such as model name
and its serial number - Click “Register this device to my account” or if you see
any other message, please contact our after-sales service team

2. Log in to your personal account page for existing user or
sign up for new user
Existing user: Please log into your personal user page by inputing your
user name and password.

New user: Please click “Sign Up” and ll in all the information.

3. Download all useful materials
All your registered devices under your account will show on the page. Each
product will be listed along with all its available les such as drivers, rmware,
user manual in different languages and bundled software etc. for download.
Please make sure you have download the necessary les such as driver before
you begin device installation.

6
Features
●Extended upper clarity with smooth mid-range for any voice or instrument applications
●Professional hand-build large-diaphragm capsule for full, open-sound and
unsurpassed audio quality
●Ideal as main and support microphone for most differing recording situations
●Cardioid pickup pattern for outstanding sound source separation and feedback
rejection
●Pressure-gradient transducer with shock-mounted capsule
●External 36-52 Volt phantom power operation
●Prefect for vocals and acoustic instruments
●Hollow form pop-lter included
●Ultra-rugged construction with metal die-cast body
●High-quality components and exceptionally rugged construction ensure long lift
●Included suspension shock mount and storage pouch

7
Operating the C1 Pro
Powering the C1 Pro
The C1 Pro is a condenser microphone and therefore needs to be operated by
connecting a 5V phantom power supply. If necessary an external 5V phantom power
supply can also be used. The C1 Pro receives the phantom power directly from a
MIC cable when connected to a mixer or other microphone input that includes a 5V
phantom supply. The power is actually sent OUT of the microphone INPUT, riding
silently along with the audio signal.
Setting up the signal level
When connecting the C1 Pro to a mixer or recorder input, be sure that the input is of
microphone level. Also, be sure that the 5V phantom power is engaged as explained
at the previous section “Powering the C1 Pro”. Most mixers and recorders of
reasonable quality will offer a microphone input with MIC trim (usually called Trim or
Gain) control. The purpose of the MIC trim control is to optimize the amount of good
signal to any noise associated with the mixers electronics. A good MIC pre with trim
also will have a Peak or Clip LED. To set a good level on the MIC, set the C1 Pro up
in front of the desired sound source and slowly raise the MIC trim control until you
see the Peak LED light up. Then, turn the mix trim control down until the LED does
not light any more. On most mixers, the ideal setting is that the trim control is turned
up as much as possible without lighting the Peak LED.
Microphone Placement
C1 Pro is a handheld condenser microphone and ideally you should point the
microphone's top net to your mouth. If you are using C1 Pro with a shock mount
for recording any other audio source such as instrument or vocal. In order to
maximize the sound quality, you must pay careful attention to the placement of
your C1 Pro and how it is positioned for the instrument or vocalist that you are
miking. All microphones, especially unidirectional or cardioids microphones, exhibit
a phenomenon know as the “proximity effect”. Very simply put, proximity effect is a
resulting change in the frequency response of a microphone based on the position of
the MIC capsule relative to the sound source. Specically, when you point a cardioid
MIC directly at the sound source (on-axis) you will get the best frequency response,
however, when you start pointing the microphone slightly away (off-axis) you will
notice the low frequency dropping off and the microphone will start to sound thinner.
For most vocal applications you’ll want to position the microphone directly in front
of the artist. The same may be true for miking instruments. However, you can make
some pretty amazing equalization adjustments by slightly changing the angle of the

8
capsule to the sound source. This can be a very useful technique in capturing the
optimum sound of drum set, acoustic guitar, piano or other instruments in a live room
or sound stage. Experimentation and experience are the best teachers in getting
good sounds, so plug in!
P-Poping
P-Poping is that annoying pop that you can get when the microphone diaphragm
gets a blast of air from a vocalist pronouncing words with the letter “P” included. C1
Pro is shipped with a hollow form pop-screen for this purpose.
Mounting the C1 Pro
Mount your C1 Pro into the provided
suspension mount as the diagrams
illustrated below.

9
Specications
Acoustical operating principle......................... Pressure gradient transducer
Directional pattern .......................................... Cardioid
Frequency range ............................................ 20Hz – 20KHz
Sensitivity ....................................................... -33±2dBV/Pa
Min. load impedance ...................................... 50 Ohms
Rated Impedance ........................................... 1000 Ohms
SPL................................................................. 132dB
S/N ratio.......................................................... 82dB
Dynamic range ............................................... 128dB
Power supply voltage ..................................... +48V(+/-4)
Current consumption ...................................... ≤3mA
Weight (Microphone only)........................... 0.26Kg (0.62lb)
(with suspension mount)................. 0.801Kg (1.76.lb)
Dimensions..................................................... 48mm (dia.) x 188mm (L)
..................................................... 0.16” (dia.) x 0.62” (L)

10
Services
If your C1 Pro needs servicing, follow these instructions.
Check our online Help Center at http://support.iconproaudio.com/hc/en-us, for
information, knowledge, and downloads such as:
1. FAQ
2. Download
3. Learn More
4. Forum
Very often you will nd solutions on these pages. If you don’t nd a solution, create
a support ticket at our online Help Center at the link below, and our technical support
team will assist you as soon as we can.
Navigate to http://support.iconproaudio.com/hc/en-us and then sign in to submit
a ticket.
As soon as you have submitted an inquiry ticket, our support team will assist you to
resolve the problem with your ICON ProAudio device as soon as possible.
To send defective products for service:
1. Ensure the problem is not related to operation error or external system devices.
2. Keep this owner's manual. We don't need it to repair the unit.
3. Pack the unit in its original packaging including end card and box. This is very
important. If you have lost the packaging, please make sure you have packed
the unit properly. ICON is not responsible for any damage that occurs due to
non-factory packing.
4. Ship to the ICON tech support center or the local return authorization. See our
service centers and distributor service points at the link below:

If you are located in US
Send the product to:
North America
Mixware, LLC – U.S. Distributor
11070 Fleetwood Street – Unit F.
Sun Valley, CA 91352; USA
Tel.: [phone]
Contact: www.mixware.net/help

If you are located in Europe
Send the product to:
Sound Service
GmbHEuropean
HeadquarterMoriz-Seeler-Straße
3D-12489 Berlin
Telephone: [phone]
Fax: [phone]
E-Mail: [email protected]
If you are located in Hong Kong
Send the product to:
ASIA OFFICE:
Unit F, 15/F., Fu Cheung Centre,
No. 5-7 Wong Chuk Yueng
Street, Fotan,
Sha Tin, N.T., Hong Kong.
Tel: [phone]
Fax: [phone]
Email: info.asia@icon-global.
com

5. For additional update information please visit our website at:
www.iconproaudio.com

11
