ICON ProCon D300 Series User manual

D300 Series
pH/ORP Digital Analyzer Controller
Operating Manual

D300 Series Operating Manual
2◀◀
|
Contents
Preface .........................................................................................................................................................................................................................................3
Features...........................................................................................................................................................................................................................................3
Technical Specications ...................................................................................................................................................................................................... 4
Typical Application.................................................................................................................................................................................................................. 4
Instrument Connection........................................................................................................................................................................................................5
Dimension......................................................................................................................................................................................................................................5
Instrument Installation .........................................................................................................................................................................................................6
Keypad Descriptions...............................................................................................................................................................................................................7
Display Descriptions ...............................................................................................................................................................................................................8
Menu Structure ..........................................................................................................................................................................................................................9
Measurement Settings (Quick Start).........................................................................................................................................................................12
Calibration Settings (Quick Start) ................................................................................................................................................................................ 13
Alarm Settings (Quick Start)............................................................................................................................................................................................14
Current Settings (Quick Start)........................................................................................................................................................................................15
Communication Settings (Quick Start) ...................................................................................................................................................................16
System Settings (Quick Start).........................................................................................................................................................................................17
Maintenance Settings (Quick Start)...........................................................................................................................................................................18
Measurement Setup.............................................................................................................................................................................................................19
pH Buffer Reading vs Temperature...........................................................................................................................................................................20
Calibration Setup....................................................................................................................................................................................................................20
Alarm Setup...............................................................................................................................................................................................................................24
Current Setup ...........................................................................................................................................................................................................................24
System Setup............................................................................................................................................................................................................................26
Maintenance..............................................................................................................................................................................................................................26
Troubleshooting......................................................................................................................................................................................................................27
Warranty.......................................................................................................................................................................................................................................27

D300 Series Operating Manual
3◀◀
|
Preface
Please read this manual carefully before use.
When receiving the instrument, please open the package carefully, check whether the instrument and accessories are damaged by
transportation and whether the accessories are complete. If any abnormalities are found, please contact our after-sales service department
or regional customer service center, and keep the package for return processing.
This instrument is an analytical measurement and control instrument with highly precision.Only skilled,trained or authorized person should
carry out installation, setup and operation of the instrument.Ensure that the power cable is physically separated from the power supply
when connection or repair. Once the safety problem occurs, make sure that the power to the instrument is off and disconnected.
For example,
1. Apparent damage to the analyzer
2. The analyzer does not work properly or provides specied measurements
3. The analyzer has been stored for a long time in an environment where the temperature exceeds 70°C
The analyzer must be installed by licensed professionals in accordance with relevant local specications, and instructions are included in
the operation manual. Comply with the technical specications and input requirements of the controller.
Features
The instrument is equipped with different types of pH or ORP sensors. Widely used in power plants, petrochemical industry, metallurgical
electronics, mining, paper industry, biological fermentation engineering, medicine, food and beverage, environmental protection water
treatment, aquaculture, modern agricultural planting and other industries. The pH (acidity and alkalinity) value, ORP (redox potential) value
and temperature value of water solution were continuously monitored and controlled.
Large LCD display
Intelligent menu operation
Automatic calibration
Manual + automatic temperature compensation
Two (2) relay control switches
4-20mA & RS485
Multi-parameter display — simultaneously shows pH, ORP and temperature
Password protection

D300 Series Operating Manual
4◀◀
|
Technical Specifications
Measuring Range pH: -2 – 16pH | ORP: -2000 – +2000mV
Unit pH | mV
Resolution pH: 0.001pH | ORP: 1mV
Basic Error pH: 0.001pH | ORP: 1mV
Temperature Range 14 – 302°F | -10 – 150°C (Sensor Selection Dependant)
Temperature Resolution 0.18°F | 0.1°C
Temperature Accuracy ±0.54°F | ±0.3°C
Temperature Compensation Manual or Automatic
Stability pH: 0.01pH/24h | ORP: 1mV/24h
Outputs Two (2) 4–20mA | 20–4mA | 0–20mA
Communication RS485 MODBUS RTU
Relay Control Contact 5A 240VAC | 5A – 28VDC
Power Supply 9 – 36VDC (std) | 85 – 265VAC | Power Consumption 3W
Working Temperature 14 – 140°F | -10 – 60°C
Relative Humidity ≤ 90%
Enclosure Rating IP65
Weight 0.5kg
Dimensions 98 × 98 × 130mm
Installation Opening Size 93 X 93mm
Installation methods Panel |Pipe |Wall
Typical Application

D300 Series Operating Manual
5◀◀
|
Instrument Connection
N/C NO 1
N/C COM 1
Temp NC 1
Temp NO 2
Input COM 2
Ref NC 2
N/C pH/ORP
N/C
N/C Pow DC+
(9–36V)
Cur 1+ Pow DC-
Com - Pow PE
Cur 2+
RS-485 B
RS-485 A
Pow ACL
(85–265V)
Pow AC N
Pow PE
Terminal Function Terminal Function
N/C No Connection NO 1 High set relay working position
N/C No Connection COM 1 Alarm relay common
Temp Temperature Sensor NC 1 High set relay resting position
Temp Temperature Sensor NO 2 Low set relay working position
Input Measurement COM 2 Alarm relay common
Ref Reference NC 2 Low set relay resting position
N/C No Connection
N/C No Connection Pow DC + (9 – 36V) DC power + (9 – 36V)
N/C No Connection Pow DC - DC power -
Cur 1 + Current output 1+ Pow PE Earth wire
Com - Current output common
Cur 2 + Current output 2+ Pow ACL (85 – 265V) Live wire
RS485 B Communication Terminal Pow AC N Neutral wire
RS485 A Communication Terminal Pow PE Earth wire
Dimension

D300 Series Operating Manual
6◀◀
|
Instrument Installation
93 mm (± 0.5 mm)
93 mm (± 0.5 mm)
Control Panel Installation
Wall Mounting
53 mm
18.4 mm
5mm
Fixture Dimension
Insert into the fixture along the chuteInstall bracket on the wall first
Installation of back
cover with
waterproofing seal

D300 Series Operating Manual
7◀◀
|
Keypad Descriptions

D300 Series Operating Manual
8◀◀
|
Display Descriptions
Check all pipe connections and electrical connections before use. The instrument will display as shown in the gure below after the power
is turned on.
Status Normal 25°C Temperature
Value + Unit
Main Display
7.00 pH
pH Output I1: 6.88 I2: 9.41 Temperature
Output
Value + Unit
pH Mode
7.00 pH
ORP Output I1: 13.05 I2: 7.33 Temperature
Output
Value + Unit
ORP Mode
254 mV

D300 Series Operating Manual
9◀◀
|
Menu Structure
Press [MENU] key to enter programming mode:
If the monitor prompts you to enter the calibration security password, press the or key to set the calibration security password, and
then press the [ENT] key to conrm the calibration security password. No initial password here, please enter directly by pressing the
[ENT] key.
Item Display Selection Sub Menu
Measurement
Electrode pH
ORP
Temperature
Type
NTC2.252 kΩ
NTC10 kΩ
Pt100
Pt1000 (Default)
Offset 0.00 (Default)
Input
Automatic (Default)
Manual
N/A
Unit °C (Default)
°F
Calibration
S-S-C
(Standard solution
calibration pH)
pH
pH 2 points 4/6/9
pH 3 points 4/6/9
pH 2 points 4/7/10
pH 3 points 4/7/10
S-S-C query
(Standard solution
calibration query pH)
Offset 1
Slope 1
Offset 2
Slope 2
On-site calibration Offset Adjustment 1
On-site query Linear
Offset
S-S-C
(Standard solution
calibration ORP)
ORP S-P (single point)
S-S-C
(Standard solution
calibration ORP)
ORP slope
On-site calibration
On-site query Offset
Linear

D300 Series Operating Manual
10◀◀
|
Item Display Selection Sub Menu
Alarm
Relay 1 (pH)
Channel pH
Alarm Mode Low Alarm
High Alarm
Limit
Hysteresis 0.00 (Default)
Relay 2 (pH)
Channel pH
Alarm Mode Low Alarm
High Alarm
Limit
Hysteresis 0.00 (Default)
Relay 1 (ORP)
Channel ORP
Alarm Mode Low Alarm
High Alarm
Limit
Hysteresis 100 (Default)
Relay 2 (ORP)
Channel ORP
Alarm Mode Low Alarm
High Alarm
Limit
Hysteresis 100 (Default)
Current setting
Current 1
Channel Major measured value (Default)
Temperature
Output Type 4-20mA | 20-4mA | 0-20mA
Upper Limit 14.00 (Default for pH)
2000 (Default for ORP)
Lower Limit 0.00 (Default for pH)
-2000 (default for ORP)
Current 2
Channel Major measured value (Default)
Temperature
Output Type 4-20mA | 20-4mA | 0-20mA
Upper Limit 100 (Default)
Lower Limit 0.0 (Default)
Communication
Baud Rate
4800 Bps
9600 Bps (Default)
19200 Bps
Parity bit
No Parity (Default)
Even Parity
Odd Parity
Stop bit 1 bit (Default)
2 bits
Address 1 (default) 1 – 247

D300 Series Operating Manual
11◀◀
|
Item Display Selection Sub Menu
System
Language English
Display
Speed
Low
Standard
Medium
High
Backlight
30 sec
1 min
5 min (Default)
15 min
30 min
Always on
Password No password (Default)
Series No XXXXXXXXXX
Version VER6.1.00
Restore Calibration
Parameter
Maintenance
Current2 4mA
Current
Current1 4mA
Current2 20mA
Current2 4mA
Current2 20mA
Relay Test Relay 1: off
Relay 1: off

D300 Series Operating Manual
12◀◀
|
Measurement Settings (Quick Start)

D300 Series Operating Manual
13◀◀
|
Calibration Settings (Quick Start)

D300 Series Operating Manual
14◀◀
|
Alarm Settings (Quick Start)

D300 Series Operating Manual
15◀◀
|
Current Settings (Quick Start)

D300 Series Operating Manual
16◀◀
|
Communication Settings (Quick Start)

D300 Series Operating Manual
17◀◀
|
System Settings (Quick Start)

D300 Series Operating Manual
18◀◀
|
Maintenance Settings (Quick Start)

D300 Series Operating Manual
19◀◀
|
Measurement Setup
Electrode Setup
When the pH electrode connected to this instrument, you need to select the electrode type as “PH” in this item. It’s the same when the
electrode becomes OPR.
Temperature Setup
There are four kinds of temperature types: NTC2.252K , NTC10K , PT100 and PT1000, user needs to choose the right temp comp for the
electrode to display the right temperature. “Err” means no temp comp.
The user can compare the temperature measured by other standard instruments with the temperature measured by the D300. If there is
an error, you can use the “temperature offset” to modify it, assuming that the temperature measured by D300 is 25°C, and the temperature
measured by other standard instruments is 24.8°C. Then enter “-0.2°C” here, then press “Esc”, and then select “Save”.
You can choose Auto, Manual and None in `Temperature input`. Choosing `Auto` the temperature is from electrode. Choosing “Manual”,
user is able to input the temperature. Choosing “None” there will be no display of temperature, the default temperature of the system is
25°C as comp.
User can choose (°C) and (°F)
Temperature Offset Setting
Temperature Input Setting
Temperature Units Setting

D300 Series Operating Manual
20◀◀
|
pH Buffer Reading vs Temperature
Temp(°C) pH 4.01 pH 6.86 pH 9.18 pH 4.00 pH 7.00 pH 10.01
04.01 6.98 9.47 4.01 7.12 10.32
54.01 6.95 9.38 4.00 7.09 10.25
10 4.00 6.92 9.32 4.00 7.06 10.18
15 4.00 6.90 9.27 4.00 7.04 10.12
20 4.00 6.88 9.22 4.00 7.02 10.06
25 4.01 6.86 9.18 4.00 7.00 10.01
30 4.01 6.85 9.14 4.01 6.99 9.97
35 4.02 6.84 9.10 4.02 6.98 9.93
40 4.03 6.84 9.07 4.03 6.97 9.89
45 4.04 6.83 9.04 4.04 6.97 9.86
50 4.06 6.83 9.01 4.06 6.97 9.83
55 4.08 6.83 8.99 4.07 6.97 9.91
60 4.10 6.84 8.96 4.09 6.98 9.97
70 4.12 6.85 8.92 4.12 6.99 9.76
80 4.16 6.86 8.89 4.16 7.00 9.74
90 4.20 6.88 8.85 4.20 7.02 9.73
Calibration Setup
Press [ESC] and [ENT] “Calibration Setup” If you are prompted to enter the password, you need to enter the password set in advance.
If the password is not set, you can directly select “OK” and press the [ENT] key to enter:
Standard
liquid calibration
pH 2 points calibration NIST: 4.00, 6.86, 9.18 Calibrate middle point rst
USA: 4.01, 7.01, 10.01 Calibrate middle point rst
pH 3 points calibration NIST: 4.00, 6.86, 9.18 Calibrate in order
USA: 4.01, 7.01, 10.01 Calibrate in order
ORP 1 Point Input ORP standard liquid value
Onsite calibration Input the onsite value
Calibration with Standard Liquid (pH, 2 points)
There are two groups of 2-point standard liquid USA: 4.01, 7.01, 10.01 and NIST:
4.00, 6.86, 9.18, The following example uses the NIST standard solution set:
Choose pH standard liquid, press [ENT] to enter the mode
