COBALT Pro™Wall Sensor Activated
Concealed Flush Valve Installation Instructions 101929 : 3200 Series
I-CON Systems, Inc., for product support call 1-866-730-7192 or visit us online at support.i-con.com
One or more products contained herein are protected by U.S. Patent with other undergoing the patent process www.i-con.com/patents
• All plumbing should be installed according to applicable state
and local codes and regulations.
•Before installation of the I-CON flush valve, ensure the water
closet or urinal fixture, drain line, and water supply line are
properly installed.
•Water supply lines must be sized to allow for appropriate water
flow for each fixture.
•Flush all water supply lines of any debris before making any
connecons.
• Do not use pipe sealant or plumbing grease on any components
or couplings, with the excepon of the control stop inlet.
• A smooth jaw or strap wrench should be used for installaon
to prevent damage to the nish of the I-CON ush valve and
components.
• Check to ensure the “L” dimension specied on the ush valve
packaging is correct for your applicaon. “L” Dimension formula
is provided below.
“L” Dimension = Wall Thickness (to the nearest whole inch)
+ 2-3/4”
The I-CON ush valve is designed to operate at water pressures
ranging from 15 to 100psi (103 to 689kPa). The xture type
determines the minimum pressure required for the valve. Most
low-consumpon water closets are designed to operate with a
minimum owing water pressure of 25psi (172kPa).
CONCEALED SENSOR FLUSH VALVES
TOOLS NEEDED
PRIOR TO INSTALLATION
page 1
