ICP DAS USA tDS-722 User manual

tDS-700 Series
User Manual Ver.1.9.1
Tiny Serial-to-Ethernet Device Server
WARRANTY
All products manufactured by ICP DAS are warranted
against defective materials for a period of one year
from the date of delivery to the original purchaser.
WARNING
ICP DAS assumes no liability for damages consequent
to the use of this product. ICP DAS reserves the right
to change this manual at any time without notice. The
information furnished by ICP DAS is believed to be
accurate and reliable. However, no responsibility is
assumed by ICP DAS for its use, nor for any
infringements of patents or other rights of third
parties resulting from its use.
COPYRIGHT
Copyright © 2016 by ICP DAS. All rights are reserved.
TRADEMARKS
Names are used for identification purposes only and
may be registered trademarks of their respective
companies.
CONTACT US
If you have any questions, please feel free to contact
us via email at:
[email protected], [email protected]
SUPPORT
This manual relates to the following modules:
tDS-712, tDS-722, tDS-732
tDS-715, tDS-725, tDS735
tDS-718, tDS-724, tDS-734
tDS-712i, tDS-722i, tDS-732i
tDS-715i, tDS-725i, tDS735i
tDS-718i, tDS-724i, tDS-734i
tDSM-712

Tiny Serial-to-Ethernet Device Server
Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. -2 -
TABLE OF CONTENTS
PACKING LIST............................................................................................................................................................. 4
MORE INFORMATION................................................................................................................................................ 4
1. INTRODUCTION ................................................................................................................................................ 5
1.1 ETHERNET SOLUTIONS.......................................................................................................................................... 7
1.2 VXCOMM TECHNOLOGY......................................................................................................................................... 8
1.3 WEB SERVER TECHNOLOGY................................................................................................................................. 10
2. HARDWARE INFORMATION .......................................................................................................................... 11
2.1 SPECIFICATIONS ................................................................................................................................................. 11
2.2 FEATURES.......................................................................................................................................................... 12
2.3 SELECTION GUIDE............................................................................................................................................... 13
2.4 APPEARANCE ..................................................................................................................................................... 14
2.5 DIMENSIONS ...................................................................................................................................................... 16
2.5.1 tDS-700 Series Module..................................................................................................................................... 16
2.5.2 CA-002 Cable.................................................................................................................................................... 17
2.6 PIN ASSIGNMENTS .............................................................................................................................................. 18
2.6.1 tDS-712/tDS-712i/tDSM-712.......................................................................................................................... 18
2.6.2 tDS-722/tDS-722i ............................................................................................................................................ 18
2.6.3 tDS-732/tDS-732i ............................................................................................................................................ 19
2.6.4 tDS-715/tDS-715i ............................................................................................................................................ 19
2.6.5 tDS-725/tDS-725i ............................................................................................................................................ 20
2.6.6 tDS-735/tDS-735i ............................................................................................................................................ 20
2.6.7 tDS-718/tDS-718i ............................................................................................................................................ 21
2.6.8 tDS-724/tDS-724i ............................................................................................................................................ 21
2.6.9 tDS-734/tDS-734i ............................................................................................................................................ 22
2.7 WIRING NOTES FOR RS-232/485/422 INTERFACES ........................................................................................... 23
2.7.1 RS-232 Wiring.................................................................................................................................................. 23
2.7.2 RS-422 Wiring.................................................................................................................................................. 24
2.7.3 RS-485 Wiring.................................................................................................................................................. 24
3. SETTING UP THE TDS-700 MODULE............................................................................................................. 25
4. WEB CONFIGURATION ................................................................................................................................... 33
4.1 LOGGING IN TO THE TDS-700 WEB SERVER ......................................................................................................... 33
4.2 HOME PAGE ....................................................................................................................................................... 35
4.3 NETWORK SETTING ............................................................................................................................................ 36
4.3.1 IP Address Settings..................................................................................................................................... 36
4.3.2 General Settings ......................................................................................................................................... 39

Tiny Serial-to-Ethernet Device Server
Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. -3 -
4.3.3 Restore Factory Defaults............................................................................................................................ 41
4.3.4 Remote Firmware Update.......................................................................................................................... 43
4.4 SERIAL PORT PAGE ............................................................................................................................................. 44
4.4.1 Port1 Settings............................................................................................................................................. 44
4.5 FILTER PAGE...................................................................................................................................................... 47
4.5.1 Accessible IP (filter is disabled when all zero) .......................................................................................... 47
4.6 MONITOR PAGE.................................................................................................................................................. 49
4.7 CHANGE PASSWORD............................................................................................................................................ 50
4.8 LOGOUT PAGE .................................................................................................................................................... 51
5. TYPICAL APPLICATIONS ................................................................................................................................ 52
5.1 VIRTUAL COM APPLICATION............................................................................................................................... 53
5.2 DIRECT SOCKET CONNECTION APPLICATIONS........................................................................................................ 54
5.3 ETHERNET I/O APPLICATIONS ............................................................................................................................ 57
5.4 PAIR-CONNECTION APPLICATIONS........................................................................................................................ 59
5.5 TCP CLIENT MODE APPLICATIONS....................................................................................................................... 66
6. CGI CONFIGURATION ..................................................................................................................................... 74
6.1 CGI URL SYNTAX............................................................................................................................................... 74
6.2 CGI COMMAND LIST ........................................................................................................................................... 75
APPENDIX A: GLOSSARY ......................................................................................................................................... 77
1. ARP (ADDRESS RESOLUTION PROTOCOL)..................................................................................................................... 77
2. CLIENTS AND SERVERS ............................................................................................................................................... 77
3. ETHERNET................................................................................................................................................................ 78
4. FIRMWARE .............................................................................................................................................................. 78
5. GATEWAY................................................................................................................................................................ 78
6. ICMP (INTERNET CONTROL MESSAGE PROTOCOL)......................................................................................................... 78
7. INTERNET ................................................................................................................................................................ 78
8. IP (INTERNET PROTOCOL)ADDRESS ............................................................................................................................. 79
9. MAC (MEDIA ACCESS CONTROL)ADDRESS .................................................................................................................. 79
10. PACKET .............................................................................................................................................................. 79
11. PING .................................................................................................................................................................. 79
12. RARP (REVERSE ADDRESS RESOLUTION PROTOCOL)................................................................................................. 80
13. SOCKET .............................................................................................................................................................. 80
14. SUBNET MASK..................................................................................................................................................... 80
15. TCP (TRANSMISSION CONTROL PROTOCOL)............................................................................................................. 80
16. TCP/IP .............................................................................................................................................................. 81
17. UDP (USER DATAGRAM PROTOCOL)...................................................................................................................... 81
APPENDIX B: ACTUAL BAUD RATE MEASUREMENT............................................................................................ 82

Tiny Serial-to-Ethernet Device Server
Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. -4 -
Packing List
The shipping package includes the following items:
Note
If any of these items are missing or damaged, please contact the local distributor for
more information. Save the shipping materials and cartons in case you need to ship the
module in the future.
More Information
Documentation
CD:\NAPDOS\tDS-700\Document
http://ftp.icpdas.com/pub/cd/tinymodules/napdos/tds-700/document/
Firmware
CD:\NAPDOS\tDS-700\Firmware
http://ftp.icpdas.com/pub/cd/tinymodules/napdos/tds-700/firmware/
Software
CD:\NAPDOS\Software
http://ftp.icpdas.com/pub/cd/tinymodules/napdos/software/
tDS-700/tDS-700i/tDSM-700 Series
Quick Start
Software CD
CA-002 Cable
Or

Tiny Serial-to-Ethernet Device Server
Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. -5 -
1. Introduction
The tDS-700 is a series of Serial-to-Ethernet device servers that are
designed to add Ethernet and Internet connectivity to any RS-232
and RS-422/485 device, and to eliminate the cable length limitation
of legacy serial communications. By using the VxComm
Driver/Utility, the built-in COM Port of the tDS-700 series can be
virtualized to a standard PC COM Port in Windows. Therefore,
users can transparently access or monitor serial devices over the
Internet/Ethernet without the need for software modification.
tDS-700 device servers can be used to create a pair-connection application (as well as serial-bridge
or serial-tunnel), and then route data between two serial devices via TCP/IP. This is useful when
connecting mainframe computers, servers or other serial devices that do not themselves have
Ethernet capability. By virtue of its protocol independence and flexibility, the tDS-700 meets the
demands of virtually any network-enabled application.

Tiny Serial-to-Ethernet Device Server
Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. -6 -
In harsh industrial environments, the tDS-700 series (for i version) also adds 2500 VDC and +/- 4 kV
ESD protection component that diverts the potentially damaging charge away from sensitive circuit
to protects the module and equipment from the sudden and momentary electric current.
To achieve maximum space savings, the tDS-700 is offered in an amazingly small form-factor that
enables it to be easily installed anywhere, even directly attached to a serial device or embedded
into a machine. The tDS-700 features a powerful 32-bit MCU that allows it to efficiently handle
network traffic. The tDS-700 offers true IEEE 802.3af-compliant (classification, Class 1) Power-over-
Ethernet (PoE) functionality using a standard category 5 Ethernet cable that allows it to receive
power from a PoE switch such as the NS-205PSE. If there is no PoE switch available on site, the tDS-
700 can accepts power input from a DC adapter.
Comparison of Device Servers:
Series
Features
PPDS
PDS
DS
tDS
tGW
Virtual COM
Yes
Yes
Yes
Yes
-
Programmable
Yes
Yes
-
-
-
PoE
Yes
-
-
Yes
Yes
Modbus Gateway
Yes
-
-
-
Yes
Multi-client
About 20 Sockets
1 Sockets/Port
10 Sockets/Port
Remarks
Professional
Powerful
Isolation for
DS-715
Cost-effective,
Entry-level
Cost-effective,
Entry-level

Tiny Serial-to-Ethernet Device Server
Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. -7 -
1.1 Ethernet Solutions
Nowadays, the Ethernet protocol has become the foremost standard for local area networks.
Connectivity via the Internet is now common in many of the latest applications from home
appliances, to vending machines, to testing equipment, to UPS, etc. An Ethernet network can link
office automation and industrial control networks, access remote systems and share data and
information between machines from multiple vendors, and also provides a cost-effective solution
for industrial control networks.

Tiny Serial-to-Ethernet Device Server
Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. -8 -
1.2 VxComm Technology
In general, writing a TCP/IP program is more difficult than writing a COM Port program. Another
issue is that perhaps the existing the COM Port communication system was built many years ago
and is now outdated.
As a result, a new technology, VxComm was developed to virtualize the COM Ports of the tDS-700
to allow up to 256 COM Ports to be used on a central computer. The VxComm driver saves time
when accessing serial devices through the Ethernet without the need for reprogramming the COM
Port software on the PC.

Tiny Serial-to-Ethernet Device Server
Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. -9 -
The VxComm driver controls all the details of the Ethernet TCP/IP programming technique,
meaning that, with the assistance of tDS-700 and VxComm technology, your COM Port program will
be able to access your serial devices through the Ethernet in the same way as through a COM Port.

Tiny Serial-to-Ethernet Device Server
Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. -10 -
1.3 Web Server Technology
Web server technology enables the tDS-700 to be configured via a standard web browser interface,
e.g. Google Chrome, Internet Explorer, or Firefox, etc. This means that it is easy to check the
configuration of the tDS-700 via an Ethernet network without needing to install any other software
tools, thereby reducing the learning curve required for maintaining the device.

Tiny Serial-to-Ethernet Device Server
Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. -11 -
2. Hardware Information
This chapter provides a detailed description of the front panel, the hardware specifications, the pin
assignments, the wiring notes and the dimensions for the tDS-700 series modules.
2.1 Specifications
Model
tDS-712
tDS-712i
tDSM-
712
tDS-722
tDS-722i
tDS-732
tDS-732i
tDS-715
tDS-715i
tDS-725
tDS-725i
tDS-735
tDS-735i
tDS-718
tDS-718i
tDS-724
tDS-724i
tDS-734
tDS-734i
System
CPU
32-bit ARM
Communication Interface
Ethernet
10/100 Base-TX, 8-pin RJ-45 x 1, (Auto-negotiating, Auto-MDI/MDIX, LED indicator)
PoE (IEEE 802.3af, Class 1)
COM1
5-wire RS-232
5-wire
RS-232
3-wire
RS-232
2-wire
RS-485
4-wire
RS-422
2-wire
RS-485
2-wire
RS-485
3-wire
RS-232
2-wire
RS-485
2-wire
RS-485
2-wire
RS-485
4-wire
RS-422
COM2
-
5-wire
RS-232
3-wire
RS-232
-
2-wire
RS-485
2-wire
RS-485
-
5-wire
RS-232
3-wire
RS-232
COM3
-
-
3-wire
RS-232
-
-
2-wire
RS-485
-
-
3-wire
RS-232
Self-Tuner
-
Yes, automatic RS-485 direction control
RS-
485
Bias Resistor
-
Yes, 1 KΩ
Node
-
254 (max.)
UART
16c550 or compatible
Isolation
2500 VDC for only tDS-712i / 722i / 732i / 715i / 725i / 735i / 718i / 724i / 734i
ESD Protection
+/-4 kV for only tDS-712i / 722i / 732i / 715i / 725i / 735i / 718i / 724i / 734i
COM Port Format
Baud Rate
115200 bps Max.
Data Bit
5, 6, 7, 8
Parity
None, Odd, Even, Mark, Space
Stop Bit
1, 2
Power
Power Input
PoE: IEEE 802.3af, Class 1
DC jack: +12 ~ 48 VDC
Power Consumption
0.07 A @ 24 VDC
Mechanism
Connector
Male DB-9 x1
10-Pin Removable Terminal Block x 1
Mounting
DIN-Rail
Case
Plastic
Metal
Plastic
Environment
Operating Temperature
-25 ~ +75 °C
Storage Temperature
-30 ~ +80 °C
Humidity
10 ~ 90% RH, non-condensing
Note: COM1/COM2/COM3 = TCP Port 10001/10002/10003

Tiny Serial-to-Ethernet Device Server
Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. -12 -
2.2 Features
Incorporates any RS-232/422/485 serial device in Ethernet
Data transmission via Virtual COM or raw TCP connection
VxComm Driver for 32-bit and 64-bit Windows XP/2003/2008/Vista/7/8/10
Max. connections: 1 socket per serial port is suggested
Supports pair-connection (serial-bridge, serial-tunnel) applications
Supports TCP client-mode and TCP server-mode operations
Supports UDP responder for device discovery (UDP Search)
Static IP or DHCP network configuration
Easy firmware update via the Ethernet (BOOTP, TFTP)
Tiny Web server for configuration (HTTP)
Contains a 32-bit MCU that efficiently handles network traffic
10/100 Base-TX Ethernet, RJ-45 x1 (Auto-negotiating, auto MDI/MDIX, LED Indicators)
Includes redundant power inputs: PoE (IEEE 802.3af, Class 1) and DC jack
Allows automatic RS-485 direction control
2500 VDC isolation and +/- 4 kV ESD protection for i versions
Male DB-9 or terminal block connector for easy wiring
Tiny form-factor and low power consumption
RoHS compliant with no Halogen
Cost-effective device servers

Tiny Serial-to-Ethernet Device Server
Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. -13 -
2.3 Selection Guide
Model
CPU
Ethernet
Baud
Rate
COM1
COM2
COM3
Non-
Isolated
Isolated
Case
tDS-712
tDS-712i
Plastic
32-bit
MCU
10/100
Base-TX,
PoE
115200
bps
5-wire RS-232
-
-
tDSM-712
-
Metal
tDS-722
tDS-722i
Plastic
5-wire RS-232
5-wire RS-232
-
tDS-732
tDS-732i
Plastic
3-wire RS-232
3-wire RS-232
3-wire RS-232
tDS-715
tDS-715i
Plastic
2-wire RS-485
4-wire RS-422
-
-
tDS-725
tDS-725i
Plastic
2-wire RS-485
2-wire RS-485
-
tDS-735
tDS-735i
Plastic
2-wire RS-485
2-wire RS-485
2-wire RS-485
tDS-718
tDS-718i
Plastic
3-wire RS-232
-
-
2-wire RS-485
4-wire RS-422
tDS-724
tDS-724i
Plastic
2-wire RS-485
5-wire RS-232
-
tDS-734
tDS-734i
Plastic
2-wire RS-485
3-wire RS-232
3-wire RS-232
3-Wire RS-232: RxD, TxD, GND (Non-isolated)
5-Wire RS-232: RxD, TxD, CTS, RTS, GND (No-isolated)
2-Wire RS-485: DATA+, DATA-, GND (Non-isolated)
4-Wire RS-422: TxD+, TxD-, RxD+, RxD-, GND (Non-islated)

Tiny Serial-to-Ethernet Device Server
Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. -14 -
2.4 Appearance
4.
Operating Mode Switch
Init Mode: Configuration mode
Run Mode: Firmware operation mode
For tDS-700 series modules, the operating mode switch is set to the Run
position by default. In order to update the firmware for the tDS-700 series
module, the switch must be moved from the Run position to the Init
position. The switch must be returned to the Run position after the update
is complete.
Front View
1.
Robust Insulated and Fire-retardant Case
2.
Serial COM Ports
The number of serial COM Ports available
depends on the type of tDS-700 series
module. For more detailed information
regarding the pin assignments for the
Serial COM ports, refer to Section 2.6 Pin
Assignments.
3.
S1: System LED indicator
Once power is supplied to the tDS-700
series module, the system LED indicator
will illuminate. An overview of the LED
functions is given below:
Function
System LED Behavior
Running Firmware
Steady ON
Network Ready
Slow flashing –
Once every 3 seconds
Serial Port Busy
Rapid flashing –
Once every 0.2 seconds







Tiny Serial-to-Ethernet Device Server
Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. -15 -
5.
+12 to +48 VDC Jack:
The tDS-700 is equipped with a +12 VDC to +48 VDC jack that can be used to
connect a power supply. If no PoE switch is available on site, a DC adapter can
be used to power the tDS-700 module.
6.
PoE and Ethernet RJ-45 Jack
The tDS-700 series module is equipped with an RJ-45 jack that is used as the
10/100 Base-TX Ethernet port and features networking capabilities. When an
Ethernet link is detected and an Ethernet packet is received, the Link/Act LED
(Orange) indicator will be illuminated. When power is supplied via PoE (Power-
over-Ethernet), the PoE LED (Green) indicator will be illuminated.

Tiny Serial-to-Ethernet Device Server
Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. -16 -
2.5 Dimensions
The following diagrams provide the dimensions of the tDS-700 series module and CA-002 cable that
can be used as a reference when defining the specifications and the DC power supply plug for any
custom enclosures. All dimensions are in millimeters.
2.5.1 tDS-700 Series Module
tDS-712/712i:
tDSM-712:

Tiny Serial-to-Ethernet Device Server
Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. -17 -
tDS-722/722i/732/732i/715/715i/725/725i/735/735i/718/718i/724/724i/734/734i:
2.5.2 CA-002 Cable
Pin Assignment
P1
P2
1 RED OPEN
2 BLACK OPEN
Note: Cable color: BLACK
NO
DESCRIPTION
QTY
UNIT
1
UL2464 18AWG 2C(RED/BLACK)
0D5.0 COLOR BLACK
1
PCS
2
DC PLUG 5.5*2.1
1
PCS
3
PVC:45/P BLACK
G

Tiny Serial-to-Ethernet Device Server
Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. -18 -
2.6 Pin Assignments
2.6.1 tDS-712/tDS-712i/tDSM-712
2.6.2 tDS-722/tDS-722i
tDS-712/tDSM-712
tDS-712i
Terminal No.
Pin Assignment
COM1
09
N/A
N/A
08
CTS1
CTS1
07
RTS1
RTS1
06
N/A
N/A
05
GND
ISO.GND
04
N/A
N/A
03
TxD1
TxD1
02
RxD1
RxD1
01
N/A
N/A
tDS-722
tDS-722i
Terminal No.
Pin Assignment
10
F.G.
F.G.
COM2
09
CTS2
CTS2
08
RTS2
RTS2
07
RxD2
RxD2
06
TxD2
TxD2
COM1
05
GND
ISO.GND
04
CTS1
CTS1
03
RTS1
RTS1
02
RxD1
RxD1
01
TxD1
TxD1

Tiny Serial-to-Ethernet Device Server
Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. -19 -
2.6.3 tDS-732/tDS-732i
2.6.4 tDS-715/tDS-715i
tDS-732
tDS-732i
Terminal No.
Pin Assignment
10
F.G.
F.G.
COM3
09
GND
ISO.GND
08
RxD3
RxD3
07
TxD3
TxD3
COM2
06
GND
ISO.GND
05
RxD2
RxD2
04
TxD2
TxD2
COM1
03
GND
ISO.GND
02
RxD1
RxD1
01
TxD1
TxD1
tDS-715
tDS-715i
Terminal No.
Pin Assignment
10
F.G.
F.G.
09
N/A
N/A
08
N/A
N/A
07
N/A
N/A
06
N/A
N/A
RS-485/RS-422
05
GND
ISO.GND
04
RxD1-
RxD1-
03
RxD1+
RxD1+
02
TxD1-/D1-
TxD1-/D1-
01
TxD1+/D1+
TxD1+/D1+

Tiny Serial-to-Ethernet Device Server
Copyright © 2016 ICP DAS CO., Ltd. All Rights Reserved. -20 -
2.6.5 tDS-725/tDS-725i
2.6.6 tDS-735/tDS-735i
tDS-725
tDS-725i
Terminal No.
Pin Assignment
10
F.G.
F.G.
09
N/A
N/A
08
N/A
N/A
07
N/A
N/A
COM2
06
GND
ISO.GND
05
D2-
D2-
04
D2+
D2+
COM1
03
GND
ISO.GND
02
D1-
D1-
01
D1+
D1+
tDS-735
tDS-735i
Terminal No.
Pin Assignment
10
F.G.
F.G.
COM3
09
GND
ISO.GND
08
D3-
D3-
07
D3+
D3+
COM2
06
GND
ISO.GND
05
D2-
D2-
04
D2+
D2+
COM1
03
GND
ISO.GND
02
D1-
D1-
01
D1+
D1+
