PRODUCT INFORMATION October 2002
More Analog Inputs for T1 µPLCs
Toshiba Houston offers the Eagle analog I/O for the T1 Series µPLCs. The Eagle I/O is universal
analog I/O. Eagle I/O allows T1 PLCs to work with the following analog signals.
For the analog inputs, the Eagle I/O performs the A to D (analog to digital) conversion and loads a
digital value directly into a T1 register. For analog outputs, the Eagle I/O reads a digital value out
ofa T1 register and performs a D to A (digital to analog conversion). Analog signal types and
PLC registers are defined using the included simple setup software.
Simple process control has never been easier or more cost effective. Now the analog values
of temperature, pressure, flow, weight, etc. canbe included into the sequencing, interlocking and
permissive control performed by the PLC.
For more information contact your nearest Toshiba programmable controller distributor, or visit the Toshiba Houston
Industrial website, www.tic.toshiba.com.
Analog Inputs
Analog Outputs
♦Thermocouples ♦0-20 mA ♦4-20 mA
♦RTDs ♦4-20 mA ♦0-100 mV
♦0-50 mV ♦0-100 mV ♦0-10 Vdc
Eagle
0201
2 Analog Inputs
1 Analog Output
Eagle 0404
4 Analog Inputs
4 Analog Output
Eagle 0800
8 Analog
I
nputs
Also
Available

SPECIFICATIONS
ANALOG INPUTS
ITEM SPECIFICATION
Part Number: See Order Numbers Below
I/O Registers Assigned: None (Uses Data Registers, 1 Register per Channel Designated by Sfwr)
Input Range: Thermocouple
Resolution
J, K, R, S, T, E, N, & B . 0-100 mV, Cold Junction Compensation Error
1°maximum, 0.5°C typical.
Input Range: RTD
Resolution
PT100 (0.00395 and 0.00385), 3 Wire Compensation, Current Sense
0.5ma. Range: -200°to 800°C
Input Range: Voltage
Current
Resolution
0-100 mV, 0-10 V (via PLC scaling/external shunt resistor)
0-20 mA
12 bit
ANALOG OUTPUTS
ITEM SPECIFICATION
Part Number: See Order Numbers Below
I/O Registers Assigned: None (Uses Data Registers, 1 Register per Channel Designated by Sfwr)
Output Range: Voltage
Current
0-10 V, Minimum Load = 400 Ω
4-20 mA Maximum Load = 500 Ω
GENERAL
ITEM SPECIFICATION
Communication Ports: PLC
IBM
Connects to T1 Programming Port
Connects to Computer for Setup Connects to OIS for PLC Access
Temperature: Operating: 0°to 50°C Storage: -25°to 80°C
Humidity: 10% to 90% Non condensing
Immunity to ESD: Level 3 per IEC61000-4-2
Immunity to Transients: Level 3 per IEC61000-4-4
Radiated Susceptibility: Level 3 per IEC61000-4-3
Emissions: EN55011 CISPR A
Certifications: CE, CSA
Isolation: Analog isolated from Digital, no isolation between channels.
Size Eagle 0800 & 0404 155mm x 102mm x 48mm
Eagle 0201 94mm x 42mm x 47 mm
Mounting: DIN rail or through hole
Weight Eagle 0800 & 0404:0.5 kg Eagle 020:1 02 kg
ORDER NUMBERS
ITEM DESCRIPTION
Eagle0201U 2 Universal Analog Inputs, 1 Analog Output.
Eagle0404U 4 Universal Analog Inputs, 4 Analog Outputs.
Eagle-0800U 8 Universal Analog Inputs.
TKEAGLE05T1 Cable, 50 cm, Connects T1 to Eagle Exp.Unit
TKEAGLE20T1 Cable, 2 m, Connects T1 to Eagle Exp.Unit1
TKEAGLE20T2 Cable, 2 m, Connects T2 to Eagle Exp.Unit
NOTES: 1. Each Eagle unit contains setup software.
2. Connection cablesmust be ordered separately
