M-4132 User Manual (Version 1.60, May/2014) PAGE：1
TM
M - 4 1 3 2
User’s Manual
Version 1.60

M-4132 User Manual (Version 1.60, May/2014) PAGE：2
Warranty
All products manufactured by ICP DAS are under warranty regarding
defective materials for a period of one year from the date of delivery to the
original purchaser.
Warning
ICP DAS assumes no liability for damages resulting from the use of this
product. ICP DAS reserves the right to change this manual at any time
without notice. The information furnished by ICP DAS is believed to be
accurate and reliable. However, no responsibility is assumed by ICP DAS
for its use, or for any infringements of patents or other right of third parties
resulting from its use.
Copyright
Copyright 2014 by ICP DAS. All rights are reserved.
Trademark
The names used for identification only may be registered trademarks of
their respective companies.
List of Revision
Date Author Version Revision
2014/05/22 Raiden 1.60 Release

M-4132 User Manual (Version 1.60, May/2014) PAGE：3
Table of Contents
1. Introduction…………………………………………………………... 4
1.1 Features ............................................................................................ 5
1.2 Hardware Specifications .................................................................. 6
2. Hardware……………………………………………………………... 8
2.1 Pin Assignment ................................................................................ 8
2.2 Wiring Instructions......................................................................... 10
2.3 Dip Switch and Trigger button ...................................................... 12
2.4 LED Status Indicators .................................................................... 14
2.5 Communication Port ...................................................................... 15
3. Configuration and Operation with Web Browser……………………16
3.1 Connection Setting ......................................................................... 16
3.2 Web Configuration—function menu ............................................. 20
3.3 Web Configuration—setup page.................................................... 22
4. Application………………………………………………………….. 48
4.1 Pair Connection.............................................................................. 48
4.2 Broadcast Connection .................................................................... 49
4.3 ETM Operation .............................................................................. 50
5. VxComm Applications………………………………………………52
5.1 Introduction .................................................................................... 52
5.2 Architecture .................................................................................... 52
5.3 Installing the VxComm Driver ...................................................... 53
5.4 VxComm communication test ....................................................... 56
6. Troubleshooting……………………………………………………...58
7. FAQ………………………………………………………………….59
8. Dimensions…………………………………………………………..70

M-4132 User Manual (Version 1.60, May/2014) PAGE：4
1. Introduction
The M-4132 module is specially designed for the remote maintenance
solution with voice streaming. This module provides 2 major technologies
on networking: Voice streaming and Pair connection functions. The Pair
connection means that the user can operate remote COM port device via
Ethernet TCP/IP protocol just like a local COM port and the Voice
streaming means the user can talk to remote operator while operate remote
COM-linked devices. Refer to the following graph. Furthermore, M-4132
integrates the Virtual com technology. That can resolve the insufficiency
of real com port in PC. By applying this technology, the maintenance man
can take the remote maintenance or monitor whatever time or place.
Figure 1: Voice streaming

M-4132 User Manual (Version 1.60, May/2014) PAGE：5
Figure 2: Pair connection
1.1 Features
● Support voice streaming on network
● Provide pair connection (RS-232,RS-485) on network
● Support server and client function.
● Server mode can manage max 64 clients. (Clients can be M-4132,
M2M-720-A, M2M-710D..)
● Support voice broadcast function in server mode.
● Support Virtual COM technology
● Support VPN (Virtual Private Network) technology
● Support DES/AES encryption and decryption
● Web-based administration
● Linux 2.6 platform
● Support TCP/IP, DHCP, PPPoE protocols
● Provide dynamic DNS function to resolve the problem without the fixed
real IP
● Provide event record and e-mail function
● Built-in web server, FTP server
● Built-in RTC

M-4132 User Manual (Version 1.60, May/2014) PAGE：6
● Built-in self-tuner ASIC chip for RS-485 port
● 2500V isolated on RS-485 port
● Provide LED indicators
● Robust, fan less design
● CE/FCC, EMI, RoHS compliance
1.2 Hardware Specifications
Item Description
CPU xScale PXA-255, 400 MHz processor
Memory SDRAM: 64 MB
Flash: 32 MB
SRAM:256 KB
Ethernet Ethernet Speed: 10/100M
Ethernet interface: RJ-45 connector
Internet connection type: DHCP, Static IP, PPPoE
Ethernet protocols & services: TCP/IP, Web server,
FTP server, Telnet & ssh
Audio Provide microphone input and stereo speaker output
Microphone and speaker interface: 3.5mm 3-pin
phone jack
Volume and tone quality adjustable
Com port Serial port - RS-232/ RS-485
COM1:RS-232 interface -- D-sub 9-pin male
RS-232: TXD, RXD, RTS, CTS, GND
COM2:RS-485 interface -- 2-pin screw terminal block
RS-485: D+, D-, self-tuner ASIC inside
Baud Rate ：
1200/2400/4800/9600/19200/38400/57600/115200 bps
Data Format: 5/6/7/8 data bits, None/Odd/Even
parity bit, 1/2 stop bit
Power
requirement
Unregulated +10V ~ +30V DC
Power consumption 2.5W
Environmental Operating temperature: -20 ~ 60 ºC
Storage temperature: -25 ~ 85 ºC

M-4132 User Manual (Version 1.60, May/2014) PAGE：7
ESD protection: 2500V
CE/FCC, EMI, RoHS compliance
Dimensions 160 x 135 x 44 (mm)

M-4132 User Manual (Version 1.60, May/2014) PAGE：8
2. Hardware
2.1 Pin Assignment
Figure 3: Pin assignment of M-4132
Table 1: 7-pin screw terminal block
Pin Name Description
1 T.GND GND of trigger input
2 Trig Trigger input
3 D+ Data+ of RS-485
4 D- Data- of RS-485
5 PWR V+ of Power Supply (+10 to +30VDC)
6 GND GND of Power Supply
7 F.G. Frame Ground

M-4132 User Manual (Version 1.60, May/2014) PAGE：9
Table 2: RJ-45 socket
Table 3: RS-232 DB9 Female Connector
Pin Name Description
1 DCD(CD) (Data) Carrier Detect
2 RXD Received Data
3 TXD Transmitted Data
4 DTR Data Terminal Ready
5 GND Signal Ground/Common
6 DSR Data Set Ready
7 RTS Request to Send
8 CTS Clear to Send
9 - N/A
Table 4: 3.5mm Phone Jack (Speaker Out)
Pin Name Description
1 GND Ground
2 Tip Left channel
3 - N/A
4 - N/A
5 Ring Right channel
Pin Name Description
1 TX+ TX+ output
2 TX- TX- output
3 RX+ RX+ input
4 - N/A
5 - N/A
6 RX- RX- input
7 - N/A
8 - N/A

M-4132 User Manual (Version 1.60, May/2014) PAGE：10
Table 5: 3.5mm Phone Jack (Microphone In)
2.2 Wiring Instructions
The communication interface of M-4132 includes RS-232, RS-485 and
Ethernet. The wiring instructions are described in section 2.2.1, 2.2.2 and
2.2.3.
2.2.1 RS-232 connection
There are two types of RS-232 ports, DTE (Data Terminal Equipment,
like M2M series, PC, Serial Printers, PLC and Video Cameras) and
DCE (Data Circuit-Terminating Equipment, like modem) type, and that
the signal names and pin numbers are the same, but signal flow is
opposite!
The M-4132 module is a DTE and the user can uses “3-wire” RS-232
or “5-wire” RS-232 to connect. When connecting the M-4132 to a DCE
device, the user just needs to match the signal names. When connecting
the M-4132 to a DTE device, the user needs to use a crossover cable
(TX crosses to RX, GND to GND,), as shown in the figure 4, 5.
Figure 4: “3-wire” RS-232 (M-4132 to DTE)
Pin Name Description
1 GND Ground
2 Tip Input Signal
3 - N/A
4 - N/A
5 Ring Ground
M-4132
RS-232 Port
DTE
RS
-
232 Port

M-4132 User Manual (Version 1.60, May/2014) PAGE：11
Figure5: “5-wire” RS-232 (M-4132 to DTE)
2.2.2 RS-485 connection
The RS-485 wiring diagram is shown in figure 6.
Figure 6: RS-485 connection
2.2.3 Ethernet connection
The M-4132 module is based on a client-server architecture model.
When the M-4132 works as a server in Internet, it should set the
firewall before the M-4132 module appropriately or else the client will
not connect to the server.
M-4132
RS-485 Port
RS-485 Port
RS-485 Port
M-4132
RS-232 Port
DTE
RS-232 Port

M-4132 User Manual (Version 1.60, May/2014) PAGE：12
Figure 7: Ethernet connection
2.3 Dip Switch and Trigger button
The M-4132 provides two switches (SW1, SW2) and a trigger button
(TB). These switches and button can decide initial function of the
system after power on and enable/disable the request to connect. The
descriptions are shown in table 6, 7.

M-4132 User Manual (Version 1.60, May/2014) PAGE：13
Figure 8: Dip Switch and Trigger Button
Table 6: Dip switch and trigger button for initial function
Option State Description
Recover default
setting forever
SW2=ON
SW1=ON
To press the TB about 40
second after power on
All system settings will be cleared and
recover default settings.
(Warning: it will not restore settings
after clear)
IP recover default
setting for this
time
SW2= OFF
SW1= ON
To press the TB about 40
second after power on
After power on, it will set IP to default
setting (192.168.1.217) for this time,
but it will restore original IP at next
time.
IP recover default
setting forever
SW2= ON
SW1= OFF
To press the TB about 40
second after power on
After power on, it will set IP to default
setting (192.168.1.217) and save to
flash.
Display the
current IP and
version
SW2=OFF
SW1=OFF
To press the TB about 40
second after power on
After power on, it will display the
message about current IP and version
information from Com Port(RS-232).
Normal setting The other states Normal state; It will not change any
setting and data.

M-4132 User Manual (Version 1.60, May/2014) PAGE：14
Table 7: Dip switch and trigger button for the request
Option State Description
Disable the request
to connect
SW2=OFF
SW1=OFF
Press the TB
Client: Send the request to disconnect. The
voice and com port connection will be
disconnected, but the login connection will
hold on.
Enable the request
to connect
SW2=ON
SW1=ON
Press the TB
Client: request server to connect.
2.4 LED Status Indicators
The M-4132 provides three LEDs to indicate the status, as shown below.
Figure 9: LED indicator
Table 8: LED status description
Name
Status Description
PWR
on Power supply is ok.
off Power supply has failed.

M-4132 User Manual (Version 1.60, May/2014) PAGE：15
Name
Status Description
SA1 flash It is receiving com port data via Ethernet.
SA2
flash slowly
Server: The Ethernet is initial ok and wait for the client to login.
Client: The Ethernet is initialized ok and log
in completely. It has
readied to enable voice and com port data connection by the server.
flash fast It is sending or receiving voice data via Ethernet.
SA1
&
SA2
on There are happening some errors. (Client: Please check
settings about
IP & DNS)
flash slowly (SA1
& SA2 flash at
the same time)
It is trying to establish the connection with the server/client. If it
can’t
connect to the server/client for a long time, please check that the M-
4132 has available network settings and is working well on Ethernet.
flash (SA1 &
SA2 alternate
flash)
Server: Receive the request to connect from the client.
Client: Request server to connect.
2.5 Communication Port
M-4132 uses several communication ports of Ethernet, as shown in the
below. If the user connects M-4132 client by “ETM operation mode”, the
communication ports will include the ports of “ETM configuration file”.
Table 9: Communication Port
Service Port number note
Web Server 80
FTP Server 21
Telnet Server 23
SSH Server 22
E-mail function 587 default
VSoIP function 443 default
VxComm function 10000, 10001
VPN function 1194

M-4132 User Manual (Version 1.60, May/2014) PAGE：16
3. Configuration and Operation with Web Browser
The M-4132 module is built-in web server, the user can configure and
operate the M-4132 by web browser (ex: IE).
3.1 Connection Setting
Before you open the web browser to configure the module, it needs to
connect the M-4132 and your PC to the same sub network or same
Ethernet Switch (as shown in figure 10) and set network settings (such
as IP/Mask/Gateway) of the PC. The example of connection setting will
describe below and Microsoft Windows XP Professional SP2 is used.
Figure 10: connection architecture
Connection steps：
Step 1: Open Network Connections
1.Click “start->Settings->Network Connections”

M-4132 User Manual (Version 1.60, May/2014) PAGE：17
Figure 11: click “start->Settings->Network Connections”
2. Double click “Local Area Connection” icon
3. click “Properties” button
Figure 12: click “Properties” button

M-4132 User Manual (Version 1.60, May/2014) PAGE：18
4. Select “Internet Protocol(TCP/IP)” and click “Properties” button
Figure 13: click “Properties” button
Step 2: Set “Internet Protocol Properties” and then click “OK” button.
The settings must have the same domain and different IP with the M-
4132. (ex: M-4132’s default IP = 192.168.1.217, PC’s IP =
192.168.1.210).
Figure 14: set “Internet Protocol Properties”

M-4132 User Manual (Version 1.60, May/2014) PAGE：19
Step 3: test connection
1. Click “start->Run...”
Figure 15: click “start->Run...”
2. Key in “cmd” and then click ”OK” button
Figure 16: key in “cmd” and then click ”OK” button
3. key in “ping 192.168.1.217” and click “Enter”. If the response
message shows “Request timed out”(figure 17), it means the network
settings between PC and the module are not correct. Please check the
network is available and the settings are all correct.

M-4132 User Manual (Version 1.60, May/2014) PAGE：20
Figure 17: Ping IP Error
If the network settings are correct, it will show “Packets: Sent=4,
Received=4, Lost=0“(figure 18).
Figure 18: Ping IP OK
3.2 Web Configuration—function menu
Now the PC is set completely and working well with the M-4132. Please
