ICP POS 566 User manual

POS-566/566L Ver2.x
AMD-K6®-2/ K6®-III / Pentium® Processor
Multimedia POS Control Board V:a
©Copyright 1999 by ICP Electronics Inc. All Rights Reserved. Manual
second edition on May.20,2000.
The information in this document is subject to change without prior notice
in order to improve reliability, design and function and does not represent
a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or inability to
use the product or documentation, even if advised of the possibility of
such damages.
This document contains proprietary information protected by copyright. All
rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of the manufacturer.
Trademarks
POS-566/566L is a registered trademark of ICP Electronics Inc. IBM PC
is a registered trademark of International Business Machines Corporation.
Intel is a registered trademark of Intel Corporation. AMI is a registered
trademark of American Megatrends, Inc. Other product names mentioned
herein are used for identification purposes only and may be trademarks
and/or registered trademarks of their respective companies.
.

1
Contents
1. Introduction.......................................................................3
1.1 Specifications..............................................................................4
1.2 What You Have...........................................................................6
2. Installation.........................................................................7
2.1 POS-566/566L's Layout...............................................................8
2.2 Unpacking Precautions................................................................9
2.3 Setting the CPU of POS-566/566L.............................................10
2.4 Voltage Setting for Flash ROM...................................................11
2.5 LCD Voltage Setting ..................................................................11
2.6 DiskOnChip™ Flash Disk ..........................................................12
2.7 Watch-Dog Timer .....................................................................12
2.8 Clear CMOS Setup ...................................................................13
2.9 RS232/RS422/RS485 Selector...................................................13
2.10 RI and COM Port Voltage Selector.............................................14
3. Connection......................................................................16
3.1 Floppy Disk Drive Connector......................................................16
3.2 PCI E-IDE Disk Drive Connector................................................17
3.3 Parallel Port...............................................................................19
3.4 Serial Ports................................................................................20
3.5 PS/2 Mouse / Keyboard ............................................................21
3.6 USB Port Connector ..................................................................22
3.7 External Switches and Indicators ...............................................22
3.8 IrDA Infrared Interface Port .......................................................23
3.9 Fan Connector ..........................................................................23
3.10 VGA Connector. ........................................................................24

2
3.11 LCD Connector. .........................................................................25
3.12 LAN RJ45 Connector..................................................................26
3.13 Audio Connector.. ......................................................................26
3.14 Isolated Digital I/O Connector.....................................................27
3.15 AT and ATX Power Connector...................................................29
4. AMI BIOS Setup..............................................................31
4.1 Getting Start ..............................................................................31
4.2 Standard CMOS Setup...............................................................32
4.3 Advanced CMOS Setup..............................................................33
4.4 Advanced Chipset Setup............................................................35
4.5 Power Management Setup ........................................................36
4.6 PCI/PLUG AND PLAY Setup......................................................37
4.7 Peripheral Setup ........................................................................39
4.8 Auto-Detect Hard Disk ...............................................................41
4.9 Change Supervisor/User Password ............................................42
4.10 Auto Configuration with Optimal Settings…................................43
4.11 Auto Configuration with Fail Save Settings.................................43
4.12 Save Settings and Exit ...............................................................44
4.13 Exit Without Saving....................................................................44
5. E2Key Function ..............................................................45
Appendix A. DMA, IRQ and 1st MB Memory........................47
Appendix B. I/O Address Map.............................................48
Appendix C. Watch-Dog Timer… .......................................49
Appendix D. Flat Panel Connection Module.......................50
Appendix E. AMD-K6 Processor Voltage Requirements ....52

3
1
Introduction
Welcome to the POS-566/566L 550MHz K6®-3 / Pentium
Processor Multimedia POS Control Board Computer. The POS-
566/566L board is a LPX Spec. board, which equipped with high
performance Pentium®CPU, LCD/CRT and 10/100Mbps Ethernet,
designed for the system manufacturers, integrators, or VARs that
want to provide all the performance, reliability, and quality at a
reasonable price.
This board has a built-in DiskOnChip™(DOC) Flash Disk Socket
for embedded application. The DOC Flash Disk is 100% software
compatible to hard disk. User can use any DOS command without
any extra software utility. The DOC currently is available from
2MB to 144MB.
The POS-566/566L provides three 168-pin DIMM sockets for its
on-board DRAM with max. 768MB. DIMM module is 3.3V SDRAM.
The board’s Realtek RTL8139 IEEE 802.u network chipset
provides 10MBps or 100MBps Ethernet with auto-sensing function.
In addition, the POS-566 is also Creative Sound Blaster 16 and
Roland MPU401 UART Mode compatible. This feature is not
available in POS-566L.
With its Isolated Digital I/O control for field site application, this
POS-566/566L is the most advanced POS solution that supports
up to 550MHz processor.

4
1.1 Specifications :
The POS-566/566L 550MHz K6-3 / PentiumProcessor Multimedia
POS Control SBC provides the following specification :
•CPU : Pentium®MMX up to 233Mhz, AMD®K6®/K6®-2/K6®-3 up to
550MHz, IDT C6, Cyrix 6x86MX, etc. Processor
•RAM : up to 768MB SDRAM 3pcs DIMMs
•Cache memory : 512KB Pipelined Burst SRAM on board
•Bus : PCISA bus expansion to support ISA and PCI bus signal
•Chipset : Aladdin 5, support 100MHz CPU clock
•LCD/CRT Controller : CHIPS 65555 64-bit flat panel controller Built-
in HiQColor Technology for super clean STN flat panel. CRT
Resolution up to
1280 x 1024, 256 color
1024 x 768, 64K color
800 x 600 , 16M color
Display Memory : 2MB EDORAM
•Support 3.3V or 5V flat panel.
•Support Mono, Color STN, TFT, EL,….wide range flat panel.
•Optional One Channel or Two Channels LVDS module.
•10/100Mbps Ethernet Controller : Realtek RTL8139 IEEE 802.u
100 BASE-TX standard
Dual Auto-sensing interface to 10MBps or 100MBps networks
RJ45 connector for 10BASE-T and 100BASE-TX
Full duplex capability, full software driver support.
For more information : www.realtek.com.tw
•Creative Sound Blaster 16 compatible and Roland MPU401 UART
Mode compatible
•Floppy disk drive interface : two 2.88 MB, 1.44MB, 1.2MB, 720KB,
or 360KB floppy disk drives.
•Four high speed Serial ports : three RS-232C, one RS-232C or RS-
422/485 Port
•Parallel Ports : Two SPP/EPP/ECP Parallel Ports

5
•Enhanced IDE Interface :
One 44-pin Header for 2.5” HDD
One 40-pin Header for 3.5” HDD
•PCISATM Bus Expansion to support ISA and PCI bus signal
•Isolated Digital I/O : 4 Digital Input and 4 Digital Output channels
•IrDA port : Support Serial Infrared (SIR) and Amplitude Shift
Keyed IR (ASKIR) interface.
•Two USB ports : Support USB port for future expansion.
•Watchdog timer : can be set by 1, 2, 10, 20, 110 or 220 seconds
period. Reset or NMI is generated when CPU does not periodically
trigger the timer.
•E2KeyTM Function : A special designed 1Kbit EEPROM (non volatile
memory) provided to accept read/ write data by customer’s program. It
is useful to store system ID, Password, Critical Data on the board.
•Flash Disk –DiskOnChip™ : The Flash Disk provides 100%
compatibility with hard disk.
•Keyboard connector
•Mouse : PS/2 Mouse Port on-board.
•Power Consumption : +5V/5.5A (AMD K6-2 350MHz,384MB SDRAM)
+12V : 170mA , -12V : 60mA
•Support ATX and AT power supply
•Operating Temperature : 0°~ 60°C ( CPU needs Cooler)
•Operating Humidity : 5-95% non-condensing

6
1.2 What You Have
In addition to this User's Manual, the POS-566/566L package
includes the following items:
•POS-566/566L 550MHz K6-3 / PentiumProcessor
Multimedia POS Control Board
•RS-232 / Printer Cable
•FDD / HDD Cable
•Audio Cable
•FP24-01 Flat Panel Connection Module (see Appendix D for
detail pin assignment).
•6-pin Mini-Din to Keyboard and Mouse Adapter Cable
If any of these items is missing or damaged, contact the dealer from
whom you purchased the product. Save the shipping materials and
carton in case you want to ship or store the product in the future.

7
2
Installation
This chapter describes how to install the POS-566/566L. The
layout of POS-566 is shown on the next page and the Unpacking
Precautions that you should be careful with are described on the
following page. Also included is the jumpers and switches setting
for this board’s configuration, such as: CPU type selection, system
clock setting and Watchdog timer.
2.1 POS-566's Layout
< please, refer to the next page >

8
2.1 POS-566's Layout
