Icy Box IB-AC619 User manual

Manual IB-AC619
3 Port USB 3.0 hub with integrated USB cable and 2x audio ports
Handbuch IB-AC619
3 Port USB 3.0 Hub mit integriertem USB 3.0 Kabel und 2x Audioports
Manuel Série IB-AC619
Concentrateur 3 ports USB 3.0 + 2 ports audio
Manuale della IB-AC619
Hub con 3 porte USB 3.0 + 2 porte audio
Manual Serie IB-AC619
USB 3.0 Hub con 3 puertos + 2 purtos de audio
Εγχειρίδιο χρήσης IB-AC619
Πλήμνη 3 λιμένων USB 3.0 + 2 θύρα ήχου
Instrukcja obsługi IB-AC619
3-portowy hub USB 3.0 + 2 porty audio
Руководство IB-AC619
3-портовый концентратор USB 3.0 + 2 Аудио порты
Manual de Utilização Série IB-AC619
3 Port Hub USB 3.0 + 2 portas de audio
Manuál IB-AC619 Series
3 Port USB 3.0 Hub + 2 Audio porty
IB-AC619

IB-AC619
Connection Diagram
IB-AC619
3x USB 3.0
Audio in/out
Introduction
IB-AC619 is a 3 port super speed USB 3.0 HUB with two audio-ports for
speakers / headphones (stereo output) and Microphone (mono input). It is
bus-powered and no external power adapter is necessary.
Package Content
1x IB-AC619, 1x quick installation guide
System requierements
Notebook / PC with USB 3.0 / 2.0 port.
CPU: Intel Pentium 1.2GHz and higher, 512 MB RAM.
Operation System: Windows and Mac OS X.

Installation
The IB-AC619 and the audio-ports will be automatically detected and the
drivers will be automatically installed after connecting to the USB port on
your PC.
Key Features
• Premium Aluminum housing
• USB 3.0 host interface up to 5 Gbit/s
• Provides 3x USB 3.0 interface up to 5 Gbit/s
• With integrated USB 3.0 cable
• 1x 3.5 mm audio output for Headphones / Speakers
• 1x 3.5 mm audio input for Microphone
• Supports Microsoft Windows and MAC OS X
IB-AC619
1x audio input
1x audio output
3x USB 3.0
USB 3.0 Host

IB-AC619
Installation
Die IB-AC619 und die Audio-Ports werden automatisch erkannt
und die Treiber werden automatisch nach dem Anschließen an den
USB-Anschluss an Ihrem PC installiert werden.
Hauptmerkmale
• Gehäuse aus hochwertigem Aluminium
• USB 3.0 Hostanschluss bis zu 5 Gbit/s
• Verfügt über 3x USB 3.0 Anschluss bis zu 5 Gbit/s
• Mit integriertem USB 3.0 Kabel
• 1x 3,5 mm Audio Qutput für Kopfhörer/Lautsprecher
• 1x 3,5 mm Audio Input für Mikrofon
• Unterstützt Microsoft Windows und MAC OS X
Installation
Le IB-AC619 et les audio-Ports seront automatiquement détectés. Les
pilotes seront installés automatiquement après la connexion au port
USB de votre PC.
Spécialités principales
• Boîtier en aluminium haut de gamme
• USB 3.0 hôte interface jusqu‘à 5 Gbit/s
• Ore 3 port USB 3.0 interface jusqu‘à 5 Gbit/s
• Ports audio pour haut-parleurs/casque et microphone
Instalación
El los audio-Ports IB-AC619 y se detectarán automáticamente. Los
controladores se instalarán automáticamente después de conectar al
puerto USB de su PC.
Caratteristiche principali
• Material: Aluminio de alta calidad
• USB 3.0 Host hasta 5 Gbit/s
• Ofrece 3 interfaz USB 3.0 hasta 5 Gbit/s
• Puertos de audio para altavoces/auriculares y micrófono

IB-AC619
Installazione
L‘audio-Ports IB-AC619 e verranno rilevate automaticamente. I driver
verranno installati automaticamente dopo la connessione alla porta
USB del PC.
Características principales
• Casseto di alluminio
• Interfaccia host USB 3.0 no a 5 Gbit/s
• Dotato di 3 interfaccia USB 3.0 no a 5 Gbit/s
• Porte audio per altoparlanti/cue e microfono
Instalacja dysku twardego
IB-AC619 i audio-Port zostanie automatycznie wykryty. Sterowniki
zostaną zainstalowane automatycznie po podłączeniu do portu USB
w komputerze PC.
Funkcje kluczowe
• Aluminiowa obudowa Premium materiału
• USB 3.0 Host Interface, aż do 5 Gbit/s
• Dostępne interfejsy 3x USB 3.0 do 5 Gbit/s
• Porty audio dla głośników / słuchawek i mikrofonu
Εγκατάσταση σκληρού δίσκου
Το IB-AC619 και ο ήχος-Ports θα πρέπει να ανιχνεύονται αυτόματα. Οι
οδηγοί θα εγκατασταθούν αυτόματα μετά τη σύνδεση στη θύρα USB
του υπολογιστή σας.
Βασικά Χαρακτηριστικά
• Θήκη αλουμινίου
• κεντρικού υπολογιστή USB 3.0 έως 5 Gbit/δευτ
• Παρέχει 3x USB 3.0 έως 5 Gbit/δευτ
• Οι θύρες ήχου για ηχεία/ακουστικά και μικρόφωνο

Установка жёсткого диска
IB-AC619 и аудио-порты будут автоматически обнаружены.
Драйверы будут установлены автоматически после подключения
к порту USB на компьютере.
Основные признаки
• алюминевый корпус
• USB 3.0 интерфейс до 5 Gбит/сек
• Интерфейсы 3x USB 3.0 до 5 Gбит/сек
• Аудио порты для подключения колонок/наушников и микрофона
Instalação
O IB-AC619 eo áudio-Ports será automaticamente detectado. Os
drivers serão instalados automaticamente após a conexão à porta
USB do seu PC.
Recursos
• Prêmio Caixa de alumínio
• Interface USB 3.0 host até 5 Gbit/s
• Dispõe das interfaces: 3x USB 3.0 até 5 Gbit/s
• Portas de áudio para alto-falantes / fones de ouvido e microfone
Instalace
IB-AC619 a audio porty budou automaticky detekovány. Řidiči budou
nainstalovány automaticky po připojení k USB portu na vašem PC.
Funkce
• Premium Hliníkové pouzdro
• USB 3.0 rozhraní hostitele až 5 Gbit/s
• Poskytuje rozhraní 3x USB 3.0 až po 5 Gbit/s
• Audio porty pro reproduktory/sluchátka a mikrofon
IB-AC619
