Tripp Lite NSS-G16D2 User manual

16 10/100/1000Mbps Port Gigabit L2 Web-Smart
Managed Switch, 2 SFP Slots, 36 Gbps, Web, 8-
Outlet 120V PDU/Surge Protect
MODEL NUMBER: NSS-G16D2
Combines a Web-Smart 16-port Gigabit network switch with a basic PDU/surge protector in one 1U rack-
mount unit. Ideal for monitoring and controlling an LAN and powering equipment in a small-to-medium
distributed network.
Description
The energy-efficient NSS-G16D2 16-Port Gigabit L2 Web-Smart Managed Switch does more than
complete your home or office LAN. It also features a basic 120V 15A PDU to distribute reliable AC power
to critical IT equipment in your wiring closet, server room or equipment rack. Two dedicated mini-GBIC
SFP ports are also included for uplinking data to other switches via optical fiber or copper.
This switch features 16 twisted-pair RJ45 Gigabit Ethernet ports that support auto-negotiable 10/100/1000
Mbps and auto MDI/MDIX cross-over detection functions for convenient plug-and-play capability. Easy-to-
read LEDs indicate connection and activity status for each port. Built-in management software lets you
monitor and control each connected device via secure web-based interface. Each port supports up to 2
Gbps with full duplex.
The rear panel contains eight NEMA 5-15R outlets that supply continuous power to connected devices.
Your equipment is protected by 3860 joules of surge suppression, as well as front-panel LEDs that let you
monitor line status at a glance. A 12A circuit breaker trips if the current drawn by connected equipment
exceeds the PDU’s maximum load rating.
The NSS-G16D2 supports IEEE802.3az Energy Efficient Ethernet standards. The heavy-duty metal
housing mounts into 1U of an EIA-standard 19-inch rack using the included hardware. The six-foot input
cord with NEMA 5-15P plug connects to a protected UPS, generator or mains input AC source.
Features
Highlights
IP-MAC-Port-Binding, ACL,
Storm Control
●
Port Security, DHCP Snooping,
802.1x, L2
●
WEB management, SNMP,
RMON features
●
16 ports and 2 dedicated Mini-
GBIC SFP slots
●
Enterprise-level, security and
layer 2 management
●
3860-joule surge protection
rating
●
Built-in 8-outlet PDU with
diagnostic LEDs
●
Package Includes
NSS-G16D2 16-Port Gigabit L2
Managed Network Switch
●
Rack-mounting hardware
●
Owner’s manual
●
1 / 4

Specifications
Enterprise Managed Network Switch
16 twisted-pair RJ45 Gigabit Ethernet ports
●
Auto-negotiable 10/100/1000 Mbps
●
Automatic MDI/MDIX cross-over detection
●
36 Gbps switching capacity (2 Gbps per port with full duplex)
●
Easy-to-read LEDs indicate connection and activity status for each port
●
Supports 10k jumbo frames
●
Supports MAC address auto-learning and auto-aging up to 16,000 addresses
●
Advanced Enterprise level, L2 management features
●
Advanced Network Monitoring
Built-in Ethernet network interface allows full remote access for monitoring, configuration and control
and notifications via web browser
●
VLAN, trunking and other features improve switch’s and network’s efficiency and performance
●
Basic 120V 15A PDU
8 NEMA 5-15R rear outlets supply continuous power to connected devices
●
3860 joules of Isobar surge suppression
●
Front-panel LEDs indicate protection, fault, and line status
●
40–80 dB EMI/RFI noise reduction
●
Dual Dedicated SFP Ports
Connect two SFP (mini-GBIC) transceiver modules for uplinking to other switches via optical fiber or
copper
●
LEDs indicate interface traffic
●
Compliant with Energy Efficient Ethernet standards
Automatically shifts unused ports to low power state without interrupting network connection
●
Meets IEEE 802.3ab, 802.3i, 802.3u, 802.3x, 802.3, 802.1q, 802.1d, 802.1w, 802.3ad and 802.3az
standards
●
Mounts Horizontally in 1U of Rack Space
Compatible with EIA-standard 19 in. racks and rack enclosures
●
Fanless metal housing for silent operation
●
NEMA 5-15P plug with 6 ft. AC power cord
●
OVERVIEW
2 / 4

UPC Code 037332195470
PDU Type Basic
OUTPUT
Output Circuit Breakers 12A
Output Receptacles (8) 5-15R
INPUT
Electrical Consumption PDU supports up to 12A total; Network switch consumes up to 30 watts
PDU Input Voltage 100; 120; 127
PDU Plug Type NEMA 5-15P
Input Phase Single-Phase
Input Cord Length (ft.) 6
Input Cord Length (m) 1.83
USER INTERFACE, ALERTS & CONTROLS
Switches 2 included switches enable HARD factory reset and SOFT factory reset options
LED Indicators Power LED (Green for Power On); Two LEDs per RJ-45 port (Green indicates 10/100Mbps link; Amber indicates
1000Mbps link; LEDs flash to indicate port activity); Two LEDs indicate SFP connection (Green); One LED indicates
system status (Green); Set of 3 LEDs indicate surge suppression status (Green: Protection Present / Red: Fault /
Green: Line OK)
SURGE / NOISE SUPPRESSION
AC Suppression Joule Rating 3860
Protection Modes L-N, L-G, N-G
Clamping Voltage (RMS) 330
EMI / RFI Filtering 40-80dB
PHYSICAL
Color Black
Minimum Required Rack Depth (cm) 39.12
Minimum Required Rack Depth
(inches) 15.4
PDU Form Factor Horizontal (1U)
Primary Form Factor Rackmount
Shipping Dimensions (hwd / cm) 11.94 x 43.18 x 52.58
Shipping Dimensions (hwd / in.) 4.70 x 17.00 x 20.70
Shipping Weight (kg) 4.90
Shipping Weight (lbs.) 10.80
3 / 4

© 2019 Tripp Lite. All rights reserved. All product and company names are trademarks or registered trademarks of their respective holders. Use of them does
not imply any affiliation with or endorsement by them. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
Tripp Lite uses primary and third-party agencies to test its products for compliance with standards. See a list of Tripp Lite's testing agencies:
https://www.tripplite.com/products/product-certification-agencies
Unit Dimensions (hwd / cm) 4.34 x 44 x 31.5
Unit Dimensions (hwd / in.) 1.71 x 17.32 x 12.4
Unit Weight (kg) 3.85
Unit Weight (lbs.) 8.49
ENVIRONMENTAL
Storage Temperature Range 14 to 158 F (-10 to 70 C)
Relative Humidity 5 to 95% (Non-condensing)
Operating Elevation (ft.) 10,000
Operating Temperature 32 to 104 F (0 to 40 C)
Operating Elevation (m) 3,000
CONNECTIONS
Ports 18
Network Switch Ports (16) 10/100/1000 (RJ45); (2) Dedicated SFP; (1) Console (RJ45)
CERTIFICATIONS
Certifications Compliant standards: IEEE 802.3ab (1000BASE-T GIGABIT ETHERNET), IEEE 802.3i (10BASE-T ETHERNET),
IEEE 802.3u (100BASE-T ETHERNET), IEEE 802.3x (FULL DUPLEX/FLOW CONTROL), IEEE 802.3 (NWAY
AUTO-NEGOTIATION), 802.1Q (TAGGED VLAN), 802.1D (STP), 802.1w (RSTP), 802.3ad (LACP), 802.3az
(ENERGY EFFICIENT ETHERNET)
Approvals Tested to: UL 60950-1, UL 1449 3rd Edition, CAN/CSA-C22.2 No. 60950-1, FCC Part 15 Class A, REACH, NOM
WARRANTY
Product Warranty Period
(Worldwide) 5-year limited warranty
4 / 4
