Planet XGS-6311 Series User manual

Layer 3 Gigabit/10 Gigabit Managed Ethernet Switch
XGS-6311/GS-6311/MGS-6311 Series
Quick Installation Guide

Table of Contents
1. Package Contents................................................................................. 3
2. Switch Management ............................................................................. 5
3. Requirements....................................................................................... 6
4. Terminal Setup..................................................................................... 7
4.1 Logging on to the Console.............................................................. 8
 4.2 ConguringIPAddress ................................................................... 8
 4.3 Setting1000BASE-Xfor10GSFP+ Port ......................................... 10
 4.4 SavingtheConguration .............................................................. 10
5. Starting Web Management .................................................................. 11
 5.1 LoggingintotheManagedSwitch................................................. 12
 5.2 SavingCongurationviatheWeb.................................................. 13
6. RecoveringBacktoDefaultConguration ............................................. 14
7. Customer Support .............................................................................. 15

3
1. Package Contents
Thank you for purchasing Layer 3 Gigabit/10 Gigabit Managed Ethernet
Switch, XGS-6311 series, MGS-6311 series or GS-6311 series. The
descriptionsofthesemodelsareasfollows:
Model Description
XGS-6311-12X Layer312-Port10GBASE-XSFP+Managed
EthernetSwitch
GS-6311-24T4X L324-Port10/100/1000T+4-Port10GSFP+
ManagedEthernetSwitch
GS-6311-16S8C4XR
L316-Port100/1000XSFP+8-PortGigabitTP/
SFP+4-Port10GSFP+ManagedEthernetSwitch
with36-72VDCRedundantPower
GS-6311-48T6X L348-Port10/100/1000T+6-Port10GSFP+
ManagedEthernetSwitch
GS-6311-24HP4X L38-Port802.3btPoE+16-Port802.3atPoE+
4-Port10GSFP+ManagedEthernetSwitch
GS-6311-48P6X L348-Port10/100/1000T802.3atPoE+6-Port
10GSFP+ManagedEthernetSwitch
MGS-6311-10T2X L38-Port2.5GBASE-T+2-Port10GBASE-T+
2-Port10GBASE-XSFP+ManagedEthernetSwitch
MGS-6311-8P2X
L38-Port2.5GBASE-T802.3atPoE+2-Port
10GBASE-T+2-Port10GBASE-XSFP+Managed
EthernetSwitch
Unless specied, “Managed Ethernet Switch” mentioned in this Quick
Installation Guide refers to the XGS-6311 series, MGS-6311 series or GS-6311
series.

4
OpentheboxoftheManaged Switchandcarefullyunpackit.Theboxshould
containthefollowingitems:
Item
Model
Quick
Installation
Guide
Sheet
DB9 to
RJ45
Console
Cable
Rack-
mount
Accessory
Kit
SFP
Dust
Cap
AC
Power
Cord
Rubber
Feet
XGS-6311-12X    12 1 4
GS-6311-24T4X    4 1 4
GS-6311-16S8C4XR    28 1 4
GS-6311-48T6X    6 1 4
GS-6311-24HP4X    4 1 4
GS-6311-48P6X    6 1 4
MGS-6311-10T2X    2 1 4
MGS-6311-8P2X    2 1 4
If any item is found missing or damaged, please contact your local reseller for
replacement.

5
2.Switch Management
TosetuptheManagedSwitch,theuserneedstoconguretheManagedSwitch
for network management. The Managed Switch provides two management
options:Out-of-Band ManagementandIn-Band Management.
Out-of-Band Management
Out-of-band management is the management through console interface.
Generally, the user will use out-of-band management for the initial
switch conguration,orwhenin-bandmanagementisnotavailable.
In-Band Management
In-band management refers to the management by logging in to the Managed
SwitchusingTelnet or HTTP,or usingSNMPmanagement softwaretocongure
the Managed Switch. In-band management enables the management of
the Managed Switch to attach some devices to the Switch. The following
proceduresarerequiredtoenablein-bandmanagement:
1. Log on to console
2.Assign/CongureIPaddress
3. Create a remote login account
4.EnableHTTPorTelnetserverontheManagedSwitch
In case in-band management fails due to Managed Switch conguration
changes, out-of-band management can be used for conguring and managing
theManagedSwitch.
The Managed Switch is shipped with VLAN1 interface IP
address 192.168.0.254/24 assigned by default. User can
assign another IP address to the Managed Switch via the
console interface to be able to remotely access the Managed
SwitchthroughTelnetorHTTP.

6
3. Requirements
zWorkstationsrunningWindowsXP/2003/Vista/2008/7/8/10/11, MACOSXor
later,Linux,UNIX,orotherplatformsarecompatiblewithTCP/IPprotocols.
zWorkstationsareinstalledwithEthernetNIC(NetworkInterfaceCard)
zSerial Port Connection(Terminal)
 The above Workstations come with COM Port (DB9) or USB-to-RS232
converter.
 The above Workstations have been installed with terminal emulator, such
as Tera Term or PuTTY.
 Serial cable -- one end is attached to the RS232 serial port, while the
otherendtotheconsoleportoftheManagedSwitch.
zEthernet Port Connection
Network cables -- Use standard network (UTP) cables with RJ45 connec-
tors.
TheabovePCisinstalledwithWebbrowser
It is recommended to use Google Chrome or above to access
the Managed Switch. If the Web interface of the Managed
Switch is not accessible, please turn off the anti-virus software
orfirewallandthentryitagain.

7
4. Terminal Setup
To congure the system, connect a serial cable to a COM port on a PC or
notebook computer and to serial (console) port of the Managed Switch. The
console port of the Managed Switch is DCE already, so that you can connect
theconsoleportdirectlythroughPCwithouttheneedofNullModem.
Managed Switch
PC / Workstation
with
Terminal Emulation Software
Serial Port
RS232 to RJ45 Cable
Console Port
RJ45
Figure 4-1 Managed Switch Console Connectivity
A terminal program is required to make the software connection to the
Managed Switch. Tera Term program may be a good choice. The Tera Term
canbeaccessedfromtheStart menu.
1. Click START menu, then Programs,andthenTera Term.
2.When the followingscreenappears,makesurethatthe COM port should be
conguredas:
Baud:9600
Parity:None
Databits:8
Stopbits:1
Flowcontrol:None
Figure 4-2 Tera Term COM Port Conguration

8
4.1 Logging on to the Console
Once the terminal is connected to the device, power on the Managed Switch,
andtheterminalwilldisplay“running testing procedures”.
Then, the following message asks for the login user name and password. The
factory default user name and password are as follows as the login screen in
Figure4-3appears.
Username:admin
Password:admin
Figure 4-3 Managed Switch Console Login Screen
The user can now enter commands to manage the Switch. For a detailed
descriptionofthecommands,pleaserefertothefollowingchapters.
Forsecurityreason, please change and memorizethenewpass-
wordafterthisfirstsetup.
4.2 ConguringIPAddress
TheIPaddresscongurationcommandsfor VLAN1 interfacearelisted below.
Before using in-band management, the Managed Switch must be congured
with an IP address by out-of-band management (i.e. console mode). The
congurationcommandsareasfollows:
Switch# cong
Switch_cong#interface vlan 1
Switch_cong_v1#ip address 192.168.1.254 255.255.255.0

9
The previous command would apply the following settings for the Managed
Switch.
IPv4Address:192.168.1.254
SubnetMask:255.255.255.0
Figure 4-4 Conguring IPv4 Address Screen
To check the current IP address or modify a new IP address for the Managed
Switch,pleaseusetheproceduresasfollows:
Show the current IP address
1. On ”Switch#” prompt, enter “show ip interface brief”.
2.The screen displays the current IP address, subnet mask and gateway as
showninFigure4-5.
Figure 4-5 Showing IP Information Screen

10
If the IP is successfully congured, the Managed Switch will apply the new
IP address setting immediately. You can access the Web interface of Managed
SwitchthroughthenewIPaddress.
If you are not familiar with console command or the related
parameter, enter “help” anytime in console to get the help
description.
4.3 Setting1000BASE-Xfor10GSFP+Port
The Managed Switch supports both 1000BASE-X and 10GBASE-X SFP
transceivers by manual setting and the default SFP+ port speed is set in the
ber auto mode,sotheend-usercanplugthetransceiverdirectly.
In another example, the end-user has to force the ber connection with
1000BASE-X SFP transceiver in the ethernet 1/0/1. The following command
congurationisrequired:
Switch#cong
Switch(cong)#interface ethernet 1/0/1
Switch(cong-if-ethernet1/0/1)#media-type ber-1g
Figure 4-6 Setting 1000BASE-FX Screen
4.4 SavingtheConguration
In Managed Switch, the running conguration le stores in the RAM. In the
current version, the running conguration sequence running-cong can
be saved from the RAM to FLASH by write command, so that the running
conguration sequence becomes the start-up conguration le, which is called
congurationsave.
Switch#write
Conrmtooverwritecurrentstartup-congconguration[Y/N]:y
Writerunning-congtocurrentstartup-cong successful
Switch#%May2200:02:57.7302023Writecongurationsuccessfully!
Figure 4-7 Write Screen

11
5. Starting Web Management
The Managed Switch provides a built-in browser interface. You can manage it
remotely by having a remote host with Web browser, such as Google Chrome,
MozillaFirefox,GoogleChrome orAppleSafari.
PC/Workstation with
Web Browser
192.168.0.X
Managed Switch
IP Address:
192.168.0.254
RJ45/UTP Cable
Figure 5-1 IP Management Diagram
The following shows how to start up the Web Management of the Managed
Switch. Please note the Managed Switch is congured through an Ethernet
connection. Please make sure the manager PC must be set to the same IP
subnet address.
For example, the IP address of the Managed Switch is congured with
192.168.0.254 on Interface VLAN 1,then the manager PC should be set to
192.168.0.x(wherexisanumberbetween2and253, except1or254),and
thedefaultsubnetmaskis255.255.255.0.
Thefactorydefaultusernameandpasswordareasfollows:
DefaultIPofInterfaceVLAN1:192.168.0.254
Username:admin
Password:admin

12
5.1 Logging in to the Managed Switch
1.Use Google Chrome or above Web browser and enter IP address
http://192.168.0.254 (that you have just set in console) to access the
Webinterface.
2.When the following dialog box appears, please enter the congured user-
name “admin” and password “admin” (or the username/password you
havechangedviaconsole).TheloginscreeninFigure5-2appears.
Figure 5-2 Login Screen
3.After entering the password, the main screen appears as shown in Figure
5-3.
Figure 5-3 Web Main Screen of Managed Switch

13
4.The Switch Menu on the left of the Web page lets you access all the
commandsandstatisticstheSwitchprovides.
Now, you can use the Web management interface to continue the switch
managementor managetheManaged Switchbyconsole interface. Pleaserefer
totheusermanualformore.
5.2 SavingCongurationviatheWeb
Theconguration area istoshowthecontentthatis selected in the navigation
area. The conguration area always contains one or more buttons, such as
“Apply”and“Delete”.
The “Apply” button indicates applying the modied conguration to
the device. The application of the conguration does not mean that the
congurationissavedinthecongurationle.
To save the conguration, you have to click “Save” on the top control bar.
“Save”functionisequivalenttotheexecutionofthewritecommand.
Figure 5-4 Save Conguration

14
6.RecoveringBacktoDefaultConguration
 IP address has been changed or admin password has been
forgotten –
To reset the IP address to the default IP address “192.168.0.254” or reset
the login password to default value, press the hardware-based reset button
on the front panel for about 10 seconds. After the device is rebooted,
you can log in the management Web interface within the same subnet of
192.168.0.xx.
XGS-6311-12X
1
2
3
4
PWR
SYS
5
6
7
8
9
10
11
12
10G
1G
LNK/ACT
LNK/ACT
Reset
Layer 3 12-Port 10GBASE-X SFP+ Managed Ethernet Switch
Figure 6-1 XGS-6311/GS-6311/MGS-6311 Series Reset Button

15
7. Customer Support
Thank you for purchasing PLANET products. You can browse our online FAQ
resource at the PLANET Web site rst to check if it could solve your issue. If
youneedmoresupportinformation,pleasecontactPLANETsupportteam.
PLANETonlineFAQs:
http://www.planet.com.tw/en/support/faq
Supportteammailaddress:
[email protected]
XGS-6311/GS-6311/MGS-6311-SeriesUser’sManual
https://www.planet.com.tw/en/support/downloads?&method=keyword&keyword
=XGS-6311&view=3#list
(Please select your switch model name from the drop-down menu of Product
Model.)
Copyright©PLANETTechnologyCorp.2023.
Contentsaresubjecttorevisionwithout priornotice.
PLANETisaregisteredtrademarkofPLANETTechnologyCorp.
Allothertrademarksbelongto theirrespectiveowners.
