idatastart HC1151A User manual

REVISION DATE
20161024
DOCUMENT NUMBER
NOTICE
The manufacturer will accept no responsability for any electrical damage resulting from
improper installation of this product, be that either damage to the vehicle itself or to the
installed device. This device must be installed by a certified technician. Please review the
Installation Guide carefully before beginning any work.
U.S. Patent No. 8,856,780
PRODUCT GUIDE
HC1151A
www.idatalink.comAutomotive Data Solutions Inc. © 2016

U.S. Patent No. 8,856,780
GETTING STARTED
WELCOME
NEED HELP?
Congratulations on the purchase of your iDataStart
HC solution. You are now a few simple steps away
from enjoying your new remote starter unit with
enhanced features.
Before starting your installation, please ensure that
your iDataStart HC module is programmed with
the correct firmware for your vehicle and that you
carefully review the install guide.
1 866 427-2999
[email protected]
idatalink.com/support
www.12voltdata.com/forum
www.facebook.com/groups/idatatech
TABLE OF CONTENTS
Box Contents 3
Tach Programming Procedure 4
Remote Programming Procedure 5
Valet Mode Programming Procedure 6
Compatible Accessories 7
Online Module Settings 9
Module Diagnostics 10
Remote Starter Error Codes 11
Module Reset Procedure 12
www.idatalink.comAutomotive Data Solutions Inc. © 2016 HC1151A
PAGE 2 OF 12
• 20161024

U.S. Patent No. 8,856,780
AUTOMATIC
TRANSMISSION
CUT LOOP
B 
NC - 4 PIN RED
TELEMATIC 2 - 4 PIN RED
TELEMATIC 1 - 4 PIN BLUE
NC - 3 PIN BLACK
PROGRAMMING BUTTON
USB
LED 1
LED 2
RF PORT/WEBLINK PORT - 4 PIN BLACK
HOOD SWITCHSTICKERS

7
9
3
10
8
6
4
1
2
5
7
9
3
10
8
11
12
6
4
1
2
5
7
9
3
10
8
11
13
14
12
15
17
18
19
20
16
6
4
1
2
5
4
5
3
2
1
6
4
2
8
1
3
5
7
6
M5
M4
01 ORANGE - ACCESSORY (+)
01 ORANGE - ACCESSORY (+)
02 RED - POWER (30A)
02 RED - POWER (30A)
03 PURPLE - STARTER (+)03 PURPLE - STARTER (+)
04 PINK/WHITE - PROG. RELAY #4 - IGNITION 2 (+) (DEFAULT)04 PINK/WHITE - PROG. RELAY #4 - IGNITION 2 (+) (DEFAULT)
05 PINK - IGNITION (+)
05 PINK - IGNITION (+)
07 RED - POWER (30A)
07 RED - POWER (30A)
08 BLACK - GROUND08 BLACK - GROUND
01 GREEN•BLACK DOT - LOCK (-) OUTPUT
01 GREEN•BLACK DOT - LOCK (-) OUTPUT
02 BLUE•BLACK DOT - UNLOCK (-) OUTPUT02 BLUE•BLACK DOT - UNLOCK (-) OUTPUT
03 RED/WHITE•BLACK DOT - TRUNK RELEASE (-) OUTPUT
03 RED/WHITE•BLACK DOT - TRUNK RELEASE (-) OUTPUT
04 GREEN/WHITE•BLACK DOT - ARM (-) OUTPUT04 GREEN/WHITE•BLACK DOT - ARM (-) OUTPUT
05 GREEN/BLACK•BLACK DOT - DISARM (-) OUTPUT05 GREEN/BLACK•BLACK DOT - DISARM (-) OUTPUT
06 BLUE/WHITE•BLACK DOT - GWR (-) OUTPUT
06 BLUE/WHITE•BLACK DOT - GWR (-) OUTPUT
07 EMPTY07 EMPTY
08 WHITE/PURPLE•BLACK DOT - POC 1 - 2ND UNLOCK OTHER DOORS (-) OUTPUT
08 WHITE/PURPLE•BLACK DOT - POC 1 - 2ND UNLOCK OTHER DOORS (-) OUTPUT
09 PURPLE/BLACK•BLACK DOT - POC 2 - RAP SHUTDOWN (-) OUTPUT09 PURPLE/BLACK•BLACK DOT - POC 2 - RAP SHUTDOWN (-) OUTPUT
10 WHITE/BLACK•BLACK DOT - POC 3 - HORN (-) OUTPUT10 WHITE/BLACK•BLACK DOT - POC 3 - HORN (-) OUTPUT
11 BROWN/BLACK•BLACK DOT - POC 4 - STARTER KILL (-) OUTPUT
11 BROWN/BLACK•BLACK DOT - POC 4 - STARTER KILL (-) OUTPUT
12 WHITE•BLACK DOT - PARKING LIGHTS (-) OUTPUT
01 BROWN•SILVER DOT - BRAKE (+) INPUT
02 BLACK/WHITE•SILVER DOT - E-BRAKE (-) INPUT
03 PURPLE•SILVER DOT - DOOR (+) INPUT
04 GREEN•SILVER DOT - DOOR (-) INPUT
05 PURPLE/WHITE•SILVER DOT - TACH (-) INPUT
06 WHITE/BLUE•SILVER DOT - X-TRIGGER (-) INPUT
07 GRAY•SILVER DOT - HOOD (-) INPUT
08 BLUE•SILVER DOT - TRUNK (-) INPUT
09 GRAY/BLACK•SILVER DOT - GLOW PLUG (+) INPUT
10 EMPTY
FUNCTIONS DEFINED BY FIRMWARE
FUNCTIONS DEFINED BY FIRMWARE
M3
M2
M1
06 WHITE - PROG. RELAY #5 (10A) - PARKING LIGHTS (+) (DEFAULT)06 WHITE - PROG. RELAY #5 (10A) - PARKING LIGHTS (+) (DEFAULT)
M3 - 10 PIN WHITE
M2 - 12 PIN BLACK M5 - 6 PIN BLUE
M4 - 20 PIN BLACK
M1 - 8 PIN BLACK
2X
BOX CONTENTS - 1 OF 1
1-WAY REMOTE
ANTENNA BUTTON
ANTENNA LED
RF PORT - 4 PIN BLACK
ANTENNA
CABLE
ANTENNA
2X
www.idatalink.comAutomotive Data Solutions Inc. © 2016 HC1151A
P
AE
3 OF 12
• 20161024

U.S. Patent No. 8,856,780
01

S
S
OP
OFF ACC ON STARTSTART
START
02
03
04
05
06
TA
   ! " # $ #
START vehicle for 15 seconds.
Press and hold the brake pedal.
Press and release the module’s programming
button. (OR if the remotes are already
programmed to the vehicle, press and hold the
start button of the remote for 2.5 seconds.)
Wait, LED 2 will flash GREEN. (See the Module
Diagnostics page)
Release the brake pedal.
Module Programming Procedure completed.
www.idatalink.comAutomotive Data Solutions Inc. © 2016 HC1151A
PAGE 4 OF 12
• 20161024

U.S. Patent No. 8,856,780
01 [4x]
02
%&'(&%
)*+,*
)*
OP
OFF ACC ON START
ON
03
04
05
06
07
08
-./0.-
12342
12
OP
OFF ACC ON STARTOFF
09
_________________________________
>>
F
_________________________________
567896 :58;5<77=>; :58?6@C56 D F 8G F
WARNING: Complete the module
programming procedure and tach
programming procedure before programming
the remotes. A maximum of four [4x] remotes
per system.
Set ignition to ON position.
Press and release the antenna button, then
press and hold the antenna button. The
antenna’s leds will turn solid BLUE.
Parking Light will flash once [1x].
Press once [1x] on the LOCK button of each
remote.
The antenna’s leds will flash BLUE once [1x]
for each successful pairing.
Release the antenna button. The antenna’s
leds will turn OFF.
Set ignition to OFF position.
Remote Programming Procedure completed.
To program an additional remote as second
vehicle mode: Follow steps 1 to 4. Press twice
[2x] on the “F” button then press once [1x] on
the LOCK button of the remote. Follow steps
6 to 9.
www.idatalink.comAutomotive Data Solutions Inc. © 2016 HC1151A
PAGE 5 OF 12
• 20161024

U.S. Patent No. 8,856,780
>>
01
02
HIJKIH
LMNOM
LM
OP
OFF ACC ON START
ON
03
04
05
PQRTQP
UVWXV
UV
OP
OFF ACC ON STARTOFF
06
>>
V YZ[\ ]^ _ [ `a^baY]]cdb `a^e[ _fa[ g h ^i h
NOTE: In Valet Mode, the Remote starter is not
functional. Keyless entry, Lock and Unlock will
remain functional. See RF kit user manual for
alternate valet mode programming.
Time restriction. Complete next step within 7
seconds.
Cycle ignition ON twice [2x OFF/ON] rapidly.
Press and release the BRAKE pedal three
times [3x].
Parking Light will flash once [1x] then will
flash twice [2x].
Set ignition to OFF position.
Valet Mode Programming Procedure
completed.
To exit valet mode: repeat steps 1 to 5.
www.idatalink.comAutomotive Data Solutions Inc. © 2016 HC1151A
PAGE 6 OF 12
• 20161024

U.S. Patent No. 8,856,780
www.idatalink.comAutomotive Data Solutions Inc. © 2016 HC1151A
PAGE 7 OF 12
• 20161024
jklmnopqrs njjsttkupst v w kx y
MODULE
TELEMATIC BLUE PORT
*For SmartStart, use the module’s RED Telematic port.
(NC)
z{|{}~z z    
10 11 12 13 14 15 16
12345678
9
   ¡ ¢£¤
MOBILE DEVICE
PORT
OBDII CONNECTOR
4 PIN BLACK CABLE
MODULE
WEBLINK PORT
OBDII CONNECTOR
WEBLINK CABLE (required accessory sold separately)
WEBLINK CABLE
COMPUTER
USB PORT
4 PIN BLACK CABLE
MODULE
WEBLINK PORT

U.S. Patent No. 8,856,780
www.idatalink.comAutomotive Data Solutions Inc. © 2016 HC1151A
PAGE 8 OF 12
• 20161024
¥¦§¨© TIBLE ACCESSORIES - 2 OF 2
4 PIN BLACK CABLE
MODULE
RF PORT
ª« ¬® ¯°±²³´µ¶µ·
ANTENNA

U.S. Patent No. 8,856,780
ONLINE MODULE SETTINGS - 1 OF 1
WEB PROGRAMMABLE MENUS DESCRIPTION
MENU 1 – Remote Starter RS related configuration options
MENU 2 – Doorlock Options Convenience feature configuration options
MENU 3 – Security Options Alarm activation and settings
MENU 4 – AUX function assignments Set transmitter AUX buttons controls
MENU 5 – Programmable outputs (POC) Set actions for programmable outputs
MENU 6 – Pulse Timer Output Configuration (PTO) Set duration for pulse timer outputs (if used)
MENU 7 – Input Configurations Set inputs for Auto by firmware/Data/Analog
MENU 8 – Output Configurations Set outputs for Auto by firmware/Data/Analog
Programming options are avaible through Weblink and Weblink Mobile only.
www.idatalink.comAutomotive Data Solutions Inc. © 2016 HC1151A
PAGE 9 OF 12
• 20161024

U.S. Patent No. 8,856,780
MODULE DIAGNOSTICS - 1 OF 1
TEST MODULE
LED 1 STATUS DIAGNOSTIC
I DURING MODULE PROGRAMMING
Flashing RED Missing/wrong information from firmware or vehicle.
Solid RED Module waiting for more vehicle information.
Flashing GREEN Additional steps required to complete module programming.
Solid GREEN then OFF Module correctly programmed.
OFF No activity or module already programmed.
II DURING TACH PROGRAMMING
1 GREEN flash Tach signal programmed in Analog
2 GREEN flashes Tach signal programmed in Data
3 RED flashes No tach signal detected
4 RED flashes System is in valet mode
5 RED flashes Tach set for ‘VTS’. No tach programming required
6 RED flashes Tach set for ‘assumed start’. No tach programming required
III DURING REMOTE START
Flashing RED Module incorrectly programmed.
Solid RED Module incorrectly programmed.
Flashing GREEN Module correctly programmed and operational.
Solid GREEN then OFF Reset in progress.
OFF Invalid ground when running status from remote starter.
IV WITH IGNITION OFF
Flashing RED Module incorrectly programmed or connected.
Solid RED Module not programmed. Waiting for more vehicle information.
Flashing GREEN False ground when running status from remote starter.
Solid GREEN then OFF Reset in progress.
OFF Module at rest and ready for a remote start sequence.
www.idatalink.comAutomotive Data Solutions Inc. © 2016 HC1151A
PAGE 10 OF 12
• 20161024

U.S. Patent No. 8,856,780
¸¹º» TE STARTER ERROR CODES - 1 OF 1
REMOTE STARTER ERROR CODES:
NOTES
[X] NUMBER OF PARKING LIGHT FLASHES DIAGNOSTIC
I WARNING: The following applies only when the parking
lights are connected and supported by the system.
01
¼½¾¿½À Á½½¿½¾Ã
02 Ke
Ä¿½ ¿¾½¿ Å
¿Æ ½ÇÅ ÈÉ Ê ÆË¿
Å
¿Æ ½Ã
II After a remote starter failure, the parking lights will fl ash
three [3x] times, then will fl ash [X] number times to
indicate an error code. See table.
03 Door is open.
04 Trunk is open.
05 Foot brake is ON.
06 Hood is open.
07 The reservation is OFF. (Manual transmission only)
08 Tach failure.
09 The vehicle is moving (VSS).
10 System is in Valet Mode.
11 CAN communication failure
12 RS not synchronized. Start vehicle with OEM key for 15 sec before trying a new RS sequence.
13 Bypass problem.
REMOTE STARTER SHUTDOWN ERROR CODES:
NOTES
[Y] NUMBER OF PARKING LIGHT FLASHES DIAGNOSTIC
I WARNING: The following applies only when the parking
lights are connected and supported by the system.
01 Engine tach signal is lost.
02 Emergency brake is lost.
II If the engine shuts down after a remote starter sequence:
Press and hold the Trunk button and the Start button at the
same time for 2.5 seconds when using a 1-WAY remote.
OR
Press once [1x] on button “4” when using a 2-WAY remote.
The parking lights will flash four [4x] times, then will flash
[Y] number times to indicate an error code. See table.
03 Foot brake is ON.
04 Hood is open.
05 Engine RPM limiter is ON.
06 Glow plug timeout error.
07 Vehicle is moving (VSS).
08 N/A
09 N/A
10 Door is open.
11 CAN communication failure during RS sequence.
12 RS not synchronized. Start vehicle with OEM key for 15 sec before trying a new RS sequence.
13 Takeover is not allowed.
14 Shutdown error, board overheat protection.
www.idatalink.comAutomotive Data Solutions Inc. © 2016 HC1151A
PAGE 11 OF 12
• 20161024

U.S. Patent No. 8,856,780
>>
01
02
03
04
05
06
07
08
>>
MODULE RESET PROCEDURE - 1 OF 1
ÌÍÎ Ï
ollo
ÐÑÒÓ ÔÕ
ocedure resets the module
programming to the vehicle. It does not reset
any settings configured online.
Disconnect all connectors from module except
the M1 BLACK 8-pin connector and the M4
BLACK 20-pin connector.
Disconnect the M1 BLACK 8-pin connector
and the M4 BLACK 20-pin connector.
PRESS AND HOLD the module’s programming
button while connecting the M1 BLACK
8-pin connector and the M4 BLACK 20-pin
connector.
Wait, LED 1 will flash RED. RELEASE
programming button.
LED 1 will turn RED for 2 seconds.
Module RESET completed.
Reconnect all connectors.
Repeat programming procedure.
Failure to follow procedure may result with a
DTC or a CHECK ENGINE error message.
www.idatalink.comAutomotive Data Solutions Inc. © 2016 HC1151A
PAGE 12 OF 12
• 20161024

U.S. Patent No. 8,856,780
20161118
REVISION DATE
ADS-RSA-TL5-[HC1151A]
FIRMWARE
HC1151A
HARDWARE
ADS-USB (OPTIONAL)
ADS-WLM-AN1/ADS-WLM-AP1 (OPTIONAL)
DRONE MOBILE DR-2000 (OPTIONAL)
COMPATIBLE RF-KIT (OPTIONAL)
ACCESSORIES
DOCUMENT NUMBER
2012-2015 SCION IQ 80-BIT STD KEY AT
www.idatalink.comAutomotive Data Solutions Inc. © 2016
INSTALL GUIDE
NOTICE
The manufacturer will accept no responsability for any electrical damage resulting from
improper installation of this product, be that either damage to the vehicle itself or to the
installed device. This device must be installed by a certified technician. Please review the
Installation Guide carefully before beginning any work.

T007_H
T-HARNESS / COMPONENT LOCATOR - 1 OF 1
A
B
C
PAGE 2 OF 9
U.S. Patent No. 8,856,780 2012-2015 Scion iQ 80-bit STD key AT
www.idatalink.comAutomotive Data Solutions Inc. © 2016 ADSRSATL5HC1151AEN
20161118

10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26 27 29 30
1 2 3 4 5 6
7 8 9
28
16
3028
3
3
T007_H
1
5
5
4
4
CUT LOOP FOR AUTOMATIC TRANSMISSION ONLYCUT LOOP FOR AUTOMATIC TRANSMISSION ONLY
JS7 IS NOT USED IF THE VEHICLE IS EQUIPPED WITH AN IMMOBILIZER
T-HARNESS / WIRING DIAGRAM - 1 OF 1
1: GRAY
1: IGNITION CONNECTOR
1: IGNITION HARNESS
1: OBDII CONNECTOR
M5
M4
M2
M3
04 GREEN/WHITE•BLACK DOT04 GREEN/WHITE•BLACK DOT
0303
0404
IGNITION SWITCH (A)
OBDII (B)
MAIN BODY ECU (C)
06 BLUE/WHITE•BLACK DOT06 BLUE/WHITE•BLACK DOT
08 WHITE/PURPLE•BLACK DOT
01 GREEN•BLACK DOT01 GREEN•BLACK DOT
02 BLUE•BLACK DOT02 BLUE•BLACK DOT
03 RED/WHITE•BLACK DOT03 RED/WHITE•BLACK DOT
05 GREEN/BLACK•BLACK DOT05 GREEN/BLACK•BLACK DOT
07 EMPTY07 EMPTY
09 PURPLE/BLACK•BLACK DOT09 PURPLE/BLACK•BLACK DOT
11 BROWN/BLACK•BLACK DOT11 BROWN/BLACK•BLACK DOT
12 WHITE•BLACK DOT - PARKING LIGHT (-) OUTPUT12 WHITE•BLACK DOT - PARKING LIGHT (-) OUTPUT
01 BROWN•SILVER DOT01 BROWN•SILVER DOT
02 BLACK/WHITE•SILVER DOT02 BLACK/WHITE•SILVER DOT
03 PURPLE•SILVER DOT03 PURPLE•SILVER DOT
04 GREEN•SILVER DOT04 GREEN•SILVER DOT
05 PURPLE/WHITE•SILVER DOT05 PURPLE/WHITE•SILVER DOT
06 WHITE/BLUE•SILVER DOT06 WHITE/BLUE•SILVER DOT
08 BLUE•SILVER DOT08 BLUE•SILVER DOT
09 GRAY/BLACK•SILVER DOT09 GRAY/BLACK•SILVER DOT
10 EMPTY10 EMPTY
0101
0202
0505
0606
0707
0808
0909
1010
1212
1313
1414
1515
1616
1717
1818
1919
2020
0101
0404
0505
07 GRAY•SILVER DOT - HOOD (-) INPUT07 GRAY•SILVER DOT - HOOD (-) INPUT
10 WHITE/BLACK•BLACK DOT - HORN (-) OUTPUT10 WHITE/BLACK•BLACK DOT - HORN (-) OUTPUT
HORN (-)
HOOD SWITCH
IF NOT EQUIPPED WITH AN OEM HOOD PIN:
– INSTALL THE SUPPLIED HOOD SWITCH.
– CHANGE REMOTE STARTER INPUT CONFIGURATION (MENU #7) “4- HOOD INPUT SOURCE” TO “1- ANALOG”.
CONNECT BLACK WIRE TO GREEN/RED WIRE
IF VEHICLE IS NOT EQUIPPED WITH IMMOBILIZER
AUTOLIGHT (-) GRAY - 28
AUTOLIGHT (-) GRAY - 28
WITH AUTOLIGHT ONLY
PARKING LIGHT (-) YELLOW - 30
PARKING LIGHT (-) YELLOW - 30
DOORLOCK (DATA) BROWN - 26
0303
0202
0606
1111
JS2
MS2
MS1
AJS5
VS5
VS6
GRAY/RED•BLUE DOTGRAY/RED•BLUE DOT
ORANGE/WHITEORANGE/WHITE
GRAY/BLACK•BLUE DOTGRAY/BLACK•BLUE DOT
GRAY•BLUE DOTGRAY•BLUE DOT
PURPLEPURPLE
JS1
JS9 JS10
VS2
VS1
MS5
1: OBDII HOLDER
GRAY/REDGRAY/RED
GRAY/BLUEGRAY/BLUE
GREEN/REDGREEN/RED
JS7
!
2
2
SOME PARTS OF THE T-HARNESS (MS4-C, MS2-A, VS3/VS4 AND JS8)
ARE NOT USED IN THIS INSTALL DO NOT CONNECT THEM.
SOME PARTS OF THE T-HARNESS (MS4-C, MS2-A, VS3/VS4 AND JS8)
ARE NOT USED IN THIS INSTALL DO NOT CONNECT THEM.
10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26
26 27 29 30
1 2 3 4 5 6
789
28 3028 1
M1
04
0101
0202
0303
0505
0707
0808
0606
!
M3
M1
M2 M5
M4
PAGE 3 OF 9
U.S. Patent No. 8,856,780 2012-2015 Scion iQ 80-bit STD key AT
www.idatalink.comAutomotive Data Solutions Inc. © 2016 ADSRSATL5HC1151AEN
20161118

T007_W
HARDWIRE / COMPONENT LOCATOR - 1 OF 1
A
B
C
PAGE 4 OF 9
U.S. Patent No. 8,856,780 2012-2015 Scion iQ 80-bit STD key AT
www.idatalink.comAutomotive Data Solutions Inc. © 2016 ADSRSATL5HC1151AEN
20161118

!
10 11 12 13 14 15 16
123456
14
6778
9
12
34
5
678
10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26
26 27 29 30
1 2 3 4 5 6
789
28 3028
T007_W
2
1
2
1
3
3
CUT LOOP FOR AUTOMATIC TRANSMISSION ONLYCUT LOOP FOR AUTOMATIC TRANSMISSION ONLY
HARDWIRE / WIRING DIAGRAM - 1 OF 1
1: WHITE
IGNITION 2 (+) LTBLUE - 04
M5
M4
M2
M3
03 BROWN/RED - CANH 1
03 BROWN/RED - CANH 1
04 BROWN/YELLOW - CANL 104 BROWN/YELLOW - CANL 1
1: GRAY
MAIN BODY ECU (C)
CANH (DATA) PURPLE - 06
IGNITION 1 (+) BROWN - 06
STARTER 2 (+) LTGREEN - 01
ACCESSORY (+) BLUE - 03
CANL (DATA) WHITE - 14
PARKING LIGHT (-) YELLOW - 30PARKING LIGHT (-) YELLOW - 30
DOORLOCK (DATA) BROWN - 26
AUTOLIGHT (-) GRAY - 28AUTOLIGHT (-) GRAY - 28
1: WHITE
IGNITION SWITCH (A)
OBDII (B)
12V (+) BLUE - 07
IMMOBILIZER (DATA) RED - 07
STARTER 1 (+) RED - 08
06 BLUE/WHITE•BLACK DOT06 BLUE/WHITE•BLACK DOT
08 WHITE/PURPLE•BLACK DOT
01 GREEN•BLACK DOT01 GREEN•BLACK DOT
02 BLUE•BLACK DOT02 BLUE•BLACK DOT
03 RED/WHITE•BLACK DOT03 RED/WHITE•BLACK DOT
05 GREEN/BLACK•BLACK DOT05 GREEN/BLACK•BLACK DOT
07 EMPTY07 EMPTY
11 BROWN/BLACK•BLACK DOT11 BROWN/BLACK•BLACK DOT
12 WHITE•BLACK DOT - PARKING LIGHT (-) OUTPUT12 WHITE•BLACK DOT - PARKING LIGHT (-) OUTPUT
01 BROWN•SILVER DOT01 BROWN•SILVER DOT
02 BLACK/WHITE•SILVER DOT02 BLACK/WHITE•SILVER DOT
03 PURPLE•SILVER DOT03 PURPLE•SILVER DOT
04 GREEN•SILVER DOT04 GREEN•SILVER DOT
05 PURPLE/WHITE•SILVER DOT05 PURPLE/WHITE•SILVER DOT
06 WHITE/BLUE•SILVER DOT06 WHITE/BLUE•SILVER DOT
08 BLUE•SILVER DOT08 BLUE•SILVER DOT
09 GRAY/BLACK•SILVER DOT09 GRAY/BLACK•SILVER DOT
10 EMPTY10 EMPTY
01 EMPTY01 EMPTY
02 EMPTY02 EMPTY
05 BLUE/RED05 BLUE/RED
06 BLUE/YELLOW06 BLUE/YELLOW
07 EMPTY07 EMPTY
08 ORANGE08 ORANGE
09 YELLOW09 YELLOW
10 EMPTY10 EMPTY
11 GRAY/RED - GROUND (-) INPUT11 GRAY/RED - GROUND (-) INPUT
12 GRAY/YELLOW12 GRAY/YELLOW
13 GREEN/RED13 GREEN/RED
14 ORANGE/WHITE - DOORLOCK (DATA)14 ORANGE/WHITE - DOORLOCK (DATA)
15 BROWN15 BROWN
16 ORANGE/BLACK - IMMOBILIZER (DATA)16 ORANGE/BLACK - IMMOBILIZER (DATA)
17 PINK17 PINK
18 PURPLE18 PURPLE
19 RED19 RED
20 BLACK20 BLACK
02 WHITE/BLACK•BLUE DOT02 WHITE/BLACK•BLUE DOT
04 WHITE/RED•BLUE DOT04 WHITE/RED•BLUE DOT
05 GRAY•BLUE DOT05 GRAY•BLUE DOT
06 WHITE•BLUE DOT06 WHITE•BLUE DOT
07 GRAY•SILVER DOT - HOOD (-) INPUT07 GRAY•SILVER DOT - HOOD (-) INPUT
10 WHITE/BLACK•BLACK DOT - HORN (-) OUTPUT10 WHITE/BLACK•BLACK DOT - HORN (-) OUTPUT
HORN (-)
HOOD SWITCH
1
04 GREEN/WHITE•BLACK DOT
WITHOUT OEM HOOD STATUS ONLY
WITH AUTOLIGHTS ONLY
01 GRAY/BLACK•BLUE DOT - AUTOLIGHT OFF (-) VEHICLE SIDE
01 GRAY/BLACK•BLUE DOT - AUTOLIGHT OFF (-) VEHICLE SIDE
03 GRAY/RED•BLUE DOT - AUTOLIGHT OFF (-) CONNECTOR SIDE
03 GRAY/RED•BLUE DOT - AUTOLIGHT OFF (-) CONNECTOR SIDE
INSTALL THE SUPPLIED HOOD SWITCH IF THE VEHICLE IS NOT EQUIPPED WITH ONE.
09 PURPLE/BLACK•BLACK DOT09 PURPLE/BLACK•BLACK DOT
M1
04 PINK/WHITE - IGNITION 2 (+)
01 ORANGE - ACCESSORY (+)
01 ORANGE - ACCESSORY (+)
02 RED - 12 VOLT (+)
02 RED - 12 VOLT (+)
03 PURPLE - STARTER (+)03 PURPLE - STARTER (+)
05 PINK - IGNITION (+)
05 PINK - IGNITION (+)
07 RED - 12V (+)
07 RED - 12V (+)
08 BLACK - GROUND08 BLACK - GROUND
06 WHITE - STARTER 2 (+)
06 WHITE - STARTER 2 (+)
!
M3
M1
M2 M5
M4
PAGE 5 OF 9
U.S. Patent No. 8,856,780 2012-2015 Scion iQ 80-bit STD key AT
www.idatalink.comAutomotive Data Solutions Inc. © 2016 ADSRSATL5HC1151AEN
20161118

01
OFF
ACC ON
START
02
03
OFF
ACC ON
START
04
OFF
ACC ON
START
05
06
07
08
09
✤✁✂✄☎ ✆✝✞✝✟✤✤✠✡✞ ✆✝☛☎✁✂✝☎ ☞ ✌ ✍ ✌
Turn key to ON position.
Wait, LED 1 will turn solid GREEN for 2
seconds.
Turn key to OFF position.
START vehicle for 15 seconds.
Press and hold the brake pedal.
Press and release the module’s programming
button.
Release the brake pedal.
Wait, LED 2 will flash GREEN.
Module Programming Procedure completed.
PAGE 6 OF 9
U.S. Patent No. 8,856,780 2012-2015 Scion iQ 80-bit STD key AT
www.idatalink.comAutomotive Data Solutions Inc. © 2016 ADSRSATL5HC1151AEN
20161118

>>
01
02
ENGINE
START
STOP
OFF ACC ON START
ON
03
04
>>
✎✣✏✑✒✚✑✓ ✔✓✒✕✑✖✗✓✑ ✘ ✙ ✒✛ ✙
All vehicle doors must be closed and locked
prior to remote start sequence.
Press unlock on OEM or aftermarket remote
or request switch.
DO NOT PRESS BRAKE PEDAL. Set ignition to
ON position. Wait 2 seconds for key validation.
Press and release BRAKE pedal.
Take over procedure completed.
Failure to follow procedure will result in
vehicle engine shutdown.
PAGE 7 OF 9
U.S. Patent No. 8,856,780 2012-2015 Scion iQ 80-bit STD key AT
www.idatalink.comAutomotive Data Solutions Inc. © 2016 ADSRSATL5HC1151AEN
20161118

INSTALLATION CHECKLIST - 1 OF 2
1 WARNING: Vehicle engine will start many times. Test in a well ventilated area.
2 Close all vehicle doors, hood and trunk.
3Press the LOCK button once [1x] on the aftermarket keyfob.

Question 1: Do the doors lock?
YES: Go to next step.

NO: Verify the remote programming, the RF connections and the wired door lock/unlock
connections as illustrated in the wiring diagram, if applicable. Repeat the test and call
technical support, if the problem persists.
4Press the UNLOCK button once [1x] on the aftermarket keyfob.

Question 2: Do the doors unlock?
YES: Go to next step.

NO: Verify the remote programming, the RF connections and the wired door lock/unlock
connections as illustrated in the wiring diagram, if applicable. Repeat the test and call
technical support, if the problem persists.
5Press the TRUNK release button once [1x] on the aftermarket keyfob if supported.

Question 3: Does the trunk or hatch open/unlock?
YES: Close trunk or hatch and go to next step.

NO: Verify the remote programming, the RF connections and the wired trunk/hatch
connections as illustrated in the wiring diagram, if applicable. Repeat the test and call
technical support, if the problem persists.
6Press the AUX 1 button once [1x] on the aftermarket keyfob if supported.

Question 4: Does the driver side sliding door open?
YES: Press the AUX 1 button once [1x] to close the driver sliding door and go to next step.
NO: Verify the remote programming and the RF connections. Repeat the test and call
technical support, if the problem persists.
7Press the AUX 2 button once [1x] on the aftermarket keyfob if supported.

Question 5: Does the passenger side sliding door open?
YES: Press the AUX 2 button once [1x] to close the passenger sliding door and go to next step.
NO: Verify the remote programming and the RF connections. Repeat the test and call
technical support, if the problem persists.
8Press the START/STOP button once [1x] on the aftermarket keyfob to remote start vehicle.

Question 6: Does the vehicle remote start?
YES: Go to next step.
NO: Verify the remote programming, the RF connections and check the remote start error
codes. Repeat the test and call technical support, if the problem persists.
9Press the START/STOP button once [1x] on the aftermarket keyfob to shut down vehicle.

Question 7: Does the vehicle shut down?
YES: Go to next step.
NO: Repeat step. If problem persists, press the brake pedal once [1x] to shut down the vehicle
and call technical support.
10 RAP and auto light shutdown test

Question 8: Did the radio, interior controls and headlights turn off within 60 seconds after
remote start shutdown?
YES: Go to next step.
NO: Verify the RAP SHUTDOWN connections as illustrated in the wiring diagram. Repeat the
test and call technical support if the problem persists.
11 Open hood.
12 If not already installed, affix the mandatory orange warning sticker under the hood and
proceed to next step.
13 Press the START/STOP button once [1x] on the aftermarket keyfob to remote start vehicle.

Question 9: Does the vehicle remote start?
YES: The vehicle is not equipped with a factory hood pin. Install a mandatory aftermarket hood
switch, then repeat the test.
NO: Go to next step.
14 Close hood.
15 Enter vehicle and close the doors.
16 Press the START/STOP button once [1x] on the aftermarket keyfob to remote start vehicle.
17 Wait for the vehicle to start.
18 Press brake pedal.

Question 10: Does the vehicle shut down?
YES: Go to next step.

NO: The module does NOT detect the brake pedal signal. Press the START/STOP button once
[1x] on the aftermarket keyfob to shut down vehicle, check connection as illustrated in the
wiring diagram, if applicable, and call technical support.
19 Exit vehicle.
20 Installation checklist completed.
CHECKLIST - WITH AFTERMARKET KEYFOB
PAGE 8 OF 9
U.S. Patent No. 8,856,780 2012-2015 Scion iQ 80-bit STD key AT
www.idatalink.comAutomotive Data Solutions Inc. © 2016 ADSRSATL5HC1151AEN
20161118
