Idea EVO24-M User manual

1
QS_EVO24-M_EN_v3.3
EVO24-M
Dual-12” Active Line-Array System QuickStart Guide
EVO24-M is an active large-format touring line array system
specically designed for professional sound reinforcement in big
events, large venues or open spaces for audiences from 5000 to
50000, in productions or events operated by rental companies or pro-
audio contractors.
Powered by 2 x 3.2 kW Powersoft power modules, EVO24-M features
dual-12” Neo LF woofers, 4 x 6.5” MF woofers in two sealed chambers
and 2 x 3” Neo compression drivers coupled to a proprietary - design
waveguide assembly.
PRESET
SELECT
GAIN
INPUT
LINK
EVO24-M
Dual-12”ActiveLine-Array
PRODUCTOFEUROPE Madein Spain
Designed,engineeredand manufactured by IDEA
inCedeira(Galicia)
Powersupply:
Universal,regulated
switchmode.
Nominalpower
requirement:
100-240V50-60Hz.
Currentconsumption:
5.4A@220V
CLIP/TEMP
SIGNAL
STATUS
6.4kW 5.4A
MAX
16units 87.5kg

2
QS_EVO24-M_EN_v3.3
TECHNICAL DATA
TECHNICAL DRAWINGS
PRESET
SELECT
GAIN
INPUT
LINK
EVO24-M
Dual-12”ActiveLine-Array
PRODUCTOFEUROPE MadeinSpain
Designed,engineeredand manufactured by IDEA
inCedeira(Galicia)
Powersupply:
Universal,regulated
switchmode.
Nominalpower
requirement:
100-240V50-60Hz.
Currentconsumption:
5.4A@220V
CLIP/TEMP
SIGNAL
STATUS
6.4kW 5.4 A
MAX
16units 87.5kg
1225 mm 550 mm
339 mm
Enclosure design 10˚ Trapezoidal cabinet
LF Transducers 2 × 12'' Neodymium woofers
MF Transducers 4 x 6.5" (2.5" voice coil)
HF Transducers 2 x 3" Neodymium compression drivers
Class D Amp Continuous Power 2 x 3.2 kW
DSP 24bit @ 48kHz AD/DA - 4 selectable presets:
Preset1: 6 array elements
Preset2: 8 array elements
Preset3: 12 array elements
Preset4: 16 array elements
Aiming/Prediction Software EASE FOCUS
SPL (Continuous/Peak) 136 / 142 dB SPL
Frequency Range (-10 dB) 47 - 23000 Hz
Frequency Range (-3 dB) 76 - 20000 Hz
Coverage 90˚ Horizontal
Audio Signal Connectors
Input
Output
XLR
XLR
AC Connectors 1 x Neutrik® PowerCON
Power Supply Universal, regulated switch mode
Nominal Power Requirements 100 - 240 V 50-60 Hz
Current Consumption 5.4 A
Cabinet Construction 15 mm Birch Plywood
Grille 1.5 mm perforated weatherised steel with protective foam
Finish Durable IDEA proprietary Aquaforce High Resistance
paint coating process
Rigging Hardware High-resistance, coated steel integrated 4-point rigging hardware
10 angulation points (0˚-10˚ internal splay angles in 1˚steps)
Dimensions (WxHxD) 1225 x 339 x 550 mm (48.2 x 13.3 x 21.7 in)
Weight 87.5 kg (192.9 lb)
Handles 2 integrated handles
Accessories Rigging frame (RF-EV24)
Transpor Cart (CRT EVO24)
Rain cover for 3 x EVO24 (COV-EV24-3)
Power module rain cover (RC-EV24,included)

3
QS_EVO24-M_EN_v3.3
• All IDEA products are guaranteed against any manufacturing defect for a period of 5 years from date of purchase for acoustical
parts and 2 years from date of purchase for electronic devices.
• The guarantee excludes damage from incorrect use of the product.
• Any guarantee repair, replacement and servicing must be exclusively done by the factory or any of authorized service centres.
• Do not open or intend to repair the product; otherwise servicing and replacement will not be applicable for guarantee repair.
• Return the damaged unit, at shipper’s risk and freight prepaid, to the nearest service centre with a copy of the purchase invoice in
order to claim guarantee service or replacement.
WARNINGS & SAFETY GUIDELINES
WARRANTY
DECLARATIONS OF CONFORMITY
• Read this document thoroughly, follow all safety warnings and keep it for future reference.
• The exclamation mark inside a triangle indicates that whatever repairing and component replacement operations must be done by
qualied and authorized personnel.
• No user serviceable parts inside.
• Only use accessories tested and approved by IDEA and supplied by the manufacturer or an authorized dealer.
• Installations, rigging and suspension operations must be done by qualied personnel.
• This is a Class I device. Do not remove Mains connector ground.
• Only use accessories specied by IDEA, complying with maximum loads specications and following local safety regulations.
• Read the specications and connection instructions before proceeding to connect the system and use only cabling supplied or rec-
ommended by IDEA. Connection of the system should be done by qualied personnel.
• Professional sound reinforcement systems can deliver high SPL levels that may result in hearing damage. Do not stand close to the
system while in use.
• Loudspeaker produce magnetic eld even while they are not in use or even when disconnected. Do not place or expose loudspeakers
to any device that is sensitive to magnetic elds such as television monitors or data storage magnetic material.
• Keep the equipment in the safe working temperature range [0º-45º] at all times.
• Disconnect the equipment during lightning storms and when it is not to be used for a long time.
• Do not expose this device to rain or moisture.
• Do not place any objects containing liquids, such as bottles or glasses, on the top of the unit. Do not splash liquids on the unit.
• Clean with a wet cloth. Do not use solvent-based cleaners.
• Regularly check the loudspeaker housings and accessories for visible signs of wear and tear, and replace them when necessary.
• Refer all servicing to qualied service personnel.
• This symbol on the product indicates that this product should not be treated as household waste. Follow local regulation for recy-
cling of electronic devices.
• IDEA declines any responsibility from misuse that may result in malfunction or damage of the equipment.
!
