Idea EVO55 User manual

QS_EVO55_System_EN_v3.2
For further information,
scan the QR Code
or refer to the following
web address:
www.ideaproaudio.com/evo55-
system
EVO55 System
Dual-5” 4-element Active Line-Array System QuickStart Guide
IDEA is always in pursuit of better performance, greater reliability and design features. Technical
specications and minor nish details may vary without notice in order to improve our products.
©2022 - I MAS D Electroacústica SL Pol. A Trabe 19-20 15350 Cedeira (Galicia – Spain)
EVO55 System is a unique professional portable sound reinforcement solution that oer
excellent modularity and versatility.
The very compact 4-element array cluster (smaller than a typical 15” 2-way loudspeaker)
will always deliver SPL and coverage beyond the physical size of the system, while it can
be rigged and operated with minimal logistical resources. It can be pole mounted, stacked
and own very easily by only operator.
EVO55 loudspeakers features HF assembly with a 1.75” compression driver and a
proprietary wave-guide design and a dual-5” woofer conguration for the LF section. These
premium-quality, high-performance European transducers a dedicated passive crossover
lter allow for a natural, linear response throughout the useful frequency range spectrum
without any processing of the system.
The integrated weatherized steel rigging structure and stacking, transport and rigging
accessories make EVO55 a really plug-and-play system.
EVO55-M EVO55-P
Enclosure design 5˚ Trapezoidal · Ported
HF Transducer 1 x 1.75” Compression Driver
LF Transducer 2 x 5” High Performance Woofers
Amp/DSP Module 1.4 kW -
RMS Power Handling * - 300 W
Nominal Impedance - 16 Ohm
SPL (Continuous/Peak) 119/125 dB SPL
SPL (Continuous/Peak) 4-element system 125/131 dB SPL
Frequency Response (-10 dB) per element 69 - 19000 Hz
Frequency Response (-3 dB) per element 95 - 17000 Hz
Connectors XLR + PowerCON + NL-4 2 x NL-4
Dimensions (WxHxD) 416 x 154 x 396 mm
(16,4 x 6,1 x 15,6 inch)
416 x 154 x 334 mm
(16,4 x 6,1 x 13,1 inch)
Dimensions (WxHxD) - System 416 x 154 x 396 mm
(16,4 x 6,1 x 15,6 inch)
Weight - per element 15.8 kg (33.3 lbs) 13.3 kg (29.3 lbs)
Weight - System 55.7 kg (122.8 lbs)
STATUS
+6
-∞
SIGNAL
CLIP/TEMP
PRESET
SELECT
INPUT
INPUT
LINK
LINK
OUTPUT
OUTPUT
A
A
OUTPUT
OUTPUT
B
B
Maximum 2xEVO55-P
Maximum 1xEVO55-P
12unitsPRESET4
8unitsPRESET3
6unitsPRESET2
4unitsPRESET1
Suspensionofthis product should be imple mented
byqualified professionals followingsafe rigging
practicesandlo calregulations.
Refertothe owner's manuals for rigging
instructions,systemcomponents and suspension
hardwareintendedfo rthisproduct.
PRODUCTOF EUROPE
PRODUCTOF EUROPE
Madein Spain
Madein Spain
Designed,engineeredand manufactured by
Designed,engineeredand manufactured by
IDEAinCedeira (Galicia)
IDEAinCedeira (Galicia)
EVO55-M
Powersupply:
Universalregulatedswitch mode
Currentconsumption:0.81A
Nominalpowerrequirement:
100-240V50-60 Hz
MAX
16units
1,4
kW 1,2A
36.5kg
416 mm
334 mm
154 mm
154mm
396 mm
TECHNICAL DATA
SpeakON NL-4 Links
XLR Audio Input
PowerCON AC Input
STATUS
+6
-∞
SIGNAL
CLIP/TEMP
PRESET
SELECT
INPUT
LINK
OUTPUTA
OUTPUTB
Maximum2x EVO55-P
Maximum1xEVO55-P
12unitsPRESET4
8unitsPRESET3
6unitsPRESET2
4unitsPRESET1
Suspensionofthis product shouldbe implemented
by qualified professionals following safe rigging
practices and local regulations.
Refer to the owner's manuals for rigging
instructions,systemcomponentsand suspension
hardware intended for this product.
PRODUCTOFEUROPE
Madein Spain
Designed, engineered and manufactured by
IDEAinCedeira (Galicia)
EVO55-M
Powersupply:
Universalregulatedswitchmode
Currentconsumption:0.81 A
Nominalpowerrequirement:
100-240V50-60Hz
MAX
16units
1,4kW
RMS 1,2A
36.5kg
BASIC SYSTEM CONFIGURATION The active EVO55-M element features a 1.4
kW Class-D amp and DSP power module by
Powersoft so one EVO55-M element powers 3
EVO55-P elements, as shown in the diagram on
the left, with the dedicated SpeakON NL-4 cable
links included with every EVO55-M.
Depending on the scale of the application, a
medium-sized EVO55-M system can be easily
split into smaller clusters for mobile and portable
solutions.
Passive systems can be congured as factory
ready with TEOd8 driven amps.

QS_EVO55_System_EN_v3.2
I MAS D Electroacústica SL
Pol. A Trabe 19-20 15350 CEDEIRA (Galicia - Spain)
Declares that: EVO55 System
Complies with the following EU Directives:
RoHS (2002/95/CE) Restriction of Hazardous Substances
LVD (2006/95/CE) Low Voltage Directive
EMC (2004/108/CE) Electro-Magnetic Compatibility
WEEE (2002/96/CE) Waste of Electric and Electronic Equipment
EN 60065: 2002 Audio, video and similar electronic apparatus. Safety requirements.
EN 55103-1: 1996 Electromagnetic compatibility: Emission
EN 55103-2: 1996 Electromagnetic compatibility: Immunity
DECLARATION OF CONFORMITY
WARNINGS AND SAFETY GUIDELINES
WARRANTY
!
• All IDEA products are guaranteed against any manufacturing defect for a period of 5 years from date of purchase for acoustical
parts and 2 years from date of purchase for electronic devices.
• The guarantee excludes damage from incorrect use of the product.
• Any guarantee repair, replacement and servicing must be exclusively done by the factory or any of authorized service centres.
• Do not open or intend to repair the product; otherwise servicing and replacement will not be applicable for guarantee repair.
• Return the damaged unit, at shipper’s risk and freight prepaid, to the nearest service centre with a copy of the purchase invoice in
order to claim guarantee service or replacement.
• Read this document thoroughly, follow all safety warnings and keep it for future reference.
• The exclamation mark inside a triangle indicates that whatever repairing and component replacement operations must be done by
qualied and authorized personnel.
• No user serviceable parts inside.
• Only use accessories tested and approved by IDEA and supplied by the manufacturer or an authorized dealer.
• Installations, rigging and suspension operations must be done by qualied personnel.
• Only use accessories specied by IDEA, complying with maximum loads specications and following local safety regulations.
• Read the specications and connection instructions before proceeding to connect the system and use only cabling supplied or rec-
ommended by IDEA. Connection of the system should be done by qualied personnel.
• Professional sound reinforcement systems can deliver high SPL levels that may result in hearing damage. Do not stand close to the
system while in use.
• Loudspeaker produce magnetic eld even while they are not in use or even when disconnected. Do not place or expose loudspeakers
to any device that is sensitive to magnetic elds such as television monitors or data storage magnetic material.
• Disconnect the equipment during lightning storms and when it is not to be used for a long time.
• Do not expose this device to rain or moisture.
• Do not place any objects containing liquids, such as bottles or glasses, on the top of the unit. Do not splash liquids on the unit.
• Clean with a wet cloth. Do not use solvent-based cleaners.
• Regularly check the loudspeaker housings and accessories for visible signs of wear and tear, and replace them when necessary.
• Refer all servicing to qualied service personnel.
• This symbol on the product indicates that this product should not be treated as household waste. Follow local regulation for recy-
cling of electronic devices.
• IDEA declines any responsibility from misuse that may result in malfunction or damage of the equipment.
