Idex Micropump I-Drive IMS Instruction Manual

1
DOC No: 7936 REV D
INSTALLATION, OPERATION AND WARRANTY INFORMATION
I-DrIve®

2
DOC No: 7936 REV D
Signature of Manufacturer
EC DECLARATION OF INCORPORATION
Herewith we declare that the motors described in this Installation, Operation, and War-
ranty Handbook comply with the following provisions applying to it:
Machinery Directive 2006/42/EC
EMC Directive 2004/108/EC
Low Voltage Directive 2006/95/EC
Applied harmonized standards, in particular:
ISO12100-1:2003 (Replacing EN292-1:1991) ISO12100-2:2003 (Replacing EN292-1:1991)
EN14121-1:2006 EN ISO13732-1:2006
EN60950-1:2002 EN563:1994
EN60529:1992 EN55014-1:2001
EN55014-2L1997 EN61000-3-2:2001
EN61000-3-3:1995 EN61000-4-2:1995
EN61000-4-3:2002 EN61000-4-4:2004
EN61000-4-5:1995 EN61000-4-6:1996
EN61000-4-8:1994 CISPR16-2-1:2003
Manufacturer: Importer in country of use:
Micropump Vancouver
1402 NE 136th Avenue
Vancouver, WA 98684
Signature of Importer
The machinery described in this certificate must not be put into service until the machinery in which it is incorporated
has been declared in conformity with the provisions of the Machinery Directive and their amendments.
PUBLISHED BY
MICROPUMP INC.
A Unit of IDEX Corporation
March 2006 © Micropump Inc.
All rights reserved.
This manual contains proprietary information which is protected by copyright.
No part of this publication may be reproduced, transcribed, stored in a retrieval system,
translated into any language (including computer language), or transmitted in any
form without the written consent of the publisher. For further information contact your
local Micropump distributor. Every effort has been made to ensure that the information
contained in this manual is accurate prior to printing. However, the products described
in this manual are subject to continuous development and improvement and Micropump
shall not be liable for any errors contained herein or for incidental or consequential
damages in connection with the furnishing, performance, or use of this manual.

3
DOC No: 7936 REV D
STANDARD LIMITED WARRANTY
The products manufactured by Micropump Incorporated are warranted to be free
from defects in workmanship and material at the time of shipment from the place of
manufacture. Micropump will repair or replace, at its option, any part or component which
fails to conform to this warranty for a period of one year. Micropump’s obligation under
this warranty is limited to the repairs or replacement of defective equipment returned to
Micropump on an F.O.B. destination and freight-prepaid basis. All normal wear and tear
is excepted, and product is subject to examination at Micropump to verify that the parts or
components were defective at the time of sale.
For the purposes of the limited warranties, the “Stator/Controller Assembly” means
only the stator and the printed circuit board and electronic components contained in
the controller housing, plus the connecting control and power cables. The “Power
Supply Assembly” means only the printed circuit board and the electronic or mechanical
components located inside or on the power supply enclosure and the “Pump head
Assembly” means all other parts of the product, including but not limited to, the rotor.
No warranty of any kind is made or shall be imposed with respect to any pump or parts
(1) that have not been properly installed and tested in operation, (2) that have been
subject to misuse, negligence, acts of God or the elements, or any other form of casualty,
or (3) that have been repaired or altered outside Micropump’s facility in a way, so as, in
our judgment, to affect performance or reliability.
The parties agree that the buyer’s sole and exclusive remedy against Micropump shall
be for repair or replacement of defective parts under the conditions stated above. The
buyer agrees that no other remedy (including but not limited to incidental or consequential
damages for lost prots, lost sales, loss of use, injury to person or property, or any other
incidental or consequential loss) shall be available to them.
This warranty shall not apply to prototype pumps, experimental pumps, or brush-type
electric motors. Warranty of equipment or accessories from outside sources, purchased
by Micropump and incorporated into Micropump’s product is subject to the manufacturer’s
standard warranty, unless specically agreed otherwise between Micropump and buyer.
A copy of the warranty on the aforementioned equipment is available on request.
The adjustment or replacement of defective parts made under this warranty will not
extend the original warranty period.
THE WARRANTY DESCRIBED ABOVE IS THE EXCLUSIVE
MICROPUMP WARRANTY AND IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING ANY
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE OR ANY WARRANTY PREVIOUSLY
ISSUED. WE NEITHER ASSUME NOR AUTHORIZE ANY PERSON
TO ASSUME FOR US ANY OTHER LIABILITY IN CONNECTION
WITH THE SALE OR USE OF OUR EQUIPMENT.

4
DOC No: 7936 REV D
represents years of uid handling experience and we feel it is the nest product available
of its type.
The product you have purchased was designed and constructed for use within designated
limits and conditions. Staying within performance limits and following the guidelines given
in this manual will result in excellent performance and maximum life.
Should you have a question or a problem, technical assistance is available worldwide.
Micropump products are designed for easy eld servicing with service kits and technical
support available for all products.
The Purpose of this Guide...
is to provide information to enable suitably qualied technicians and tters to install,
operate and maintain the Micropump I-Drive and common pump/motor combinations.
Use the Guide...
when you have purchased a motor or pump/motor combination. This guide contains
specic information for installation, operation, and maintenance of the I-Drive and
references some of the most common pump/motor combinations. This guide should
be read in conjunction with the instructions provided with your specic pump. General
information is given on installation within a system, but reference should always be made
to instructions provided with ancillary equipment when installing the unit.
Abbreviations
The following abbreviations are used in this guide:
°C Degrees Celsius °F Degrees Fahrenheit
EMC Electromagnetic Compliance DC Direct Current
LVD Low Voltage Directive
IOM Installation, Operation and Maintenance Manual
Max Maximum Min Minimum
RPM Revolutions Per Minute SELV Safety Electric Low Voltage
V Volt(s) W Watt(s)
Bracket
/Flange
Power
Option
Driving
Magnet
Motor Options Code:
Product Labeling
Micropump products are labeled with a product code. The code describes the I-Drive
conguration. The rst nine positions of the code describe the base conguration. The
remaining three positions in the code describe the optional features. Options that are not
used are not shown in the code. For pump/motor assemblies the product code consists of
the rst four positions of the pump code with later positions describing the adaptor and/or
motor. Your Micropump distributor can provide additional information about the product
code.
Type Series Modier Rated
Torque
Speed
Range
Input
Power
Port
Fittings
Enclosure Mount
Motor Code:
Your Micropump Product...

5
DOC No: 7936 REV D
The following are used throughout this guide to indicate procedure that, if not followed
correctly, may result in injury to personnel or damage to equipment.
Warnings are used to alert the reader to a procedure or practice, which if
not followed correctly, could result in personal injury.
Limits of Use 6
Installation in Explosive and Fire Danger Zones 7
Description 7
Function 7
Unpacking and Storage 8
Assembly 8
Space Requirements 8
Location 9
Bulkhead Mounting 9
EMC Compatibility 9
Electrical Connection 10
Lead Assignments 12
Operation 13
Manual Control Adjustment 14
Magnet Decoupling 15
Maintenance 15
Fault Isolation 16
Technical Specication 17-19
Notes 20-22
Table of Contents
CAUTION
NOTE
Warning - Hot Surface is used to alert the reader to a procedure or
practice, which if not followed correctly, could result in personal injury
due to contact with a hot surface.
Cautions are used to alert the reader to a procedure or practice, which
if not followed correctly, could result in damage to the pump, motor, or
ancillary equipment.
Notes are used to highlight important information that may assist the reader in
carrying out a procedure or in understanding the text.
Safety

6
DOC No: 7936 REV D
Limits of Use
The I-Drive motor is intended for use with pumps handling uids in a variety of pumping
systems. These uids may be innocuous or hazardous, depending on the specic
application. You should contact your local Micropump distributor or contact Micropump
directly about special limitations of your pump/motor unit with regard to your specic
system.
To achieve optimum performance and safe operation Micropump products must be
operated with the limits given in the Technical Specication. Operation outside these
limits is not recommended and may result in damage to the pump, motor, and/or ancillary
equipment.
Temperature. Operating beyond the maximum operating temperature
given in the Technical Specication is not recommended and may result
in damage to the product and compromise safety by creating high surface
temperature.
CAUTION
CAUTION
CAUTION
Corrosive Liquids. Corrosive liquids may eventually produce leak paths
around the sealing surfaces of the product. The product should be
inspected for leaks on a regular basis.
Flooding and Water Immersion. The products covered by this guide
are not designed to operate immersed in water. Refer to the Technical
Specication for the environmental rating.
Condensation. When pumping cold liquids ensure that condensation does
not present a safety hazard. Condensation on the external surfaces of the
magnet cup may result in a short-circuit in the motor controller.
Mechanical Danger. The product must be installed in a location that
exposes it to a low risk of external damage.
Hot Surfaces. Under some operating conditions, surface temperatures can
exceed 90°C (195°F.) Do not touch products while operating. Do not touch
within 30 minutes of system shutdown to allow surfaces to reach safe
handling temperature.
NOTE
The I-Drive enclosure is rated to IP55 when properly assembled with the pump
and sealing o-ring. This is dust-protected (not dust-proof) and may be operated
in such an environment.

7
DOC No: 7936 REV D
Installation in Explosive and Fire Danger Zones
The I-Drive motor is not designed or intended for use in explosive or re danger zones.
Contact your local Micropump distributor or contact Micropump directly to determine a
pump/motor assembly that can be certied for this use.
The I-Drive cannot be certied for use in potentially explosive
atmospheres.
Description
The I-Drive is a brushless DC motor with integrated controller specially designed to be
electromagnetically coupled to a variety of Micropump pump heads. When properly
assembled to the pump head with sealing o-ring, this compromises a sealed unit where
the driven magnet is within a magnet cup that separates the pumped uid from the
atmosphere.
The brushless DC motor is enclosed by an anodized aluminum housing and a
polypropylene cover. The motor is capable of rotating in both directions and has 0-5 V,
4-20 mA or manual speed control input. A tachometer signal, with a 0-5 V square-wave
output provides speed feedback. The tachometer output has 2 pulses per revolution.
The output frequency is multiplied by 30 to obtain RPM. The main input power is 24 VDC
from a class 2 (SELV) source.
There are two I-Drive models, the IMS and IEG. Both models are available in 24 VDC
versions only, with speed control and power supply as separate functions. Each model
has 0-5 V square wave tachometer feedback and FWD/REV capability.
Both I-Drive models can be controlled using one of three options:
1. Externally applied 0-5 VDC supply
2. Externally applied 4-20 mA signal
3. Adjustable manual speed control located at the rear of the unit
Function
The driven magnet is connected to the pumping parts and is sealed in the magnet cup.
This magnet forms the rotor of the brushless DC motor is driven by the rotating magnetic
eld in the stator. Rotation of the pumping elements produces ow.
The control signal (supplied internally or externally) controls pump speed. Internal
feedback monitors the rotational speed of the pump and maintains the speed in relation
to the control voltage. The closed loop controller increases current to maintain speed
against increasing back pressure (within the operating limits of the pump and motor).

8
DOC No: 7936 REV D
Before installing the product ensure all transit packaging has been removed.
Remove the blanks from any inlet and outlet ports. If the pump is to be stored prior to
installation, re-pack the pump in its original packing, ret the blanks to the ports and store
in a dry, covered environment.
Protect the pump head from damage during unpacking and installation. Impacts to the
magnet cup can cause internal damage or result in rub between the magnet cup and
driven magnet upon assembly with the motor.
Inspect the magnet cup, hub, or adaptor (if present) before assembly
with the motor. Replace or repair if there are signs of damage.
If the pump head housing assembly and I-Drive motor are supplied separately they will
need to be assembled prior to the installation.
Insert the sealing o-ring (1) into the groove in the face of the I-Drive (3). Align the adaptor
ange (2) so that it ts into the matching recessed on the I-Drive housing. Secure
using the three screws (4) supplied with the I-Drive. Tighten screws evenly and in an
alternating pattern. Torque screws to 0.8 N-m (7 in-lbs).
4
1
3
2
Loose bolts may result in pump/motor misalignment. Tighten bolts
appropriately. Pump/motor misalignment may result in weakening the
sealing of the enclosure. O-Ring 2-070 described below is required for
IP55 rating.
Assembly
Unpacking and Storage
Proper assembly is required to prevent magnet rub due to misalignment.
Space Requirements
Refer to the Technical Specication for overall dimensions and weights of the I-Drive and
some of the most common pump/motor combinations.

9
DOC No: 7936 REV D
The product should be located with the inlet below or even with the liquid level of the uid
supply. The product can be mounted in any position. Ensure that there is adequate space
for operation, inspection and maintenance.
Location
Pump head or adaptor cannot support the weight of the motor. Ensure
the motor is adequately supported by the foundation and/or mounting
bracket.
The foundation must be capable of supporting the combined weight of
the pump and motor and provide a rigid support.
Bulkhead Mounting (IEG Model Only)
If mounting the pump/I-Drive assembly through a bulkhead, insert the bulkhead o-ring (1)
into the groove in the face of the I-Drive (3). Position the adaptor ange (2) through the
bulkhead hole so that it does not interfere with the sealing of the bulkhead hole. Secure
the pump/I-Drive assembly using four screws, nuts, and washers as needed. Tighten
screws evenly and in an alternating pattern.
EMC Compliance
To maintain EMC compliance, the shield (bare wire) is connected internally to the motor
housing through a 220nF capacitor.
NOTE
Compliance with EMC Directive 89/336/EC and subsequent amending
directives is only applicable when the drive is used with the power lead that
has been supplied. Use of another power lead may result in non-compliance.
O-Ring 2-033 described below is necessary to ensure bulkhead is
sealed.
CAUTION
Ø68.3 ±1[2.70 ±.04]
70 2.76
Ø5[.20]
1
3
2

10
DOC No: 7936 REV D
Pumping ammable uids without a proper earthing connection may
cause spontaneous ignition.
I-Drive Electrical Connection
Ensure that the pump motor is earthed. The pump may be electrically
isolated from the motor depending on the mounting conguration. Some
installations may need an earthing connection on the pump head.
Before starting any electrical installation work ensure that the main
electrical supply is adequately isolated.
Electrical installation must be carried out by qualied personnel who are
conversant with local electricity installation regulations.
Ensure that the voltage and frequency of the supply are correct for the
motor being connected, and that the source is Class 2 or a Limited
Power Source.
CAUTION
Ensure that all electrical connections use a common earth ground to
avoid hazardous ground loops.
Ensure that only power supplies having SELV specication are
connected to the I-Drive.
CAUTION
Ensure that all associated equipment has a form of overcurrent
protection. If a fuse is used see table below for recommendations.
CAUTION
The I-Drive does not have reverse-polarity protection. If the common
(black) lead is connected to the positive terminal of the power supply the
motor will be irreparably damaged.
CAUTION
Power In
The main input power is 14 to 30 VDC from a Class 2 (SELV) source applied across the
power in and common ground leads. This voltage must be maintained within the specied
limits as the motor is loaded to its maximum current of 1.8A (Model - IMS) or 2.9A
(Model - IEG.)
Ensure that the power supply voltage ripple is maintained below 5% peak
to peak.
CAUTION
I-DrIve MoDel ProDuct coDe recoMMenDeD fuse
IMs DG-D42.H2 Accu GuArD P/n f1206B3r00fWtr
IeG DG-f61.G1 Accu GuArD P/n f0612D4r00fWtr

11
DOC No: 7936 REV D
I-Drive Electrical Connection (Continued)
Control Signal In
For motors having 0 to 5 VDC or 4 to 20 mA speed control, when the lead is connected
to a supply within the range the motor speed is proportional to the input. If the lead is
connected to a greater input, the motor will run at its maximum speed. If the lead is
connected to a lesser (or reverse polarity) input, the motor will stop.
Common Ground
The input voltage, the 0 to 5 VDC control input, and the tachometer output all use a
common ground. It is possible that ground potential differences between the power
supply, control voltage source and the frequency counter (if used) will be forced to the
same ground reference when connected to the I-Drive. While not typical, in some cases
large current ows can result or undesirable currents can ow through these devices’
ground wires if more than one device is connected to earth ground. Ensure only one
earth ground is used.
Isolated Ground
The motor common (black) wire is isolated from the motor housing. There is an internal
connection between the motor housing and the cable shield (bare wire) which is a
capacitive coupling (220nF, 63V) with the common (black) wire. If the black lead is
connected to the shield, EMC will not be affected. This can be done at the customer
input end of the cable.
Using The Tachometer Output
The tachometer output can be monitored using a frequency counter. The tachometer
output is 0-5V square wave pulse that occurs twice per pump drive revolution. The
frequency range is 0-200Hz. To convert the tachometer output to rpm, multiply the
frequency by 30.
Inadvertent connection of the tachometer output (green) wire to ground
or the supply voltage can cause damage to the drive. If the tachometer is
not used, trim and insulate the green lead.
CAUTION
DO NOT reverse the direction of rotation of the drive until the drive has
come to a complete stop. Reversing the direction while the drive is still
turning may damage the motor.
CAUTION
NOTE
Inadvertent grounding of the forward/reverse (orange) wire will cause the drive
to operate in reverse. If reverse operation is not required, trim and insulate the
orange lead.
COMMON
SHIELD
HOUSING
220nF
63VDC
Forward/Reverse Operation
The direction of uid ow can be changed by connecting the orange wire to ground.
For FORWARD ow, make NO CONNECTION to the orange wire. For REVERSE ow,
connect the orange wire to GROUND.

12
DOC No: 7936 REV D
1
2
3
5
4
6
1
2
3
5
4
6
MODEL IMS
MODEL IEG
Lead Function Color 0-5 VDC
4-20mA Control
Manual Control
1 Power In Red +24 VDC, Class 2 (SELV)
2 Common Black Isolated from motor housing
3 Control Signal In White 0-5 VDC or 4-20mA potentiometer
4 Tachometer Out Green 5 V square wave-2 pulses per revolution
5 FWD/REV Orange Forward (oat and insulate), Reverse
(ground)
6 Shield -- Connected to housing
I-Drive Lead Wire Assignments
The 0-5 VDC Control Signal In is protected to withstand -30 to +30 V applied
to it. Above 6 V and below 0 V the impedance is greater than or equal to 10
kOhm. Within the 0-6 V input range, the input impedance is 30.6 kOhm.
NOTE

13
DOC No: 7936 REV D
Flow rate should always be adjusted by controlling motor speed where
possible. Ensure that overpressure does not occur in the discharge pipe.
NEVER throttle ow by an inlet valve.
Starting or running the pump with the discharge valve closed will
overload the motor resulting in overpressure in the discharge pipe.
Post Start-up Checks
Once the pump has started, carry out the following checks:
1. Check that the pump and motor operate smoothly and are free from vibration.
2. Check the inlet and discharge ttings are free from leaks.
Operation
Start-up Procedure
Before starting the pump ensure that any valves in the inlet or discharge lines are open
and that any inlet lters are clean and free from obstruction.
1. Set the external control signal input to minimum value (0 VDC or 4mA or turn the
manual control fully anti-clockwise.)
2. Set the power supply (24 VDC to max 30 VDC) to ON. With the control input set to
0 VDC, 4mA or the manual control turned fully anti-clockwise, the pump will show a
nominal 40mA to 70mA current draw and will not turn.
3. Adjust the control signal input to the required level. Current demand will rise and fall as
the pump load and speed varies.
Once started the pump should prime if it has not already been lled with uid. If the pump
fails to prime, stop the pump and ll the pump head with liquid.
Shut-down Procedure
Switch off the I-Drive by rst setting the external control signal input to the minimum
value, then switch off the power supply. Check that the unit runs down in a steady
manner. Close the inlet and discharge valves. Drain the pump if it is to be shut-down for
long periods or installed in areas where the liquid may freeze. Refer to the Maintenance
section for instruction on draining.
Extended periods of dry running may result in permanent damage to the
pump and may cause surface temperature to exceed the operating
temperature of the pump. Ensure that the pump head temperature does
not exceed the ash point temperature of the uid or area. Shut down
pump for a no uid condition. Shut down the pump for a no ow condition.
CAUTION
Ensure the pump head temperature does not exceed the ash point
temperature of the uid or area.
Two-wire mode is available on the 0 to 5 VDC control models. To run the
motor in two-wire mode, the control (white) wire can be connected to the
positive supply (red) wire. The motor will run at its maximum speed. The
speed control will not be damaged if the applied voltage is within +/-30 VDC of
the common (black) wire, though maximum speed is achieved at +5 VDC or
higher, and the motor will stop if 0 VDC or lower is applied.
NOTE

14
DOC No: 7936 REV D
The drive enclosure is rated to IP55. The enclosure rating is maintained
by using the manual control cover screw and seal. After adjustment,
these components must be replaced and secured to the proper torque
in order to maintain the enclosure rating and protection of internal drive
controller.
Manual Control Adjustment
Manual Control Adjustment
If your drive is equipped with the manual control option, the speed of the drive is
controlled by local adjustment of an internal potentiometer. To adjust the speed set point:
1. Remove and retain the M3 cover screw (1) using a small screwdriver.
2. Remove and retain the screw seal (2).
3. Insert a small screwdriver (3) into the access hole and engage the potentiometer
adjustment screw. To increase speed, rotate the adjustment clock-wise. To decrease
speed, rotate the adjustment counter-clockwise. The potentiometer is equipped with
a slip coupling which will allow the user to continue to turn the adjustment screw after
maximum and minimum speed is reached.
4. When adjustment is complete, replace the screw seal (2) and (1) the cover screw.
Tighten the cover screw to 6 in-lb (678 mNm).
CAUTION
1
2
3

15
DOC No: 7936 REV D
Maintenance
Excessive wear to the pump can result in driven magnet rub on the
magnet cup. This can generate high surface temperatures or degrade the
capability of the pressure boundary. Remove the pump from service and
replace or repair if pump performance degrades signicantly or the pump
becomes noisy.
Ensure that heavy deposits of dust are not allowed to accumulate. Clean
the pump periodically.
The pump cannot be drained completely, a certain amount of liquid will
remain in the magnet cup area. Ensure that the pump is either ushed
with a suitable ushing agent or precautions are taken against the effect
of any remaining liquid during servicing. When the pump has been
handling ammable, toxic or hazardous uid, the pump internals must
be properly decontaminated by suitably qualied personnel. The Material
Safety Data Sheet for the pumped liquid must be referred to for correct
procedures and precautions to be followed when handling the liquid.
Micropump I-Drive motors are designed to be maintenance free and, apart from manual
speed control models, require no adjustments. To ensure the motor or pump/motor
assembly retains optimum performance maintain the uid circuit to keep lters clean and
prevent abrasive solids from passing through the pump.
A program that includes periodic monitoring of your Micropump product is
recommended to provide timely detection and assessment of any problem.
NOTE
Magnet Decoupling
The I-Drive pump/motor combinations do not decouple. If pump load becomes excessive,
current limiting in the controller prevents motor overload. Additional protection is provided
by a thermal sensor which shuts down the drive if the housing temperature exceeds
80°C (176°F).

16
DOC No: 7936 REV D
Fault Isolation
If the I-Drive does not meet its design performance or fails to operate correctly, refer to
the following tables for assistance in identifying the cause and remedy:
MOTOR WILL NOT OPERATE
Cause Remedy
No power to motor. Ensure proper voltage has been applied to motor power leads.
Check leads to ensure no short circuits are present.
Control Input lead is shorted. Clear and isolate Control Input lead from Tachometer Out lead. Clear and
isolate Control Input lead from Common lead.
No Control Input applied. Ensure proper control input is applied to Control Input lead.
If manual control I-Drive, adjust potentiometer clockwise.
Ensure control power supply common is connected to the Common lead.
Thermal Limit is active. Turn off motor and wait for temperature to cool below 70°C (158°F). NOTE: If
power voltage and control signals are present, motor will automatically restart
when temperature is reached.
Reduce motor load conditions and/or improve cooling of motor housing if
persistent limit occurs.
Motor has been damaged. Contact your Micropump Distributor or contact Micropump directly for replace-
ment product.
CYCLIC NOISE OR VIBRATIONS
Cause Remedy
Loose motor mounting bolts. Tighten motor mounting bolts.
Foundation not rigid. Relocate motor.
Pump loose on motor. Tighten pump mounting bolts.
Pump is worn. Replace or repair pump.
Tachometer Out lead is shorted
to FWD/REV lead.
Clear and isolate Tachometer Out lead from FWD/REV lead.
NO TACHOMETER SIGNAL
Cause Remedy
No power to motor. Ensure proper voltage has been applied to motor power leads.
Check leads to ensure no short circuits are present.
Improper wiring. Check that the Tachometer Out lead is connected to the positive input of the
frequency counter.
Check that the common lead of the frequency counter is connected to the motor
Common lead.
Check leads to ensure no short circuits are present.
Motor is stopped. Ensure proper voltage has been applied to motor power leads Ensure proper
control input is applied to Control Input lead.
If manual control I-Drive, adjust potentiometer clockwise.
Ensure control power supply common is connected to the Common lead.
MOTOR RUNS IN THE WRONG DIRECTION
Cause Remedy
FWD/REV lead is shorted to
Common lead.
Clear and isolate FWD/REV lead from Common lead. Check leads to ensure no
short circuits are present.
Execution of troubleshooting steps, determination of root cause and
corrective actions should be performed by a skilled maintenance person.

17
DOC No: 7936 REV D
All Dimensions in mm.[inch]
Technical Specication
Not all possible congurations are shown. Contact your local Micropump
distributor or contact Micropump directly for additional versions.
I-Drive
Model IMS
Product Code DG-D42.H2
Speed Range 500 to 6000 rpm
Typical No-Load Speed
(24 VDC Input / 5 VDC Control / 25°C
Ambient)
6000 rpm
Speed @ Rated Torque 3500 rpm @ 56 mNm (8 oz-in)
Input Voltage Range 14 to 30 VDC
Max Full-Load Current @ Nominal Voltage
(25°C Ambient)
1.8A @ 24 VDC
Speed Control 0 to 5 VDC / 4 to 20mA / Manual
Tachometer Out 0 to 5 VDC square wave - 2 pulse per revolution
Thermal Shutdown 80°C (176°F)
Thermal Restart 70°C (158°F)
Storage Temperature -40 to +85°C (-40 to +185°F)
Maximum Ambient Operating Temperature 40°C (104°F)
Reversible Yes
Enclosure Rating IP55
Weight 0.37 kg (.82 lbs)
52.4 2.06
71 2.80
44.4 1.75
30.5 [0.60]
48.3 [0.95]
Ø4.2 [Ø0.08]
Model IMS
NOTE
NOTE

18
DOC No: 7936 REV D
57.7 2.27
5 .20
88.9 3.50
70 2.76
70 2.76
Ø 5 .20
I-Drive
Model IEG
Product Code DG-F61.G1
Speed Range 500 to 5500 rpm
Typical No-Load Speed
(24 VDC Input / 5 VDC Control / 25°C
Ambient)
5500 rpm
Speed @ Rated Torque 3500 rpm @ 106 mNm (15 oz-in)
Input Voltage Range 14 to 30 VDC
Max Full-Load Current @ Nominal Voltage
(25°C Ambient)
2.9A @ 24 VDC
Speed Control 0 to 5 VDC / 4 to 20mA / Manual
Tachometer Out 0 to 5 VDC square wave - 2 pulse per revolution
Thermal Shutdown 80°C (176°F)
Thermal Restart 70°C (158°F)
Storage Temperature -40 to +85°C (-40 to +185°F)
Maximum Ambient Operating Temperature 40°C (104°F)
Reversible Yes
Enclosure Rating IP55
Weight 0.37 kg (.82 lbs)
Model IEG

19
DOC No: 7936 REV D
85.5 3.37
55 2.17
50.8 2.00
40.8 1.61
5 .20
77.9 3.07
44.5 1.75
126.4 4.97
61.9 2.44
4.7 .19
Model IMS Mounting Bracket
Model IEG Mounting Bracket

20
DOC No: 7936 REV D
Notes
