1. Revision Log
Rev
Date
Approved
Changes
1.00
9-24-2008
AGK
Initial requirements
1.10
4-19-2012
Added details for the AutoFill output
1.20
5-01-2015
GMC
Changed part number of Transducer
1.30
6-12-2019
MH
Added passwords to turn on/off start-up text scroll

FORM-ENG-0018 REV A 05-27-03
607 NW 27th Ave
Ocala, FL 34475
Ph: 352-629-5020 or 1-800-533-3569
Fax : [phone] or 1-800-520-3473
SUITABLE FOR EXTERNAL DISTRIBUTION
OPERATION MANUAL
PAGE
5 of 27
DATE
6/12/2019
PRODUCT GROUP
ITL40
P/N
118404-XX
REV
1.30
PRODUCT
Intelli-Tank Level 40
BY
AMS
MANUAL P/N:118253 PRINTED:6/12/19
2. System Overview
2.1. Scope
The Intelli-Tank Level 40 (ITL40) is designed to display a liquid’s volume to an eighth of a tank level accuracy through
180-degree viewable ultra-bright LEDs. An Intelli-Tank Level 40 set as a MASTER uses a 0-5 PSI (0-34.47 kPa,
0-0.3447 bar) pressure sensor to obtain tank level information and then relays that information along the
communication line(s) (1-Wire or CAN) to ITL40’s set as REMOTES. Multiple REMOTE units can be linked to the
MASTER tank level.
2.2. Part numbers Standard with auto fill
Tank Level Gauge C1 –p/n 118404-01 123340-01 –Red LEDs
p/n 118404-02 123340-02 –Amber LEDs
p/n 118404-03 123340-03 –Yellow LEDs
p/n 118404-04 123340-04 –Green LEDs
p/n 118404-05 123340-05 –Blue LEDs
p/n 118404-06 123340-06 –2 Red, 2 Yellow, 2 Blue, 2 Green rows of LEDs
Labels C1 –p/n 117691 –water (blue)
p/n 117692 –foam (red)
p/n 117693 –foam (green)
Pressure Sensor C1 –p/n 200-00093 –0 to 5 PSI (0 to 34.47 kPa, 0 to 0.3447 bar) gage
Adapter bushing C1 –p/n 102219 –¾ to ¼ NPT
Installation Harness C1 –p/n 118485-10 –Master display, 10 feet
p/n 118485-20 –Master display, 20 feet
p/n 118485-30 –Master display, 30 feet
p/n 118485-40 –Master display, 40 feet
p/n 118695 –Remote display
Terminating resistor (CAN) C1 –p/n DT06-3S-P006
“Y” connector (CAN) C1 –p/n DT04-3P-P007
Operation Manual C1 –p/n 118253
One Page Manual C1 –p/n 118252
2.3. Modes of Operation
Master When the ITL40 display is calibrated with a proper pressure signal it automatically becomes a MASTER
display and will send tank level information along the communication line(s) (either 1-wire or CAN) to all
other REMOTE displays.
Remote ITL40 displays are initially shipped as REMOTE displays. A REMOTE display only requires power,
ground and communications line(s) (either 1-wire or CAN). The REMOTE display mimics the MASTER
display’s LEDs by reading the appropriate information on the communication line(s).

FORM-ENG-0018 REV A 05-27-03
607 NW 27th Ave
Ocala, FL 34475
Ph: 352-629-5020 or 1-800-533-3569
Fax : [phone] or 1-800-520-3473
SUITABLE FOR EXTERNAL DISTRIBUTION
OPERATION MANUAL
PAGE
6 of 27
DATE
6/12/2019
PRODUCT GROUP
ITL40
P/N
118404-XX
REV
1.30
PRODUCT
Intelli-Tank Level 40
BY
AMS
MANUAL P/N:118253 PRINTED:6/12/19
3. Operation
3.1. LED indications
The ITL40 display uses 8 rows of LEDs to show the unit status, tank level indication (section 3.1.2), and error
indications (section 3.1.3).
3.1.1. Initial power ON indications
When the ITL40 is first powered up the display will…
1. Turn ON all of the LEDs then immediately cycle OFF each LED starting at the top row.
2. Display the custom scroll greeting (default is “CLASS 1”, but can be custom configured –section 3.8).
3. The LEDs will show the tank level indication (section 3.1.2) or error indication (section 3.1.3).
3.1.2. Level indications
