Idex Godiva GV10000 User manual

Vehicle Mounted Fire Pump GV10000
Model
Installation Manual
Operation Manual
Workshop Manual
Parts List
Godiva Ltd
A Unit of IDEX Corporation
Charles St
Warwick CV34 5LR
England
Tel [phone]
Fax [phone]
www.godiva.co.uk
[email protected]
GP/180/02 Issue 2021

2
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the right
to amend specifications without notice or obligation.
AMENDMENT RECORD
Model: GV10000
Mod
No.
Date
Page/s
Amendment
New Issue No.
July 2002
New Issue
1
1
Sep 2021
39
Insertion of installation manual with
corresponding drawings. Addition of
shipping details and
lifting locations.
Layout of manual
also updated;
previous content remains the same.
2

3
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the right
to amend specifications without notice or obligation.
CONTENTS
AMENDMENT RECORD .............................................................................................................................. 2
CONTENTS .................................................................................................................................................. 3
SAFETY ........................................................................................................................................................ 4
IN OPERATION ............................................................................................................................................. 4
TRAINING.................................................................................................................................................... 4
MAINTENANCE ............................................................................................................................................ 4
ENVIRONMENTAL PROTECTION .................................................................................................................... 4
RISK ASSESSMENT...................................................................................................................................... 4
TRANSPORTATION AND STORAGE ................................................................................................................ 4
POST-PRODUCTION CLEANING FLUID ........................................................................................................... 5
WARRANTY................................................................................................................................................. 5
ESSENTIAL INSTALLATION DATA.................................................................................................................... 6
INSTALLATION............................................................................................................................................ 7
LIFTING POINTS.......................................................................................................................................... 8
OPERATION................................................................................................................................................. 9
GENERAL DESCRIPTION......................................................................................................................... 10
SHIPPING DETAILS:.................................................................................................................................... 10
LUBRICATION ........................................................................................................................................... 10
PROTECTION AGAINST FROST.............................................................................................................. 10
PERFORMANCE CURVE .......................................................................................................................... 11
PUMP OVERHAUL .................................................................................................................................... 12
SUCTION TUBE &SUCTION TUBE SEALING RING ............................................................................ 12
SUCTION TUBE SEALING RING ........................................................................................................... 12
VOLUTE BODY ...................................................................................................................................... 13
PRIMING VALVE .................................................................................................................................... 13
IMPELLER .............................................................................................................................................. 14
IMPELLER .............................................................................................................................................. 14
CARBON SEAL &SEALING RING ETC................................................................................................. 15
WEARING RING ..................................................................................................................................... 16
TACHOMETER DRIVE........................................................................................................................... 16
OIL SEALS.............................................................................................................................................. 16
DRIVE SHAFT BEARINGS..................................................................................................................... 17
WATER RING PRIMER .......................................................................................................................... 17
WATER RING PRIMER .......................................................................................................................... 18
PRIMER DISENGAGING UNIT .............................................................................................................. 19
SPARE PARTS LIST.................................................................................................................................. 20
HOW TO READ THE SPARE PARTS LIST ............................................................................................ 21
GVB10000 SPARE PARTS......................................................................................................................... 22
PUMP HEAD AND PUMP DRIVE SHAFT ........................................................................................................ 26
VOLUTE BODY AND SUCTION TUBE ASSEMBLY ........................................................................................... 27
WATER RING PRIMER................................................................................................................................ 28
PRIMING VALVE ........................................................................................................................................ 29
PRIMER DISENGAGING UNIT ...................................................................................................................... 30
GV10000 PUMP ASSEMBLY DRAWING....................................................................................................... 31
INSTALLATION POINTS................................................................................................................................ 33
SPECIFICATION ........................................................................................................................................ 36
GODIVA CUSTOMER SUPPORT DOCUMENTS ..................................................................................... 37

4
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the right
to amend specifications without notice or obligation.
SAFETY
Please read this manual before operating the machinery.
Safety notices -
= Non-compliance could affect safety
= In case of damage to pump
= In case of personal hazards
In operation
Rotating parts must be guarded against accidental contact.
Water ring primer pulley, lift off cylinder area and assembly need to be guarded by
vehicle builder.
Do not insert items into the suction tube when pump is running.
Discharge hoses must not be disconnected when the unit is running.
No components must be unfastened when the unit is running.
When installing or removing the pump, suitable lifting equipment must be used.
Suitable ear protection must be worn when pump is running – if necessary.
Maximum allowable inlet pressure is 12 bar.
Do not run the pump without water for more than one minute.
Training
Godiva pumps must only be operated by trained personnel.
Maintenance
The user must maintain the equipment in an operational condition, as per regulation 5 in
the Provision and Use of Work Equipment Regulations 1998.
Environmental Protection
Used oil from the pump bearing housing must be disposed of in accordance with your
local regulations
Risk Assessment
It is the duty of the pump installer to make a method statement and risk assessment of
their operations when installing the pump, please contact Godiva Ltd. if assistance is
required.
Transportation and Storage
The pump is supplied mounted on a wooden pallet and covered with a tri-walled
cardboard box. This protection is suitable for standard methods of freight handling using
forklift trucks. No more than one pump should be stacked on top of another. The tri-walled
IMPORTANT
ATTENTION
!

5
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the right
to amend specifications without notice or obligation.
cardboard box is not suitable for storage outside, or when open to the elements. The
pump is sprayed internally with a moisture inhibitor when leaving the factory, this
treatment may be required if the pump is in long term storage (6 months or more) before
use. On receipt of the pump a full inspection must be carried out, if any damage has
occurred please contact Godiva Ltd.
Post-production Cleaning Fluid
Immediately after production a special cleaning solution is used to clear the pump of any
oil or grease that may be remaining inside the pump. Occasionally this cleaning solution
leaves a deposit. This deposit has no effect on the performance and will be flushed away
when the pump is first used.
Warranty
For all issues relating to warranty claims please contact Godiva Ltd. Please be prepared
to quote the six-figure pump serial number located on the pump volute.
Cleaning fluid deposit –
will be flushed away
when pump is used

6
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the right
to amend specifications without notice or obligation.
Essential installation data
Fastening bolts, pump to chassis
cross-member
Use 3/4” UNC or M18 fasteners four off,
minimum strength grade 8.8.
Alignment of pump drive lines
7° Effective joint angle – maximum.
Tank to suction pipework
No tank to pump connection.
Pump speed sensor (accessory)
A mechanical tachometer is available
Godiva part UFP2568. Please contact
sales for the drive cable.
Pump weight
321kg
Pump connections
Flexible joints are required to be fitted
by the vehicle builder to include the
drive coupling, the suction coupling, and
the delivery connection.
Cooling
A thermal relief valve, to prevent
overheating If the pump is operated
without discharging water for a long
period, is available to purchase from
Godiva. If this option is not chosen, the
vehicle builder should install a cooling
system to prevent overheating.
Pressure
If the pump will be used above the 18
Bar discharge pressure, then the
vehicle builder must add a way to
ensure this does not happen. For
instance by incorporating a pressure
relief valve.

7
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the right
to amend specifications without notice or obligation.
INSTALLATION
1) Before installation check the pump for any transit damage.
2) Water Ring Primer (WRP)
This type requires a header tank (4.5 litres, 1 gallon capacity minimum) to be
installed by the vehicle builder. Information sheet ref. DS325 (page 22) provides
details.
In cold weather a suitable anti-freeze concentration must be maintained in the
tank.
3) Pump draining
The pump can be fitted with a drain system from the plug (G ½”) at the bottom of
the volute. This should terminate at a ball valve located lower than the pump.

8
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the right
to amend specifications without notice or obligation.
LIFTING POINTS
Weight:
Mk21 – Gunmetal
321Kg.
Use lifting straps that
can support the
respective weights
above.
Mount strap around the
suction tube flange.
Mount strap around the
pump driving shaft.

9
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the right
to amend specifications without notice or obligation.
OPERATION
Basic Operation
The Godiva Prima pump is designed for extinguishing fires with an unrestricted water
source. Water must be as clean as possible and can be fresh water or sea water.
Operator Controls
Operation of the pump is by two basic controls – discharge valve and pump speed control.
After use:
If pump has been used with foam, stale water or contaminated water, flush after use.
•Do not use the pump in explosive environments.
•Do not use the pump without the inlet screen fitted.
•Do not run the pump without water for longer than one minute, as dry running
will damage the seal.
•Do not exceed the maximum inlet pressure of 12 bar.

10
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the right
to amend specifications without notice or obligation.
GENERAL DESCRIPTION
The Godiva single-stage centrifugal pump is driven in a clockwise direction as viewed
from the drive end. The pump drive shaft is stainless steel and runs on ball bearings in
an oil bath. Shaft sealing is by a special mechanical face seal ensuring efficiency and
long life without adjustment. The tachometer drive gears provide a 4:1 reduction ratio.
Priming is achieved automatically by means of a water ring primer. When the pump is
started, the primer is driven via a pulley on the pump shaft and a fibre wheel on the
primer shaft. The water ring primer impeller is thus turned to cause a depression in the
priming pipes, so allowing atmospheric pressure to force water into the suction tube.
When the water reaches the pump impeller and pressure builds up in the volute, this
pressure is transmitted to the disengaging unit which lifts the primer out of engagement
with the pump drive pulley.
A non—return valve is provided on the water ring primer to prevent air from passing
through the primer and into the pump.
The GVB10000 is made of phosphor-bronze (Gunmetal).
The Pump is fitted with 203mm (8”) diameter suction flange and 127mm (5”) diameter
discharge flange.
Shipping details:
case size: 76 x 760 x 910
Weight 336Kg
LUBRICATION
The oil bath provided for the pump shaft ball bearings has a capacity of approximately 2
pints (1.14 litres) and should be topped up when necessary with S.A.E.30 oil until the oil
reaches the top of the filler hole. It is suggested that the oil bath is drained and refilled
with fresh oil every six months.
The bearings for the water ring primer are sealed with grease and it should be necessary
to re-sealed with grease only if the primer is dismantled. Use a good quality general
purpose grease.
PROTECTION AGAINST FROST
As a precautionary measure when frost is anticipated, drain the water from the pump and
its ancillaries.
The pump itself is drained by removing the drain plug from the underside of the volute.
The water ring primer should also be drained, the method of doing this will depend on the
installation of the pump

11
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the right
to amend specifications without notice or obligation.
PERFORMANCE CURVE

12
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the right
to amend specifications without notice or obligation.
PUMP OVERHAUL
CHAPTER 1
SUCTION TUBE & SUCTION TUBE SEALING RING
Removing and Refitting
To remove the suction tube, undo the union nuts at each end of the priming suction pipe
and take off the pipe.
Remove the eight bolts and sealing washers securing the suction tube to the volute body
and take off the suction tube. This will reveal the suction tube sealing ring which has four
holes tapped ½” UNC to allow jacking bolts to be used.
Joint washers are fitted between the volute body and the sealing ring, and between the
sealing ring and the suction tube.
When refitting the suction tube sealing ring and the suction tube, ensure that the flanges
are clean. Fit new joint washers with a smear of jointing compound.
CHAPTER 2
SUCTION TUBE SEALING RING
Maintenance Attention
Check diameter ‘A’ of the suction tube sealing ring (see Fig. 1). If it exceeds 207.3mm
(8.163”) the suction tube sealing ring should be renewed.
Figure 1

13
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the right
to amend specifications without notice or obligation.
CHAPTER 3
VOLUTE BODY
Removing & Refitting
Slacken the clips and disconnect the rubber hose from the priming valve to the primer.
Remove the sixteen bolts and sealing washers which attach the volute body to the pump
head and remove the volute body.
When re-assembling, ensure that the flange faces are clean. Fit a new joint washer with
a smear of jointing compound.
A 5/8” UNC stud, fitted temporarily into one of the tapped holes in the volute body, will be
useful in guiding the volute body into position when re-assembling.
CHAPTER 4
PRIMING VALVE
Maintenance Attention
The priming valve may be left in position for examination of internal components, but if it
is necessary to remove the valve, remove the priming pipe and rubber hose from the
valve and remove the nuts, spring washers, plain washers and bolts which secure it to its
bracket. Lift off the valve.
To dismantle the valve, remove the three nuts, spring washers, plain washers and bolts
which retain the end plates. These can then be removed together with the spring. The
diaphragm is exposed and may be examined for deterioration, cracks, wear etc.
To examine the valve sealing washer, unscrew the self-locking nut from the centre bolt
and remove the spring washer, large stepped washer, and the nitrile rubber seal. The
seal and its seating should be examined for damage. Should the diaphragm require
renewing, this should be carried out at this stage.
When refitting the end covers ensure that the flange faces are clean. Use a new paper
gasket with jointing compound on the inlet cover, (this is at the end opposite to the
diaphragm) and replace in position. Fit the return spring. Push the three bolts through the
cover and the body and refit the diaphragm end cover plate. Replace the nuts and
washers to complete the assembly.

14
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the right
to amend specifications without notice or obligation.
CHAPTER 5
IMPELLER
Removing & Refitting
In order to remove the impeller, take off the volute body as in Chapter 3. Undo the impeller
nut and remove the impeller from the splined shaft, carefully levering between the impeller
and the pump head if necessary.
When refitting the impeller, use a new split pin to secure the slotted nut. There is a hole
through the shaft to receive the split pin.
CHAPTER 6
IMPELLER
Maintenance Attention
Check dimensions ‘B1’ and ‘B2’ on the impeller (see Fig. 2). If ‘B1’ is less than 204.5mm,
(8.05”) or if ‘B2’ is less than 203.2mm (8.00”), fit a replacement impeller.
Figure 2

15
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the right
to amend specifications without notice or obligation.
CHAPTER 7
CARBON SEAL & SEALING RING ETC
Maintenance Attention
With the impeller removed, (see Chapter 5), access is gained to the carbon seal seating
ring, its spring, the carbon seal and the wearing ring.
In the event of excessive leakage past the carbon seal or from the drain hole in the pump
head, first examine the two O-rings (one under the carbon seal, and one in the carbon
seal seating ring). Renew if necessary.
To remove the O-rings, pull the shaft sleeve off the shaft complete with carbon seal
seating ring.
The seating ring can be removed from the shaft sleeve by removing the round wire circlip
which retains it. The O-ring can then be seen inside the seating ring.
The carbon seal can now be removed from the housing and will reveal the other O-ring.
Examine the carbon seal. If the end face which bears on the seating ring is scored, a new
carbon seal must be fitted. In this case it is advisable to also renew the seating ring. The
original seating ring can be re-used if the sealing face is lapped flat.
Re-assembly is straight forward, the round wire circlip to retain the seating ring on the
shaft sleeve.
To install the seal do not use grease, use a water-based lubricant. Clean the faces with
a solvent and wet faces with clean water before assembly.

16
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the right
to amend specifications without notice or obligation.
CHAPTER 8
WEARING RING
Maintenance Attention
Check diameter ‘C’ (Fig. 3) of the wearing ring. If it exceeds 205. 9mm (8.107”), fit a new
wearing ring. This entails the removal of six bolts and washers. Two 5/16” UNC jack bolts
may be used.
Figure 3
CHAPTER 9
TACHOMETER DRIVE
Maintenance Attention
To remove the tachometer drive, remove the two bolts and spring washers securing the
tacho drive housing to the bearing housing. Take out the drive assembly.
Normally requires no attention, but if a new pinion has to be fitted, a new thrust button
must also be fitted.
CHAPTER 10
OIL SEALS
Removing & Refitting
In the remote event of an oil leak from the bearing housing, then one, or both, oil seals
must be replaced.
To remove the oil seal from the drive flange end, remove the split pin, slotted nut, and
washer, from the pump shaft, and pull off the drive flange. The oil seal housing will now
be exposed and can be removed by undoing the six bolts and washers which secure it.

17
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the right
to amend specifications without notice or obligation.
Press out the old oil seal towards the stepped face of the housing. Press in the new oil
seal in the opposite direction, making sure that the open end of the seal is towards the
stepped face of the housing.
To remove the oil seal from the impeller end of the bearing housing it is necessary to
remove the volute body (see Chapter 3), the impeller (Chapter 5), and the carbon seal,
undo the six nuts and washers which join the pump head to the bearing housing and
remove the pump head. The oil seal housing is now exposed and can be removed by
undoing the six bolts and washers which retain it. Press out the old oil seal towards the
flat face of the housing. Press in the new oil seal in the opposite direction making sure
that the open end of the seal is towards the stepped face side of the housing.
CHAPTER 11
DRIVE SHAFT BEARINGS
Removing & Refitting
To gain access to the drive shaft bearings the pump has to be dismantled by removing
the volute body, impeller, pump head, tachometer drive, and both oil seal housings, as
detailed in the previous chapter. The water ring primer can also be removed if necessary
(see Chapter 12). The shaft may then be tapped out towards the impeller end, with the
bearing and the tachometer gear piece. Should the bearing remain in the bearing housing
it should be tapped out with a soft drift.
The drive end bearing will remain in the housing after the shaft has been tapped out. It
can be removed by tapping with a soft drift.
To re-assemble, the impeller end bearing must first be pressed on to the shaft, ensuring
that it fits firmly against the shoulder on the shaft. The shaft and bearing assembly are
fitted into the bearing housing from the impeller end. Fit the tachometer gear piece to the
shaft by sliding on from the flange end.
The bearing at the drive end should now be fitted. The driving flange and slotted nut can
be fitted temporarily and used to draw the bearing into the housing.
When the bearing is fitted, remove the slotted nut and driving flange and refit the oil seal
housing at each end of the bearing housing, then refit the driving flange, washer, slotted
nut, and split pin.
Reassembly of the rest of the pump is a reversal of the dismantling procedure.
CHAPTER 12
WATER RING PRIMER
Removing & Refitting
To remove the water ring primer, slacken the hose clips on the rubber hose, disconnect
the primer return spring, remove the bolts and spring washers securing the primer fulcrum
shaft keep plate, slacken the locknuts and grubscrews in the primer pivot, then tap out
the primer fulcrum shaft.

18
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the right
to amend specifications without notice or obligation.
On refitting the primer, it is advisable to rotate the fulcrum shaft from its original position
so that the grubscrews bear on a new part of the shaft. Before tightening the grubscrews,
ensure that both sides of the primer fibre wheel bear on the sides of the groove in the
pump pulley. Ensure that the fibre wheel is correctly lined with the drive pully.
CHAPTER 13
WATER RING PRIMER
Maintenance Attention
To dismantle the primer, remove the nuts and washers from the studs in the primer body.
Remove the bearing housing complete with shaft, bearings, impeller and pulley. Examine
the inner diameter of the impeller, and the corresponding surface of the suction and
delivery cover for excessive scoring, renewing these parts if necessary.
To fit a new suction and delivery cover, remove the self-locking screws which secure the
cover plate to the suction and delivery cover. Fit this cover plate to the new part, noting
that no gasket is used, but a jointing compound should be used on the contacting faces.
To fit a new impeller, undo the impeller retaining screw and pull off the impeller. (note -if
the impeller binds on the shaft it will be necessary to remove the primer shaft as described
below).
To remove the primer shaft, take off the impeller as detailed above. If the impeller binds
on the shaft, then remove the impeller retaining screw. At the other end of the shaft, knock
back the tab— washer and remove the nut securing the pulley to the shaft. Remove the
pulley and extract the woodruff key and the circlip. Tap out the shaft from the impeller
end. The shaft will bring the bearing with it and these can now be replaced if necessary.
The shaft seal will remain in position and If this requires renewing it should be drifted out,
together with its backing washer, towards the impeller end.
When fitting a new seal ensure that the lip on the backing washer and the open end of
the seal face is towards the impeller.
To fit a new friction drive pulley, remove the pulley from the shaft as detailed above, undo
the four nuts, bolts, and washers securing the pulley to the centre piece. Fit the new
pulley.
To examine the non-return valve, remove the three nuts and washers securing the primer
elbow to the primer body. If the non-return valve O-ring is faulty, a new one must be fitted.

19
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the right
to amend specifications without notice or obligation.
CHAPTER 14
PRIMER DISENGAGING UNIT
Maintenance Attention
To remove the disengaging unit, slacken the hose clips and remove the rubber priming
hose. Disengage the primer return spring, and swing the primer upwards and clear of
the disengaging unit.
Disconnect the pipe union on the underside of the disengaging unit and unscrew the
disengaging unit from the bracket.
The primer release pipe may now be removed from the pump body if necessary.
The disengaging unit is dismantled by removing the circlip, washer and rubber cap from
the spindle, then unscrewing the six nuts and washers from the studs in the housing.
The diaphragm should now be examined for deterioration cracks, etc. To dismantle the
diaphragm assembly, unscrew the self-locking nut from the end of the spindle.
When re-assembling the diaphragm assembly, ensure that the diaphragm pressure
plate is fitted and use a new self-locking nut.

20
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the right
to amend specifications without notice or obligation.
SPARE PARTS LIST
TO ORDER SPARE PARTS:
ALWAYS QUOTE:
1. The pump serial number as identified on the unit. The serial number is stamped
on the volute casing, near the delivery flange.
2. The item number, part number and the description, as given in the parts list
below.
The company cannot accept responsibility for parts not ordered in accordance with
these instructions.
GENERAL:
1. PAYMENT:
In the absence of an approved account, goods will be invoiced “Pro Forma” or sent
C.O.D. Delivery is ex-works, carriage and packing being extra.
2. DAMAGE:
The company does not hold itself responsible for goods lost or damaged in transit. All
packages should be signed for on receipt as “unexamined”. In the event of loss or
damage, a claim should be made on the carrier without delay.
3. PARTS CLAIMED TO BE DEFECTIVE AND REPLACEABLE UNDER
GUARANTEE.
Such parts must be returned to the works, carriage paid, for examination.
THE DATE OF DELIVERY AND SERIAL NUMBERS MUST ALWAYS BE GIVEN. The
cost of carriage and of any work entailed in refitting replacement parts is chargeable to
the claimant.
4. PATTERNS
If there is any doubt, send the old parts as patterns. Such patterns must be CLEARLY
LABELLED, INDICATING THE SENDER’S NAME AND ADDRESS.
If the patterns are to be returned, they must be marked accordingly, otherwise they will
be scrapped.
5. WARNING.
It is of the greatest importance that only genuine spare parts supplied by GODIVA LTD.
are used, otherwise the guarantee will be null and void.
6. All sales are made subject to the Company' s Standard Conditions of Sale in
force at the time of the sale.
