SERVICE AND OPERATING MANUAL

Table of Contents

Engineering Data and Performance Curve............................................................ 1

Explanation of Pump Nomenclature ...................................................................... 2

Dimensions ............................................................................................................ 3

Principle of Operation ............................................................................................ 4

Installation and Start-Up ........................................................................................ 4

Air Supply .............................................................................................................. 4

Air Inlet & Priming .................................................................................................. 4

Installation Guide ................................................................................................... 5

Externally Serviceable Air Distribution System .......................................................... 6

Air Exhaust ............................................................................................................ 7

Between Uses ....................................................................................................... 7

Check Valve Servicing ........................................................................................... 7

Diaphragm Servicing ............................................................................................. 7

Pilot Valve .............................................................................................................. 8

Pilot Valve Actuator ................................................................................................ 8

Service Instructions: Troubleshooting ................................................................... 9

Warranty ................................................................................................................ 9

Grounding The Pump .......................................................................................... 10

Important Safety Information ............................................................................... 11

Recycling ............................................................................................................. 11

Material Codes .................................................................................................... 12

Composite Repair Parts List ...........................................................................13-14

Composite Repair Drawing.................................................................................. 15

CE Declaration of Conformity - Machinery .......................................................... 16

CE Declaration fo Conformity - ATEX .................................................................. 17

X75 Metallic Flap Valve Pump

Design Level 2

x75mfvmdl2sm-rev0411

IDEX Pump Technologies (Ireland) Ltd., • A Unit of IDEX Corporation, R79, Shannon, Co Clare, IRELAND.

• TEL: +353 61 471933 FAX: +353 61 475046 www.blagdonpump.com • e-Mail: sales@blagdonpump.com

II 2GD T5





Original Instructions

x75mfvmdl2sm-rev0411 Page 1

INTAKE/DISCHARGE PIPE SIZE

HDF3-M: 3" 150# ANSI Flange

HDF4-M: 4" 150# ANSI Flange

CAPACITY

0 to 260 gallons per minute

(0 to 988 liters per minute)

AIR VALVE

No-lube, no-stall

design

SOLIDS-HANDLING

Up to nearly 3" (75mm)

HEADS UP TO

125 psi or 289 ft. of water

(8.8 Kg/cm2 or 88 meters)

Pumps are designed to be powered only by compressed air.

U.S. Gallons per minute

100

20 40 60 80 100 120 140 160 180 200 220 240 260

20(34)

60 PSI

40 PSI

40(68)

60(101.9)

80(135.9)

100(169.9)

120(203.9)

140(237.9)

160(271.8)

180(305.8)

20 PSI Air Inlet Pressure

100 PSI

80 PSI

Liters per minute

CAPACITY

0 100 200 300 400 500 600 700 800 900 1000

AIR CONSUMPTION

SCFM (M3/hr)

PSI

BAR

HEAD

200(339.8)

MODEL HDF3-M /HDF4-M Performance Curve

Performance based on the following: elastomer fitted pump, flooded suction,

water at ambient conditions. The use of other materials and varying hydraulic

conditions may result in deviations in excess of 5%.

X75 Metallic Flap Valve Pump

Design Level 2

Air-Operated

Double Diaphragm Pump

ENGINEERING, PERFORMANCE

& CONSTRUCTION DATA

II 2GD T5





x75mfvmdl2sm-rev0411 Page 2

II 2GD T5











Materials

Operating Temperatures

For specic applications, always consult “Chemical Resistance Chart" Technical Bulletin

Nitrile General purpose, oil-resistant. Shows good solvent, oil, water and hydraulic uid resistance. Should

not be used with highly polar solvents like acetone and MEK, ozone, chlorinated hydrocarbons and nitro

hydrocarbons.

NEOPRENE All purpose. Resistant to vegetable oils. Generally not affected by moderate chemicals, fats,

greases and many oils and solvents. Generally attacked by strong oxidizing acids, ketones, esters, nitro

hydrocarbons and chlorinated aromatic hydrocarbons.

Urethane Shows good resistance to abrasives. Has poor resistance to most solvents and oils.

Santoprene® Injection molded thermoplastic elastomer with no fabric layer. Long mechanical ex life. Excel-

lent abrasion resistance.

Maximum Minimum

‡CF-8M Stainless Steel equal to or exceeding ASTM specication A743 for corrosion resistant iron chro-

mium, iron chromium nickel, and nickel based alloy castings for general applications. Commonly referred

to as 316 Stainless Steel in the pump industry.

190°F -10°F

88°C -23°C

200°F -10°F

93°C -23°C

150°F +32°F

66°C 0°C

275°F -40°F

135°C -40°C

Maximum and Minimum Temperatures are the limits for which

these materials can be operated. Temperatures coupled with

pressure affect the longevity of diaphragm pump components.

Maximum life should not be expected at the extreme limits of

the temperature ranges.

TYPICAL CODE= X75. 01. C. C. F. T. B. B. S.

Model - X75

Design Level

Non-Wetted Components

C: Cast Iron

Wetted Components

C: Cast Iron

Valve Type

F: Flap

Suction Orientation

T: Top

Valve Seats:

S: Stainless Steel

Flap Valves

B: Nitrile

N: Neoprene

R: Santoprene

P: Polyurethane

Diaphragms

B: Nitrile

R: Santoprene

N: Neoprene

Maximum delivery: 988 ltrs/min

Max. working pressure: 8.6 bar

Max. solid particle size: 75mm

Air inlet: 3/4” NPT

Temperatur limits: Determined by elastomers

Suction/Discharge: 3’ ANSI Flange

Intallation: Surface mounted

Accessories included: Metal Exhaust air silencer

x75mfvmdl2sm-rev0411 Page 3

Dimensions:

Dimensions are ± 1/8"

Figures in parenthesis = millimeters

x75mfvmdl2sm-rev0411 Page 4

PRINCIPLE OF PUMP OPERATION

This ap swing check valve pump is powered by compressed air and is a 1:1 pressure ratio design. It alternately pressurizes

the inner side of one diaphragm chamber, while simultaneously exhausting the other inner chamber. This causes the diaphragms,

which are connected by a common rod, to move endwise. Air pressure is applied over the entire surface of the diaphragm, while

liquid is discharged from the opposite side. The diaphragm operates under a balanced condition during the discharge stroke,

which allows the unit to be operated at discharge heads over 200 feet (61 meters) of water head.

Since the diaphragms are connected by a common rod, secured by plates to the center of the diaphragms, one diaphragm

performs the discharge stroke, while the other is pulled to perform the suction stroke in the opposite chamber.

For maximum diaphragm life, keep the pump as close to the liquid being pumped as possible. Positive suction head in excess

of 10 feet of liquid (3.048 meters) may require a back pressure regulating device. This will maximize diaphragm life.

Alternate pressuring and exhausting of the diaphragm chamber is performed by means of an externally mounted, pilot operated,

four-way spool type air distribution valve. When the spool shifts to one end of the valve body, inlet air pressure is applied to

one diaphragm chamber and the other diaphragm chamber exhausts. When the spool shifts to the opposite end of the valve

body, the porting of chambers is reversed. The air distribution valve spool is moved by an internal pilot valve which alternately

pressurizes one side of the air distribution valve spool, while exhausting the other side. The pilot valve is shifted at each end of

the diaphragm stroke by the diaphragm plate coming in contact with the end of the pilot valve spool. This pushes it into position

for shifting of the air distribution valve.

The chambers are manifolded together with a suction and discharge check valve for each chamber, maintaining ow in one

direction through the pump.

INSTALLATION & START-UP

Locate the pump as close to the product being pumped as possible, keeping suction line length and number of ttings to a

minimum. Do not reduce line size.

For installations of rigid piping, short exible sections of hose should be installed between pump and piping. This reduces

vibration and strain to the piping system. A pulsation dampener is recommended to further reduce pulsation in ow.

This pump was tested at the factory prior to shipment and is ready for operation. It is completely self-priming from a dry start

for suction lifts of 20 feet (6.096 meters) or less. For suction lifts exceeding 20 feet of liquid, ll the chambers with liquid prior to

priming.

AIR SUPPLY

Air supply pressures cannot exceed 125 psi (8.61 bar). Connect the pump air inlet to an air supply of sufcient capacity and

pressure required for desired performance. When the air line is solid piping, use a short length of exible hose (not less than 3/4"

(19mm) in diameter) between pump and piping to eliminate strain to pipes.

AIR INLET & PRIMING

For start-up, open an air valve approximately 1/2" to 3/4" turn. After the unit primes, an air valve can be opened to increase

ow as desired. If opening the valve increases cycling rate, but does not increase ow rate, cavitation has occurred, and the

valve should be closed slightly.

For the most efcient use of compressed air and the longest diaphragm life, throttle the air inlet to the lowest cycling rate that

does not reduce ow.

SERVICE AND OPERATING MANUAL

II 2GD T5





X75 Metallic Flap Valve Pump

Design Level 2

x75mfvmdl2sm-rev0411 Page 5

INSTALLATION GUIDE

Bottom Discharge Flap Valve Unit

The air exhaust should be

piped to an area for safe

disposition of the product

being pumped, in the event

of a diaphragm failure.

CAUTION

Available from

Distributor

Available from

Warren Rupp

x75mfvmdl2sm-rev0411 Page 6

A NOTE ABOUT AIR VALVE LUBRICATION

The pump’s pilot valve and main air valve assemblies are designed to operate WITHOUT lubrication. This is the

preferred mode of operation. There may be instances of personal preference, or poor quality air supplies when lubrication of

the compressed air supply is required. The pump air system will operate with properly lubricated compressed air supplies. Proper

lubrication of the compressed air supply would entail the use of an air line lubricator set to deliver one drop of 10 weight, non-

detergent oil for every 20 SCFM of air the pump consumed at its point of operation. Consult the pump’s published Performance

Curve to determine this.

It is important to remember to inspect the sleeve and spool set routinely. It should move back and forth freely. This is most

important when the air supply is lubricated. If a lubricator is used, oil accumulation will, over time, collect any debris from the

compressed air. This can prevent the pump from operating properly.

Water in the compressed air supply can create problems such as icing or freezing of the exhaust air causing the pump to

cycle erratically, or stop operating. This can be addressed by using a point of use air dryer (available from Warren Rupp) to

supplement a plant’s air drying equipment. This device will remove excess water from the compressed air supply and alleviate

the icing or freezing problem.

EXTERNALLY SERVICEABLE AIR DISTRIBUTION SYSTEM

Please refer to the exploded view drawing and parts list in the Service Manual supplied with your pump. If you need replacement

or additional copies, contact your local Distributor, or the factory Literature Department at the number shown below. To receive

the correct manual, you must specify the MODEL information found on the name plate of the pump.

MODELS WITH 1" SUCTION/DISCHARGE OR LARGER AND METAL CENTER SECTIONS

The main air valve sleeve and spool set is located in the valve body mounted on the pump with four hex head capscrews. The

valve body assembly is removed from the pump by removing these four hex head capscrews.

With the valve body assembly off the pump, access to the sleeve and spool set is made by removing four hex head capscrews

(each end) on the end caps of the valve body assembly. With the end caps removed, slide the spool back and forth in the sleeve.

The spool is closely sized to the sleeve and must move freely to allow for proper pump operation. An accumulation of oil, dirt or

other contaminants from the pump’s air supply, or from a failed diaphragm, may prevent the spool from moving freely. This can

cause the spool to stick in a position that prevents the pump from operating. If this is the case, the sleeve and spool set should

be removed from the valve body for cleaning and further inspection.

Remove the spool from the sleeve. Using an arbor press or bench vise (with an improvised mandrel), press the sleeve from

the valve body. Take care not to damage the sleeve. At this point, inspect the o-rings on the sleeve for nicks, tears or abrasions.

Damage of this sort could happen during assembly or servicing. A sheared or cut o-ring can allow the pump’s compressed air

supply to leak or bypass within the air valve assembly, causing the pump to leak compressed air from the pump air exhaust or not

cycle properly. This is most noticeable at pump dead head or high discharge pressure conditions. Replace any of these o-rings as

required or set up a routine, preventive maintenance schedule to do so on a regular basis. This practice should include cleaning

the spool and sleeve components with a safety solvent or equivalent, inspecting for signs of wear or damage, and replacing

worn components.

To re-install the sleeve and spool set, lightly lubricate the o-rings on the sleeve with an o-ring assembly lubricant or lightweight

oil (such as 10 wt. air line lubricant). Press the set into the valve body easily, without shearing the o-rings. Re-install one end cap,

gasket and bumper on the valve body. Using the arbor press or bench vise that was used in disassembly, press the sleeve back

into the valve body. You may have to clean the surfaces of the valve body where the end caps mount. Material may remain from

the old gasket. Old material not cleaned from this area may cause air leakage after reassembly. Take care that the bumper stays

in place allowing the sleeve to press in all the way. Reinstall the spool, the opposite end cap, gasket and bumper on the valve

body. After inspecting and cleaning the gasket surfaces on the valve body and intermediate, reinstall the valve body on the pump

using new gaskets. Tighten the four hex head capscrews evenly and in an alternating cross pattern.

x75mfvmdl2sm-rev0411 Page 7

that the bumper stays in place allowing the sleeve to press in all the way. Reinstall the spool, opposite end cap, gasket and

bumper on the valve body. After inspecting and cleaning the gasket surfaces on the valve body and intermediate, reinstall the

valve body on the pump using new gaskets. Tighten the four hex head capscrews evenly and in an alternating cross pattern.

AIR EXHAUST

If a diaphragm fails, the pumped liquid or fumes can enter the air end of the pump, and be exhausted into the atmosphere.

When pumping hazardous or toxic materials, pipe the exhaust to an appropriate area for safe disposition.

This pump can be submerged if materials of construction are compatible with the liquid. The air exhaust must be piped above

the liquid level. Piping used for the air exhaust must not be smaller than 1" (2.54 cm). Reducing the pipe size will restrict air ow

and reduce pump performance .When the product source is at a higher level than the pump (ooded suction), pipe the exhaust

higher than the product source to prevent siphoning spills.

Freezing or icing-up of the air exhaust can occur under certain temperature and humidity conditions. Use of an air dryer unit

should eliminate most icing problems.

BETWEEN USES

When used for materials that tend to settle out or transform to solid form, the pump should be completely ushed after each

use, to prevent damage. Product remaining in the pump between uses could dry out or settle out. This could cause problems

with valves and diaphragms at re-start. In freezing temperatures, the pump must be drained between uses in all cases.

FLAP VALVE SERVICING

Valve inspection requires removal of 3/8" hex nuts and elbows. When the top suction elbows are removed, the valve and

seat are connected as an assembly. When the bottom discharge elbows are removed, the valve and seat stay with the outer

chamber. Visual inspection and cleaning is possible. If parts are to be replaced, remove the self-locking nuts and all parts

are accessible.

DIAPHRAGM SERVICING

Diaphragms can be inspected or the diaphragm assembly removed without removing the suction and discharge anges.

Remove (8) nuts around the chamber ange, and the housing assembly will pull off. Flap valves can be inspected for proper

seating at this point as well as the diaphragm. Use care to keep foreign matter from behind the diaphragm. The opposite

diaphragm may be inspected by the same procedure. If either diaphragm has to be replaced, follow closely these steps:

Pull the outer diameter of one diaphragm off the (8) capscrews. NOTE: One side only! On the free diaphragm assembly, use a 3/8"

allen wrench to turn the assembly (diaphragm, plates and screw) loose from the shaft. Once the assembly has turned, it will turn out by

hand by use of the diaphragm. Now the opposite diaphragm assembly and the drive shaft will pull free from the capscrews and pump

intermediate assembly. The interior components consisting of sleeve bearings, rod seals, and pilot valve actuator bushings are

now accessible for service if required. Hold the shaft in a clamping device making sure to protect surface of shaft so as not to

scratch or mar it in any way. The diaphragm assembly will turn loose. To disassemble the components, turn a 1/4"-20 capscrew

by hand into the tapped hole in the inner plate. This keeps the plate from turning while the socket head capscrew is removed.

To do this, place assembly in a vise so the two protruding ends of screws are loose in the vise jaws (about 3/4" apart). Turn the

center screw loose from the back plate and the assembly will come apart.

REASSEMBLY

All procedures for reassembling the pump are the reverse of the previous instructions with further instructions as shown:

1. The diaphragm assemblies are to be installed with the natural bulge outward or toward the head of the center screw. Make

sure both plates are installed with outer radii against the diaphragm. After all components are in position in a vise and hand

tight, set a torque wrench for 480 inch pounds (40 ft. pounds) (54.23 Newton meters) or, 600 inch pounds (50 ft. pounds)

(67.79 Newton meters) for Santoprene, using a (3/8") allen head socket. After each diaphragm sub assembly has been

completed, thread one assembly into the shaft (held near the middle in a vise having soft jaws to protect the nish) making sure

the stainless steel washer is in place on the capscrew.

Make sure 1/4"-20 mounting screw has been removed and that the bumper (Item #19 on drawing) is in place in the shaft.

Install this sub assembly into the pump and secure by placing the outer chamber housing and capscrews on the end

with the diaphragm. This will hold the assembly in place while the opposite side is installed. Make sure the last diaphragm

assembly is torqued to 30 ft. lbs. (40.67 Newton meters) before placing the outer diaphragm over the capscrews. If the holes

in the diaphragm ange do not line up with the holes in the chamber ange, turn the diaphragm assembly in the direction of

tightening to align the holes so that the capscrews can be inserted. This nal torquing of the last diaphragm assembly will lock

the two diaphragm assemblies together. Place remaining outer chamber on the open end and tighten down the securing nuts

x75mfvmdl2sm-rev0411 Page 8

gradually and evenly on both sides.

Caution should be used while reassembling Flap valves. The valves are designed for some preload over the retainer hinge pad.

This is done to insure proper face contact with the seat. After all parts are in place, tighten the lock nuts down on the assembly

to the point where visual inspection shows that seat and valve face mate without gap. This is important for dry prime. However,

after priming action has started, valves will function due to differential pressure without concern or trouble.

PILOT VALVE

The pilot valve assembly is accessed by removing the main air distribution valve body from the pump and lifting the pilot valve

body out of the intermediate housing.

Most problems with the pilot valve can be corrected by replacing the o-rings. Always grease the spool prior to inserting it

into the sleeve. If the sleeve is removed from the body, reinsertion must be at the chamfered side. Grease the o-rings to slide

the sleeve into the valve body. Securely insert the retaining ring around the sleeve. When reinserting the pilot valve, push both

plungers (located inside the intermediate bracket) out of the path of the pilot valve spool ends to avoid damage.

PILOT VALVE ACTUATOR

Bushings for the pilot valve actuators are threaded into the intermediate bracket from the outside. The plunger may be removed for

inspection or replacement. First remove the air distribution valve body and the pilot valve body from the pump. The plungers can be located

by looking into the intermediate. It may be necessary to use a ne piece of wire to pull them out. The bushing can be turned out through the

inner chamber by removing the outer chamber assembly. Replace the bushings if pins have bent.

x75mfvmdl2sm-rev0411 Page 9

WARRANTY:

This unit is guaranteed for a period of ve years against defective material and workmanship.

PROBLEM

Pump cycles but will not pump. (Note: higher suction lifts require faster cycling speed for priming.)

POSSIBLE CAUSES:

A. Air leak in suction line.

B. Excessive suction lift.

C. Flap valve not seating properly.

D. Leakage at joint of suction manifold or elbow ange.

E. Suction line or strainer plugged.

F. Diaphragm ruptured.

PROBLEM

Pump will not cycle. (Note: Always disconnect air supply to relieve air pressure before disassembling any portion of pump.)

POSSIBLE CAUSES:

A. Discharge hose or line plugged, or discharge head requirement greater than air supply pressure.

(Disconnect discharge line to check.)

B. Spool in air distribution valve not shifting. (Remove end cap and check spool — must slide freely.)

C. Diaphragm ruptured. (Air will escape out discharge line in this case.)

D. Blockage in diaphragm chamber preventing movement. (Shut off air supply and reopen after pressure is relieved.)

PROBLEM

Uneven discharge ow. (Indicates one chamber not operating properly.)

POSSIBLE CAUSES:

A. Flap valve not sealing properly in one chamber.

B. Diaphragm failure in one chamber.

C. Air leak at suction manifold joint or elbow ange one side.

For additional information, see the Troubleshooting Guide.

TROUBLESHOOTING - For additional information, see the Troubleshooting Guide.

x75mfvmdl2sm-rev0411 Page 10

The eyelet end is fastened to the pump hardware.

ThIS end is installed to a true earth ground.

To reduce the risk of static electrical sparking, this pump must be

grounded. Check the local electrical code for detailed grounding

instruction and the type of equipment required, or in the absence of local

codes, an industry or nationally recognized code having juristiction over

specic installations.

This 8 foot long (244 centimeters) Ground Strap, part

number 920-025-000, can be ordered as a service item.

To reduce the risk of static electrical sparking, this pump must be grounded.

Check the local electrical code for detailed grounding instruction and the

type of equipment required.

Grounding The Pump WARNING

Take action to prevent static

sparking. Fire or explosion

can result, especially when

handling ammable liquids.

The pump, piping, valves, containers or

o the r mis c ella n eous equ i p men t mus t

be grounded.

x75mfvmdl2sm-rev0411 Page 11

This pump is pressurized

internally with air pressure

during operation. Always

make certain that all bolting

is in good condition and

that all of the correct

bolting is reinstalled during assembly.

WARNING

Before pump operation,

inspect all gasketed

fasteners for looseness

caused by gasket creep. Re-

torque loose fasteners to

prevent leakage. Follow recommended torques

stated in this manual.

CAUTION

When used for toxic or

aggressive uids, the pump

should always be ushed

clean prior to disassembly.

WARNING

Before maintenance or

repair, shut off the com-

pressed air line, bleed the

pressure, and disconnect

the air line from the pump.

The discharge line may be

pressurized and must be bled of its pressure.

WARNING Before doing any main-

tenance on the pump,

be certain all pressure is

completely vented from the

pump, suction, discharge,

piping, and all other

openings and connections. Be certain the air

supply is locked out or made non-operational,

so that it cannot be started while work is being

done on the pump. Be certain that approved

eye protection and protective clothing are worn

all times in the vicinity of the pump. Failure to

follow these recommendations may result in

serious injury or death.

WARNING

Airborne particles and

loud noise hazards.

Wear ear and eye

protection.

WARNING

In the event of diaphragm

rupture, pumped material

may enter the air end of the

pump, and be discharged

into the atmosphere. If

pumping a product which is hazardous or toxic,

the air exhaust must be piped to an appropriate

area for safe disposition.

IMPORTANT SAFETY

INFORMATION Take action to prevent static

sparking. Fire or explosion

can result, especially when

handling ammable liquids.

The pump, piping, valves,

containers or other miscellaneous equipment

must be grounded. (See page 10)

WARNING

IMPORTANT

Read these safety warnings

and instructions in this

manual completely, before

installation and start-up

of the pump. It is the responsibility of the

purchaser to retain this manual for reference.

Failure to comply with the recommendations

stated in this manual will damage the pump,

and void factory warranty.

Read these safety warnings

and instructions in this

manual completely, before

installation and start-up

of the pump. It is the responsibility of the

purchaser to retain this manual for reference.

Failure to comply with the recommendations

stated in this manual will damage the pump,

and void factory warranty.

RECYCLING

Many components of AODD pumps are made

of recyclable materials (see chart on page 12 for material

specications). We encourage pump users to recycle worn out parts

and pumps whenever possible, after any hazardous pumped uids

are thoroughly ushed.

x75mfvmdl2sm-rev0411 Page 12

 



 

 

 

 

 

 

 

 

 



 

 



 

 

 

 



 



 

 

 

 

 

 

 

 

 

 

 

 

 

 

 

 

 

 

 

 

 

 

 

 

 

 

 

 



 

 

 

 

 

 

MATERIAL CODES

THE LAST 3 DIGITS OF PART NUMBER

 

 



 

 

 



 





 

 

 

 



 

 



 

 

 



 

 

 

 

 



 



 

 

 

 

 

 

 

 

 

 

 

 

 

 

 

 





 

 

 

 

 

 

 

 

 

 



 

 

 

 

 

 

 

 

 

 



 

 

 

 

 

 

 

 

 

 

 

 

 

 

 

 

 

 

 



 

 



 





























x75mfvmdl2sm-rev0411 Page 13

ITEM TOTAL

NO. PART NUMBER DESCRIPTION RQD.

1 070.006.170. Bearing, Sleeve 2

2 114.002.010. Bracket, Intermediate 1

3 132.022.360. Bumper 2

4 135.016.162. Bushing, Threaded, with O-Ring 2

5 620.011.114. Plunger, Actuator 2

7 360.041.379. Gasket, Valve Body 1

8 560.001.360. O-Ring 2

9 132.014.358. Bumper, Valve Spool 2

10 095.073.001. Pilot Valve Assembly 1

10-A 095.070.558. Pilot Valve Body 1

10-B 755.025.000. Sleeve, with O-Ring 1

10-C 560.033.360. O-Ring (Sleeve) 4

10-D 775.026.000. Spool, with O-Ring 1

10-E 560.023.360. O-Ring (Spool) 2

10-F 675.037.080. Retaining Ring 1

11 165.011.010. Cap, End 2

12 360.048.425. Gasket, Valve Body 1

13 360.010.425. Gasket, End Cap 2

14 560.020.360. O-Ring 6

15 031.018.000. Sleeve & Spool Set 1

16 170.032.330. Capscrew, Hex Head 8

17 095.043.010. Body, Valve 1

18 196.100.015. Chamber, Inner 2

19 560.022.360. O-Ring 2

20 170.045.330. Capscrew, Hex Head 4

21 530.036.000. Mufer, Exhaust 1

22 685.041.120. Rod, Diaphragm 1

23 115.068.080. Bracket, Support 1

24 170.024.330. Capscrew, Hex Head 8

25 900.006.330. Washer, Lock 8

26 720.004.360. Seal, U-Cup 2

27 722.007.010 Seat, Flap Valve-Angle 4

28 326.004.080. Mounting Foot 2

29 132.002.360. Bumper 2

30 612.090.010. Plate, Outer Diaphragm Assy. 2

31 807.046.330. Stud 2

32 612.124.010. Plate, Inner Diaphragm 2

33 286.098.365. Diaphragm 2

286.098.360. Diaphragm 2

286.098.354. Diaphragm 2

34 900.003.330. Washer, Lock 22

35 545.008.330. Nut, Hex 16

39 807.017.330. Stud 8

40 618.003.330. Pipe Plug 4

41 900.006.330. Washer, Lock 4

42 170.012.330. Capscrew, Hex Head 6

43 360.013.379. Gasket, Seat 4

360.013.384. Gasket, Seat 4

SERVICE AND OPERATING MANUAL

X75 Metallic Flap Valve Pump

Design Level 2

II 2GD T5





x75mfvmdl2sm-rev0411 Page 14

ITEM TOTAL

NO. PART NUMBER DESCRIPTION RQD.

44 360.014.379. Gasket, Flange 4

360.014.384. Gasket, Flange 4

45 670.006.115. Retainer, Flap Valve 4

46 807.016.330. Stud 12

47 170.023.330. Capscrew, Hex Head 4

48 545.007.330. Nut, Hex 20

49 807.018.110. Stud 8

50 547.002.115. Nut, Stop 8

51 334.020.000. Flange, Follower 4

52 360.021.000. Gasket 4

53 170.055.330. Capscrew, Hex Head 12

54 901.006.330. Flat Washer 14

55 170.095.330. Capscrew, Hex Head 2

56 196.060.010. Chamber, Outer 2

57 312.015.010. Elbow, Suction 2

58 312.016.010. Elbow, Discharge 2

59 518.045.010. Manifold 2

60 338.011.354. Flap Valve 4

338.011.356. Flap Valve 4

338.011.357. Flap Valve 4

338.008.360. Flap Valve 4

338.008.365. Flap Valve 4

61 570.002.360. 4

570.002.365. 4

62 170.082.330. Capscrew, Hex Head 14

63 570.010.360. Pad, Wear 2

570.010.365. Pad, Wear 2

Not Shown:

031.021.010. Valve Body Assembly 1

(consists of Items 9, 11,

13, 14, 15, 16, 17)

901.035.115. Washer, Flat 8

(use w/Santoprene aps only)

*Available in Kit form. Order P/N 031.055.000.

which also includes items 3, 5, 7, 12.

476.251.000. AIR END KIT

Seals, O-Rings, Gaskets, Air Valve Sleeve and Spool,

Pilot Valve Assembly

476.250.360. WETTED END KIT

Buna Diaphragms Flap Valves, Hinge Pads, Gaskets

476.250.365. WETTED END KIT

Neoprene Diaphragms, Flap Valves, Hinge Pads, Gaskets

x75mfvmdl2sm-rev0411 Page 15

USE WITH

HDF4-M ONLY

Declaration of Conformity

Date of issue

Printed name of authorized person

Revision Level: E

Title

Des Monaghan Production & Tech Manager

October 20, 2005

Date of revision

May 27, 2010

Manufacturer: IDEX Pump Technologies (Ireland) Ltd.,

A Unit of IDEX Corporation, R79, Shannon, Co Clare, IRELAND.

Certifies that Air-Operated Double Diaphragm Pump B and X Series, comply with

the European Community Directive 2006/42/EC on Machinery, according to Annex VIII.

This product has used Harmonized Standard EN 809, Pumps and Pump Units for

Liquids - Common Safety Requirements, to verify conformance.

Signature of authorized person

EC Declaration of Conformity

In accordance with ATEX Directive 94/9/EC,

Equipment intended for use in potentially explosive environments.

Applicable Standard:

EN13463-1: 2001,

EN13463-5: 2003

DATE/APPROVAL/TITLE:

27 MAY 2010

AODD Pumps Equipped with Aluminium

Type Examination Certificate: KEMA 09ATEX0072 X

AODD (Air-Operated Double Diaphragm) Pumps

EC Type Examination Certificate No. Pumps: KEMA 09ATEX0071 X

KEMA Quality B.V.

Utrechtseweg 310

6812 AR Arnhem, The Netherlands

Manufacturer: IDEX Pump Technologies (Ireland) Ltd.,

A Unit of IDEX Corporation, R79, Shannon, Co Clare, IRELAND.

Production and Technical Manager
