Idex Sandpiper Signature Series Parts list manual


Model ST1½ & ST40
Containment Duty
Design Level 5

A Unit of IDEX Corporation
800 N. Main St.,
Manseld, Ohio 44902 USA
Telephone [phone]
Fax [phone]
WWW.SANDPIPERPUMP.COM
©2017 Warren Rupp, Inc.
Certied Quality
ISO 9001 Certied
ISO 14001 Certied
SERVICE & OPERATING MANUAL
Original Instructions
1: PUMP SPECS2: INSTAL & OP3: EXP VIEW4: AIR END5: WARRANTY

www.sandp ipe rpu mp.c om
st15dl5sm-rev1218
Model ST1½/ST40
IMPORTANT
Read the safety warnings and instructions in this manual
before pump installation and start-up. Failure to comply with
the recommendations stated in this manual could damage the
pump and void factory warranty.
When used for toxic or aggressive uids, the pump should
always be ushed clean prior to disassembly.
Airborne particles and loud noise hazards. Wear eye and ear
protection.
Before maintenance or repair, shut off the compressed air line,
bleed the pressure, and disconnect the air line from the pump.
Be certain that approved eye protection and protective clothing
are worn at all times. Failure to follow these recommendations
may result in serious injury or death.
When the pump is used for materials that tend to settle out
or solidify, the pump should be ushed after each use to
prevent damage. In freezing temperatures the pump should be
completely drained between uses.
Before pump operation, inspect all fasteners for loosening
caused by gasket creep. Retighten loose fasteners to prevent
leakage. Follow recommended torques stated in this manual.
CAUTION
WARNING
Nonmetallic pumps and plastic components are not UV
stabilized. Ultraviolet radiation can damage these parts and
negatively affect material properties. Do not expose to UV light
for extended periods of time.
In the event of diaphragm rupture, pumped material may enter
the air end of the pump, and be discharged into the atmosphere.
If pumping a product that is hazardous or toxic, the air exhaust
must be piped to an appropriate area for safe containment.
This pump is pressurized internally with air pressure during
operation. Make certain that all fasteners are in good condition
and are reinstalled properly during reassembly.
Take action to prevent static sparking. Fire or explosion can
result, especially when handling ammable liquids. The pump,
piping, valves, containers and other miscellaneous equipment
must be properly grounded.
Safety Information
ATEX Pumps - Conditions For Safe Use
WARNING
Pump not designed, tested or certied to be powered by
compressed natural gas. Powering the pump with natural
gas will void the warranty.
Use safe practices when lifting
kg
WARNING
The use of non-OEM replacement parts will void (or negate)
agency certications, including CE, ATEX, CSA, 3A and EC1935
compliance (Food Contact Materials). Warren Rupp, Inc. cannot
ensure nor warrant non-OEM parts to meet the stringent
requirements of the certifying agencies.
1. Ambient temperature range is as speci ed in tables 1 to 3 on the next page (per Annex I of DEKRA 18ATEX0094X)
2. ATEX compliant pumps are suitable for use in explosive atmospheres when the equipment is properly grounded in
accordance with local electrical codes
3. Non-Metallic ATEX Pumps only — See Explanation of Pump Nomenclature / ATEX Details Page
Conductive Polypropylene, conductive Acetal or conductive PVDF pumps are not to be installed in applications where the
pumps may be subjected to oil, greases and hydraulic liquids.
4. The optionally provided solenoids shall be protected by a fuse corresponding to its rated current (max 3*Irat according
to EN 60127) or by a motor protecting switch with short circuit and thermal instantaneous tripping (set to the rated
current) as short circuit protection. For solenoids with a very low rated current, a fuse with the lowest current value
according to the indicated standard will be suffi cient. The fuse may be accommodated in the associated supply unit
or shall be separately arranged. The rated voltage of the fuse shall be equal or greater than the stated rated voltage of the
solenoid. The breaking capacity of the fuse shall be as high as or higher than the maximum expected short circuit current
at the location of the installation (usually 1500 A). The maximum permissible ripple is 20% for all dc solenoids.
*Not applicable for all pump models — See Explanation of Pump Nomenclature / ATEX Details Page
5. When operating pumps equipped with non-conductive diaphragms that exceed the maximum permissible projected area,
as de ned in EN ISO 80079-36 : 2016 section 6.7.5 table 8, the following protection methods must be applied
- Equipment is always used to transfer electrically conductive fl uids or
- Explosive environment is prevented from entering the internal portions of the pump, i.e. dry running.
6. Pumps provided with the pulse output kit and used in the potentially explosive atmosphere caused by the presence of
the combustible dust shall be installed in such a way that the pulse output kit is protected against impact
*Not applicable for all pump models — See Explanation of Pump Nomenclature / ATEX Details Page
UNIVERSAL ALL AODD

www.sa ndp ipe rpu mp.c om Model ST1½/ST40 • 3
st15dl5sm-rev1218
Temperature Tables
Ambient Temperature
Range [°C]
Process Temperature
Range [°C]1
Temperature
Class
Maximum Surface Tem-
perature [°C]
-20°C to +60°C
-20°C to +80°C T5 T100°C
-20°C to +108°C T4 T135°C
-20°C to + 160°C T3
T200°C
-20°C to +177°C (225°C) T2

Ambient Temperature
Range [°C]
Process Temperature
Range [°C]
Temperature
Class
Maximum Sur-
face Temperature
[°C]
Options
Pulse Output
Kit
Integral Solenoid
-20°C to +60°C -20°C to +100°C T5 T100 X
-20°C to +50°C -20°C to +100°C T5 T100 X
Ambient Temperature
Range [°C]
Process Temperature
Range [°C]
-20°C to +60°C -20°C to +150°C
1Per CSA standards ANSI LC6-2018 US & Canadian Technical Letter R14, G-Series Natural Gas Models are restricted to (-20°C to + 80°C) process temperature
Note: The ambient temperature range and the process temperature range should not exceed the operating
temperature range of the applied non-metallic parts as listed in the manuals of the pumps.
2ATEX Pulse output or Intergral Solenoid Not Available For All Pump Models See Explanation of Pump Nomenclature / ATEX Details Page



www.sa ndp ipe rpu mp.c om
4 • Model ST1½/ST40
st15dl5sm-rev1218
Table of Contents
SECTION 1: PUMP SPECIFICATIONS ..............1
• Explanation of Nomenclature
• Performance
• Materials
• Dimensional Drawings
SECTION 2: INSTALLATION & OPERATION ...4
• Principle of Pump Operation
• Recommended Installation Guide
• Filling the Driver Chambers with Fluid
• Troubleshooting Guide
SECTION 3: EXPLODED VIEW ..........................8
• Composite Repair Parts Drawing
• Composite Repair Parts List
• Material Codes
SECTION 4: AIR END ......................................11
• Air Valve with Stroke Indicator Assembly
• Pilot Valve Assembly
SECTION 5: WARRANTY & CERTIFICATES . . 13
• Warranty
• CE Declaration of Conformity - Machinery
• ATEX Declaration of Conformity
MODEL SPECIFIC
1: PUMP SPECS2: INSTAL & OP3: EXP VIEW4: AIR END5: WARRANTY

www.sa ndp ipe rpu mp.c om Model ST1½/ST40 • 5
st15dl5sm-rev1218
ATEX Detail
Explanation of Pump Nomenclature
Diaphragm Check Valve Materials
GI EPDM Driver Diaphragms, PTFE Pumping
Diaphragms, and PTFE Check Balls
GN Neoprene Driver Diaphragms, PTFE Pumping
Diaphragms, and PTFE Check Balls
GV FKM Driver Diaphragms, PTFE Pumping
Diaphragms, and PTFE Check Balls
Design Level
5
Construction
A Aluminum Wetted, Aluminum Air
CI Cast Iron Wetted, Aluminum Air
II Cast Iron Wetted, Cast Iron Air
SI Stainless Steel Wetted, Cast Iron Air
SS Stainless Steel Wetted, Aluminum Air
Pump Series
S SANDPIPER®
Pump Design
T Spill Containment
Pump Size & Options
15 NPT
40 1½" BSP Tapered
Options
VL Visual Leak Detection Sight Tubes
Discharge Porting Position
S Side
__ __ _____ __ ___ __ __
Pump Pump Pump Size Discharge Diaphragm/ Design Construction
Series Design and Options Porting Valve Level
XX X XXXXXX, XX XXX X XX
Model #:
(ll in from pump
nameplate)
Your Model #:
(1)
II 2GD T5
II 2 G Ex h IIB T5...225°C (T2) Gb
II 2 D Ex h IIIB T100°C...T200°C Db
All Pump Models:
MODEL SPECIFIC
1: PUMP SPECS

www.sa ndp ipe rpu mp.c om
6 • Model ST1½/ST40
st15dl5sm-rev1218
Performance
ST1½ & ST40
SUCTION/DISCHARGE PORT SIZE
• ST1½: 1½ (37.5mm) NPT (F)
• ST40: 1½ (37.5MM) BSP (F)(Tapered)
CAPACITY
• 0 to 106 gallons per minute
(0 to 400 liters per minute)
AIR DISTRIBUTION VALVE
• No-lube, no-stall design
SOLIDS-HANDLING
• Occasional solids only.
Up to ¼ in. (6.3mm)
HEADS UP TO
• 125 psi or 289 ft. of water
(8.8 Kg/cm2or 88 meters)
MAXIMUM OPERATING PRESSURE
• 125 psi (8.6 bar)
DISPLACEMENT/STROKE
• .37 Gallon / 1.29 liter
SHIPPING WEIGHT
• Aluminum 99 lbs. (46kg)
• Cast Iron 146 lbs. (66kg)
• Stainless Steel 212 lbs. (95kg)
100 PSI
40 PSI
60 PSI
80 PSI
0 50 100 150 200 250 300 350
0
1
2
3
4
5
6
7
PSI
BAR
8
9
125 PSI
400
20 PSI Air Inlet Pressure
US Gallons per minute
Liters per minute
CAPACITY
HEAD
AIR CONSUMPTION
SCFM (M3/hr)
MODEL ST1½/ST40 Performance Curve
Performance based on the following: PTFE fitted pump, flooded suction,
water at ambient conditions. The use of other materials and varying hydraulic
conditions may result in deviations in excess of 5%.
0
20
40
60
80
100
120
140
0 20 40 60 80 100
510(17)
20(34)
30(51) 40(68) 50(85)
60(102)
70(119)
80(136)
90(159.9)
Materials
Material Prole: Operating
Temperatures:
Max. Min.
Conductive Acetal: Tough, impact resistant, ductile. Good
abrasion resistance and low friction surface. Generally inert, with
good chemical resistance except for strong acids and oxidizing
agents.
190°F
88°C
-20°F
-29°C
EPDM: Shows very good water and chemical resistance. Has
poor resistance to oils and solvents, but is fair in ketones and
alcohols.
280°F
138°C
-40°F
-40°C
FKM: (Fluorocarbon) Shows good resistance to a wide range
of oils and solvents; especially all aliphatic, aromatic and
halogenated hydrocarbons, acids, animal and vegetable oils.
Hot water or hot aqueous solutions (over 70°F(21°C)) will
attack FKM.
350°F
177°C
-40°F
-40°C
Hytrel®: Good on acids, bases, amines and glycols at room
temperatures only.
220°F
104°C
-20°F
-29°C
Neoprene: All purpose. Resistance to vegetable oils. Generally
not affected by moderate chemicals, fats, greases and many
oils and solvents. Generally attacked by strong oxidizing acids,
ketones, esters and nitro hydrocarbons and chlorinated aromatic
hydrocarbons.
200°F
93°C
-10°F
-23°C
Nitrile: General purpose, oil-resistant. Shows good solvent, oil,
water and hydraulic uid resistance. Should not be used with
highly polar solvents like acetone and MEK, ozone, chlorinated
hydrocarbons and nitro hydrocarbons.
190°F
88°C
-10°F
-23°C
Nylon: 6/6 High strength and toughness over a wide
temperature range. Moderate to good resistance to fuels, oils
and chemicals.
180°F
82°C
32°F
0°C
Polypropylene: A thermoplastic polymer. Moderate tensile
and ex strength. Resists stong acids and alkali. Attacked by
chlorine, fuming nitric acid and other strong oxidizing agents.
180°F
82°C
32°F
0°C
PVDF: (Polyvinylidene Fluoride) A durable uoroplastic with
excellent chemical resistance. Excellent for UV applications.
High tensile strength and impact resistance.
250°F
121°C
0°F
-18°C
Santoprene®: Injection molded thermoplastic elastomer with
no fabric layer. Long mechanical ex life. Excellent abrasion
resistance.
275°F
135°C
-40°F
-40°C
UHMW PE: A thermoplastic that is highly resistant to a broad
range of chemicals. Exhibits outstanding abrasion and impact
resistance, along with environmental stress-cracking resistance.
180°F
82°C
-35°F
-37°C
Urethane: Shows good resistance to abrasives. Has poor
resistance to most solvents and oils.
150°F
66°C
32°F
0°C
Virgin PTFE: (PFA/TFE) Chemically inert, virtually impervious.
Very few chemicals are known to chemically react with PTFE;
molten alkali metals, turbulent liquid or gaseous uorine and
a few uoro-chemicals such as chlorine triuoride or oxygen
diuoride which readily liberate free uorine at elevated
temperatures.
220°F
104°C
-35°F
-37°C
Maximum and Minimum Temperatures are the limits for which these materials can be operated.
Temperatures coupled with pressure affect the longevity of diaphragm pump components.
Maximum life should not be expected at the extreme limits of the temperature ranges.

Alloy C: Equal to ASTM494 CW-12M-1 specication for nickel and nickel alloy.
Stainless Steel: Equal to or exceeding ASTM specication A743 CF-8M for corrosion
resistant iron chromium, iron chromium nickel and nickel based alloy castings for
general applications. Commonly referred to as 316 Stainless Steel in the pump industry.
For specic applications, always consult the Chemical Resistance Chart.
CAUTION! Operating temperature limitations are as follows:
MODEL SPECIFIC UNIVERSAL ALL AODD
1: PUMP SPECS

www.sa ndp ipe rpu mp.c om Model ST1½/ST40 • 7
st15dl5sm-rev1218

Dimensions are ±1/8". Figures in parentheses = millimeters.
19.09 485
(ST1 1/2VL)
.13 3
.36 9
16.63 422
16.00 406
17.35 441
(ST1 1/2)
DISCHARGE PORT
1 1/2 NPT
1 1/2 BSPT
SUCTION PORT
1 1/2 NPT
1 1/2 BSPT
11.12 282
9.85 250
18.68 475
13.00 330
5.09 129
10.33 262
*10.06 256
4.76 121
*4.04 103
*12.42 315
11.00 279
14.00 356
4X
.50 13
MOUNTING HOLE
8.88 225
10.25 260 .50 13
PUMP TO BASE
MOUNTING HOLE
17.02 432
AIR INLET
3/4 NPT
AIR EXHAUST
3/4 NPT
*
INDICATES DIMENSION WITH SUCTION AND DISCHARGE
PORTS ROTATED 180 TO A VERTICAL POSITION
Dimensional Drawings
MODEL SPECIFIC
1: PUMP SPECS

www.sa ndp ipe rpu mp.c om
8 • Model ST1½/ST40
st15dl5sm-rev1218
Principle of Pump Operation
Air Line
Discharged
Fluid
Discharge
Stroke Suction
Stroke
Primed
Fluid
Air-Operated Double Diaphragm (AODD) pumps are powered by
compressed air or nitrogen.
The main directional (air) control valve ①distributes compressed
air to an air chamber, exerting uniform pressure over the inner
surface of the diaphragm
②. At the same time, the exhausting air
③ from behind the opposite diaphragm is directed through the
air valve assembly(s) to an exhaust port ④.
As inner chamber pressure (P1) exceeds liquid chamber
pressure (P2), the rod ⑤connected diaphragms shift together
creating discharge on one side and suction on the opposite side.
The discharged and primed liquid’s directions are controlled by
the check valves (ball or ap)⑥orientation.
The pump primes as a result of the suction stroke. The suction
stroke lowers the chamber pressure (P3) increasing the chamber
volume. This results in a pressure differential necessary for
atmospheric pressure (P4) to push the uid through the suction
piping and across the suction side check valve and into the outer
uid chamber ⑦.
Suction (side) stroking also initiates the reciprocating (shifting,
stroking or cycling) action of the pump. The suction diaphragm’s
movement is mechanically pulled through its stroke. The
diaphragm’s inner plate makes contact with an actuator plunger
aligned to shift the pilot signaling valve. Once actuated, the
pilot valve sends a pressure signal to the opposite end of the
main directional air valve, redirecting the compressed air to the
opposite inner chamber.
This Containment Duty SANDPlPER unit differs from other SANDPIPER units only in that it utilizes four
(4) diaphragms instead of two (2). Two rod-connected diaphragms are the driver diaphragms. The other
two (outermost) diaphragms are the actual pumping diaphragms. Each driver diaphragm (of neoprene
or other elastomer), and the pumping diaphragm (of PTFE), are separated by a chamber lled with liquid
which transmits the reciprocating motion of the driver diaphragm to the pumping diaphragm. The PTFE
pumping diaphragms, in turn, create the alternating suction and discharge action in the outer diaphragm
chambers, and are the only diaphragms in contact with liquid being pumped.
SAFE AIR
EXHAUST
DISPOSAL
AREA
PUMP INSTALLATION AREA
1" DIAMETER AIR
EXHAUST PIPING
1" DIAMETER AIR
EXHAUST PIPING
1" DIAMETER AIR
EXHAUST PIPING
MUFFLER
LIQUID
LEVEL
SUCTION
LINE
LIQUID
LEVEL
SUCTION
LINE
MUFFLER
MUFFLER
SUBMERGED ILLUSTRATION
Pump can be submerged if the pump materials of construction
are compatible with the liquid being pumped. The air exhaust
must be piped above the liquid level. When the pumped product
source is at a higher level than the pump (ooded suction
condition), pipe the exhaust higher than the product source to
prevent siphoning spills.
MODEL SPECIFIC
2: INSTAL & OP

www.sa ndp ipe rpu mp.c om Model ST1½/ST40 • 9
st15dl5sm-rev1218
Installation And Start-Up
Locate the pump as close to the product being pumped as possible. Keep the suction line length and number of ttings to a minimum. Do not reduce the suction line
diameter.
Air Supply
Connect the pump air inlet to an air supply with sufcient capacity and pressure to achieve desired performance. A pressure regulating valve should be installed to
insure air supply pressure does not exceed recommended limits.
Air Valve Lubrication
The air distribution system is designed to operate WITHOUT lubrication. This is the standard mode of operation. If lubrication is desired, install an air line lubricator
set to deliver one drop of SAE 10 non-detergent oil for every 20 SCFM (9.4 liters/sec.) of air the pump consumes. Consult the Performance Curve to determine air
consumption.
Air Line Moisture
Water in the compressed air supply may cause icing or freezing of the exhaust air, causing the pump to cycle erratically or stop operating. Water in the air supply can
be reduced by using a point-of-use air dryer.
Air Inlet And Priming
To start the pump, slightly open the air shut-off valve. After the pump primes, the air valve can be opened to increase air ow as desired. If opening the valve
increases cycling rate, but does not increase the rate of ow, cavitation has occurred. The valve should be closed slightly to obtain the most efcient air ow to pump
ow ratio.
Surge Suppressor
Shut-Off Valve
Pressure Gauge
Drain Port
Shut-Off
Valve
Check
Valve
Air Inlet
Discharge
Unregulated Air
Supply to Surge
Suppressor
Pipe Connection
(Style Optional)
Flexible Connector
Flexible Connector
Vacuum
Gauge
Suction
Shut-Off Valve
Drain Port
Air Dryer
Filter Regulator
Muffler
(Optional Piped Exhaust)
Recommended Installation Guide

 Surge Suppressor
Filter/Regulator
Air Dryer
1

3
Note: Surge Suppressor and
Piping must be supported after
the exible connection
CAUTION
The air exhaust should
be piped to an area
for safe disposition
of the product being
pumped, in the event of
a diaphragm failure.
Principle of Pump Operation
SUBMERGED ILLUSTRATION
UNIVERSAL ALL AODD, EXCEPT FLAP
2: INSTAL & OP

www.sa ndp ipe rpu mp.c om
10 • Model ST1½/ST40
st15dl5sm-rev1218
Filling the Driver Chambers with Liquid
THE DRIVER CHAMBERS WILL BE
FILLED WITH DISTILLED WATER AT THE

CAST IRON, THE UNIT IS FILLED WITH

If you prefer to substitute another liquid, to prevent
system contamination consult the factory rst to
determine compatibility of the substitute with pump
construction.
Follow the steps listed below to replace the liquid
in the pump after disassembly or liquid loss:
Step 1. Disconnect air supply from pump before
starting any work. Remove the ll and drain
plugs (¼ NPT) (.0635 cm) from the driver chambers.
After the chambers are completely drained of all
liquid, replace the drain plugs and tighten them
securely. NOTE: Use thread sealant on plug threads.
 . Remove the two large (1 NPT) (2.54
cm) pipe plugs (one on each side) located in
the rear of the innermost air chambers.
Step 3. Determine which side of the pump is on the
discharge stroke and which side is on the suction
stroke by checking the positions of the diaphragm
assemblies. The cast inner diaphragm plate closest
to the pump intermediate housing, or centerline,
is the chamber in the suction stroke position. The
opposite chamber, with cast inner diaphragm plate
away from unit centerline, is in the discharge stroke
position. NOTE: The diaphragm assemblies (cast
inner diaphragm plates) are visible through the two
tapped holes in the inner chambers from which the
two large pipe plugs were removed.
Step 4. For pumps with air valve assemblies
031.098.010 or 031.098.156
Insert the safety clip (210-008-330) on one side
of the main air valve body and cycle the pump at 5
to 10 psi. As you face the pump, the side with the pin
should be the rst driver uid reservoir to be lled.
The driver diaphragm will be on a suction
stroke. Pour the correct amount of liquid into the
reservoir. The uid level will not come completely to
the top. Loosely install the pipe plug, with pipe dope,
PTFE tape or o-ring (depending on pump model)
placed on the threads. Release all air pressure to the
pump and remove the safety clip. The diaphragm will
relax and will come to center. Watch the loose pipe
plug closely as air escapes and the driver uid level
rises. Insert the safety clip on the opposite side and
add a small amount of air pressure. When you see
liquid weeping out between the loose pipe plug and
ll hole, tighten the pipe plug. Repeat the procedure
for the unlled chamber.
If you have a problem getting the driver uid to come
to the top, a blunt instrument can be inserted into the
chamber port of the pump and pressure can manually
be applied to the pumping diaphragm to cause the
liquid to come to the top. Do this carefully. A needle
valve for precision stroking control is recommended
at the air inlet for this procedure. Please be aware that
air left in the chambers will result in faulty operation of
the pump and will cause premature pumping
diaphragm failure.
For pumps not equipped with Visual Leak Detection
sight tubes, ll with 1200ml/ 40.6 . oz.
For pumps equipped with Visual Leak Detection sight
tubes, ll with 1250ml/ 42.3 . oz.
Use pipe sealant on pipe plugs. Cast iron fluid
chambers typically lled with normal antifreeze.
Step 5. After lling, the liquid will not come all the
way to the top of the lling hole. Use a screwdriver or
similar tool to apply leverage on the inner diaphragm
plate (diaphragm assembly) forcing the driver
diaphragm on the side you have just lled partially
through its discharge stroke until the liquid level in the
chamber you are lling comes to the top of the ll hole.
This displaces any air in the chamber. CAUTION: Do
not pry on or damage the elastomer diaphragm while
performing this step of the lling instructions.
Step 6. Re-plug the ll hole and tighten securely.
NOTE: Use thread sealant on plug threads and tighten
only until snug.
Step 7. Using a screwdriver or similar tool apply
leverage on the inner diaphragm plate (diaphragm
assembly), on the side just lled, forcing the pump to
“shift” or reverse diaphragm positions.
Follow steps (4) thru (6) to ll the opposite
driver chamber.
Step 9. Re-install the two large pipe plugs in the rear
of the pump inner air chambers. NOTE: Use thread
sealant on plug threads.
2: INSTAL & OP

www.sa ndp ipe rpu mp.c om Model ST1½/ST40 • 11
st15dl5sm-rev1218
Troubleshooting Guide
For additional troubleshooting tips contact After Sales Support at [email protected] or 419-524-8388
  
Pump Cycles Once Deadhead (system pressure meets or exceeds air
supply pressure).
Increase the inlet air pressure to the pump. Pump is designed for 1:1 pressure ratio at zero ow.
(Does not apply to high pressure 2:1 units).
Air valve or intermediate gaskets installed incorrectly. Install gaskets with holes properly aligned.
Bent or missing actuator plunger. Remove pilot valve and inspect actuator plungers.
Pump Will Not Operate
/ Cycle
Pump is over lubricated. Set lubricator on lowest possible setting or remove. Units are designed for lube free operation.
Lack of air (line size, PSI, CFM). Check the air line size and length, compressor capacity (HP vs. cfm required).
Check air distribution system. Disassemble and inspect main air distribution valve, pilot valve and pilot valve actuators.
Discharge line is blocked or clogged manifolds. Check for inadvertently closed discharge line valves. Clean discharge manifolds/piping.
Deadhead (system pressure meets or exceeds air
supply pressure).
Increase the inlet air pressure to the pump. Pump is designed for 1:1 pressure ratio at zero ow.
(Does not apply to high pressure 2:1 units).
Blocked air exhaust mufer. Remove mufer screen, clean or de-ice, and re-install.
Pumped uid in air exhaust mufer. Disassemble pump chambers. Inspect for diaphragm rupture or loose diaphragm plate assembly.
Pump chamber is blocked. Disassemble and inspect wetted chambers. Remove or ush any obstructions.
Pump Cycles and Will
Not Prime or No Flow
Cavitation on suction side. Check suction condition (move pump closer to product).
Check valve obstructed. Valve ball(s) not seating
properly or sticking.
Disassemble the wet end of the pump and manually dislodge obstruction in the check valve pocket.
Clean out around valve ball cage and valve seat area. Replace valve ball or valve seat if damaged.
Use heavier valve ball material.
Valve ball(s) missing (pushed into chamber or
manifold).
Worn valve ball or valve seat. Worn ngers in valve ball cage (replace part). Check Chemical
Resistance Guide for compatibility.
Valve ball(s) / seat(s) damaged or attacked by product. Check Chemical Resistance Guide for compatibility.
Check valve and/or seat is worn or needs adjusting. Inspect check valves and seats for wear and proper setting. Replace if necessary.
Suction line is blocked. Remove or ush obstruction. Check and clear all suction screens or strainers.
Excessive suction lift. For lifts exceeding 20’ of liquid, lling the chambers with liquid will prime the pump in most cases.
Suction side air leakage or air in product. Visually inspect all suction-side gaskets and pipe connections.
Pumped uid in air exhaust mufer. Disassemble pump chambers. Inspect for diaphragm rupture or loose diaphragm plate assembly.
Pump Cycles Running
Sluggish / Stalling,
Flow Unsatisfactory
Over lubrication. Set lubricator on lowest possible setting or remove. Units are designed for lube free operation.
Icing. Remove mufer screen, de-ice, and re-install. Install a point of use air drier.
Clogged manifolds. Clean manifolds to allow proper air ow.
Deadhead (system pressure meets or exceeds air
supply pressure).
Increase the inlet air pressure to the pump. Pump is designed for 1:1 pressure ratio at zero ow.
(Does not apply to high pressure 2:1 units).
Cavitation on suction side. Check suction (move pump closer to product).
Lack of air (line size, PSI, CFM). Check the air line size, length, compressor capacity.
Excessive suction lift. For lifts exceeding 20’ of liquid, lling the chambers with liquid will prime the pump in most cases.
Air supply pressure or volume exceeds system hd. Decrease inlet air (press. and vol.) to the pump. Pump is cavitating the uid by fast cycling.
Undersized suction line. Meet or exceed pump connections.
Restrictive or undersized air line. Install a larger air line and connection.
Suction side air leakage or air in product. Visually inspect all suction-side gaskets and pipe connections.
Suction line is blocked. Remove or ush obstruction. Check and clear all suction screens or strainers.
Pumped uid in air exhaust mufer. Disassemble pump chambers. Inspect for diaphragm rupture or loose diaphragm plate assembly.
Check valve obstructed. Disassemble the wet end of the pump and manually dislodge obstruction in the check valve pocket.
Check valve and/or seat is worn or needs adjusting. Inspect check valves and seats for wear and proper setting. Replace if necessary.
Entrained air or vapor lock in chamber(s). Purge chambers through tapped chamber vent plugs. Purging the chambers of air can be dangerous.
Product Leaking
Through Exhaust
Diaphragm failure, or diaphragm plates loose. Replace diaphragms, check for damage and ensure diaphragm plates are tight.
Diaphragm stretched around center hole or bolt holes. Check for excessive inlet pressure or air pressure. Consult Chemical Resistance Chart for compatibility
with products, cleaners, temperature limitations and lubrication.
Premature Diaphragm
Failure
Cavitation. Enlarge pipe diameter on suction side of pump.
Excessive ooded suction pressure. Move pump closer to product. Raise pump/place pump on top of tank to reduce inlet pressure.
Install Back pressure device (Tech bulletin 41r). Add accumulation tank or pulsation dampener.
Misapplication (chemical/physical incompatibility). Consult Chemical Resistance Chart for compatibility with products, cleaners, temperature limitations
and lubrication.
Incorrect diaphragm plates or plates on backwards,
installed incorrectly or worn.
Check Operating Manual to check for correct part and installation. Ensure outer plates have not been
worn to a sharp edge.
Unbalanced Cycling Excessive suction lift. For lifts exceeding 20’ of liquid, lling the chambers with liquid will prime the pump in most cases.
Undersized suction line. Meet or exceed pump connections.
Pumped uid in air exhaust mufer. Disassemble pump chambers. Inspect for diaphragm rupture or loose diaphragm plate assembly.
Suction side air leakage or air in product. Visually inspect all suction-side gaskets and pipe connections.
Check valve obstructed. Disassemble the wet end of the pump and manually dislodge obstruction in the check valve pocket.
Check valve and/or seat is worn or needs adjusting. Inspect check valves and seats for wear and proper setting. Replace if necessary.
Entrained air or vapor lock in chamber(s). Purge chambers through tapped chamber vent plugs.
Filling the Driver Chambers with Liquid
UNIVERSAL ALL SANDPIPER, EXCEPT FLAP
2: INSTAL & OP

www.sa ndp ipe rpu mp.c om
12 • Model ST1½/ST40
st15dl5sm-rev1218
 
Sleeve and Spool Set, Seals, Gaskets, O-rings, Bumpers,
Plunger Actuator, Plunger Bushings, and Pilot Valve Assembly
 
Seals, O-rings, Gaskets, Grease Packet Bumpers, Plunger
Actuators, Plunger Bushings
 
EPDM Driver Diaphragms, PTFE Pumping Diaphragms, PTFE
Check Balls, PTFE Gasets, EDPM O-rings,
and FEP Encapsulated Silicone O-rings
 
Neoprene Driver Diaphragms, PTFE Pumping Diaphragms,
PTFE Check Balls, PTFE Gaskets, Nitrile O-rings, and FEP
Encapsulated Silicone O-rings
 
FKM Driver Diaphragms, PTFE Pumping Diaphragms,
PTFE Check Balls, PTFE Gaskets, FKM O-rings, and FEP
Encapsulated Silicone O-rings

Check Valve Seat & Conductive Neoprene Seat Gaskets,
and Fasteners
Check Valve Seat & Conductive Buna Seat Gaskets,
and Fasteners
Check Valve Seat & Conductive PTFE Seat Gaskets,
and Fasteners
29
16
23
26
30
12
52
25
2
53
52
34
29
32
2
37
25
14
52
15
18
43
22
38
50
49
17
39
42
21
41
44
52
34 20
8
33
51
31
43
36
45 35 9
27
4
28
13
26
7
6
12
52
1
52
11
47
46
34 52
37
7
6
49
3
40
BBBB
AA
43
48
48
B
10
55
57
56
54
TORQUE: 480 in-lbs
(54 N-m)
TORQUE: 400 in-lbs
(45 N-m)
TORQUE: 400 in-lbs
(45 N-m)
26
51
26
13
23
27
30
12
58
25
259
58
35
26
50
26
33
2
38
25
55
15
58
45
32
54
16
18
44
22
39
53
52
17
40
43
21
42
46
58
35
20
8
34
57
10
31
44
37
47 36 9
28
4
29
14
27
7
6
12
58
1
58
11
49
48
35 58
38
7
6
52
3
41
BBBBB
AA
Optional Angle Valve Kit: A
These items available in kit form
only Order PN: 475.102.000.
Optional Rubber Foot Kit: B
These items available in kit form
only Order PN: 475.101.000.
56
Composite Repair Parts Drawing

MODEL SPECIFIC
3: EXP VIEW

www.sa ndp ipe rpu mp.c om Model ST1½/ST40 • 13
st15dl5sm-rev1218
Composite Repair Parts List
Item Part Number Description Qty.
30 518.003.110 MANIFOLD 1
518.003.156 MANIFOLD 1
518.003.010 MANIFOLD 1
31 530.033.000 MUFFLER 1
32 544.002.115 NUT, HEX FLANGED, 3/8-16 6
33 545.005.110 NUT, HEX, 5/16-18 4
34 545.007.115 NUT, HEX - 7/16-14 40
35 560.001.360 O-RING 2
36 560.022.360 O-RING 2
37 560.028.610 O-RING 2
38 560.043.360 O-RING 2
560.043.363 O-RING 2
560.043.364 O-RING 2
39 560.070.610 O-RING 2
40 612.007.150 PLATE, BASE 1
41 612.052.157 PLATE, INNER DIAPHRAGM 2
612.052.010 PLATE, INNER DIAPHRAGM 2
42 612.096.110 PLATE, OUTER DIAPHRAGM 2
43 618.003.110 PLUG, PIPE, 1/4 6
618.003.112 PLUG, PIPE, 1/4 4
44 618.007.115 PLUG, PIPE, 1" NPT 2
45 620.011.114 PLUNGER, ACTUATOR 2
46 685.007.120 BUMPER, DIAPHRAGM 1
47 720.004.360 SEAL, U-CUP 2
48 722.105.110 SEAT, CHECK VALVE - SUCTION 2
49 807.017.115 7/16-14 X 3 STUD 4
50 807.033.115 STUD, 7/16-14 X 2.00 16
51 900.005.110 WASHER, LOCK, 3/8 5
52 900.006.115 WASHER, LOCK, 7/16 56
53 905.001.306 WASHER, TAPERED 4
Items Included on ST1 1/2VL only
54 538.083.110 NIPPLE, PIPE, 1/4" NPT, CLOSE 4
55 835.005.110 TEE, PIPE, 1/4 NPT 4
56 860.064.606 TUBE 2
57 866.060.110 CONNECTOR, TUBE 4
Not Shown:
242-001-000 Fill Bottle
Item Part Number Description Qty.
1* 031.215.010 ASSEMBLY, MAIN AIR VALVE (See Pg 11) 1
031.215.156 ASSEMBLY, MAIN AIR VALVE (See Pg 11) 1
2 050.010.600 BALL, CHECK 4
3 070.006.170 BEARING 2
4 095.073.001 PILOT VALVE ASSEMBLY 1
5 114.002.010 BRACKET, INTERMEDIATE 1
114.002.156 BRACKET, INTERMEDIATE 1
6 115.062.080 BRACKET, MOUNTING FOOT, LEFT 2
7 115.063.080 BRACKET, MOUNTING FOOT, RIGHT 2
8 132.002.360 BUMPER, DIAPHRAGM 2
9 135.016.162 BUSHING, THREADED 2
10 170.006.110 CAPSCREW, HEX HD, 5/16-18 X 7/8 4
11 170.024.115 CAPSCREW, HEX HD, 7/16-14 X 1 8
12 170.035.115 CAPSCREW, HEX HD, 7/16-14 X 1.50 4
13 170.045.115 CAPSCREW, HEX HEAD 5/16-18 X 1 1/4 4
14 170.058.115 CAPSCREW, HEX HD, 7/16-14 X 1.25 4
15 170.060.115 CAPSCREW, HEX HD, 7/16-14 X 2.00 20
16 170.131.115 CAPSCREW, HEX HD, 3/8-16 X 6 6
17 171.002.110 CAPSCREW, SOC HD, 5/8-11 X 1.50 2
18 196.027.110 CHAMBER, OUTER 2
196.027.156 CHAMBER, OUTER 2
196.027.010 CHAMBER, OUTER 2
19 196.028.010 CHAMBER, SPILL CONTAINMENT 2
196.028.110 CHAMBER, SPILL CONTAINMENT 2
196.028.156 CHAMBER, SPILL CONTAINMENT 2
20 196.029.010 CHAMBER, INNER 2
196.029.156 CHAMBER, INNER 2
21 286.005.354 DIAPHRAGM 2
286.005.363 DIAPHRAGM 2
286.005.364 DIAPHRAGM 2
286.005.365 DIAPHRAGM 2
22 286.017.604 DIAPHRAGM, PUMPING 2
23 334.006.110 FLANGE, DISCHARGE 1
334.006.156 FLANGE, DISCHARGE 1
334.006.010 FLANGE, DISCHARGE 1
24 334.007.110 FLANGE, SUCTION 1
334.007.156 FLANGE, SUCTION 1
334.007.010 FLANGE, SUCTION 1
25 334.008.110 FLANGE, PORTING 2
334.008.156 FLANGE, PORTING 2
334.008.010 FLANGE, PORTING 2
334.008.110 E FLANGE, PORTING, BSP TAPERED 2
334.008.156 E FLANGE, PORTING, BSP TAPERED 2
334.008.010 E FLANGE, PORTING, BSP TAPERED 2
26 360.022.600 GASKET, MANIFOLD 2
27 360.041.379 GASKET 1
28 360.048.425 GASKET 1
29 360.116.608 GASKET, MANIFOLD/SEAT 4
LEGEND:
= Items contained within Air End Kits
= Items contianed within Wet End Kits
* Air End Kit includes sleeve and spool set, not entire air valve
assembly
Note: Kits contain components specic to the material codes.
MODEL SPECIFIC
3: EXP VIEW

www.sa ndp ipe rpu mp.c om
14 • Model ST1½/ST40
st15dl5sm-rev1218
Material Codes - The Last 3 Digits of Part Number
000.....Assembly, sub-assembly;
and some purchased items
010.....Cast Iron
015.....Ductile Iron
020.....Ferritic Malleable Iron
080.....Carbon Steel, AISI B-1112
110 .....Alloy Type 316 Stainless Steel
111 .....Alloy Type 316 Stainless Steel
(Electro Polished)
112 .....Alloy C
113 .....Alloy Type 316 Stainless Steel
(Hand Polished)
114 .....303 Stainless Steel
115 .....302/304 Stainless Steel
117 .....440-C Stainless Steel (Martensitic)
120.....416 Stainless Steel
(Wrought Martensitic)
148.....Hardcoat Anodized Aluminum
150.....6061-T6 Aluminum
152.....2024-T4 Aluminum (2023-T351)
155.....356-T6 Aluminum
156.....356-T6 Aluminum
157.....Die Cast Aluminum Alloy #380
158.....Aluminum Alloy SR-319
162.....Brass, Yellow, Screw Machine Stock
165.....Cast Bronze, 85-5-5-5
166.....Bronze, SAE 660
170.....Bronze, Bearing Type,
Oil Impregnated
180.....Copper Alloy
305.....Carbon Steel, Black Epoxy Coated
306.....Carbon Steel, Black PTFE Coated
307.....Aluminum, Black Epoxy Coated
308.....Stainless Steel, Black PTFE Coated
309.....Aluminum, Black PTFE Coated
313.....Aluminum, White Epoxy Coated
330.....Zinc Plated Steel
332.....Aluminum, Electroless Nickel Plated
333.....Carbon Steel, Electroless
Nickel Plated
335.....Galvanized Steel
337.....Silver Plated Steel
351.....Food Grade Santoprene®
353.....Geolast; Color: Black
354.....Injection Molded #203-40
Santoprene®Duro 40D +/-5;
Color: RED
356.....Hytrel®
357.....Injection Molded Polyurethane
358.....Urethane Rubber
(Some Applications)
(Compression Mold)
359.....Urethane Rubber
360.....Nitrile Rubber Color coded: RED
363.....FKM (Fluorocarbon)
Color coded: YELLOW
364.....EPDM Rubber
Color coded: BLUE
365.....Neoprene Rubber
Color coded: GREEN
366.....Food Grade Nitrile
368.....Food Grade EPDM
371.....Philthane (Tuftane)
374.....Carboxylated Nitrile
375.....Fluorinated Nitrile
378.....High Density Polypropylene
379.....Conductive Nitrile
408.....Cork and Neoprene
425.....Compressed Fibre
426.....Blue Gard
440.....Vegetable Fibre
500.....Delrin®500
502.....Conductive Acetal, ESD-800
503.....Conductive Acetal, Glass-Filled
506.....Delrin®150
520.....Injection Molded PVDF
Natural color
540.....Nylon
542.....Nylon
544.....Nylon Injection Molded
550.....Polyethylene
551.....Glass Filled Polypropylene
552.....Unlled Polypropylene
555.....Polyvinyl Chloride
556.....Black Vinyl
558.....Conductive HDPE
570.....Rulon II®
580.....Ryton®
600.....PTFE (virgin material)
Tetrauorocarbon (TFE)
603.....Blue Gylon®
604.....PTFE
606.....PTFE
607.....Envelon
608.....Conductive PTFE
610.....PTFE Encapsulated Silicon
611 .....PTFE Encapsulated FKM
632.....Neoprene/Hytrel®
633.....FKM/PTFE
634.....EPDM/PTFE
635.....Neoprene/PTFE
637.....PTFE, FKM/PTFE
638.....PTFE, Hytrel®/PTFE
639.....Nitrile/TFE
643.....Santoprene®/EPDM
644.....Santoprene®/PTFE
656.....Santoprene®Diaphragm and
Check Balls/EPDM Seats
661.....EPDM/Santoprene®
666.....FDA Nitrile Diaphragm,
PTFE Overlay, Balls, and Seals
668.....PTFE, FDA Santoprene®/PTFE
• Delrin and Hytrel are registered
tradenames of E.I. DuPont.
• Nylatron is a registered tradename
of Polymer Corp.
• Gylon is a registered tradename
of Garlock, Inc.
• Santoprene is a registered tradename
of Exxon Mobil Corp.
• Rulon II is a registered tradename
of Dixion Industries Corp.
• Ryton is a registered tradename
of Phillips Chemical Co.
• Valox is a registered tradename
of General Electric Co.
RECYCLING
Many components of SANDPIPER®AODD
pumps are made of recyclable materials.
We encourage pump users to recycle worn
out parts and pumps whenever possible,
after any hazardous pumped fluids are
thoroughly ushed.
UNIVERSAL ALL SP
3: EXP VIEW

1.D
1.F
1.C
1.A1.A
1.H
1.B
1.G
1.D
1.E
Page 19
1.J
Note to Trent: Do not paste this table in S/M. Only use to modify on
on page 19
www.sa ndp ipe rpu mp.c om Model ST1½/ST40 • 15
st15dl5sm-rev1218
Air Valve with Stroke Indicator Assembly
MAIN AIR VALVE ASSEMBLY PARTS LIST
Item Part Number Description Qty
1 031.215.156 Air Valve Assembly 1
1.A 031.214.000 Sleeve and Spool Set 1
1.B 095.043.156 Air Valve Body 1
1.C 132.014.358 Bumper 2
1.D 165.066.010 End Cap 2
1.E 170.032.330 Hex Head Capscrew 1/4-20 UNC 2B x .75 long 8
1.F 360.010.425 Gasket 2
1.G 210.008.330 Safety Clip 1
1.H 560.020.360 O-ring 6
For Pumps with Cast Iron Center Sections:
1 031.215.010 Air Valve Assembly 1
1.A 031.214.000 Sleeve and Spool Set 1
1.B 095.043.010 Air Valve Body 1
1.C 132.014.358 Bumper 2
1.D 165.066.010 End Cap 2
1.E 170.032.330 Hex Head Capscrew 1/4-20 UNC 2B x .75 long 8
1.F 360.010.425 Gasket 2
1.G 210.008.330 Safety Clip 1
1.H 560.020.360 O-ring 6
1.J 560.023.360 O-ring (included with item 1.D) 2
Air Distribution Valve Servicing
See repair parts drawing, remove screws.
Step 1: Remove end cap (1-D).
Step 2: Remove bumper (1-C).
Step 3: Remove spool part of (1-A) (caution, do not scratch).
Step 4: Press sleeve (1-A) from body (1-B).
Step 5: Inspect O-Ring (1-H) and replace if necessary.
Step 6: Lightly lubricate O-Rings (1-H) on spool (1-A).
Step 7: Press sleeve (1-A) into body (1-B).
Step 8: Reassemble in reverse order.
Note: Sleeve and spool (1-A) set is match ground to a specied clearance.
Individual parts cannot be interchanged.
LEGEND:
= Items contained within Air End Kits
Note: Kits contain components specic to the material codes.
1.J 560.023.360 O-ring (included with item 1.D) 2
MODEL SPECIFIC
4: AIR END

www.sa ndp ipe rpu mp.c om
16 • Model ST1½/ST40
st15dl5sm-rev1218
Pilot Valve Assembly
PILOT VALVE ASSEMBLY PARTS LIST
Item Part Number Description Qty
4 095.073.001 Pilot Valve Assembly 1
4-A 095.070.558 Valve Body 1
4-B 755.025.000 Sleeve (With O-Rings) 1
4-C 560.033.360 O-Ring (Sleeve) 4
4-D 775.026.000 Spool (With O-Rings) 1
4-E 560.023.360 O-Ring (Spool) 2
4-F 675.037.080 Retaining Ring 1
4-A
4-F
4-D
4-B
4-C
4-E
Pilot Valve Servicing
With Pilot Valve removed from pump.
Step 1: Remove snap ring (4-F).
Step 2: Remove sleeve (4-B), inspect O-Rings (4-C),
replace if required.
Step 3: Remove spool (4-D) from sleeve (4-B),
inspect O-Rings (4-E), replace if required.
Step 4: Lightly lubricate O-Rings (4-C) and (4-E).
Reassemble in reverse order. LEGEND:
= Items contained within Air End Kits
Note: Kits contain components specic to the material codes.
MODEL SPECIFIC
4: AIR END

www.sa ndp ipe rpu mp.c om Model ST1½/ST40 • 17
st15dl5sm-rev1218
Pilot Valve Assembly
Declaration of Conformity
Signature of authorized person Date of issue
Authorised Representative:
IDEX Pump Technologies
R79 Shannon Industrial Estate
Shannon, Co. Clare, Ireland
Attn: Barry McMahon
Revision Level: F
Title
Director of Engineering
October 20, 2005
Date of revision
February 27, 2017
Manufacturer: Warren Rupp, Inc., 800 N. Main Street
Mansfield, Ohio, 44902 USA
Certifies that Air-Operated Double Diaphragm Pump Series: HDB, HDF, M Non-Metallic,
S Non-Metallic, M Metallic, S Metallic, T Series, G Series, U Series, EH and SH High Pressure,
RS Series, W Series, F Series, SMA and SPA Submersibles, and Tranquilizer®Surge Suppressors comply with
the European Community Directive 2006/42/EC on Machinery, according to Annex VIII.
This product has used Harmonized Standard EN809:2012, Pumps and Pump Units
for Liquids - Common Safety Requirements, to verify conformance.
5 - YEAR Limited Product Warranty
Warren Rupp, Inc. (“Warren Rupp”) warrants to the original end-use purchaser that no product sold by Warren Rupp that
bears a Warren Rupp brand shall fail under normal use and service due to a defect in material or workmanship within five
years from the date of shipment from Warren Rupp’s factory. Warren Rupp brands include Warren Rupp®,SANDPIPER®,
SANDPIPER Signature SeriesTM, MARATHON®, Porta-Pump®, SludgeMaster™ and Tranquilizer®.
The use of non-OEM replacement parts will void (or negate) agency certifications, including CE, ATEX, CSA, 3A and
EC1935 compliance (Food Contact Materials). Warren Rupp, Inc. cannot ensure nor warrant non-OEM parts to meet the
stringent requirements of the certifying agencies.
~ See sandpiperpump.com/content/warranty-certifications for complete warranty,
including terms and conditions, limitations and exclusions. ~
UNIVERSAL ALL SP
7: WARRANTY

www.sa ndp ipe rpu mp.c om
18 • Model ST1½/ST40
st15dl5sm-rev1218
DATE/APPROVAL/TITLE:
26 SEP 2018 David Roseberry, Director of Engineering
EU Declaration of Conformity
Manufacturer:
Warren Rupp, Inc.
A Unit of IDEX Corporation
800 North Main Street
Mansfield, OH 44902 USA
Warren Rupp, Inc. declares that Air Operated Double Diaphragm Pumps (AODD) and Surge Suppressors
listed below comply with the requirements of Directive 2014/34/EU and all applicable standards.
Applicable Standards
• EN ISO 80079-36: 2016 • EN ISO 80079-37: 2016 • EN ISO 60079-25: 2010
Hazardous Location Applied:
II 2 G Ex h IIC T5...225°C (T2) Gb
II 2 D Ex h IIIC T100°C...T200°C Db
II 2 G Ex h IIB T5...225°C (T2) Gb
II 2 D Ex h IIIB T100°C...T200°C Db
• Metallic pump models with external aluminum components (S Series, HD Series, G Series,
DMF Series, MSA Series, U Series, F Series, T Series)
• Conductive plastic pump models with integral muffler (S Series, PB Series)
• Tranquilizer® surge suppressors
Hazardous Location Applied:
I M1 Ex h I Ma
II 1 G Ex h IIC T5...225°C (T2) Ga
II 1 D Ex h IIIC T100°C...T200°C Da
II 2 G Ex h ia IIC T5 Gb
II 2 D Ex h ia IIIC T100°C Db
II 2 G Ex h mb IIC T5 Gb
II 2 D Ex mb tb IIIC T100° Db
• Metallic pump models with no external aluminum (S series, HD Series, G series)
• Conductive plastic pumps equipped with metal muffler (S series, PB Series)
• ATEX pump models equipped with ATEX rated pulse output kit or solenoid kit
See “ATEX Details” page in user’s manual for more information
See “Safety Information” page for conditions of safe use
Meander 1051
6825 MJ Arnhem
The Netherlands
1. AODD Pumps and Surge Suppressors - Technical File No.: 20310400-1410/MER
2. AODD Pumps - EU Type Examination Certificate No.: DEKRA 18ATEX0094X - DEKRA Certification B.V. (0344)
ATEX
UNIVERSAL ALL SP
7: WARRANTY
