Idex Godiva Prima SmartCAFS PC1 Series User manual

Prima Pump with Integrated
Models: PC1_ or PC2_ with FoamLogix 3.3, 5.0 or 6.5 and
SmartCAFS200 (from September 2010)
Installation and Operation Manual
Godiva Ltd.
A Unit of IDEX Corporation
Charles St
Warwick CV34 5LR
England
[phone]
[phone] / 623689
www.godiva.co.uk
[email protected]




GP/276
Issue 6, January 2014

2
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the
right to amend specifications without notice or obligation.
AMENDMENT RECORD
Model: PC1_ or PC2_ with FoamLogix 3.3, 5.0, 6.5 Systems and SmartCAFS200 Control
Mod
Date
Page/s
Amendment
New Issue
No.
1
September
2010
All
New Issue
Issue 1,
2
August
2011
7, 44
Gauges –do not use solvents. Use mild detergent and
water
Issue 2
3
September
2011
28
Additional diagram –Compressor / Oil Water separator
location relationship
Issue 3
4
April 2012
10
Gearbox oil capacity –now 1.2 litres
Issue 4
5
April 2012
46
CAFS mixing manifold –greasing ball valve
Issue 4
6
September
2012
7, 43
Information on clutch sparking, normal condition
Issue 5
7
Jan 2013
28
Compressor / Oil Separator tank –revised installation
instructions on pipework
Issue 6
8
Jan 2013
9, 37
Insert minimum pump idle speed information
Issue 6
9
Jan 2013
14
Items 11,12,13 –can be located on top row
Issue 6
10
Jan 2013
12
Add details on new Interlock for compressor clutch
control
Issue 6

3
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the
right to amend specifications without notice or obligation.
CONTENTS
AMENDMENT RECORD.........................................................................................................2
CONTENTS.............................................................................................................................3
INTRODUCTION .....................................................................................................................6
IMPORTANT NOTES ..............................................................................................................6
SAFETY - RELEVANT DATA .................................................................................................7
MAINTENANCE........................................................................................................................7
TRAINING ...............................................................................................................................7
SAFETY POINTS......................................................................................................................7
NOISE....................................................................................................................................7
CLUTCH ENGAGEMENT............................................................................................................7
ENVIRONMENTAL PROTECTION .........................................................................................8
GENERAL DATA ....................................................................................................................9
COMPRESSOR ........................................................................................................................9
COOLING SYSTEM...................................................................................................................9
FOAM PROPORTIONING SYSTEM 3.3 -CLASS AAND BFOAM COMPATIBLE ..................................9
FOAM PROPORTIONING SYSTEM 5.0 -CLASS AAND BFOAM COMPATIBLE ..................................9
FOAM PROPORTIONING SYSTEM 6.5 -CLASS AAND BFOAM COMPATIBLE ..................................9
DIRECTION OF ROTATION -GEARBOX INPUT FLANGE .................................................................9
LUBRICANTS........................................................................................................................10
COMPRESSOR ......................................................................................................................10
PUMP GEARBOX ...................................................................................................................10
PUMP BEARING HOUSING......................................................................................................10
MODEL IDENTIFICATION SYSTEM ............................................................................................10
RECOMMENDED FOAM AGENTS.......................................................................................11
HALE FOAMLOGIX MODELS 3.3, 5.0, 6.5 CAN BE USED WITH THE FOAM CONCENTRATES SPECIFIED
ON THE HALE FOAM PROPORTIONING SYSTEM FOAM CONCENTRATE COMPATIBILITY LIST
PROVIDED AT THE REAR OF THIS MANUAL,HALE BULLETIN #650, REV 32 ,7-17-07....................11
MAJOR COMPONENTS AND CONTROLS..........................................................................12
GENERAL ARRANGEMENT......................................................................................................12
INTERLOCK FOR COMPRESSOR CLUTCH CONTROL ..................................................................12
FOAMLOGIX 3.3, 5.0, 6.5 FOAM PUMP COMPONENT GROUP ....................................................13
CONTROL PANEL FOAMLOGIX 3.3, 5.0, 6.5 -TYPICAL...............................................................13
SYSTEM OVERVIEW............................................................................................................15
FOAMLOGIX -FOAM PROPORTIONING SYSTEM........................................................................16
INSTALLATION AND INITIAL SET-UP ................................................................................17
LIFTING POINTS ....................................................................................................................17
FORK LIFT POINTS.................................................................................................................17
FOAMLOGIX 3.3, 5.0, 6.5 SYSTEM –REMOTE MOUNTED..........................................................18
FLUID DRAIN POINTS.............................................................................................................19
OIL FILLING POINTS ..............................................................................................................20
GEARBOX OIL FILLING AND CHECKING –VERTICAL POSITION ....................................................21

4
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the
right to amend specifications without notice or obligation.
WHEN THE GEARBOX IS IN THE VERTICAL POSITION,AN OIL FILL POINT AND OIL LEVEL CHECK POINT
ARE LOCATED ON BOTH SIDES OF THE HOUSING. ......................................................................21
GEARBOX OIL FILLING AND LEVEL CHECKING -HORIZONTAL POSITION,LEFT OR RIGHT OF PUMP22
COMPRESSOR DRIVE BELT....................................................................................................23
SEPARATOR TANK FOR COMPRESSOR OIL ..............................................................................24
COMPRESSOR OIL COOLING UNIT ..........................................................................................24
SMARTCAFS MIXING MANIFOLD............................................................................................25
SCHEMATIC -CAFS FLUID ....................................................................................................26
COMPRESSOR AND SEPARATOR TANK –RELATIVE POSITIONS IN INSTALLATION..........................28
SCHEMATIC –PLUMBING CONNECTIONS –PART 2...................................................................29
SMARTCAFS200WIRING HARNESS –WITH KZCO ACTUATOR EH5 PRIMA ..............................30
FOAM PUMP HARNESS DIAGRAM............................................................................................31
PRIMA SMARTCAFS ENGINE CONTROL SCHEMATIC................................................................33
ADDITIONAL INSTALLATION POINTS.........................................................................................34
VEHICLE DESIGN CONSIDERATIONS ...............................................................................35
INSTALLATION AND INITIAL SET-UP FOAMLOGIX 3.3/5.0/6.5........................................36
OPERATION..........................................................................................................................37
FOAMLOGIX CONTROL PANEL FUNCTIONS ..............................................................................37
COMMISSIONING /START-UP PROCEDURE..............................................................................37
CALIBRATION OF FOAMLOGIX.................................................................................................38
SMART SWITCH OPERATION...................................................................................................38
WET AND DRY BUTTONS......................................................................................................39
WET AND DRY LEDS...........................................................................................................39
CONFIGURE THE WET AND DRY PRESETS..............................................................................39
CONFIGURE THE WET PRESET...............................................................................................39
CONFIGURE THE DRY PRESET...............................................................................................39
OPEN AND CLOSE BUTTONS ...............................................................................................39
OPEN AND CLOSE LEDS....................................................................................................39
VALVE POSITION BARGRAPH INDICATOR (LEDS) ......................................................................40
OPERATING THE PC2_ OR PC1_ FROM A VEHICLE WATER SOURCE ........................................40
FOAMLOGIX CONTROL PANEL................................................................................................41
ENGAGING PTO &PRIMING MAIN PUMP.................................................................................41
OPTIONAL TANK SELECTION FOR FOAMLOGIX 3.3/5.0/6.5 .......................................................41
DISCHARGING FOAM /WATER SOLUTION ONLY .......................................................................42
DISCHARGING CAFS ............................................................................................................42
OVERHEAT SHUT DOWN ........................................................................................................43
FLUSHING.............................................................................................................................43
MAINTENANCE SCHEDULE PC2_/PC1_............................................................................44
MAINTENANCE OPERATIONS PC2....................................................................................45
STRAINER -HIGH PRESSURE .................................................................................................45
MAINTENANCE OPERATIONS PUMP –PC1 OR PC2 .......................................................46
CAFS MIXING MANIFOLD –GREASING BALL VALVE.................................................................46
VACUUM TEST......................................................................................................................46
PRESSURE TEST –CARRIED OUT WITHOUT PUMP RUNNING.......................................................46
THERMAL RELIEF VALVE (TRV) TEST –IF OPTION FITTED........................................................47
FAULT FINDING ...................................................................................................................48
PUMP OPERATING FAULTS 1–LOSS OF SUCTION......................................................48

5
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the
right to amend specifications without notice or obligation.
PUMP OPERATING FAULTS 2–EXCESSIVE PUMP NOISE...........................................49
GENERAL OPERATING FAULTS -CAFS..........................................................................50
AIR INJECTION FAULTS...................................................................................................51
RECOMMENDED SPARES KIT FOR BI-ANNUAL SERVICE..............................................54
NOTES.................................................................................................................................54
INSTALLATION DRAWINGS –PC2_ WITH SMARTCAFS200 ...........................................55
FIGURE 1A (BASED ON PC2_4010)........................................................................................55
FIGURE 1C (BASED ON PC2_4010) .......................................................................................57
FIGURE 1F (BASED ON PC2_4010)........................................................................................60
FIGURE 3B COOLING.............................................................................................................64
FIGURE 4A OIL SEPARATOR ..................................................................................................65
FIGURE 5A FOAMLOGIX DIMENSIONS .....................................................................................67
FIG 5B FOAMLOGIX BASEPLATE MOUNTING HOLE LOCATIONS...................................................67
RECOMMENDED FOAM AGENTS.......................................................................................68

6
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the
right to amend specifications without notice or obligation.
INTRODUCTION
This manual contains information relevant to Godiva single or multi-pressure Prima Series
Pumps, when partnered with Compressed Air Foam Systems (CAFS) FoamLogix Models
3.3, 5.0 and 6.5 and the SmartCAFS200 control system.
Distinction between the models regarding Installation, Maintenance, Operation and
Specification is clearly noted with text and illustrations.
For further information on the FoamLogix 3.3, 5.0 and 6.5 Foam Proportioning Systems,
MDTII Manual Dual Tank Selector, Compressor and Intelli-tank Water/foam level display unit,
please see the separate manuals supplied.
IMPORTANT NOTES
Please read this manual before operating the pump.
CRITICAL: The pump Bearing Housing, Gearbox and Compressor are NOT filled with oil ex
works. Refer to section Installation and Set-up (Oil Filling Points) before operation.
Correct lubrication and maintenance is essential if satisfactory performance is to be
maintained.
Do not run the pump without water in the pump casing.
The terms ‘Left Hand’ (LH) and ‘Right Hand’ (RH) apply when the pump unit is viewed from
the suction tube end; for the purposes of this document, this is regarded as the front of the
assembly.
!

7
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the
right to amend specifications without notice or obligation.
SAFETY - RELEVANT DATA
Thank you for purchasing a Godiva Pump.
Godiva Pumps are designed to give safe and reliable service. BEFORE use however, it
is essential that the Operating and Installation Instructions are carefully read and
understood.
Maintenance
It is the responsibility of the user to ensure that the equipment is maintained in a safe
operational condition. Local legislative conditions may apply. UK only, Maintenance
(Regulation 5) of the Provision and Use of Work Equipment Regulations 1998 applies.
Training
It is ESSENTIAL that Godiva pumps are operated ONLY by TRAINED PERSONNEL. Please
contact Godiva Ltd. Ltd to discuss your training needs.
Follow the operating procedures laid down in this document and avoid personal injury.
Safety Points
The following points apply to pumps driven by petrol, diesel or other means:
DO NOT OPERATE the unit close to flammable materials or structures.
DO NOT SMOKE while operating the unit.
DO NOT inhale fumes or gases.
Avoid prolonged skin contact with fluids, particularly if corrosive or carcinogenic.
When in use, keep ALL UNTRAINED people AWAY from the unit.
Where appropriate, eye protection should be worn.
Isolate the electrical supply when working on the pump.
Batteries produce EXPLOSIVE GASES, do not expose to sources of heat and naked
flames.
DO NOT lift heavy weights without assistance.
DO NOT remove protective guards or shields.
Noise
Operators must wear suitable EAR PROTECTION when the pump is running.
Gauges
Do not clean the glass surfaces of the gauges with abrasive or solvent cleaners. These will
cloud the glass surface. Use a mild detergent and water.
Clutch Engagement
When the clutch is first engaged it is possible to observe some sparking occurring around the
clutch assembly. This small amount of sparking is quite normal and nothing to be concerned
about. The lower the engagement speed the less sparking will occur.

8
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the
right to amend specifications without notice or obligation.
ENVIRONMENTAL PROTECTION
It is prohibited to pour engine oil and other contaminants onto the ground, down sewers,
drains, or into water courses.
Dispose of lubricants through authorised waste disposal contractors, licensed waste disposal
sites, or to the waste reclamation trade.
If in doubt, contact your Local Environmental Agency for advice regarding disposal policies.

9
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the
right to amend specifications without notice or obligation.
GENERAL DATA
Compressor
Model Enduro 12
Maximum Operating Speed 6500 rev/min
Nominal speed of operation 5000 rev/min
Nominal power consumption 40.0kW
Direction of rotation Anti-clockwise (viewed on pulley)
Volume output 5650 l/min
Operational pressure range 4 to 10 bar
Pump
Minimum idle speed 900-1000rpm
Cooling System
Type Oil / Water Shell & tube type
Cooling water flow-rate 50 l/min at 7.0 Bar
Foam Proportioning System 3.3 - Class A and B Foam Compatible
Manufacturer Hale Products Inc
Model FoamLogix 3.3
Type Electronic foam proportioning system
Operating voltage 12 and 24 volt systems available
Fuse rating 12V / 24V 60 / 40 amp
Current draw (Operating) 12V / 24V 30 / 15 amp
Current draw (Max) 12V / 24V 60 / 30 amp
Wire size 12V / 24V Minimum 8.5mm2
Max. Foam Agent Flow rate 12 l/min
Foam Proportioning System 5.0 - Class A and B Foam Compatible
Manufacturer Hale Products Inc
Model FoamLogix 5.0
Max. Foam Agent Flow rate 19 l/min
Other data as per FoamLogix 3.3
Foam Proportioning System 6.5 - Class A and B Foam Compatible
Manufacturer Hale Products Inc
Model FoamLogix 6.5
Max. Foam Agent Flow rate 24 l/min
Other data as per FoamLogix 3.3, 5.0
Direction of Rotation - Gearbox Input Flange
Clockwise only - viewed on gearbox input drive flange

10
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the
right to amend specifications without notice or obligation.
LUBRICANTS
Compressor Recommended: Screw compressor oil in
compliance with ISO Viscosity grade 32 to 46.
Alternative: SAE 10W/40 automotive multigrade oil.
Capacity 12 litres
Pump Gearbox Recommended: BP Energol GR XP 68 or similar
Capacity 1.2 litres approximately
Pump Bearing Housing Recommended: 10W/40 or 15W/40 Multi-grade
engine oil. Capacity 1.0 litres approximately
Model Identification System
Variations of the Godiva Prima pump with CAFS are identified thus:
P C 1 A 4010
Compressed air foam
1 = single pressure 2 = twin pressure
A = aluminium B = bronze
Godiva Prima series pump
4010 = 4000 l/min @ 10 bar. 3010 = 3000 l/min @ 10 bar
Main pump output

11
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the
right to amend specifications without notice or obligation.
RECOMMENDED FOAM AGENTS
Hale FoamLogix Models 3.3, 5.0, 6.5 can be used with the foam concentrates specified
on the Hale Foam Proportioning System Foam Concentrate Compatibility List provided
at the rear of this manual, Hale Bulletin #650, Rev 32 , 7-17-07.
The foam concentrates in the list have been tested by Hale Products to ensure compatibility
with FoamLogix systems. This information is intended to assist the end user in selecting
compatible foam concentrate(s) but is not a determination of fire fighting efficiency. Always
consult local application and environmental regulations before selecting a foam concentrate
and refer to the FoamLogix user manual for additional information.
Note: Valid from October 2008. Please contact your Godiva representative if your foam is
not listed.

12
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the
right to amend specifications without notice or obligation.
MAJOR COMPONENTS AND CONTROLS
General Arrangement
Interlock for Compressor Clutch Control
Models built from mid-2013 are fitted with a solid state device complete with pressure switch
indicating LEDs and compressor hours run meter. This unit is primarily of interest to service
technicians for CAFS fault diagnosis. The device is located on the left side of the pump.
COMPRESSED AIR
OUTLET
PTO driven Gearbox with
compressor drive via an
electromagnetic clutch
Rotary twin screw
compressor
Mounting platform, incorporates
forklift points, anti-vibration
mountings and fluid drain points
Integral gearbox oil cooler
LEDs for water pressure
switch and air pressure switch
–will be alight when circuit is
closed (no pressure).
LED –replicates the Air
Enabled Indicator on the
main panel (see page 14,
item 11)
Compressor hours run

13
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the
right to amend specifications without notice or obligation.
FoamLogix 3.3, 5.0, 6.5 Foam Pump Component Group
Note: Hale FoamLogix 3.3, 5.0 or 6.5 foam pump is supplied loose for mounting by vehicle
builder.
FoamLogix 3.3 shown
Dual Tank
Selector
(mandatory
option)
Literature
Pack
Dual Tank
Selector
Extension
Harness
In-Line Filter / Valve
Assembly
(mandatory option)
Dual tank distribution box
Harness
Dual Tank
Instruction
Plate
Control Head Harness
(fitted to pump)
Low foam level sensor

14
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the
right to amend specifications without notice or obligation.
1 2 3 4 5 6 7 8
Control panel FoamLogix 3.3, 5.0, 6.5 - typical
NB: Options and gauge types may vary.
1 - Engine speed control - Up = increase, Down = decrease, Left or right = pre-set speeds.
2 - Vehicle status lamps: Engine - high coolant temperature. Engine - low oil pressure Vehicle -
low battery charge. Vehicle - low fuel
3 - Pump low pressure gauge
4 - Compound gauge
5 - Emergency STOP
6 - Pump high pressure gauge
7 - Pump Tachometer (rev / min) & Hour counter
8 - Foam tank level gauge, Tank A
9 - Foam tank level gauge, Tank B –if fitted
10 - Foam On indicator
11* - Air Enabled indicator
12 * - Solution or CAFS selector switch
13 * - Top –Compressor temperature warning light
Bottom –Air inject on
14 - FoamLogix control unit
15 - SmartCAFS control unit
16 - Compressor pressure
17 - High pressure discharge valve LH –open/close, PC2_ model only –if fitted
18 - High pressure discharge valve RH –open/close, PC2_ model only –if fitted
19 - Low / High pressure hose reel selection –pneumatic control option, PC2_ model only.
20 - Spare switch / light locations for other options
21 - Water tank level gauge
22 - High pressure stage strainer –PC2_ model only.
* 11,12,13 –on later models these switches fitted on top row.
Compressor
pressure
Enlarged view of 15
3 4 5 6 10 14 15 17 18 19 20
22
7
2
1
8
9
11 12 13
16
21
11 12 13

15
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the
right to amend specifications without notice or obligation.
SYSTEM OVERVIEW
The PC1_ or PC2_ is a Compressed Air Foam System comprising of three major
components (in addition to the main water pump) –Air compressor (with separate heat
exchanger and oil/water separator), FoamLogix (foam proportioning unit) and manifold (foam
mixing and control system).
The FoamLogix (foam pump and motor assembly), manifold and compressor heat exchanger
and oil/water separator components are mounted separately from the water pump and are
designed to be remotely mounted according to the vehicle builders requirements.
A metered amount of foam concentrate is introduced into the Manifold and mixed with water
from the pump discharge manifold to produce a solution. The foam and water blend is then
fed to a control valve (ARC) where wet or dry foam may be selected (air ratio control section
of manifold). Compressed air is then injected and the resulting foam / water / air combination
is completely mixed by the X-mixers during discharge.
Safety interlocks are provided to ensure that:
1. Foam concentrate cannot be introduced unless water is flowing through the unit.
Compressed air cannot be introduced unless foam concentrate is flowing.
2. ‘Slugging’(unmixed air and water) in the discharge line is prevented. Air cannot be
injected in the absence of foam and water.
3. Air injection when the foam tank is empty is prevented. Foam tank low level switches
are provided and MUST be fitted.
Compressor
The rotary twin-screw compressor is rated at 200 SCFM @ 10 bar and is driven by a
synchronous belt. The compressor is engaged, or disengaged from the pump drive, via an
electro-magnetic clutch.
Oil Cooler
Compressor lubricating oil is cooled by water taken from the main pump, via the water supply
line; cooling water being supplied from pump delivery and returned to pump suction. The
compressor will reject up to 32.0 kW of heat energy to cooling. The installer must consider
this additional thermal load.
When the compressor is stationary, residual system pressure is vented by a blow-down
valve.
NOTE: The compressor should not be run without cooling water.
Separator Tank
The separator tank holds the oil required for lubricating the compressor and separates the oil
from the oil/air mix discharged from the compressor. The separator tank also has a minimum
pressure valve that ensures that air pressure is maintained above 3 bars to maintain correct
lubrication.

16
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the
right to amend specifications without notice or obligation.
Manifold
The manifold incorporates an air ratio control valve through which degrees of wet or dry foam
mixture can be selected. Compressed air is then injected and the resulting foam / water / air
combination is thoroughly mixed by the X-mixers during discharge.
A By-pass valve is fitted to help obtain the required dry foam flow rate, this valve is adjusted
and set during the installation stage, it is not required during normal operation.
CAFS units are best suited for use with Fresh Water.
For salt water compatible foams, seek advice from the foam agent manufacturers.
FoamLogix - Foam Proportioning System
The FoamLogix system consists of three main components:
1) Foam Pump / Motor Assembly.
2) Control Panel (integral with main pump control panel).
3) Flow measurement and injection manifold.
All three elements combine to provide accurate foam proportioning. From the control panel
the operator can initiate the system, adjust the foam ratio, monitor ‘real time’water flow rate
and record total water and foam concentrate usage.
The FoamLogix system is powered up when the PTO is engaged. Foam concentrate is only
injected when the RED ON control button is operated.
The Foam ON light (10) will illuminate when the FoamLogix is turned on, and flash when
injecting foam.
The FoamLogix 3.3, 5.0, 6.5 system for Class A or B foams, will inject foam in the range of
0.1% to 6.0%.
Further information is available in the FoamLogix Model 3.3/5.0/6.5 Description, Installation
and Operation manual, part number 029-0021-68-0.

17
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the
right to amend specifications without notice or obligation.
INSTALLATION AND INITIAL SET-UP
The following connection points should be considered when installing the PC1_ or PC2_
assembly into a vehicle.
Lifting Points
Secure handling of the unit for installation and maintenance is vital. Use only the lifting points
provided on the unit.
Fork Lift points

18
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the
right to amend specifications without notice or obligation.
FoamLogix 3.3, 5.0, 6.5 System –Remote Mounted
(Model 3.3 shown)
Inlet from foam tank,
Models 3.3, 5.0 –19mm (3/4inch) NPT
Model 6.5 –25.4mm (1inch) NPT
Note: foam tank must be located above
FoamLogix unit
Also refer to installation notes in
FoamLogix manual.
To foam injection point on
manifold. 13mm (1/2inch) NPT
Tubing suitable for 22.5 bar
pressure
By-pass valve and
connection point
(on reverse of valve)

19
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the
right to amend specifications without notice or obligation.
Fluid Drain Points
Pump bearing housing, and gearbox oil drain points are located at the lower left side of the
pump (viewed from the suction tube end).
Gearbox coolant and the pump drain points are located at the lower right hand side of the
pump.

20
©Godiva Ltd. Our policy is one of continuous development. We therefore reserve the
right to amend specifications without notice or obligation.
Oil Filling Points
The unit is supplied without oil and must be filled with the correct quantity and specification
before starting the pump.
Bearing Housing
The oil filling point for the pump bearing housing is located on the right side of the pump
(viewed from suction tube).
Pump bearing housing
- oil fill point
Pump bearing housing -
oil level dipstick.
The dipstick is accessed
from the left side of the
pump.
The correct level is
when the oil is between
the upper and lower
marks.
