Sanus New VisionMount VLL10-B1 User manual

NEW VisioNmouNt®
supEr slim loW-profilE mouNts
Specially designed to highlight the sleek look of ultra-thin flat-panel TVs
New VML10 and VLL10 Super Slim mounts are designed to emphasize
the sleek look of ultra-thin LCD, plasma and LED TVs by placing them
just .67" from the wall. But unlike other low-profile mounts, Sanus’ new
Super Slim mounts feature exclusive ClickStand™technology, which holds
the bottom of the TV away from the wall for easy access to cables —
without removing the TV from the mount. The VML10 and VLL10 also offer
lateral shift adjustment, allowing you to slide the TV left and right on the
wall plate so it’s positioned exactly where you want it, even
with off-center wall studs.
www.sanus.com • 800.359.5520
Self-level system provides
hands-free leveling of
mount on wall
ClickStand™holds TV
away from wall for easy
cable access
VLL10 mounting holes are
spaced for 16" or 24" studs
Pull down on quick-release
tabs to access ClickStand™
VLL10-B1 shown
TV is positioned just .67"
from wall for a sleek,
flush appearance
Lateral shift ensures perfect
TV placement, even with
off-center studs
MODEL VLL10-B1
MODEL VML10-B1
MODEL VLL10-B1

MODEL VLL10 Low-Profile Mount for 32" – 60" TVs
MODEL VML10 Low-Profile Mount for 26" – 42" TVs
PRODUCT DIMENSIONS (w x d x h)
30.5" x .67" x 17.5"
77.5 x 1.7 x 44.45 cm
PACKAGE DIMENSIONS (w x d x h)
32" x 6.22" x 2"
81.3 x 15.8 x 5 cm
PACKAGE WEIGHT
7.44 lbs / 3.4 kg
TV SIZE/WEIGHT CAPACITY
32" – 60" / 125 lbs
94 – 152 cm / 56.7 kg
PROFILE
.67" / 1.7 cm
FINISH
Black – VLL10
•TV is positioned less just .67" from wall for a sleek, flush appearance
•Self-level system provides hands-free leveling of mount on wall
•Lateral shift ensures perfect TV placement, even with off-center studs
•ClickStand™holds TV away from wall for easy cable access
•Pull down on quick-release tabs to access ClickStand™
•Mounting holes are spaced for 16" or 24" studs
PRODUCT DIMENSIONS (w x d x h)
18.72" x .67" x 17.5"
45.5 x 1.7 x 44.45 cm
PACKAGE DIMENSIONS (w x d x h)
20" x 5.9" x 1.9"
50.8 x 15 x 4.8 cm
PACKAGE WEIGHT
5.73 lbs / 2.6 kg
TV SIZE/WEIGHT CAPACITY
26" – 42" / 80 lbs
66 – 107 cm / 36.3 kg
PROFILE
.67" / 1.7 cm
FINISH
Black – VML10
•TV is positioned just .67" from wall for a sleek, flush appearance
•Self-level system provides hands-free leveling of mount on wall
•Lateral shift ensures perfect TV placement, even with off-center studs
•ClickStand™holds TV away from wall for easy cable access
•Pull down on quick-release tabs to access ClickStand™
MASTER PACK QUANTITY
4
MASTER PACK DIMENSIONS
(w x d x h)
32.6" x 6.9" x 8.82"
82.8 x 17.5 x 22.4 cm
MASTER PACK WEIGHT
30.58 lbs / 13.9 kg
LIST PRICE
$109.99
AVAILABLE
May 2010
UPC
793795521316
MASTER PACK QUANTITY
4
MASTER PACK DIMENSIONS
(w x d x h)
20.8" x 6.9" x 8.82"
52.8 x 17.5 x 22.5 cm
MASTER PACK WEIGHT
23.8 lbs / 10.8 kg
LIST PRICE
$89.99
AVAILABLE
May 2010
UPC
793795521323
