IDTECH ValueScan III User manual

ValueScan III
IDBB-4244MRB
Barcode Scanner
User Manual
Version: 1.4
Date: 25 August 2019

2
Revision History
Version
Date
Description
Page #
1.0
2019/10/18
Initial release
1.2
2019/11/20
Updated scanner specifications
56
1.3
2019/12/17
Added Presentation Mode
2
1.4 2020/08/25
Modified the description of Disable
code39 transmit and Enable code39
transmit.
Updated manual style.
40-41

3
Regulatory Compliance
FEDERAL COMMUNICATIONS COMMISSION
INTERFERENCE STATEMENT
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and
receiver.
•Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/ TV
technician for help.

4
CAUTION:
Any changes or modifications not expressly approved by
the grantee of this device could void the user's authority
to operate the equipment.
Note: All brands and trademarks are the property of their
respective owners.
Note: The specifications contained herein are subject to
change without notice.
警告使用者:
這是甲類的資訊產品，在居住的環境中使用時，可
能會造成射頻干擾，在這種情況下，使用者會被要
求採取某些適當的對策。

5
Contents
1. INTRODUCTION ............................................................................ 6
2. UNPACKING .................................................................................. 8
3. GET STARTED ............................................................................... 9
3.1. INSTALLATION......................................................................................9
3.1.1. Set Up Your Scanner ...............................................................................9
3.2. HOW TO SCAN ..................................................................................10
4. CONTROLS AND SETTINGS.......................................................11
4.1. VERSION INFORMATION SETTING CODE .........................................11
4.2. INTERFACE MODE SETTING CODES................................................12
4.3. SCAN MODE SETTING CODES.........................................................13
4.4. SOUND SETTING CODES..................................................................14
4.5. CHARACTER DELETE,INSERT,AND REPLACEMENT SETTINGS....15
4.6. SERIAL PORT SETTINGS ..................................................................18
4.7. NORMAL FUNCTION SETTING CODES ............................................20
4.8. PREFIX /SUFFIX SETTING ................................................................22
4.9. MULTI-LANGUAGE SETTING CODES ..............................................24
4.10. CHARACTER TABLE........................................................................27
4.11. ENABLE AND DISABLE BARCODES...............................................40
5. PREFIX / SUFFIX CODE SETTING INSTRUCTIONS .................53
5.1. COMMON PRE/SUFFIX CODE .........................................................53
5.2. ADDING AN EXCLUSIVE SUFFIX CODE..............................................54
5.3. SLEEP TIME SETTING /BUTTON TIMEOUT SETTING ......................55
5.4. HIDING CHARACTERS.......................................................................56
6. BARCODE TYPES CODE TABLE.................................................57
7. ASCII TABLE 1 .............................................................................58
7.1. TIP 1..................................................................................................59
7.2. TIP 2..................................................................................................59
8. ASCII TABLE 2 .............................................................................60
9. SPECIFICATIONS ........................................................................65

6
1. Introduction
Your VALUESCAN III is a 1D CCD scanner that has been
configured at the factory with default settings.
Because many host systems have unique formats and
protocol requirements, ID TECH provides a wide range of
configurable features that may be selected using this
bar-code-based configuration tool. After the
configuration is completed, the scanner stores the
settings in nonvolatile memory. The embedded memory
saves the settings when the power is turned off.
Turn off the computer’s power before connecting the
scanner, and then power up the computer after the
scanner is fully connected.
To change a parameter value, scan the appropriate bar
codes in this guide. These new values replace the default
values in memory.
NOTE: Most computer monitors allow uses to scan bar
codes directly from the screen. When scanning from a
screen, be sure to set the document magnification to a
level where you can see the bar code clearly and bars
and/or spaces are not merging.

7
Application Field:
•Jewelry Tag
•Manufacturing
•Transportation & Logistics
•Healthcare
Features:
•Makes daily work simple and easy
•2500-pixel CCD image sensor
•Scan Speed ≧270 times/sec
•Maximum reading resolution: 3mil (0.762mm)
•Depth of Field: 15~330mm
(EAN, 13mil/0.33mm, PCS 90%)
•Drop resistance: 1.5 meters onto concrete
•Auto-sensing (presentation) mode available
Presentation Mode
※
Just scan the Presentation
Mode barcode on the stand to
easily switch to presentation
mode for the VALUESCAN III
scanner.

8
2. Unpacking
Make sure the following items were included in your
package:
•Scanner x1
•Stand x1
•Quick Start Guide x1
•USB Cable x1
When you receive your scanner, open the package
immediately and inspect for shipping damage. If you
discover any damage, contact the shipping company and
file a claim. ID TECH is not responsible for any damage
incurred during shipping. Save all packing materials for
the shipping company to inspect.
Note: If any item is missing, contact your local dealer.

9
3. Get started
This chapter provides information about installing,
connecting, and using your scanner.
3.1. Installation
Install your scanner with the steps below.
3.1.1. Set Up Your Scanner
1. Plug the RJ45 connector into the scanner’s RJ45 port,
until it clicks.
2. Insert the USB connector to your computer.
3. Turn on your computer. It will autodetect your
scanner.
4. To test your scanner, start a text editing program like
Notepad or Microsoft Word. Scan a bar code to see if
the scanner can send data to your computer. If it’s
successful, you’ll hear a beep and see the bar code
data in the text editing program.

10
3.2. How to scan
VALUESCAN III emits a light bar when it is scanning. To
scan a barcode, make sure the aiming beam crosses every
bar and space of the barcode. This bar needs to cross the
bar code horizontally to decode it.

11
4. Controls and settings
Customize your scanner to work efficiently.
VALUESCAN III offers many features to match your
preferences. The following section provides
information about changing your scanner’s
controls and settings.
4.1. Version information setting code
Version (custom)
000A0
Display internal string (custom)
000A1
Display serial number (custom)
000A2
Factory default
000B0
Enable the code setting function
09990
Disable the code setting
function
09991

12
4.2. Interface Mode Setting Codes
VALUESCAN III supports USB HID and virtual COM. By
default, your scanner can detect the interface
automatically. When it detects USB, it selects HID as the
interface.
USB-HID (Default)
000602
USB Virtual Com
000603
Note: If you use the scanner to communicate with your
computer via a serial interface (e.g., COM1 ... COM8), but
your computer does not have a serial port, the scanner
requires a virtual COM port driver. Use this driver to
assign a virtual COM port connection number to devices
connected via a USB port and to enable bidirectional
communication between your computer and the
VAUESCAN III.
To get the USB virtual COM port driver, go to the ID TECH
global website (https://idtechproducts.com/).
Download and install the driver. After installing the
driver, restart your computer. The system will then
automatically detect your scanner.

13
4.3. Scan Mode Setting Codes
Trigger mode (default)
013340
Continuous scan mode
013344
Presentation mode
013380
Key delay
013342
Single not triggered
013341
Key delay not triggered
013343
Auto flashing
013345

14
4.4. Sound Setting Codes
Sound on (default)
014201
Sound off
014200
Buzzer frequency 2048
0145800
High volume sound
014300
Low volume sound
014301
Buzzer frequency 2731
0145AAA

15
4.5. Character Delete, Insert, and
Replacement Settings
Code ID off (default)
01400
Code ID on
01401
Rear code ID on
01402
Display code front character
(default)
0201x
Hide code front blank
0200[SPACE]
Display code rear character
(default)
0203
Hide code rear character n
(“n” indicates a blank key.)
0202[SP]
Display characters inside code
(default)
0205-
Hide – inside code
0204-
Disable A replace 0 in code
(default)
020600

16
Enable A replace 0 in code
02060A
Display rear characters (default)
023300
Hide rear 5 characters
023305
Hide rear 1 characters
023301
Display front characters
(default)
023400
Hide front 5 characters
023405
Display middle characters
(default)
023900
Hide 5 middle characters
023905
Forward start from 4th
character
024004
FUNC1 replace with 1
0160049
FUNC2 replace with 2
0161050

17
FUNC3 replace with 3
0162051
FUNC4 replace with 4
0163054
Disable enter replace (default)
0182013
Enter replace with 5
0182055

18
4.6. Serial Port Settings
Baud rate 600bps
000701
Baud rate 1200bps
000702
Baud rate 2400bps
000703
Baud rate 4800bps
000704
Baud rate 9600bps (default)
000705
Baud rate 19200bps
000706
Baud rate 38400bps
000707
Baud rate 57600bps
000708
Baud rate 115200bps
000709
Serial Port: No Check
001200
Serial port: XON/OFF
001201

19
Serial port: RTS/CTS
001202
Serial port handshake timeout
2s
0013020
Serial port handshake timeout
5s
0013050
Serial port 8-bit data
00080
Serial port 7-bit data
00081
Serial port 1 stop bit
00090
Serial port 2 stop bits
00091
Serial port No parity check
001000
Serial port odd parity check
001001
Serial port even parity check
001002

20
4.7. Normal Function Setting Codes
Enable upload setting barcodes
02501
Disable upload setting barcodes
(default)
02500
FUNC cast light upon cancel
(default)
01640
Disable change
02510
All uppercase
02511
All lowercase
02512
Uppercase interchange
with lowercase
02513
Enable command beep
01411
Disable command beep
01410
Forward image identify (default)
00161
Reverse image identify
