USER MANUAL

SecureHead™

Encrypted Magnetic Read Head

SPI Interface with FPC

80101515-001-C

28 December 2020

User Manual, SecureHead SPI Interface

Page 2 of 67

Agency Approved

Specifications for subpart B of part 15 of FCC rule for a Class A computing device.

Limited Warranty

ID TECH warrants to the original purchaser for a period of 12 months from the date of invoice that this

product is in good working order and free from defects in material and workmanship under normal use

and service. ID TECH’s obligation under this warranty is limited to, at its option, replacing, repairing,

or giving credit for any product which has, within the warranty period, been returned to the factory of

origin, transportation charges and insurance prepaid, and which is, after examination, disclosed to ID

TECH’s satisfaction to be thus defective. The expense of removal and reinstallation of any item or

items of equipment is not included in this warranty. No person, firm, or corporation is authorized to

assume for ID TECH any other liabilities in connection with the sales of any product. In no event shall

ID TECH be liable for any special, incidental or consequential damages to Purchaser or any third party

caused by any defective item of equipment, whether that defect is warranted against or not. Purchaser’s

sole and exclusive remedy for defective equipment, which does not conform to the requirements of

sales, is to have such equipment replaced or repaired by ID TECH. For limited warranty service during

the warranty period, please contact ID TECH to obtain a Return Material Authorization (RMA)

number & instructions for returning the product.

THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES OF MERCHANTABILITY OR

FITNESS FOR PARTICULAR PURPOSE. THERE ARE NO OTHER WARRANTIES OR

GUARANTEES, EXPRESS OR IMPLIED, OTHER THAN THOSE HEREIN STATED. THIS

PRODUCTIS SOLD AS IS. IN NO EVENT SHALL ID TECH BE LIABLE FOR CLAIMS BASED

UPON BREACH OF EXPRESS OR IMPLIED WARRANTY OF NEGLIGENCE OF ANY OTHER

DAMAGES WHETHER DIRECT, IMMEDIATE, FORESEEABLE, CONSEQUENTIAL OR

SPECIAL OR FOR ANY EXPENSE INCURRED BY REASON OF THE USE OR MISUSE, SALE

OR FABRICATIONS OF PRODUCTS WHICH DO NOT CONFORM TO THE TERMS AND

CONDITIONS OF THE CONTRACT.

provided to the user as a convenience. While every effort has been made to ensure accuracy, ID TECH

is not responsible for damages that might occur because of errors or omissions, including any loss of

profit or other commercial damage. The specifications described herein were current at the time of

publication, but are subject to change at any time without prior notice.

ID TECH is a registered trademark of International Technologies & Systems Corporation. SecureHead

and Value through Innovation are trademarks of International Technologies & Systems Corporation.

User Manual, SecureHead SPI Interface

Page 3 of 67

Revision History

Revision

Date

Description of Changes

10/01/2013

Initial Release

Candy H

11/19/2020

Updated Appendix I

12/28/2020

Removed commands related to Fixed Keys.

User Manual, SecureHead SPI Interface

Page 4 of 67

Table of Contents

1. INTRODUCTION ..............................................................................................................................................................................................5

2. SPECIFICATIONS ............................................................................................................................................................................................ 6

3. SPI OPER ATION...............................................................................................................................................................................................9

3.1. SPI Da ta Tra nsm ission ........................................................................................................................................................................... 9

3.2. Clock Polarity and Pha se....................................................................................................................................................................... 9

3.3. Master Input, Slave Output (MISO)...................................................................................................................................................10

3.4. Master Output, Slave Input (MOSI)...................................................................................................................................................10

3.5. Data Available Output (DAV) ............................................................................................................................................................11

3.6. Chip Select..............................................................................................................................................................................................12

3.7. Voltage Input and Ground...................................................................................................................................................................13

3.8. Communication......................................................................................................................................................................................13

4. CONFIGURATION .........................................................................................................................................................................................14

4.1. Communication Tim in g .......................................................................................................................................................................15

4.2. Default Settings .....................................................................................................................................................................................15

4.3. General Se lect ions .................................................................................................................................................................................16

4.4. Review Settings .....................................................................................................................................................................................17

4.5. Review Firmware Ve rsion ...................................................................................................................................................................17

4.6. Review Serial Number.........................................................................................................................................................................17

4.7. Message Formatting Selections (Only for Security Level 1 & 2).................................................................................................18

4.8. Magnetic Track Selections (Only for Security Level 1 & 2).........................................................................................................19

4.9. Review KSN ( DUKPT Key m a na gement only)...............................................................................................................................20

4.10. Review Security Level .......................................................................................................................................................................21

4.11. Encrypt External Data Comma nd.....................................................................................................................................................21

4.12. Encrypted Output for Decoded Data................................................................................................................................................21

4.12.1. Encrypt Functions...............................................................................................................................................................21

4.13. Level 4 Activate Authentication Sequence.....................................................................................................................................32

4.14. Other Command Protocol Settings...................................................................................................................................................36

5. APPE NDIX A. DEFAULT SETTING T ABLE ..........................................................................................................................................38

5.1. Default Setting Table............................................................................................................................................................................38

6. APPE NDIX B: MAGNE TIC STRIPE STANDAR D FORM ATS ..........................................................................................................39

6.1. ISO Credit Card Format.......................................................................................................................................................................39

6.2. AAMVA Driver’s License Format.....................................................................................................................................................40

7. APPENDIX C: OTHER M ODE CARD DATA OUTPUT.......................................................................................................................42

8. APPENDIX D: GUIDE TO E NCRYPTING AND DECR YPTING DATA .........................................................................................43

9. APPENDIX E: KEY MANAGEME NT FLOW CH ART .........................................................................................................................44

10. APPENDIX F: EXAMPLE OF DEC ODED DAT A DECRYPTION...................................................................................................46

11. APPENDIX G: E XAM PLE OF IDTECH RAW DATA DECRYPTION ...........................................................................................53

12. APPENDIX H: E XAM PLE OF SPI MASTER CHIP CONTROLI NG ...............................................................................................55

13. APPENDIX I: MAGNETIC HEADS MECH ANICAL DE SIGN GUIDELI NES .............................................................................61

Track Locations...........................................................................................................................................................................................61

Reference Surface/Wear-Plate ................................................................................................................................................................62

Card Reader Rails/Slot and Magnetic Head Protrusion..................................................................................................................63

User Manual, SecureHead SPI Interface

Page 5 of 67

1. INTRODUCTION

The SPI SecureHead™ magnetic stripe reader can read 1, 2, or 3 tracks of magnetic stripe information.

When connected to the host, the SecureHead is completely compatible with SPI Specification. The raw

data or decoded data send to host through the SPI.

The SecureHead supports both unencrypted and encrypted data output. When the encryption is not

turned on, the decoded data can be formatted with preamble/postamble and terminator characters to

match the format expected by the host.

This document is to describe the electrical, firmware and mechanical information of SecureHead SPI

interface with Flexible Printed Circuit (FPC).

User Manual, SecureHead SPI Interface

Page 6 of 67

2. SPECIFICATIONS

General

1. 1.

Card Speed 5 to 60 inches per second

Electrical

•Operating voltage: 3V or 5V

•Maximum support current: 7mA

ESD

•Units will withstand electrostatic discharge of 4KV anywhere on the unit without damage, 8KV

through air. 8KV ESD to head case with case properly grounded without damage.

Environment

•Operating Temperature: -4°F to 158°F ( -20°C to 70°C)

•Storage Temperature: -40°F to 158°F ( -40°C to 70°C)

•Humidity: Maximum 95% non-condensing

Durability

•Head Wear: 1,000,000 transactions in benign conditions, use by the general public

•MTBF: Calculated for electronics is 300,000 POH minimum

User Manual, SecureHead SPI Interface

Page 7 of 67

Dimension:

PINOUT:

SPI Interface

PIN #

SIGNAL

DAV

NCS

MISO

MOSI

SPCK

GND

Head Case GND

User Manual, SecureHead SPI Interface

Page 8 of 67

Mounting Options:

Wing spring mounting is the standard mounting option and can be used on most swipe readers. The

protrusion of the head for the surface of the spring is 3.50 mm.

SecureHead SPI Interface with FPC User Manual

Page 9 of 67

3. SPI OPERATION

This section describes the SPI (Serial Peripheral Interface), the SPI bus interface timing,

communication protocol, timeouts, and data output format.

3.1. SPI Data Transmission

A serial peripheral interface (SPI) is an interface that enables the serial exchange of data between two

devices, one called a master and the other called a slave. The host (master) generates the clock signal

(SPCK) to trigger data exchange on the SPI bus.

During each SPI clock cycle, the data is transmitted in both directions at the same time (full duplex

transmission)

on the MOSI line, the master sends a bit and the slave reads it

on the MISO line, the slave sends a bit and the master reads it

The SPI bus transmits data in an 8-bit data groups, sending data one bit at a time from MSB to LSB.

An example of bit transmission for byte A and byte B would be

A(bit 7) A(bit 6) … A(bit 0) B(bit 7) B(bit 6) … B(bit 0)

3.2. Clock Polarity and Phase

The clock polarity and phase can be configured with respect to the data. The serial clock input

frequency can go up to 400k bps.

1.2 .

When clock polarity =0 the base value of the clock is 0

1.2.1.

For clock phase=0, data are read on the clock's rising edge (low->high transition) and data

are changed on a falling edge (high->low transition).

1.2.2.

For clock phase=1, data are read on the clock's falling edge and data are changed on a

rising edge.

1.3 .

When clock polarity=1 the base value of the clock is 1

1.3.1.

For clock phase=0, data are read on clock's falling edge and data are changed on a rising

edge.

1.3.2.

For clock phase=1, data are read on clock's rising edge and data are changed on a falling

edge.

The signal is required to read card data from the device. See SPI clock phase and polarity property in

section 3 for commands to configure clock phase and polarity.The device defaults to clock phase = 0

and clock polarity = 0

The following picture shows an example of clock polarity=0 and clock phase=0. The data is read on

the rising edge of the clock and is changed on the falling edge. On MOSI line, the host sends out data

00000010, which is 02h.

SecureHead SPI Interface with FPC User Manual

Page 10 of 67

3.3. Master Input, Slave Output (MISO)

The MISO signal is the serial data output sent from for the device, it’s also the data line that is received

by the host. When the device is not active (Chip Select is high), the MISO becomes high impedance

(disconnected). The MISO signal would be in an indeterminate state after the device is power cycled or

reset for a maximum of 1 second. This signal should be ignored during this time.

3.4. Master Output, Slave Input (MOSI)

The MOSI signal is the serial data input for the device and serial data output for the host. This signal is

sent from the host (master) to the device (slave). The signal might not be required once some device

parameters such as the device key has been set and saved. Set the signal to be high if it is not being

used.

SecureHead SPI Interface with FPC User Manual

Page 11 of 67

3.5. Data AvailableOutput (DAV)

The DAV signal is low where there is no data to be transmitted. When the DAV signal is high, it

indicates that there is data available for output. The host and then sends out the clock signal to read the

data. After all the data is transmitted, the device would set the DAV signal low again.

The signal can be used for the host to determine if the device has data ready to transmit. However, the

signal should be ignored right after (1 second maximum) the power cycle or reset as it would be in an

indeterminate state.

In the case when the DAV signal is not used, the host would need to poll the device periodically to

determine if it has data to transmit. The host needs to toggle SCL to get card data from MISO. The first

non-IDLE byte indicates the start of valid card data. IDLE is FF. For more details, please refer to the

communication protocol section of this document.

The last signal shown in the below graph is the DAV signal:

After the command is received and the response is ready, the DAV would be set to high for the host to

receive response. After the response is received, the DAV would be low, indicating there is no more

data to be transmitted.

SecureHead SPI Interface with FPC User Manual

Page 12 of 67

About 20ms after receiving command, response is ready and DAV set to high. For some specific

commands, the delay will be longer.

About 20us after the last byte of response is read out by host, DAV is pulled low. So if user polls DAV

status to check whether there are data available, we suggest using 100us polling interval.

3.6. Chip Select

SPI interface allows connecting several SPI devices while master selects each of them with NCS (Chip

Select, Active Low). The device would only respond to SPCK and MOSI signals after a NCS is pulled

low. NCS needs to be low the whole time when the host is communicating with the particular device.

The Chip Select signal should be connected to ground if is not used by the host. Special case: in the

situation of clock phase = 1, NCS needs to generate a falling edge for each command.

SecureHead SPI Interface with FPC User Manual

Page 13 of 67

The NCS is pulled low when the host is communicating with the device.

3.7. Voltage Input and Ground

The VIN signal is the power input for the device and has an operating range of 3.0 to 3.6 volts DC.

The GND signal is logic ground. The head case GND signal is chassis ground which is connected to

the head case. For optimum ESD protection, this signal should be connected to earth ground.

3.8. Communication

When the host has a frame to send, it simply clocks it out. When the device has a frame to send, it

raises its data available (DAV) signal and waits for the host to clock in the frame. The host normally

clocks out IDLE characters to clock in a frame from the device. Since the device typically loads its one

transmit buffer with IDLE byte when it has nothing to transmit, the first 1 byte clocked out from the

device after the DAV signal is asserted could be IDLE bytes instead of a valid byte. If this is the case,

simply discard this byte. To detect whether the device has a frame to send, the host can either monitor

the DAV signal or, optionally, periodically clock in up to two bytes from the device to see if the device

has sent a valid data. Up to two bytes should be clocked in instead of just one because the first byte

could be IDLE byte that was loaded into the device’s transmit buffers before the device had anything

to send. The host should look at each byte it clocks in to see if it is a valid byte. If a valid byte is found,

then the subsequent bytes will contain the frame.

SecureHead SPI Interface with FPC User Manual

Page 14 of 67

4. CONFIGURATION

The SecureHead reader must be appropriately configured to your application. Configuration settings

enable the reader to work with the host system. Once programmed, these configuration settings are

stored in the reader’s non-volatile memory (so they are not affected by the cycling of power).

4.1.

Setup Commands Structure

Commands sent to SecureHead

a. Setting Command:

b. Read Status Command:

c. Special Function Command:

Response from SecureHead

a. Setting Command

Host

SecureHead

Setting Command





<ACK> if OK



<NAK> if Error

b. Read Status Command

Host

SecureHead

Read Status Command





<ACK> and <Response> if



<NAK> if Error

c. Special Function Command

Host

SecureHead

Special Function Command





<ACK> and <Response> if



<NAK> if Error

SecureHead SPI Interface with FPC User Manual

Page 15 of 67

Where:

<STX>

02h

<S>

Indicates setting commands. 53h

<R>

Indicates read status commands. 52h

One byte Function ID identifies the

particular function or settings affected.

<Len>

One byte length count for the following data

block<FuncData>

data block for the function

<ETX>

03h

Check Sum: The overall Modulo 2

(Exclusive OR) sum (from <STX> to

<CheckSum>) should be zero.

<ACK>

06h

<NAK>

15h

4.1. Communication Timing

The SecureHead has a 50ms start up period, during this period, it doesn’t support communication and

card reading. If the terminal tries to talk to SecureHead during this period, SecureHead may not be

functional until restart.

SecureHead also takes time to process a command. During that processing time, it will not respond to a

new command.

Card swipe actions can interrupt command process, instead of sending command responses,

SecureHead will only send card data.

The typical delay for the reader to respond to a command is 20ms, the maximum delay for the reader to

respond can be as much as 40ms. Caution must therefore be taken to maintain a minimum delay

between two commands.

A minimum delay of 50μs is required between each character send to SecureHead through SPI

interface.

If the noise of working environment interferences the SPI communication, to the level that SecureHead

can’t receive commands correctly, SecureHead will restart to reduce the impact. Restart takes 600ms.

Terminal won’t get any command response in this situation.

4.2. Default Settings

The SecureHead reader is shipped from the factory with the default settings already programmed. In

the following sections, the default settings are shown in boldface.

For a table of default settings, see Appendix A.

SecureHead SPI Interface with FPC User Manual

Page 16 of 67

4.3. General Selections

This group of configuration settings defines the basic operating parameters of SecureHead.

4.1.1.

SPI Clock Phase and Polarity Settings

The clock phase and polarity of SPI interface can be adjusted. Both the host and device must be set to

the same SPI setting in order to communicate correctly.

SPI Settings:

‘0’ Clock phase = 0 and Polarity = 0. data are read on the clock's rising edge and data are

changed on a falling edge

‘1’ Clock phase = 0 and Polarity = 1. data are read on clock's falling edge and data are changed

on a rising edge.

‘2’ Clock phase = 1 and Polarity = 0. data are read on clock's falling edge and data are changed

on a rising edge.

‘3’ Clock phase = 1 and Polarity =1. data are read on clock's rising edge and data are changed

on a falling edge.

4.1.2.

Change to Default Settings

This command does not have any <FuncData>. It returns all settings for all groups to their default

values.

4.1.3.

MSR Reading Settings

Enable or Disable the SecureHead. If the reader is disabled, no data will be sent out to the host.

MSR Reading Settings:

“0” MSR Reading Disabled

“1” MSR Reading Enabled

4.1.4.

Decoding Method Settings

The SecureHead can support four kinds of decoded directions.

Decoding Method Settings:

“0” Raw Data Decoding in Both Directions, send out in ID TECH mode

“1” Decoding in Both Directions. If the encryption feature is enabled, the key management

method used is DUKPT.

“2” Moving stripe along head in direction of encoding. If the encryption feature is enabled, the key

management method used is DUKPT.

“3” Moving stripe along head against direction of encoding. If the encryption feature is enabled, the

key management method used is DUKPT.

SecureHead SPI Interface with FPC User Manual

Page 17 of 67

“4” Raw Data Decoding in Both Directions, send out in other mode. If the encryption feature is

enabled, the key management method used is fixed key.

With the bi-directional method, the user can swipe the card in either direction and still read the data

encoded on the magnetic stripe. Otherwise, the card can only be swiped in one specified direction to

read the card. Raw Decoding just sends the card’s magnetic data in groups of 4 bits per character. The

head reads from the first byte of each track, starting from the most significant bit. The data starts to being

collected when the first 1 bit is detected. No checking is done except to verify track has or does not have

magnetic data.

4.4. Review Settings

This command does not have any <FuncData>. It activates the review settings command. SecureHead

sends back an <ACK> and <Response>.

<Response> format:

The current setting data block is a collection of many function-setting blocks <FuncSETBLOCK> as

follows:

Each function-setting block <FuncSETBLOCK> has the following format:

Where:

<FuncID> is one byte identifying the setting(s) for the function.

<Len> is a one byte length count for the following function-setting block <FuncData>

<FuncData> is the current setting for this function. It has the same format as in the sending command

for this function.

<FuncSETBLOCK> are in the order of their Function ID<FuncID>

4.5. Review Firmware Version

This command is to get device firmware version.

4.6. Review Serial Number

This command is to get device serial number.

SecureHead SPI Interface with FPC User Manual

Page 18 of 67

4.7. Message Formatting Selections (Only for Security Level 1 & 2)

4.1.5.

Terminator Setting

Terminator characters are used to end a string of data in some applications.

<Terminator Settings>: Any one character, 00h is none; default is CR (0Dh).

4.1.6.

Preamble Setting

Characters can be added to the beginning of a string of data. These can be special characters for

identifying a specific reading station, to format a message header expected by the receiving host, or

any other character string. Up to fifteen ASCII characters can be defined.

Where:

<Len>= the number of bytes of preamble string

<Preamble> = {string length}{string}

NOTE: String length is one byte, maximum fifteen <0Fh>.

4.1.7.

Postamble Setting

The postamble serves the same purpose as the preamble, except it is added to the end of the data string,

after any terminator characters.

Where:

<Len> = the number of bytes of postamble string

<Postamble> = {string length}{string}

NOTE: String length is one byte, maximum fifteen <0Fh>.

4.1.8.

Track n Prefix Setting

Characters can be added to the beginning of a track data. These can be special characters to identify the

specific track to the receiving host, or any other character string. Up to six ASCII characters can be

defined.

Where:

<n> = 34h for track 1; 35h for track 2 and 36h for track 3

SecureHead SPI Interface with FPC User Manual

Page 19 of 67

<Len> = the number of bytes of prefix string

<Prefix> = {string length}{string}

NOTE: String length is one byte, maximum six.

4.1.9.

Track n Suffix Setting

Characters can be added to the end of track data. These can be special characters to identify the

specific track to the receiving host, or any other character string. Up to six ASCII characters can be

defined.

Where:

<n> = 37h for track 1; 38h for track 2 and 39h for track 3

<Len> = the number of bytes of suffix string

<Suffix> = {string length}{string}

NOTE: String length is one byte, maximum six.

4.8. Magnetic Track Selections (Only for Security Level 1 & 2)

4.1.10.

Track Selection

There are up to three tracks of encoded data on a magnetic stripe.

This option selects the tracks that will be read and decoded.

Track_Selection Settings:

“0” Any Track

“1” Require Track 1 Only

“2” Require Track 2 Only

“3” Require Track 1 & Track 2

“4” Require Track 3 Only

“5” Require Track 1 & Track 3

“6” Require Track 2 & Track 3

“7” Require All Three Tracks

“8” Any Track 1 & 2

“9” Any Track 2 & 3

Note: If any of the required multiple tracks fail to read for any reason, no data for any track will be

sent.

SecureHead SPI Interface with FPC User Manual

Page 20 of 67

4.1.11.

Track Separator Selection

This option allows the user to select the character to be used to separate data decoded by a multiple-

track reader.

<Track_Separator> is one ASCII Character. The default value is CR, 0h means no track separator.

4.1.12.

Start/End Sentinel and Track 2 Account Number Only

The SecureHead can be set to either send, or not send, the Start/End sentinel, and to send either the

Track 2 account number only, or all the encoded data on Track 2. (The Track 2 account number setting

doesn’t affect the output of Track 1 and Track 3.)

SendOption:

“0” Don’t send start/end sentinel and send all data on Track 2

“1” Send start/end sentinel and send all data on Track 2

“2” Don’t send start/end sentinel and send account # on Track 2

“3” Send start/end sentinel and send account number on Track 2

4.1.13.

Encryption Settings

Enable or disable the SecureHead Encryption output in ID TECH protocol. If encryption is disabled,

original data will be sent out to the host. If it enabled, encrypted data will be send out to the host.

Encryption Settings:

“0” Encryption Disabled

“1” Enable TDES Encryption

“2” Enable AES Encryption (Not for Raw Data Decoding in Both Directions, send out in other

mode.)

4.9. Review KSN (DUKPT Key management only)

This command is to get DUKPT key serial number and counter.

Other manuals for SecureHead

Table of contents

Other IDTECH Control Unit manuals

IDTECH

IDTECH uSign 300 User manual

Popular Control Unit manuals by other brands

SMC Corporation

SMC Corporation EX260-SIL1-X207 Operation manual

Mitel

Mitel T941AM8 installation guide

Emerson

Emerson KTM RICHARDS FIGURE R382 Installation and operating instructions

Huawei

Huawei MU509 Series Hardware Migration Guide

Doyson

Doyson S 200 FM BT user manual

SCUBAPRO-UWATEC

SCUBAPRO-UWATEC MK17 Maintenance Procedure

TESY

TESY ESP32-SOLO-1 quick start

System Sensor

System Sensor M210E installation instructions

Belden

Belden Lumberg Automation LioN-P 0980 ESL... manual

Mitsubishi Electric

Mitsubishi Electric CC-Link IE-NZ2GNSS2-8D user manual

Avid Technology

Avid Technology SYNC HD Guide

Yoshitake

Yoshitake DP-200 Series manual

Clack

Clack WS2CI/QC manual

GEM

GEM 635 Installation, operating and maintenance instructions

Procentec

Procentec ProfiHub F1 user manual

Eaton

Eaton NRX Digitrip 1150 Instruction leaflet

Honeywell Home

Honeywell Home HR91 FAQ & Setup Guide

Siemens

Siemens Flowrite VF 599 Series Technical instructions

IDTECH SecureHead User manual

Popular Control Unit manuals by other brands
