IEI Technology ITDB-100L User manual

ITDB-100L Barcode Reader
Page i
User Manual
MODEL:
ITDB-100L
2D Barcode Reader
RoHS Compliant
Rev. 1.02 – 22 April, 2014

ITDB-100L Barcode Reader
Page ii
Revision
Date Version Changes
22 April, 2014 1.02 Updated Chapter 5 for the latest setup tool version
13 March, 2014 1.01 Updated for the latest hardware, specifications and
application version
Added Chapter 6: Configuring the ITDB-100L via an
Android Device
25 July, 2013 1.00 Initial release

ITDB-100L Barcode Reader
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

ITDB-100L Barcode Reader
Page iv
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 OVERVIEW.................................................................................................................. 2
1.2 FEATURES................................................................................................................... 2
1.3 EXTERNAL OVERVIEW................................................................................................ 3
1.3.1 Front Panel........................................................................................................ 3
1.3.2 Rear Panel ......................................................................................................... 3
1.3.3 Bottom Surface................................................................................................... 4
1.4 TECHNICAL SPECIFICATIONS ...................................................................................... 5
1.5 DIMENSIONS............................................................................................................... 7
1.5.1 ITDB-100L Dimensions ..................................................................................... 7
1.5.2 Mounting Bracket Dimensions........................................................................... 8
1.6 ITDB-100LFUNCTION COMPATIBILITY GUIDELINE................................................... 9
2 UNPACKING............................................................................................................... 10
2.1ANTI-STATIC PRECAUTIONS.......................................................................................11
2.2 UNPACKING PRECAUTIONS........................................................................................11
2.3 UNPACKING CHECKLIST........................................................................................... 12
3 INSTALLATION ......................................................................................................... 14
3.1 INSTALLATION PRECAUTIONS................................................................................... 15
3.2 MOUNTING THE ITDB-100L.................................................................................... 15
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTORS................................................... 18
3.3.1 6-Pin Connector for Trigger Connection......................................................... 18
3.3.1.1 Digital Output Wiring ............................................................................... 20
3.3.1.2 Digital Input Wiring.................................................................................. 20
3.3.1.3 Digital Input and Output Connection........................................................ 21
3.3.2 Ethernet Connector.......................................................................................... 22
3.3.2.1 Network Connection................................................................................. 23
3.3.3 Micro USB Connector...................................................................................... 24
3.3.3.1 USB Keyboard Wedge.............................................................................. 25
3.3.4 Power Input Connector.................................................................................... 25

ITDB-100L Barcode Reader
Page v
3.4 READING DISTANCE AND FIELD OF VIEW................................................................. 26
4 DRIVER AND PC SETUPTOOLINSTALLATION............................................... 27
4.1 OVERVIEW................................................................................................................ 28
4.2 DRIVER INSTALLATION............................................................................................. 28
4.3 SETUP TOOL INSTALLATION...................................................................................... 32
5 BARCODE READER SETUPTOOL........................................................................ 35
5.1 OVERVIEW................................................................................................................ 36
5.2 LAUNCHING THE SETUP TOOL .................................................................................. 36
5.3 INITIAL SCREEN........................................................................................................ 37
5.4 INITIAL SETTING....................................................................................................... 37
5.5AUTOMATIC SETUP................................................................................................... 39
5.6 VERIFICATION MENU................................................................................................ 41
5.6.1 Region of Interest............................................................................................. 42
5.6.2 Training Mode.................................................................................................. 43
5.6.3 Loading Saved Images..................................................................................... 45
5.7 SETTINGS MENU ...................................................................................................... 47
5.8 NETWORK MENU ..................................................................................................... 50
5.9 SECURITY MENU...................................................................................................... 51
5.10 FWUPGRADE AND BACKUP MODE ........................................................................ 52
5.10.1 FW Upgrade Flow Chart............................................................................... 52
5.10.2 Upgrading the FW ......................................................................................... 53
5.10.3 Backup Mode ................................................................................................. 54
6 CONFIGURINGTHEITDB-100LVIAAN ANDROID DEVICE............................. 55
6.1 OVERVIEW................................................................................................................ 56
6.2 INSTALLING AND LAUNCHING THE ANDROID APP..................................................... 56
6.3 SETTINGS MENU ...................................................................................................... 58
6.4 BARCODE READER LIST........................................................................................... 59
6.5 CONFIGURING THE BARCODE READER TO DECODE AN IMAGE SUCCESSFULLY ........ 60
6.5.1 Live View Function........................................................................................... 60
6.5.2 Using the External Sensor to Trigger the Barcode Reader.............................. 61
6.5.3 Single Image Decoding.................................................................................... 61
6.5.4 Continuous Image Decoding............................................................................ 61
6.5.5 Setting an Image to Training Mode.................................................................. 62

ITDB-100L Barcode Reader
Page vi
6.5.6 Parameter Settings........................................................................................... 63
6.5.6.1 Automatic Setting...................................................................................... 63
6.5.6.2 LED Brightness......................................................................................... 64
6.5.6.3 Exposure Time .......................................................................................... 65
6.5.6.4 Gain Parameter.......................................................................................... 65
6.5.6.5 Decoding Time.......................................................................................... 66
6.6 CHECKING THE DECODED IMAGES ........................................................................... 67
6.6.1 Checking Captured Images.............................................................................. 67
6.6.2 Sending an Captured Image to IEI................................................................... 68
A SAFETY PRECAUTIONS......................................................................................... 70
A.1 SAFETY PRECAUTIONS ............................................................................................ 71
A.1.1 General Safety Precautions............................................................................. 71
A.1.2 Anti-static Precautions .................................................................................... 72
A.1.3 Product Disposal............................................................................................. 73
A.2 MAINTENANCE AND CLEANING PRECAUTIONS........................................................ 73
A.2.1 Maintenance and Cleaning.............................................................................. 73
A.2.2 Cleaning Tools................................................................................................. 74
B HAZARDOUS MATERIALS DISCLOSURE ......................................................... 75
B.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ....................................... 76

ITDB-100L Barcode Reader
Page vii
List of Figures
Figure 1-1: ITDB-100L ....................................................................................................................2
Figure 1-2: ITDB-100L Front Panel................................................................................................3
Figure 1-3: ITDB-100L Rear Panel.................................................................................................4
Figure 1-4: ITDB-100L Bottom Surface.........................................................................................4
Figure 1-5: ITDB-100L Dimensions (millimeters) ........................................................................7
Figure 1-6: Mounting Bracket Dimensions (millimeters)............................................................8
Figure 3-1: Securing the Mounting Bracket to the ITDB-100L.................................................16
Figure 3-2: Mounting the ITDB-100L...........................................................................................17
Figure 3-3: Adjusting the ITDB-100L ..........................................................................................18
Figure 3-4: Trigger Connection...................................................................................................19
Figure 3-5: Digital Output Wiring................................................................................................20
Figure 3-6: Digital Input Wiring...................................................................................................20
Figure 3-7: Digital Input and Output Connection......................................................................21
Figure 3-8: Ethernet Connection.................................................................................................22
Figure 3-9: Network Connection.................................................................................................23
Figure 3-10: Micro USB Connection...........................................................................................24
Figure 3-11: USB Standard Type A Connection........................................................................25
Figure 3-12: Reading Distance and Field of View .....................................................................26
Figure 4-1: Device Manager.........................................................................................................28
Figure 4-2: Found New Hardware Wizard...................................................................................29
Figure 4-3: Install from Specific Location..................................................................................29
Figure 4-4: Locate Driver Files....................................................................................................30
Figure 4-5: Driver Installation......................................................................................................31
Figure 4-6: Driver Installation Complete ....................................................................................31
Figure 4-7: InstallShield Wizard..................................................................................................32
Figure 4-8: Select Installation Folder..........................................................................................33
Figure 4-9: Ready for Installation................................................................................................33
Figure 4-10: Installation Complete..............................................................................................34
Figure 5-1: Setup Tool Icon .........................................................................................................36
Figure 5-2: Initial Screen..............................................................................................................37

ITDB-100L Barcode Reader
Page viii
Figure 5-3: Detecting the Available Connection Type..............................................................38
Figure 5-4: Connection Type Selection......................................................................................38
Figure 5-5: Connection Status ....................................................................................................39
Figure 5-6: Auto Setup.................................................................................................................40
Figure 5-7: Automatic Setup........................................................................................................40
Figure 5-8: Setup Complete.........................................................................................................41
Figure 5-9: Verification.................................................................................................................41
Figure 5-10: Setting the Region of Interest................................................................................42
Figure 5-11: Locking the ROI Setting .........................................................................................43
Figure 5-12: Train Code Item.......................................................................................................44
Figure 5-13: Training Mode Timer is Started .............................................................................44
Figure 5-14: Trained Mode...........................................................................................................45
Figure 5-15: Loading an Image....................................................................................................45
Figure 5-16: Loading Images.......................................................................................................46
Figure 5-17: Settings....................................................................................................................47
Figure 5-18: Symbology Settings................................................................................................49
Figure 5-19: Network Setting.......................................................................................................50
Figure 5-20: Change Password...................................................................................................51
Figure 5-21: FW Upgrade.............................................................................................................53
Figure 6-1: QR Code.....................................................................................................................56
Figure 6-2: App Icon.....................................................................................................................57
Figure 6-3: Settings Menu............................................................................................................58
Figure 6-4: Barcode Reader List.................................................................................................59
Figure 6-5: Decoding Image Screen ...........................................................................................60
Figure 6-6: Parameter Settings ...................................................................................................63
Figure 6-7: Percentage of LED Brightness ................................................................................64
Figure 6-8: Exposure Time ..........................................................................................................65
Figure 6-9: Gain Parameter..........................................................................................................66
Figure 6-10: Decoding Time ........................................................................................................67
Figure 6-11: Parameter Values....................................................................................................68

ITDB-100L Barcode Reader
Page ix
List of Tables
Table 1-1: Technical Specifications..............................................................................................6
Table 3-1: Connector Pinouts......................................................................................................20
ITDB-100L

ITDB-100L Barcode Reader
Page 1
Chapter
1
1 Introduction

ITDB-100L Barcode Reader
Page 2
1.1 Overview
Figure 1-1: ITDB-100L
The ITDB-100L barcode reader is able to provide high-speed decoding and robust
decoding for common distortion, which is suitable for industrial purpose such as the
high-speed production line. In addition, the ITDB-100L comes with a PC setup tool for
configuring the barcode reader and reading barcodes.
1.2 Features
The ITDB-100L features are listed below:
Image display: Capture/Preview
Trigger modes: One shot/Serial shot/Batch/Presentation
CMOS sensor configuration:
oAutomatic/Manual Exposure
oGain
Image format: RAW/BMP/JPEG
Region of interest setting
Firmware upgradable via USB/Ethernet
Other configurations: Target Brightness/Illumination/Decode Timeout/Decode
Interval
Supports remote monitoring and control via Android phone and tablet
RoHS compliant

ITDB-100L Barcode Reader
Page 3
1.3 External Overview
1.3.1 Front Panel
The ITDB-100L front panel contains:
2 x Illumination LEDs
1 x Lens
An overview of the front panel is shown in Figure 1-26.
Figure 1-2: ITDB-100L Front Panel
1.3.2 Rear Panel
The ITDB-100L rear panel contains:
1 x 6-pin connector for trigger connection
1 x DC in jack
1 x Ethernet connector
1 x Micro USB port
1 x Power indicator
1 x Trigger and tuning control button

ITDB-100L Barcode Reader
Page 4
An overview of the rear panel is shown in 6Figure 1-3 below.
Figure 1-3: ITDB-100L Rear Panel
1.3.3 Bottom Surface
The bottom surface of the ITDB-100L contains four retention screw holes for the mounting
bracket.
Figure 1-4: ITDB-100L Bottom Surface

ITDB-100L Barcode Reader
Page 5
1.4 Technical Specifications
The ITDB-100L technical specifications are listed in Table 1-1.
Specifications
Supported 1D Symbologies Code 39, code 93, interleaved 2 of 5, UPC/EAN (ISBN, UPCA,
UPCE, EAN13, EAN8), EAN 128, code 128, MSI, codabar
Supported 2D Symbologies PDF-417, Micro PDF-417, QR Code/microQR Code,
Data Matrix
Sensor Major Specifications
Sensor: 1/3 inch CMOS with global shutter
Resolution: 752 x 480
Acquisition: Max. rate 60fps
Lens Major Specifications
Focus: Fixed
Code resolution: ≥0.33 mm
Reading distance (at code resolution): 50 mm ~ 330 mm
Illumination Element (nm) 2 x Red LEDs
Visible red light (λ= 650 nm ~ 660 nm)
I/O Interfaces
1 x Micro USB port (USB 2.0 data transmission rate: 480 Mbit/s)
1 x Ethernet port (Ethernet data transmission rate: 10/100 Mbit/s)
1 x DC in jack (Φ2.5/Φ5.5)
1 x 6-pin connector for trigger connection
1 x Trigger and tuning control button
1 x Power indicator
Acoustic indicators: Beeper
Operating Limits of the 6-pin
Connector for Trigger
Connection
Output of LED Flash Trigger
Current: 8mA
Voltage: 3.3VDC
Input of Interrupt Trigger
Current: 1.4mA@5VDC, 4mA@12VDC, 6.2mA@18VDC
Recommended operating voltage: 5VDC ~ 18VDC
Absolute voltage limits: 4.5VDC ~ 24VDC

ITDB-100L Barcode Reader
Page 6
Specifications
Power Supply
Operating voltage: 12V/3.3A
Power consumption:
Power on = 7.7 W
Max. PD = 9.9 W
Supported OS
Microsoft® Windows® XP 32-bit & 64-bit
Microsoft® Windows® Vista™ 32-bit & 64-bit
Microsoft® Windows® 7 32-bit & 64-bit
Mechanical Specifications
Housing: Die-casting aluminum
Housing color: Silver
Front cover: Transparent plastic
Weight: 290 g (without mounting bracket)
Dimensions (LxWxH): 89.8 mm x 62 mm x 32 mm
Shock Resistance EN 60068-2-27 (2009-05)
Vibration MIL-STD-810F 514.5C-1 and IEC-60068-2-06
Environment
RoHS compliant
Operating temperature: 0°C ~ 50°C
Storage temperature: -10°C ~ 60°C
Permissible relative humidity: 90% (non-condensing)
Ambient light safety: 2,000 lx, on code
Table 1-1: Technical Specifications

ITDB-100L Barcode Reader
Page 7
1.5 Dimensions
1.5.1 ITDB-100L Dimensions
Figure 1-5: ITDB-100L Dimensions (millimeters)

ITDB-100L Barcode Reader
Page 8
1.5.2 Mounting Bracket Dimensions
Figure 1-6: Mounting Bracket Dimensions (millimeters)

ITDB-100L Barcode Reader
Page 9
1.6 ITDB-100L Function Compatibility Guideline
Function USB Connection
(via API)
LAN
Connection*
(via API)
USB
Keyboard
Wedge (HID)
Transfer to
Database Built-in Web Management
USB
Connection
(via API)
O X O X
LAN
Connection*
(via API) O X O X
USB
Keyboard
Wedge (HID) X X X X
Transfer to
Database O O X X
Built-in Web
Management X X X X
O: Compatible X: Incompatible
* LAN connection interface includes the PC setup tool, Android app or QNAP NAS app. The users
can only choose one to connect to the ITDB-100L.

ITDB-100L Barcode Reader
Page 10
Chapter
2
2 Unpacking

ITDB-100L Barcode Reader
Page 11
2.1 Anti-static Precautions
WARNING:
Failure to take ESD precautions during installation may result in
permanent damage to the ITDB-100L and severe injury to the user.
Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the ITDB-100L. Dry climates are especially susceptible to ESD. It is therefore
critical that whenever the ITDB-100L or any other electrical component is handled, the
following anti-static precautions are strictly adhered to.
Wear an anti-static wristband: Wearing a simple anti-static wristband can
help to prevent ESD from damaging the board.
Self-grounding: Before handling the board, touch any grounded conducting
material. During the time the board is handled, frequently touch any
conducting materials that are connected to the ground.
Use an anti-static pad: When configuring the ITDB-100L, place it on an
antic-static pad. This reduces the possibility of ESD damaging the ITDB-100L.
2.2 Unpacking Precautions
When the ITDB-100L is unpacked, please do the following:
Follow the anti-static precautions outlined in Section 2.1.
Make sure the packing box is facing upwards so the ITDB-100L does not fall
out of the box.
Make sure all the components shown in Section 2.3 are present.
