IEI Technology prox.pad Assembly instructions

IEI prox.padTM
Proximity Reader/Keypad
Access Control
Installation/Programming Manual
Document # 055 7 , Rev 2.2, D4b

prox.pad Installation/Programming Manual
Table of Contents
Chapter 1: Introduction/Installation.................................................................................8
1.1 About this Manual..........................................................................................................................8
1.2 Safety Warnings and Cautions......................................................................................................8
1. Design Change Disclaimer............................................................................................................8
1.4 Reproduction Disclaimer...............................................................................................................8
1.5 FCC Statement..............................................................................................................................8
1.6 Technical Support.........................................................................................................................9
1.7 Warranty .......................................................................................................................................9
1.8 Items Supplied from the Factory.................................................................................................10
1.9 Items the Installer Must Supply...................................................................................................10
1.10 General Description...................................................................................................................11
1.11 Operating Modes.......................................................................................................................11
1.12 prox.pad Specifications.............................................................................................................12
1.1 Installation Configurations.........................................................................................................1
1.14 Other Installation Considerations..............................................................................................14
1.14.1 Power Supply/Current Requirements................................................................................14
1.14.2 Gang Box and Mounting....................................................................................................14
1.14. Mounting the Unit on Metal................................................................................................14
1.14.4 RF Interference .................................................................................................................14
1.15 Checking the Cables.................................................................................................................15
1.16 Mounting the prox.pad Unit.......................................................................................................19
1.16.1 Performing a Wall Mounted Installation.............................................................................19
1.16.2 Performing a Glass Mounted Installation...........................................................................20
1.16. Performing a Secure Installation........................................................................................21
1.16.4 Installing a Tamper Switch.................................................................................................2
1.16.4.a Mounting over a metal or plastic single gang J-Box...................................................2
1.16.4.b Wall mounting.............................................................................................................2
1.17 Removing/Inserting Circuit Boards............................................................................................24
1.18 Defaulting prox.pad Memory.....................................................................................................25
Chapter 2: Standalone Mode........................................................................................26
2.1 Standalone Mode Description.....................................................................................................26
2.1.1 Standalone Features............................................................................................................26
2.2 Inputs/Outputs ............................................................................................................................26
2. Unit Capacity...............................................................................................................................27
2.4 Alarm Output Selection...............................................................................................................27
2.5 Wiring the prox.pad Unit..............................................................................................................28
2.5.1 Wiring the AUX Relay for Use as Alarm Shunt....................................................................28
2.5.2 Wiring the AUX Relay for Use as Forced Door...................................................................29
2.5. Wiring the AUX Relay for Use as Propped Door................................................................. 0
2.5.4 Wiring the Door Contact Input.............................................................................................. 1
2.5.5 Wiring an External REX Switch (Request to Exit)............................................................... 2
2.5.6 Wiring the Main Relay..........................................................................................................
2.6 Testing the prox.pad.................................................................................................................... 4
2.6.1 Testing the Controller/Keypad............................................................................................. 4
2.7 Programming in Standalone Mode.............................................................................................. 5
Page 2 of 8 Document # 055 7 , Rev 2.2, D4b

prox.pad Installation/Programming Manual
2.7.1 General Programming Features.......................................................................................... 5
2.7.1.a Changing the Master Code........................................................................................... 5
2.7.1.b prox.pad Default Settings............................................................................................. 6
2.7.1.c prox.pad LED Indicators/Sounder Operations – Standalone Mode............................. 7
2.7.2 Programming Users............................................................................................................. 8
2.7.2.a User Types.................................................................................................................... 8
2.7.2.b Programming a “Code Only” User................................................................................ 8
2.7.2.c Programming “Card Only” Users by Presentation....................................................... 9
2.7.2.d Programming 26-Bit “Card Only” Users without Presentation.................................... 9
2.7.2.e Programming “Code AND Card” Users........................................................................ 9
2.7.2.f Programming “Code OR Card” Users...........................................................................40
2.7.2.g Programming 26-Bit “Card Only” Users via Batch Entry without Presentation............40
2.7.2.h Programming Consecutive “Card Only” Users via Batch Entry by Presentation.........41
2.7.2.i Command 50 Quick Program Feature - “Code Only” or “Card Only”............................41
2.7. Deleting Users......................................................................................................................42
2.7. .a Deleting a Single User..................................................................................................42
2.7. .b Deleting a Block of Users.............................................................................................42
2.7.4 Programming Output Relays and Audio Alerts....................................................................4
2.7.4.a Changing the Main Relay Time....................................................................................4
2.7.4.b Programming the Aux Relay Output Function..............................................................4
2.7.4.c Programming the Propped Door Audio Alert................................................................44
2.7.4.d Programming the Forced Door Audio Alert..................................................................44
2.7.4.e Programming the Propped Door Time.........................................................................45
2.7.4.f Programming the Forced Door Time.............................................................................45
2.7.5 Programming Keypad Options and Parameters..................................................................46
2.7.5.a Enabling/Disabling Audio Keypress Feedback.............................................................46
2.7.5.b Enabling/Disabling Visual Keypress Feedback............................................................46
2.7.5.c Enabling/Disabling Auto-Entry......................................................................................47
2.7.5.d Enabling/Disabling the Internal Request to Exit (REX) Switch....................................47
2.7.5.e Enabling/Disabling Daylight Savings Time...................................................................48
2.7.5.f Selecting Daylight Savings Time Format......................................................................48
2.7.5.g Programming Timed Anti-Passback.............................................................................49
2.7.5.h Programming the Facility Code for Card Programming without Presentation.............50
2.7.5.i Programming Invalid PIN Lockout.................................................................................50
2.7.6 Reseting System Defaults and Erasing Memory.................................................................52
2.7.6.a Erasing Entire Memory/Resetting System Defaults.....................................................52
2.8 Using the Printing Features.........................................................................................................5
2.8.1 Selecting Transaction Log Information................................................................................5
2.8.2 Dumping a Transaction Event Log......................................................................................54
2.8.2.a Programming a Log Dump Code or Card.....................................................................54
2.8.2.b Dumping a Transaction Log Manually..........................................................................54
2.8.2.c Erasing the Transaction Log Memory...........................................................................55
2.8.2.d Dumping a Programmed User List...............................................................................55
2.9 Standalone Program Commands................................................................................................56
Chapter : Wiegand Front End Mode...........................................................................60
.1 Wiegand Front End Mode Description........................................................................................60
.2 Wiring the Wiegand Front End....................................................................................................60
Document # 055 7 , Rev 2.2, D4b Page 3 of 8

prox.pad Installation/Programming Manual
. Wiegand Front End Programming...............................................................................................61
. .1 Entering Program Mode.......................................................................................................61
. .2 Changing the Master Code..................................................................................................61
. . Enabling Wiegand Front End Mode.....................................................................................62
. .4 Wiegand Keypad Data.........................................................................................................62
. .5 Programming the Facility Code for Wiegand Keypad Data.................................................62
. .6 Card Data.............................................................................................................................62
. .7 Enabling/Disabling Audio Keypress Feedback....................................................................6
. .8 Enabling/Disabling Visual Keypress Feedback...................................................................6
. .9 Enabling/Disabling Auto-Entry.............................................................................................64
. .10 Enabling/Disabling the Red LED.......................................................................................64
. .11 Enabling/Disabling the Green LED....................................................................................65
. .12 Programming the Red LED Active State...........................................................................65
. .1 Programming the Green LED Active State........................................................................66
. .14 Programming the Wiegand Pulse Width............................................................................66
. .15 Programming the Wiegand Inter-Pulse Spacing...............................................................67
. .16 Reseting System Defaults and Erasing Memory...............................................................67
. .17 Wiegand Mode LED Indicators/Sounder Operations.........................................................68
. .18 Wiegand Front End Mode Default Settings.......................................................................68
.4 Wiegand Programming Commands............................................................................................69
Chapter 4: Secured Series Front End Mode.................................................................70
4.1 Secured Series Front End Mode Description..............................................................................70
4.2 Wiring the Secured Series Front End..........................................................................................70
4. Secured Series Front End LED Indicators/Sounder Operations................................................71
4.4 Secured Series Front End Mode Default Settings......................................................................71
4.5 Secured Series Front End Programming....................................................................................72
4.5.1 Entering Program Mode.......................................................................................................72
4.5.2 Changing the Master Code..................................................................................................72
4.5. Enabling Secured Series Front End Mode..........................................................................7
4.5.4 Selecting the Card Type......................................................................................................7
4.5.5 In/Out Select........................................................................................................................74
4.5.6 Enabling/Disabling Facility Code Matching..........................................................................74
4.5.7 Programming Facility Code..................................................................................................75
4.5.8 Corporate 1000 Company ID...............................................................................................75
4.5.9 Programming Timed Anti-Passback....................................................................................76
4.5.10 Enabling/Disabling Audio Keypress Feedback..................................................................77
4.5.11 Enabling/Disabling Visual Keypress Feedback.................................................................77
4.5.12 Enabling/Disabling Auto-Entry...........................................................................................78
4.5.1 Reseting System Defaults and Erasing Memory...............................................................78
4.6 Secured Series Front End Program Commands........................................................................79
Chapter 5: Troubleshooting..........................................................................................80
5.1 Before Calling IEI........................................................................................................................80
5.2 Performing a Keypad Self-Test...................................................................................................80
5. Troubleshooting Flow Charts......................................................................................................82
5.4 Performing Power Supply Integrity Test ....................................................................................85
5.5 Correcting Possible Water Problems..........................................................................................85
5.5.1 Silicone.................................................................................................................................85
Page 4 of 8 Document # 055 7 , Rev 2.2, D4b

prox.pad Installation/Programming Manual
5.5.2 Wire Run..............................................................................................................................85
5.5. Lithium Battery Replacement...............................................................................................85
Document # 055 7 , Rev 2.2, D4b Page 5 of 8

prox.pad Installation/Programming Manual
List of Tables
Table 1: prox.pad Specifications...........................................................................................................12
Table 2: prox.pad Pin Connectors.........................................................................................................17
Table : IEI-Supplied Parts/Optional Items...........................................................................................18
Table 4: prox.pad Default Settings – Standalone Mode........................................................................ 6
Table 5: prox.pad LED Indicators/Sounder Operations – Standalone Mode........................................ 7
Table 6: prox.pad User Types............................................................................................................... 8
Table 7: Transaction Log Events...........................................................................................................5
Table 8: Standalone Programming Commands....................................................................................56
Table 9: prox.pad LED Indicators/Sounder – Wiegand Mode...............................................................68
Table 10: Wiegand Programming Commands.....................................................................................69
Table 11: prox.pad LED Indicators/Sounder Operations – Secured Series Mode...............................71
Table 12: Secured Series Front End Programming Commands...........................................................79
Table 1 : Troubleshooting Chart...........................................................................................................81
Page of 8 Document # 055 7 , Rev 2.2, D4b

prox.pad Installation/Programming Manual
List of Illustrations
Figure 1: prox.pad Wiring Harness........................................................................................................15
Figure 2: Identifying Pin Connectors.....................................................................................................16
Figure : Performing a Wall Mounted Installation.................................................................................19
Figure 4: Performing a Glass Mounted Installation...............................................................................20
Figure 5: Performing a Secure Installation............................................................................................22
Figure 6: Tamper Switch Locations.......................................................................................................2
Figure 7: Removing/Inserting Printed Circuit Board..............................................................................24
Figure 8: Program Button Location on Main Circuit Board....................................................................25
Figure 9: Wiring the Aux Relay for Alarm Shunt Operation...................................................................28
Figure 10: Wiring the Aux Relay for Forced Door Alarm.......................................................................29
Figure 11: Wiring the Aux Relay for Propped Door Alarm.................................................................... 0
Figure 12: Wiring the Door Contact Input.............................................................................................. 1
Figure 1 : Wiring the REX Switch......................................................................................................... 2
Figure 14: Electric Strike (Fail Secure) Wiring......................................................................................
Figure 15: MagLock (Fail Safe) Wiring Diagram...................................................................................
Figure 16: Wiring to a Wiegand Panel...................................................................................................60
Figure 17: Wiring the prox.pad to the Secured Series DCM.................................................................70
Document # 055 7 , Rev 2.2, D4b Page 7 of 8

prox.pad Installation/Programming Manual
Chapter 1: Introduction/Installation
1.1 About this Manual
This manual is designed for installers of the International Electronics prox.pad Standalone Proximity Reader/Keypad Access Control
System. The de ice has three operating modes, Stand-Alone (see Chapter 2), Wiegand Front End (see Chapter 3), and Secured Series
Front End (see Chapter 4). All wiring and programming instructions for a particular mode are grouped in a separate chapter along with
related illustrations.
Installation instructions are common to all three modes, and are pro ided in this chapter.
1.2 Safety Warnings and Cautions
This system must be installed in accordance with the National Electrical code (NFPA70), local codes, and the authorities ha ing
jurisdiction.
When handling the main printed circuit board, to guard against possible static discharges, touch a grounded object before touching the
prox.pad unit. Static shock can render the product unusable.
1.3 Design Change Disclaimer
Due to design changes and product impro ements, information in this manual is subject to change without notice. IEI assumes no
responsibility for any errors that may appear in this manual.
1.4 Reproduction Disclaimer
Neither this manual nor any part of it may be reproduced, photocopied, or electronically transmitted in any way without the written
permission of IEI.
1.5 FCC Statement
Changes or modifications not expressly appro ed by the party responsible for compliance could oid the users' authority to operate
this equipment. The reader is intended to be powered from a limited power source output of a pre iously certified power supply.
Page 8 of 8 Document # 055 7 , Rev 2.2, D4b

prox.pad Installation/Programming Manual
1. Technical Support
Service Company: Before calling IEI for installation assistance, refer to Chapter 5, Troubleshooting. This chapter includes a list of
common system problems, possible causes, and correcti e actions plus easy-to-use diagnostic flow charts. To contact IEI’s Technical
Support department, call 1- 800-343-9502 Monday through Friday. Questions can also be submitted through our website at
www.ieib.com. You can also download an electronic ersion of this manual from this site.
End User: Please contact your ser ice company.
1.7 Warranty
International Electronics Incorporated (IEI) warrants its products to be free from defects in material and workmanship, when they
ha e been installed in accordance with the manufacturer’s instructions, and ha e not been modified or tampered with. IEI does not
assume any responsibility for damage or injury to person or property due to improper care, storage handling, abuse, misuse, normal
wear and tear, or an act of God.
IEI’s sole responsibility is limited to the repair (at IEI’s option) or the replacement of the defecti e product or part when sent to IEI’s
facility (freight and insurance charges prepaid), after obtaining IEI’s Return Merchandise Authorization. IEI will not be liable to the
purchaser or any one else for incidental or consequential damages arising from any defect in, or malfunction of, its products.
This warranty shall expire two years after shipping date for prox.pad Keypads. Except as stated abo e, IEI makes no warranties, either
expressed or implied, as to any matter whatsoe er, including, without limitation to, the condition of its products, their merchantability,
or fitness for any particular application.
Document # 055 7 , Rev 2.2, D4b Page 9 of 8

prox.pad Installation/Programming Manual
1.8 Items Supplied from the Factory
The following items are supplied from the factory with the initial prox.pad shipment.
●prox.pad unit
●Request to Exit (REX) button (also called the “Filler Piece”)
●Request to Exit Label and Blank Label
●Antenna Housing and Backplate for mounting
●2 Pin jumper (installed on connector)
●Lithium battery (installed in unit)
●Silicone Rubber “dogbone” for Request to Exit switch
●Self-Adhering Pads
●Hex Wrench
●Wire Harnesses
●Installation Hardware
●Quick Start Installer Guide
●CD with Installation/Programming Manuals
1.9 Items the Installer Must Supply
For each prox.pad unit installation, the installer must supply the following items:
●Proximity Cards or Keyfobs; The prox.pad unit works with these four types of cards:
•Prox Card II
•IsoProx II
•Duo Prox II
•Proxkey FOB
●an appropriately rated linear DC Power Supply (12-15 VDC) (filtered and regulated recommended)
●the appropriate installation electrical tools
●Remote Antenna Cable [ALPHA 1294C (22AWG) 4-wire, stranded and shielded] (this is required ONLY if you choose to
remote the antenna 10 feet away from the keypad/controller)
●Wiegand Interface Cable [ALPHA 1295C] (22AWG) 5-conductor, stranded and shielded] (this is required ONLY if using a
separate Wiegand control panel)
●Power Supply Cable (18AWG-22AWG) 2-wire stranded (depends on distance)
●Door Lock Cable (18AWG-22AWG) 2-wire stranded (depends on distance)
●Door Monitor Cable (18AWG-22AWG) 2-wire stranded (depends on distance)
●REX Cable (if using remote switch) [ALPHA 2421C 18 AWG or ALPHA 1292C 22 AWG, 2-conductor, stranded and
shielded]
●Tamper Switch; Either Ademco 945T or PR-20451 magnet and reed switch or equi alent
Page 10 of 8 Document # 055 7 , Rev 2.2, D4b

prox.pad Installation/Programming Manual
1.10 General Description
The IEI prox.pad Proximity Reader/Keypad Door Access Control pro ides card and/or keypad access control for a single door. You
can install the unit either in a one-stage configuration, or a higher security, two-stage (or “remote”) configuration.
In the “secure” (or remote) configuration, you can detach the antenna and mount it up to a maximum of 10 feet away from the main
prox.pad unit. For installation details, see section 1.16.3.
The prox.pad is compatible with all HID proximity cards, up to 40 bit format. You can program cards either by presentation (up to 40
bit) or through batch programming without presenting the cards (only for 26-bit HID cards). All programming is performed using the
built-in keypad on the unit.
In standalone mode, the following four user types are a ailable in the prox.pad unit:
●0-Toggle/latch lock
●1-Normal access
●2-log Dump
●3-Lockout
In standalone mode, the unit can store up to 2000 users and 1000 transaction e ents, which can both be transmitted ia the IR LED for
collection by the optional Data Collection De ice for reporting purposes.
The unit is equipped with a lock release main relay and an auxiliary relay, which you can program for alarm shunt, forced door or
propped door access control functions.
1.11 Operating Modes
During initial installation, the installer programs the prox.pad unit for one of three operating modes, “Standalone,” “Wiegand Front
End,” or “Secured Series Front End.” Only one operating mode can be selected at any one time. If you plan to use Standalone mode
(the default, out-of-the-box, mode), no programming is required.
In “Standalone” mode (Chapter 2), all the access control decisions are made by the prox.pad unit. The unit operates entirely on its
own. The unit contains a main relay for controlling the locking de ice and a programmable auxiliary relay for access control functions
such as alarm shunt, forced door and propped door. The unit has an input for a door position switch and a request to exit (REX)
de ice. The prox.pad stores all transactions the transactions locally in memory and has an IR LED for dumping the transaction e ent
log to the Data Collection De ice. You can use the de ice as a keypad, card reader or combination to gain access.
In “Wiegand Front End” mode (Chapter 3), the prox.pad is used as front end for a Wiegand access control panel. No access control
decision are made in the prox.pad. The Wiegand data is just sent to the Wiegand control panel. The panel then makes all access
control decisions and controls the prox.pad LEDs. You can use it as a keypad or a card reader. The keypad data is only sent as 26-Bit
card data, but the card reader just passes the data from the card to the panel. You can use up to 40-Bit HID format cards.
In “Secured Series Front End” mode, the prox.pad unit is used as a front end with an IEI Secured Series Door Control Module. Either
standard 26-bit or Corporate 1000 prox cards can be used during Secured Series mode. No other format cards can be used. The PIN
data is extracted from these card types and sent to the Secured Series Door Control Module for erification (for details, see Chapter 4).
In all operating modes, the prox.pad unit maintains programmability so that prox.pad system parameters can be set. The default
factory setting during programming is for the unit to “time out” after 45 seconds of inacti ity.
Document # 055 7 , Rev 2.2, D4b Page 11 of 8

prox.pad Installation/Programming Manual
1.12 prox.pad Specifications
Table 1: prox.pad Specifications
Electrical
Power Supply/Current Requirements 10-15 VDC, linear filtered and regulated power supply; 100mA
Wiring
Remote Antenna Cable (if installing in a
secured configuration) [ALPHA 1294C (22AWG) 4-conductor, stranded and shielded]
Wiegand Interface Cable [ALPHA 1295C (22AWG) 5-conductor, stranded and shielded]
Secured Series Front End Cable [ALPHA 1295C (22AWG) 4-conductor, stranded and shielded]
Power Supply Cable 18AWG - 22AWG 2-wire stranded (depends upon distance)
Door Lock Cable 18AWG - 22AWG 2-wire stranded (depends upon distance)
Door Monitor Cable 18AWG - 22AWG 2-wire stranded (depends upon distance)
REX Cable [ALPHA 2421C 18 AWG or ALPHA 1292C 22 AWG, 2-conductor,
stranded and shielded] (if using remote switch)
Mechanical
Height 5.25 in (1 . cm)
Width 2.75 in (7 cm)
Depth 1.625 in (4.1 cm)
Relay Outputs
Main Relay Form C (switches up to 2A)
Program for either timed (1-99 sec) or toggle
Aux Relay Form C (switches up to 1A)
One of three functions can be programmed: Alarm Shunt Relay,
Forced Door Relay, or Propped Door Relay
Monitor Inputs
Door Position Switch Normally Closed, Dry Contact
Other Outputs
Infrared LED Output Output to optional Data Collection Device PDA Software
Sounder 4000 Hz, defeatable
Bi-Color LED Red/Green
Yellow LED
Compatible Proximity Cards (All HID cards up to 40 bits, including the following)
Prox Card II, IsoProx II, DuoProx II, ProxKey FOB
Specifications continued on next page.
Page 12 of 8 Document # 055 7 , Rev 2.2, D4b

prox.pad Installation/Programming Manual
Specifications Continued
Unit Capacity
Users (standalone mode only) 2000 Maximum (each user can have a card, PIN or both)
Transactions (standalone mode only) 1000 Maximum (includes event number, time, date, and user
number if applicable)
Environmental (Indoor or Outdoor)
Operating Temperature - 1° to 150° F (- 5° to 66° C)
Operating Humidity 5% to 95% relative humidity, non-condensing
1.13 Installation Configurations
NOTE: IEI recommends that first-time installers test the prox.pad unit before actually mounting and wiring the unit. This allows you
to become familiar with its operation and sa e time on the job site (see section 2.6).
It is the installer’s responsibility to determine the appropriate prox.pad installation configuration, which differs from installation to
installation. These three installation configurations are possible:
●Wall Mounted Installation (exterior to the room to be accessed).
In this configuration, a single gang electrical box can be used. Typically, the prox.pad unit is wall mounted (surface mounted)
outside the access area on the unsecured side.
●Glass Mounted Installation
In this configuration, the prox.pad unit is affixed with the four IEI supplied adhesi e pads to the glass door or the window
adjacent to the door being accessed, on the interior side of the glass. The side cut-out on the unit is used to bring the wires out
of the side of the prox.pad case.
●Secure Installation (or “two-stage” configuration)
In this configuration, the prox.pad antenna is located a maximum of 10 feet away from the keypad; the keypad is located on
the secure side of the door.
Document # 055 7 , Rev 2.2, D4b Page 13 of 8

prox.pad Installation/Programming Manual
1.14 Other Installation Considerations
Sections 1.15.1 - 1.15.4 describe important considerations the installer must decide upon before actually starting to install and wire the
prox.pad.
1.14.1 Power Supply/Current Requirements
Power for the prox.pad unit must be from a minimum 10-15 olt DC linear, filtered and regulated access control power limited power
supply. The prox.pad unit draws approximately 55mA of current. It is typical for the chosen power supply to power both the prox.pad
unit and the locking de ice. When using one power supply for both the prox.pad unit and locking de ice, be sure to include both
de ices in your current requirements calculations.
NOTE: IEI recommends that you ground the power supply to earth ground.
1.14.2 Gang Box and Mounting
For the wall mounted installation configuration, a single gang electrical box can be used. Typically, the prox.pad unit is wall mounted
outside the access area on the unsecured side of the door.
1.14.3 Mounting the Unit on Metal
The prox.pad unit uses radio frequency (RF) to transfer power to and communicate with the proximity card or key fob. If the antenna
is mounted directly on a metal building or wall, some of the energy is absorbed by the metal, resulting in less power being transmitted
to the card/key fob; this causes reduced read range. If you must mount the prox.pad unit on metal, test the unit in place before
permanently installing it. If read range distance distance is not adequate, a non-metallic spacer can be fabricated and installed between
the unit’s antenna and the metal mounting surface.
1.14.4 RF Interference
The prox.pad unit should not cause interference to other equipment as it is designed to meet FCC guidelines. Howe er, other de ices
can interfere with prox.pad operation. A oid locating the prox.pad unit closer than 3 feet (1 meter) to a computer monitor or tele ision
or another prox.pad unit. If you belie e you are experiencing reduced read range due to interference, try repositioning the prox.pad
unit, remoting the antenna, or relocating other nearby electrical equipment.
Page 14 of 8 Document # 055 7 , Rev 2.2, D4b

prox.pad Installation/Programming Manual
1.15 Checking the Cables
Figure 1 below pro ides a detailed illustration of the prox.pad’s wiring harness. Figure 2 illustrates the pin connectors on the main
circuit board; Table 2 describes these four Pin connectors, P1, P2, P3, and P4.
Document # 055 7 , Rev 2.2, D4b Page 15 of 8
Figure 1: prox.pad Wiring Harness

prox.pad Installation/Programming Manual
Page 1 of 8 Document # 055 7 , Rev 2.2, D4b
Figure 2: Identifying Pin Connectors

prox.pad Installation/Programming Manual
Table 2: prox.pad Pin Connectors
Pin Connector (on main circuit board) Description/Use
P1 (5-pin connector, top left-most location)
Pin Wire Color Use
1 Gray Main Relay Normally Closed
2 Green Main Relay Normally Open
Blue Main Relay Common
4 Black Ground (Power Supply)
5 Red +12V Input (Power Supply)
P (4-pin connector, top middle location)
Pin Wire Color Use
1 Blue Not Used
2 Brown Wiegand LED Control
White Wiegand Data 1 (SS White/Yellow)
4 Green Wiegand Data 0 (SS White/Black)
P2 (6-pin connector, top right-most location)
Pin Wire Color Use
1 Green Aux Relay Normally Open
2 Gray Aux Relay Normally Closed
Blue Aux Relay Common
4 Brown REX Loop
5 Orange Door Contact Loop
6 White Loop Common
NOTE: Pins 1, 2, can be wired at the installer’s option for one of
the following alarm outputs, Alarm Shunt, Forced Door, or
Propped Door. Mandatory: If you are not installing door contacts
per Figure 12, twist the white and orange wires together. If not
done, the REX input won't work.
P4 (4-pin connector, bottom location) Pin Wire Color Use
1 Red Bi-Color LED (Red +)
2 Black Bi-Color LED (Green +)
White Antenna (no polarity)
4 White Antenna (no polarity)
Document # 055 7 , Rev 2.2, D4b Page 17 of 8

prox.pad Installation/Programming Manual
Table 3: IEI-Supplied Parts/Optional Items
Quantity Description
1 Keypad/control unit assembly, with Prox Sensor, Backplate, hex socket screw
1 Filler Piece/REX Button
1 Press to Exit Label
4 Wall Anchors
4 Mounting Screws
1 Antenna Backplate for remote mounting
1 Silicone Rubber “dogbone”
4 Self-Adhering Pads (for glass mounting)
1 Installer Guide
1 CD-ROM containing instruction manuals
4 Cable Assemblies
1 Tamper Screw
Optional Items
1 Data Collection Device (to capture user list and transaction event log)
1 prox.pad Replacement Battery: Panasonic BR1225, Renata CR1225 or Varta CR1225;
Refer to caution below.
lots of 25 only ProxKey Keytags (IEI part number 0297 01)
lots of 25 only ProxCard II Cards (IEI part number 0297401)
Page 18 of 8 Document # 055 7 , Rev 2.2, D4b
Caution: Replace battery with types listed above only. Use
of another battery may present risk of fire or explosion.
Battery may explode if mistreated. Do not recharge,
disassemble or dispose of battery in fire.

prox.pad Installation/Programming Manual
1.1 Mounting the prox.pad Unit
Select one of these three installation configurations, wall mount, glass mount, or secure as appropriate for this installation. Then refer
to the following sections.
1.1 .1 Performing a Wall Mounted Installation
This section pro ides general considerations when performing a wall mounted installation. Typically, the prox.pad unit is mounted on
a flat, le el surface (drywall, masonry, wood, etc.) exterior to the room to be accessed. A single-gang electrical box (or back box) can
be used. Typically, the prox.pad unit is wall mounted outside the access area on the unsecured side of the door.
Figure 3 below illustrates the components on the prox.pad unit used for wall mounting. Two single-gang box holes align with two
corresponding holes in the single-gang box. A wire exit knockout is supplied through which the prox.pad wiring is pulled. A typical
wall mounted installation proceeds as follows:
1. Install a single-gang box in the desired location.
2. Punch out the two single-gang box knockouts on the controller backplate of the prox.pad unit.
3. Disconnect the controller backplate of the prox.pad unit from the front keypad/controller. Align the two single-gang box
holes on the controller backplate o er the two corresponding holes on the single-gang box, pre iously secured at step 1.
4. Secure the backplate to the single-gang box by inserting/tightening two screws into the two single-gang box holes.
5. Connect the front keypad/controller to the back housing.
6. Pull the prox.pad wiring through the wiring exit as appropriate.
7. Install the tamper screw into the hole at the bottom front of the enclosure using a #6 spanner bit (not included, but a ailable
from IEI).
Document # 055 7 , Rev 2.2, D4b Page 19 of 8
Figure 3: Performing a Wall Mounted Installation

prox.pad Installation/Programming Manual
1.1 .2 Performing a Glass Mounted Installation
Figure 4 below shows the four IEI-supplied pressure-sensiti e adhesi e pads and the two side cut-outs used for this installation. In this
configuration, the prox.pad unit is affixed with the four self-adhesi e pads to the glass or the glass window adjacent to the door being
accessed, on the interior side of the glass. One of the two side cut-outs is used to bring the wires out of the side of the prox.pad case.
A typical glass mounted installation proceeds as follows:
1. Disconnect the back housing from the front keypad/ controller. Remo e the tape from the four self-adhesi e pads on the back
housing and apply the pads to the four corners of the backplate.
2. Affix the back housing to the glass door or the glass window adjacent to the door being accessed, on the interior side of the
glass.
3. Determine which of the two side cut-outs on the back housing to use for the wiring and remo e that cut-out using the
appropriate cutting tool.
4. Pull the wiring through the selected side cut-out as required.
5. Connect the front keypad/controller to the back housing.
6. Install the tamper screw into the hole at the bottom front of the enclosure using a #6 spanner bit (not included, but a ailable
from IEI).
Page 20 of 8 Document # 055 7 , Rev 2.2, D4b
Figure 4: Performing a Glass Mounted Installation
