IEI Technology KINO-HM551 User manual

KINO-HM551
Page I
User Manual
KINO-HM551
MODEL:
Mini-ITX SBC Supports Socket G1 for Intel® mobile Core™ i7/i5/i3 and
Intel® Celeron®, VGA/DVI/LVDS/HDMI Display, Dual GbE,
Eight USB 2.0, Dual PCIe Mini, Four SATA 3Gb/s, Audio, RoHS
Rev. 1.03 - 22 October, 2014

KINO-HM551
Page II
Revision
Date Version Changes
22 October, 2014 1.03 Added Section 3.2.19: SPI Flash Connector
Minor update
15 February, 2012 1.02 Updated Table 3-6: Fan Connector Pinouts
15 September, 2011 1.01 Modified Chapter 3 Connectors
17 November, 2011 1.00 Initial release

KINO-HM551
Page III
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

KINO-HM551
Page IV
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 CONNECTORS ............................................................................................................. 3
1.3 DIMENSIONS............................................................................................................... 4
1.4 DATA FLOW................................................................................................................ 5
1.5 TECHNICAL SPECIFICATIONS ...................................................................................... 6
2 UNPACKING................................................................................................................. 8
2.1ANTI-STATIC PRECAUTIONS........................................................................................ 9
2.2 UNPACKING PRECAUTIONS......................................................................................... 9
2.3 PACKING LIST........................................................................................................... 10
2.3.1 Optional Items...................................................................................................11
3 CONNECTORS ........................................................................................................... 12
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 13
3.1.1 KINO-HM551 Layout ...................................................................................... 13
3.1.2 Peripheral Interface Connectors ..................................................................... 14
3.1.3 External Interface Panel Connectors............................................................... 15
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 15
3.2.1 Audio Connector .............................................................................................. 15
3.2.2 Digital I/O Connector...................................................................................... 16
3.2.3 Fan Connector (CPU)...................................................................................... 17
3.2.4 Fan Connector (System) .................................................................................. 17
3.2.5 Front Panel Indicators..................................................................................... 18
3.2.6 Infrared Connector .......................................................................................... 19
3.2.7 Inverter Connector........................................................................................... 20
3.2.8 Keyboard/Mouse Connector ............................................................................ 21
3.2.9 LVDS Connector .............................................................................................. 22
3.2.10 PCIe Mini Card Slot (Full-size)..................................................................... 23
3.2.11 PCIe Mini Card Slot (Half-size)..................................................................... 24
3.2.12 Power Supply Connector ............................................................................... 26

KINO-HM551
Page V
3.2.13 RS-232/422/485 Serial Port Connector......................................................... 26
3.2.14 RS-232 Serial Port Connector....................................................................... 27
3.2.15 SATA Drive Connectors ................................................................................. 28
3.2.16 SATA Power Connectors................................................................................ 29
3.2.17 SMBus Connector .......................................................................................... 30
3.2.18 SPDIF Connector........................................................................................... 31
3.2.19 SPI Flash Connector...................................................................................... 32
3.2.20 TPM Connector.............................................................................................. 33
3.2.21 USB Connectors............................................................................................. 34
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 35
3.3.1 Adapter Connector........................................................................................... 36
3.3.2 Audio Connector .............................................................................................. 37
3.3.3 Ethernet/USB Connector ................................................................................. 37
3.3.4 HDMI Connector............................................................................................. 38
3.3.5 Serial Port DB-9 Connector ............................................................................ 39
3.3.6 VGA and DVI Connector ................................................................................. 40
4 INSTALLATION ......................................................................................................... 42
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 43
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 44
4.2.1 Installation Notices.......................................................................................... 44
4.3 UNPACKING.............................................................................................................. 45
4.4 CPU, CPU COOLING KIT AND SO-DIMM INSTALLATION........................................ 45
4.4.1 Socket G1 CPU Installation............................................................................. 46
4.4.2 Socket G1 Cooling Kit Installation.................................................................. 48
4.4.3 SO-DIMM Installation..................................................................................... 50
4.5 JUMPER SETTINGS .................................................................................................... 50
4.5.1 AT/ATX Power Select Jumper Settings ............................................................ 51
4.5.2 Clear CMOS Jumper........................................................................................ 52
4.5.3 ME RTC Register Jumper................................................................................ 53
4.5.4 LVDS Voltage Selection.................................................................................... 54
4.5.5 LVDS Screen Resolution Selection................................................................... 55
4.5.6 Serial Port Select Jumper ................................................................................ 56
4.6 CHASSIS INSTALLATION............................................................................................ 57
4.6.1 Airflow.............................................................................................................. 57

KINO-HM551
Page VI
4.6.2 Motherboard Installation................................................................................. 57
4.7 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 57
4.7.1 Dual RS-232 Cable with Slot Bracket.............................................................. 58
4.7.2 SATA Drive Connection ................................................................................... 59
4.8 EXTERNAL PERIPHERAL INTERFACE CONNECTION ................................................... 60
4.8.1 Audio Connector .............................................................................................. 60
4.8.2 HDMI Display Device Connection.................................................................. 61
4.8.3 LAN Connection............................................................................................... 62
4.8.4 USB Connection............................................................................................... 63
4.8.5 Serial Device Connection ................................................................................ 64
4.8.6 VGA Monitor Connection ................................................................................ 65
4.8.7 DVI Display Device Connection...................................................................... 66
4.9 SOFTWARE INSTALLATION ........................................................................................ 67
5 BIOS.............................................................................................................................. 69
5.1 INTRODUCTION......................................................................................................... 70
5.1.1 Starting Setup................................................................................................... 70
5.1.2 Using Setup...................................................................................................... 70
5.1.3 Getting Help..................................................................................................... 71
5.1.4 Unable to Reboot After Configuration Changes.............................................. 71
5.1.5 BIOS Menu Bar................................................................................................ 71
5.2 MAIN........................................................................................................................ 72
5.3ADVANCED............................................................................................................... 73
5.3.1 ACPI Configuration......................................................................................... 74
5.3.2 Trusted Computing........................................................................................... 75
5.3.3 CPU Configuration.......................................................................................... 75
5.3.4 SATA Configuration ......................................................................................... 77
5.3.5 USB Configuration........................................................................................... 78
5.3.6 Super IO Configuration ................................................................................... 79
5.3.7 H/W Monitor.................................................................................................... 80
5.3.7.1 Serial Port Console Redirection................................................................ 85
5.3.7.2 Console Redirection Settings.................................................................... 86
5.4 CHIPSET ................................................................................................................... 87
5.4.1 Northbridge Configuration.............................................................................. 88
5.4.2 Southbridge Configuration .............................................................................. 89

KINO-HM551
Page VII
5.4.3 Intel IGD SWSCI OpRegion............................................................................. 90
5.5 BOOT........................................................................................................................ 92
5.6 SECURITY................................................................................................................. 94
5.7 EXIT......................................................................................................................... 95
A BIOS MENU OPTIONS............................................................................................. 97
B TERMINOLOGY...................................................................................................... 100
C DIGITAL I/O INTERFACE..................................................................................... 105
C.1 INTRODUCTION...................................................................................................... 106
C.2ASSEMBLY LANGUAGE SAMPLE 1.......................................................................... 107
C.3ASSEMBLY LANGUAGE SAMPLE 2.......................................................................... 107
D WATCHDOG TIMER .............................................................................................. 108
E HAZARDOUS MATERIALS DISCLOSURE ........................................................111
E.1 HAZARDOUS MATERIAL DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ......................................112

KINO-HM551
Page VIII
List of Figures
Figure 1-1: KINO-HM551 ................................................................................................................2
Figure 1-2: Connectors ..................................................................................................................3
Figure 1-3: KINO-HM551 Dimensions (mm).................................................................................4
Figure 1-4: Data Flow Block Diagram...........................................................................................5
Figure 3-1: Connector and Jumper Locations...........................................................................13
Figure 3-2: Audio Connector Location.......................................................................................16
Figure 3-3: Digital I/O Connector Location ................................................................................16
Figure 3-4: Fan Connector Locations.........................................................................................17
Figure 3-5: Fan Connector Locations.........................................................................................18
Figure 3-6: Front Panel Indicator Location................................................................................19
Figure 3-7: Infrared Connector Locations..................................................................................20
Figure 3-8: Inverter Connector Location....................................................................................20
Figure 3-9: Keyboard/Mouse Connector Location....................................................................21
Figure 3-10: LVDS Connector Locations....................................................................................22
Figure 3-11: Full-size PCIe Mini Card Slot Connector Location ..............................................23
Figure 3-12: Half-size PCIe Mini Card Slot Connector Location..............................................25
Figure 3-13: +12V Power Supply Connector Location..............................................................26
Figure 3-14: RS-232/422/485 Serial Port Location.....................................................................27
Figure 3-15: RS-232 Serial Port Connector Location................................................................28
Figure 3-16: SATA Drive Connector Locations .........................................................................29
Figure 3-17: SATA Power Connector Locations .......................................................................30
Figure 3-18: SMBus Connector Pinout Locations.....................................................................31
Figure 3-19: SPDIF Connector Pinout Locations......................................................................32
Figure 3-20: SPI Flash Connector Location...............................................................................33
Figure 3-21: TPM1 Connector Location......................................................................................34
Figure 3-22: USB Connector Pinout Locations.........................................................................35
Figure 3-23: KINO-HM551 External Peripheral Interface Connector .......................................36
Figure 3-24: 4-pin Power Mini-DIN Connection .........................................................................36
Figure 3-25: Audio Connector.....................................................................................................37
Figure 3-26: Ethernet Connector.................................................................................................38
Figure 3-27: Serial Port DB-9 Male Connector...........................................................................39

KINO-HM551
Page IX
Figure 3-28: VGA Connector .......................................................................................................40
Figure 4-1: Make sure the CPU socket retention screw is unlocked ......................................47
Figure 4-2: Lock the CPU Socket Retention Screw...................................................................48
Figure 4-3: Cooling Kit Support Bracket....................................................................................49
Figure 4-4: SO-DIMM Installation................................................................................................50
Figure 4-5: Jumper Locations.....................................................................................................50
Figure 4-6: AT/ATX Power Select Jumper Location..................................................................52
Figure 4-7: AT Auto Button Select Jumper Settings.................................................................53
Figure 4-8: ME RTC Register Jumper Location.........................................................................54
Figure 4-9: LVDS Voltage Selection Jumper Locations ...........................................................55
Figure 4-10: LVDS Panel Resolution Jumper Pinout Locations..............................................56
Figure 4-11: Serial Port Jumper Location..................................................................................57
Figure 4-12: Dual RS-232 Cable Installation ..............................................................................58
Figure 4-13: SATA Drive Cable Connection...............................................................................59
Figure 4-14: Audio Connector.....................................................................................................61
Figure 4-15: HDMI Connection....................................................................................................62
Figure 4-16: LAN Connection......................................................................................................63
Figure 4-17: USB Connector........................................................................................................64
Figure 4-18: Serial Device Connector.........................................................................................65
Figure 4-19: VGA Connector .......................................................................................................66
Figure 4-20: DVI Connector .........................................................................................................67
Figure 4-21: Introduction Screen................................................................................................68
Figure 4-22: Available Drivers.....................................................................................................68

KINO-HM551
Page X
List of Tables
Table 1-1: Technical Specifications..............................................................................................7
Table 3-1: Peripheral Interface Connectors...............................................................................15
Table 3-2: Rear Panel Connectors..............................................................................................15
Table 3-3: Audio Connector Pinouts ..........................................................................................16
Table 3-4: Digital I/O Connector Pinouts....................................................................................17
Table 3-5: Fan Connector Pinouts..............................................................................................17
Table 3-6: Fan Connector Pinouts..............................................................................................18
Table 3-7: Front Panel Indicator Pinouts....................................................................................19
Table 3-8: Infrared Connector Pinouts.......................................................................................20
Table 3-9: Inverter Connector Pinouts .......................................................................................21
Table 3-10: Keyboard/Mouse Connector Pinouts .....................................................................21
Table 3-11: LVDS Connector Pinouts.........................................................................................23
Table 3-12: Full-size PCIe Mini Card Slot Pinouts.....................................................................24
Table 3-13: Half-size PCIe Mini Card Slot Pinouts ....................................................................26
Table 3-14: +12V Power Supply Connector Pinouts.................................................................26
Table 3-15: RS-232/422/485 Serial Port Connector Pinouts.....................................................27
Table 3-16: RS-232 Serial Port Connector Pinouts...................................................................28
Table 3-17: SATA Drive Connector Pinouts...............................................................................29
Table 3-18: SATA Power Connector Pinouts.............................................................................30
Table 3-19: SMBus Connector Pinouts ......................................................................................31
Table 3-20: SPDIF Connector Pinouts........................................................................................32
Table 3-21: SPI Flash Connector Pinouts ..................................................................................33
Table 3-22: TPM1 Connector Pinouts.........................................................................................34
Table 3-23: USB Connector Pinouts...........................................................................................35
Table 3-24: Adapter Connector Pinouts.....................................................................................36
Table 3-25: LAN Connector Pinouts...........................................................................................38
Table 3-26: USB Connector Pinouts...........................................................................................38
Table 3-27: HDMI Connector Pinouts .........................................................................................39
Table 3-28: USB Connector Pinouts...........................................................................................40
Table 3-29: VGA Connector Pinouts...........................................................................................41
Table 3-30: DVI Connector Pinouts.............................................................................................41

KINO-HM551
Page XI
Table 4-1: Jumpers.......................................................................................................................51
Table 4-2: AT/ATX Power Select Jumper Settings....................................................................51
Table 4-3: Clear CMOS Jumper Settings....................................................................................53
Table 4-4: ME RTC Register Jumper Settings ...........................................................................53
Table 4-5: LVDS Voltage Selection Jumper Settings................................................................54
Table 4-6: LVDS Screen Resolution Jumper Settings..............................................................56
Table 4-7: Serial Port Jumper Settings.......................................................................................56
Table 5-1: BIOS Navigation Keys................................................................................................71

KINO-HM551
Page XII
List of BIOS Menus
BIOS Menu 1: Main.......................................................................................................................72
BIOS Menu 2: Advanced..............................................................................................................73
BIOS Menu 3: ACPI Configuration..............................................................................................74
BIOS Menu 4: TPM Configuration...............................................................................................75
BIOS Menu 5: CPU Configuration...............................................................................................76
BIOS Menu 6: IDE Configuration.................................................................................................77
BIOS Menu 7: USB Configuration...............................................................................................78
BIOS Menu 8: Super IO Configuration........................................................................................79
BIOS Menu 9: Hardware Health Configuration..........................................................................80
BIOS Menu 10: Serial Port Console Redirection Menu.............................................................85
BIOS Menu 11: Console Redirection Settings...........................................................................86
BIOS Menu 12: Chipset................................................................................................................87
BIOS Menu 13:Northbridge Chipset Configuration...................................................................88
BIOS Menu 14:Southbridge Chipset Configuration..................................................................89
BIOS Menu 15: Intel IGD SWSCI OpRegion ...............................................................................90
BIOS Menu 16: Boot.....................................................................................................................92
BIOS Menu 17: Security...............................................................................................................94
BIOS Menu 18:Exit........................................................................................................................95

KINO-HM551
Page 1
1 Introduction
Chapter
1

KINO-HM551
Page 2
1.1 Introduction
Figure 1-1: KINO-HM551
The KINO-HM551 motherboard is a Socket G1 32nm Intel® Core™ i3, i5 and i7 processor
platform. Two SO-DIMM sockets support up to 8 GB of 800 MHz or 1066 MHz DDR3
SDRAM memory.
The integrated Intel® HM55 Express Chipset supports two GbE LAN ports through dual
Realtek RTL8111E Ethernet controllers (ASF 2.0 support on LAN1). The KINO-HM551
also supports four SATA 3Gb/s drives and provides 5 V SATA power.
The KINO-HM551 supports dual display via VGA, HDMI and an internal LVDS connector.
Eight USB 2.0 channels and two PCIe Mini expansion sockets provide flexible expansion
options. High Definition Audio (HDA) support ensures HDA devices can be easily
implemented on the KINO-HM551. Serial device connectivity is provided by three internal
RS-232, one external RS-232, and two internal RS-232/422/485 connectors.

KINO-HM551
Page 3
1.2 Connectors
The connectors on the KINO-HM551 are shown in the figure below.
Figure 1-2: Connectors

KINO-HM551
Page 4
1.3 Dimensions
The dimensions of the board are listed below:
Length: 170 mm
Width: 170 mm
Figure 1-3: KINO-HM551 Dimensions (mm)

KINO-HM551
Page 5
1.4 Data Flow
4Figure 1-4 shows the data flow between the two on-board chipsets and other components
installed on the motherboard and described in the following sections of this chapter.
Figure 1-4: Data Flow Block Diagram

KINO-HM551
Page 6
1.5 Technical Specifications
KINO-HM551 technical specifications are listed in table below.
Specification KINO-HM551
Form Factor Mini-ITX
Socket Socket G1 (rPGA989)
Socket 988A
CPU Supported 32 nm Intel® Core™ i3 processor
32 nm Intel® Core™ i5 processor
32 nm Intel® Core™ i7 processor (i7 processors without
integrated graphics)
Intel® Celeron® processor
Express Chipset Intel® HM55
Memory Two 204-pin SO-DIMM sockets support 800/1066 MHz
4.0 GB (max.) dual-channel DDR3 SDRAM SO-DIMM
(system max. 8GB)
Audio Realtek ALC888 HD 7.1 channel audio codec
LAN Dual Realtek RTL8111E PCIe GbE controllers withASF 2.0
support on LAN1
Super I/O Fintek F81865
BIOS AMI uEFI BIOS label
Watchdog Timer Software programmable supports 1~255 sec. system reset
Expansion
PCIe Two PCIe Mini slot
I/O Interface Connectors
Audio Connector One internal audio connector (10-pin header)

KINO-HM551
Page 7
Specification KINO-HM551
Display Ports One VGA port (2048x1536)
One HDMI port (up to 1080p)
One internal LVDS connector (1600x1200)
One DVI-D port (1600x1200)
Ethernet Two RJ-45 GbE ports
Serial Ports Three RS-232 via three 10-pin headers
One external RS-232 serial connector via DB-9 male
Two RS-232/422/485 via 14–pin header
USB 2.0/1.1 Ports Four external USB ports
Four internal USB ports via two 8-pin headers
Storage
Serial ATA Four SATA 3.0 Gb/s connectors
Two 5 V SATA power connectors
Environmental and Power Specifications
Power Supply 12 V DC input only
ATX and AT power supported
Power Connector One external DIN 4-pin DC jack
One internal 4-pin Molex power connector for power supply
Power Consumption [email protected] (2.66 GHz Intel® Core™ i7 620M CPU with two
1333 MHz 4 GB DDR3 SO-DIMM)
Operating Temperature -10ºC ~ 60ºC (requires cooler and silicone heat sink paste)
Humidity 5% ~ 95% (non-condensing)
Physical Specifications
Dimensions 170 mm x 170 mm
Weight GW/NW 900 g / 450 g
Table 1-1: Technical Specifications

KINO-HM551
Page 8
2 Unpacking
Chapter
2
