IEI Technology PCISA-6770-RS User manual

1
PCISA Intel Pentium-M/Celeron-M CPU Card with LCD/CRT
VGA,Dual LAN,USB2.0 and Audio
PCISA-6770-RS
Quick Installation Guide
Version 2.0
May. 4, 2007
Package Contents
PCISA-6770-RS package includes the following items:
 1x PCISA-6770-RS single board computer
 1x ATA66/100 HDD cable P/N: 32200-000052-RS
 1x KB/PS2 Mouse Y cable P/N: 32000-000138-RS
 1x RS232 cable P/N: 19800-000027-RS
 1x RS232/422/485 cable P/N:32200-000077-RS
 1x USB cable P/N: CB-USB02A-RS
 1x Audio cable P/N:19800-000044-RS
 1 x mini jumper pack
 1 x Utility CD
 1 x QIG (quick installation guide)
©2006 Copyright by IEI Technology corp.
All rights reserved.

2
Specifications

CPU: Intel Pentium M/Celeron M Socket 479 up to 400MHz
FSB/Onboard Celeron M 800MHz zero cache
 System Chipset: Intel 852GM+ICH4
 BIOS: AMI BIOS Label
 System memory: DDR266 SDRAM socket support up to 1GB
 Ethernet: 2x 10/100 Mbps Intel 82562ET/82551ER fast Ethernet
controller onboard
 I/O
I/O Interface:
1 x RS-232
1 x RS-232/422/485
1 x LPT by pin-header
1 x IrDA by pin-header
5 x USB 2.0( 1 in rear,4 by pin header)
1x ATA-100
1x ATA-33 IDE channel
2 x PS/2 keyboard/mouse
1 x FDD
Supper I/O: W83697HG
Digital I/O:4 input / 4output
 Display: CRT integrated in Intel 852GM
 Audio: AC'97 Audio codec

Power supply:5V/12V, AT/ATX power support
 Power Consumption:
[email protected], [email protected]
Pentium M 1.7G/2M,DDR266/512MB
[email protected], [email protected]
Celeron M 800MHz,DDR 400/1 GB
 Temperature: 0 ~ 60°C( 32 ~ 140°F)
 Watchdog timer: Software programable 1-255 sec. by supper I/O

3
Ordering Information
Standard
PCISA-6770E2-RS-R20
PCISA Intel Pentium-M/Celeron-M CPU Card with LCD/CRT VGA,Dual
LAN,USB2.0 and Audio
PCISA-6770E2-RS-800Z-R20
PCISA Intel Celeron-M 800MHz Zero Cache CPU Card with LCD/CRT
VGA,Dual LAN,USB2.0 and Audio
Optional:
1. FDD cable P/N:32200-000058-RS
2. RS232/LPT cable P/N: 19800-000027-RS
Jumpers setting and Connectors
LABEL FUNCTION
JP1 CMOS state setting
JP2 CompactFlash Master(1-2)/Slave(2-3) setting
JP3 LVDS LCD power source 3.3V(1-2)/5v(2-3) setting
JP1 : Clear CMOS Setup
JP1 DESCRIPTION
1-2 Normal Operation
2-3 Clear CMOS Setup
JP3 : 3.3V/5V Mode Setting
JP3 DESCRIPTION
1-2 3.3V
2-3 5V
JP2 : Master/Salve Mode
Setting
JP2 DESCRIPTION
1-2 Master
2-3 Slave

4
Label Function
IDE1 Ultra ATA100 Primary (40 Pin)
IDE2 Secondary IDE connectors (44 PIN )
FDD1 Floppy connector
LPT1 Parallel port connector
DIO1 Digital I/O
COM1 Serial port connector(10 Pin)
COM2 RS-232/422/485 connector(14 PIN)
J1 Compact Flash Storage Card Type II connector
IR1 IRDA infrared interface port
USB1 USB port connector
USB2 USB dual port connector
USB3 USB dual port connector
J4 LAN1 RJ45 (10/100) connectors
J5 LAN2 RJ45(10/100/1000(optional)) connectors
KBM1 6-pin Mini-Din Keyboard & Mouse connector
KB1 External 5-pin Header Keyboard Connector
FAN1 FAN connector
CN3 External switches and indicators
CD-IN Audio CD IN connector
CN4 Backplane to CPU board ATX power control Connector
DVI DVI DISPLAY( Optional)
LVDS1 LVDS1 CONNECTOR
CN1 Backlight Inverter Connector
COM1 : 10-pin header onboard
COM2 : 14-pin header onboard
PIN DESCRIPTION PIN DESCRIPTION
1 DATA CARRIER
DETECT (DCD) 2 DATA SET READY
(DSR)
3 RECEIVE DATA
(RXD) 4 REQUEST TOSEND
(RTS)
5 TRANSMIT DATA
(TXD) 6 CLEAR TO SEND (CTS)
7 DATA TERMINAL
READY (DTR) 8 RING INDICATOR (RI)
9 GROUND 10 NC
(11) RS-422 TX+
RS-485 Data+ (12) RS-422 TX-
RS-485 Data-
(13) RS-422 RX+
(14) RS-422 RX-

5
CN3 : External Switches and Indicators
PIN DESCRIPTION PIN DESCRIPTION
1 +5V 2 Speaker +Power LED
3 GND 4 N/C
5 BUTTON PIN1 6 N/CATX POWER
BUTTON 7 BUTTON PIN2 8 Speaker -
Speaker
9 HDD LED + 10 Reset PIN1HDD LED
11 HDD LED - 12 Reset PIN2
Reset
Button
KB1 : 5-pin Header
Keyboard Connector
PIN DESCRIPTION
1 KEYBOARD
CLOCK
2 KEYBOARD DATA
3 N/C
4 GROUND
5 +5V
FAN1 : Fan Connector
PIN DESCRIPTION
1 GROUND
2 +12V
3 Rotation Signal
CDIN1 : CD-IN
PIN DESCRIPTION
1 CD LEFT SIGNAL
2 GROUND
3 GROUND
4 CD RIGHT SIGNAL
USB2&USB3: USB Port Connector
PIN DESCRIPTION PIN DESCRIPTION
1 VCC 2 GROUND
3 DATA0- 4 DATA1+
5 DATA0+ 6 DATA1-
7 GROUND 8 VCC
CN4 : Backplane to CPU
board Connector
PIN DESCRIPTION
1 GND
2 ATX-ON
3 5VSB
IR1: IrDA connector
PIN DESCRIPTION
1 VCC
2 NC
3 IR-RX
4 Ground
5 IR-TX
6 NC

6
DVI1 : DVI Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 DATA2- 14 Vcc
2 DATA2+ 15 GND
3 GND 16 HP_DET
4 NC 17 DATA0-
5 NC 18 DATA0+
6 DDCCLK 19 GND
7 DDCDATA 20 NC
8 NC 21 NC
9 DATA1- 22 GND-
10 DATA1+ 23 CLK+
11 GND 24 CLK-
12 NC 25 GND
13 NC
CN1: backlight inverter connector
PIN DESCRIPTION
1 NC
2 GROUND
3 BKL_POWER
4 GROUND
5 VCC
J3:External Power Connector
PIN DESCRIPTION
1 +5V
2 GROUND
3 GROUND
4 +12V
DIO1: Digital I/O
PIN DESCRIPTION PIN DESCRIPTION
1 GND 2 +5V
3 OUT0 4 OUT1
5 OUT2 6 OUT3
7 IN0 8 IN1
9 IN2 10 IN3

7
LVDS1 : LVDS Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 16 LVDSB_Y3-
2 GND 17 LVDSB_CLK+
3 LVDS_Y3+ 18 LVDSB_CLK-
4 LVDS_Y3- 19 LVDSB_Y2+
5 LVDS_CLK+ 20 LVDSB_Y2-
6 LVDS_CLK- 21 LVDSB_Y1+
7 LVDS_Y2+ 22 LVDSB_Y1-
8 LVDS_Y2- 23 LVDSB_Y0+
9 LVDS_Y1+ 24 LVDSB_Y0-
10 LVDS_Y1- 25 GND
11 LVDS_Y0+ 26 GND
12 LVDS_Y0- 27 VCC_LCD
13 GND 28 VCC_LCD
14 GND 29 VCC_LCD
15 LVDSB_Y3+ 30 VCC_LCD
AUDIO1
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 SPEAK(L) 2 SPEEAK(R)
3 GND 4 GND
5 LINE_OUT(L) 6 LINE_OUT(R)
7 LINEIN(L) 8 LINEIN(R)
9 GND 10 GND
11 MIC 12 GND

8
Board Layout: Jumper and Connector Locations
