IEI Technology WAFER-945GSE User manual

WAFER-945GSE 3.5" Motherboard
Page i
IEI Technology Corp.
User Manual
3.5" SBC with Intel® Atom™ Processor with support for VGA
and LVDS Displays, Dual PCIe GbE, CF Type II, and SATA
MODEL:
WAFER-945GSE
Rev. 2.01 – 20 April, 2012

WAFER-945GSE 3.5" Motherboard
Page ii
Revision
Date Version Changes
20 April, 2012 2.01 Updated Section
1.4: Dimensions
20 September, 2011 2.00 Updated for R20 version
23 August, 2011 1.04 Modified SATA connector description
15 June, 2009 1.03 Modified LVDS connector description in Section 3.2.10
12 March, 2009 1.02 Changed model name
8 January, 2009 1.01 Added a warning for using heat sink enclosure in Section 4.8
4 November, 2008 1.00 Initial release

WAFER-945GSE 3.5" Motherboard
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

WAFER-945GSE 3.5" Motherboard
Page iv
Table of Contents
