IEI Technology WSB-G41A User manual

1
Full-size PICMG 1.0with Intel® G41 supports socket
LGA775 Intel® Core™2 QuadCPU card with VGA, Dual PCIe
GbE, SATAII, COM, USB 2.0 and Audio, RoHS
WSB-G41A
Quick Installation Guide
Version 1.0
Apr. 07, 2010
Package Contents
WSB-G41A package includes the following items:
l1 x WSB-G41A Single Board Computer
l1 x Mini Jumper Pack
l4 x SATA Cable
l1 x Dual RS-232 Cable
l1 x USB Cable
l1 x IO-KIT-001-R20 ( DVI Model Only )
l1 x Utility CD
l1 x QIG (Quick Installation Guide)
©2006Copyright by IEI Technology corp.
All rights reserved.

2
Specifications
lCPU: LGA775 45nm Intel® Core™ 2 Extreme/Quad/Duo,
Celeron processors with 1333/1066/800MHz FSB supports
lSystem Chipset: Intel®G41+ICH7
lBIOS: AMI BIOS
lSystem Memory: 2x 240-pin dual-channel DDR3
800/1066MHz SDRAM up to 4GB
lEthernet: Dual PCIe Intel® 82583V GbE Controller (PCIe x1
Interface)
lI/O Interface:
2x RS-232
7x USB2.0 (1on bracket, 6on board by 2x4-pin pin header)
4x SATA II
1xIDE
1x FDD
1x LPT
1 x 6-pin pin header for PS/2 KB/MS
1 x PS/2 KB/MS
lSuper I/O: ITE IT8718F
lDigital I/O: 8-bit Digital I/O, 4-bit input / 4-bit output
lInfrared Interface: 1 x 5-pin pin header
lGraphic:
Intel® Graphics Media Accelerator X4500 (Intel® GMA X4500)
lDisplay:
VGA Intgrated in Intel® G41
DVI by Silicon Image SIL1362 (WSB-G41A-DVI only)
lAudio:
10-pin on board header connects to the IEI Audio kit
(AC-KIT-883HD-RD / AC-KIT08R-R10)
lWatchdog timer: Software programmable 1-255 sec. by
Super I/O:ITE IT8718F
lPower supply: ATXPower Support
lPower Consumption:
5V@7.13,12V@0.27A, 5V@0.11A, Vcore_12V@3.02A

3
(Running 3D Mark20001SE with Intel® Core™2 Duo E8500
3.16GHz 1333MHz FSB CPU with 2*2GB DDR3SDRAM)
lOperation Temperature: 0 ~ 60°C( 32°F ~ 140°F)
lOperation Humidity: 5% ~ 95%,non-condensing
lDimensions: 338mm X 122mm
lWeight: 1.1Kg
Ordering Information
WSB-G41A-R10:
Full-size PICMG 1.0with Intel® G41 supports socket LGA775 Intel®
Core™2 Quad CPU card with VGA, Dual PCIe GbE, SATAII, COM,USB
2.0 and Audio, RoHS
WSB-G41A-DVI-R10:
Full-size PICMG 1.0with Intel® G41 supports socket LGA775 Intel®
Core™2 Quad CPU card with VGA / DVI, Dual PCIe GbE, SATAII, COM,
USB 2.0 and Audio, RoHS
AC-KIT883HD-R10:
7.1Channel HD Audio kit with Realtek ALC883 support dual audio streams
AC-KIT08R-R10:
5.1Channel AC’97 audio kit with Realtek ALC655
CF-775A-RS:
High performance CPU cooler (92mm x92mm x73mm , 130W)
CF-520-RS-R11:
High performance CPU cooler (115mm x115mm x67mm , 115W)
CB-USB14-RS:4 ports USB cable
32102-000100-100-RS/32102-000100-200-RS/32102-000100-300-RS:
SATA power cable
19800-000049-RS: LPT cable
32200-000052-RS: ATA66 IDE flat cable

4
Jumpers setting and Connectors
LABEL FUNCTION
J_CMOS1 Clear CMOS setting Jumper
VGA1 External VGA 15-pin Female Connector
USB_C1 External USB Port Connectors
LAN1、LAN2External RJ45 LAN Connectors
KB1/MS1 Internal PS/2 KEYBOARD/MOUSE Connector
COM1
COM2 Internal Serial Port Connectors
USB1Internal USB Connector
J_AUDIO1 External Audio Module Connector
SATA1
SATA2
SATA3
SATA4
Serial ATA Connectors
IR1 Infrared Interface Connector
PIDE Internal IDE Connector
FDD1 Internal FDD Connector
LPT1 Internal LPT Connector
CPU_FAN1 CPU Fan Connector
DIO1 Digital Input / Output Connector
F_PANEL1 PWR、RST Buttons、Speaker and Indicators
CPU12V1 ATX-12V CPU Power Input Connector

5
J_CMOS1: Clear CMOS setting Jumper
J_CMOS1
DESCRIPTION
1-2
(Default) Normal
2-3Clear CMOS Data
VGA1 : 15-pin Female Connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1RED 2GREEN
3BLUE 4NC
5GND 6GND
7GND 8GND
9VCC 10 GND
11 NC 12 DDCDAT
13 HSYNC 14 VSYNC
15 DDCCLK
LAN1、LAN2: RJ45 LAN Connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1MDIA3-5MDIA1+
2MDIA3+ 6MDIA2+-
3. MDIA2-7MDIA0-
4. MDIA1-8MDIA0+
USB1:Internal USB Connector
PIN
DESCRIPTION
PIN
DESCRIPTION
1VCC (+5V) 2GND
3DATA-4DATA+
5DATA+ 6DATA-
7GND 8VCC (+5V)
USB_C1:USB Connector
PIN NO.
DESCRIPTION
1VCC
2DATA-
3DATA+
4GROUND

6
SATA1~SATA4 : Serial ATA Connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1GND 5RX-
2TX+ 6RX+
3TX-7GND
4GND 8N/C
J_AUDIO1 : External Audio Module Connector
PIN
DESCRIPTION PIN
DESCRIPTION
1ACZ_SYNC 2ACZ_BITCLK
3ACZ_SDOUT 4ACZ_PCBEEP
5ACZ_SDIN 6ACZ_RST#
7ACZ_VCC(+5V)
8ACZ_GND
9ACZ_12V 10 ACZ_GND
MS/KB1:
Internal 6
-
pin
Keyboard
Connector
PIN NO. DESCRIPTION
1VCC(+5V)
2Mouse Data
3Mouse Clock
4Keyboard Data
5Keyboard Clock
6Ground
COM1,COM2: Internal Serial Port Connector
PIN
DESCRIPTION
PIN
DESCRIPTION
1DCD#2DSR#
3RXD 4RTS#
5TXD 6CTS#
7DTR#8RI#
9GND 10
NC

7
PIDE1: IDE Interface Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1RESET# 2GND
3DATA 7 4DATA 8
5DATA 6 6DATA 9
7DATA 5 8DATA 10
9DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 GND 20 N/C
21 IDE DRQ 22 GND
23 IOW# 24 GND
25 IOR# 26 GND
27 IDE CHRDY 28 BALE –DEFAULT
29 IDE DACK 30 GND
31 INTERRUPT 32 N/C
33 SA1 34 PDIAG#
35 SA0 36 SA2
37 HDC CS0# 38 HDC CS1#
39 HDD ACTIVE# 40 GND
IR1:IrDA Connector
PIN
DESCRIPTION
1VCC (+5V)
2NC
3IR-RX
4GND
5IR-TX
CPU_FAN1 :
CPU Fan Connector
PIN NO.
DESCRIPTION
1Ground
2+12V
3Rotation Signal
4Control
DIO1 : Digital Input / Output Connector
PIN
DESCRIPTION PIN
DESCRIPTION
1Ground 2VCC (+5V)
3Output 3 4Output 2
5Output 1 6Output 0
7Input 3 8Input 2
9Input 1 10 Input 0

8
FDD1: FDC Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1GND 2REDUCE WRITE
3GND 4N/C
5N/C 6N/C
7GND 8INDEX#
9GND 10 MOTOR ENABLE A#
11 GND 12 DRIVE SELECT B#
13 GND 14 DRIVE SELECT A#
15 GND 16 MOTOR ENABLE B#
17 GND 18 DIRECTION#
19 GND 20 STEP#
21 GND 22 WRITE DATA#
23 GND 24 WRITE GATE#
25 GND 26 TRACK 0#
27 GND 28 WRITE PROTECT#
29 GND 30 READ DATA#
31 GND 32 SIDE 1 SELECT#
33 GND 34 DISK CHANGE#
LPT1: Parallel Port Connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1STROBE# 14 AUTO FORM FEED #
2DATA0 15 ERROR#
3DATA1 16 INITIALIZE#
4DATA2 17 PRINTER SELECT LN#
5DATA3 18 GND
6DATA4 19 GND
7DATA5 20 GND
8DATA6 21 GND
9DATA7 22 GND
10 ACKNOWLEDGE#23 GND
11 BUSY 24 GND
12 PAPER EMPTY 25 GND
13 PRINTER SELECT

9
F_PANEL1 : PWR、RST Buttons、Speaker and Indicators
Function
PIN
DESCRIPTION
PIN
DESCRIPTION
Function
1+5V 2+5V
3N/C 4N/C
Power LED
5GROUND 6N/C
7PWRBTN+ 8Speaker
Speaker
PWRBTN
9PWRBTN-10
N/C
11
+5V 12
Reset-
HDDLED
13
HDLED-14
GND RESET
CPU12V1: ATX
-
12V CPU Power Input connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1GND 2GND
3+12V 4+12V

10
