IEI Technology KINO-9452 User manual

KINO-9452 Mini-ITX SBC
Page I
KINO-9452 Mini-ITX SBC

KINO-9452 Mini-ITX SBC
Page II
Revision
Date Version Changes
2008-07 v2.00 -Changed Northbridge chipset from Intel® 945GM to Intel® 945GME
-Changed to new manual format
-Changed 14-pin RS-232/422/485 serial port from COM2 to COM3
-Added three jumper information:
 AT/ATX power mode select jumpers

LVDS screen resolution select jumper
 COM3 mode select jumpers
2007-10 v1.00 Initial Release

KINO-9452 Mini-ITX SBC
Page III
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

KINO-9452 Mini-ITX SBC
Page IV
Manual Conventions
WARNING!
Warnings appear where overlooked details may cause damage to the equipment or result
in personal injury. Warnings should be taken seriously. Warnings are easy to recognize.
The word “warning” is written as “WARNING,” both capitalized and bold and is followed by
text. The text is the warning message. A warning message is shown below:
WARNING:
This is an example of a warning message. Failure to adhere to warning
messages may result in permanent damage to the KINO-9452 or
personal injury to the user. Please take warning messages seriously.
CAUTION!
Cautionary messages should also be heeded to help reduce the chance of losing data or
damaging the KINO-9452. Cautions are easy to recognize. The word “caution” is written
as “CAUTION,” both capitalized and bold and is followed. The italicized text is the
cautionary message. A caution message is shown below:

KINO-9452 Mini-ITX SBC
Page V
CAUTION:
This is an example of a caution message. Failure to adhere to cautions
messages may result in permanent damage to the KINO-9452. Please
take caution messages seriously.
NOTE:
These messages inform the reader of essential but non-critical information. These
messages should be read carefully as any directions or instructions contained therein can
help avoid making mistakes. Notes are easy to recognize. The word “note” is written as
“NOTE,” both capitalized and bold and is followed by text. The text is the cautionary
message. A note message is shown below:
NOTE:
This is an example of a note message. Notes should always be read.
Notes contain critical information about the KINO-9452. Please take
note messages seriously.

KINO-9452 Mini-ITX SBC
Page VI
Packing List
NOTE:
If any of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the IEI reseller or
vendor you purchased the KINO-9452 from or contact an IEI sales
representative directly. To contact an IEI sales representative, please
send an email to [email protected].
The items listed below should all be included in the KINO-9452 package.
 1 x KINO-9452 single board computer
 1 x IDE flat cable
 1 x HDTV cable
 2 x SATA cables
 1 x SATA power cable
 1 x Dual RS-232 cable
 1 x I/O shielding
 1 x Mini jumper pack
 1 x Utility CD
 1 x Quick installation guide
Images of the above items are shown in Chapter 3.

KINO-9452 Mini-ITX SBC
Page VII
Table of Contents
1INTRODUCTION..................................................................................................... 1
1.1 KINO-9452 OVERVIEW............................................................................................. 2
1.1.1 KINO-9452 Benefits........................................................................................... 3
1.1.2 KINO-9452 Features.......................................................................................... 3
1.2 KINO-9452 BOARD OVERVIEW................................................................................. 4
1.2.1 KINO-9452 Connectors..................................................................................... 4
1.2.2 Technical Specifications..................................................................................... 5
2DETAILED SPECIFICATIONS ............................................................................. 8
2.1 OVERVIEW ................................................................................................................. 9
2.2 DIMENSIONS .............................................................................................................. 9
2.2.1 Board Dimensions.............................................................................................. 9
2.2.2 External Interface Panel Dimensions.............................................................. 10
2.3 DATA FLOW.............................................................................................................. 10
2.4 COMPATIBLE PROCESSORS ........................................................................................11
2.4.1 Compatible Processor Overview ......................................................................11
2.4.2 Supported Processors ...................................................................................... 12
2.5 INTEL®945GME GRAPHICS AND MEMORY CONTROLLER HUB............................... 13
2.5.1 Intel®945GME Overview................................................................................ 13
2.5.2 Intel® 945GME Front Side Bus (FSB) Support .............................................. 13
2.5.3 Intel®945GME Memory Support..................................................................... 14
2.5.4 Intel®945GME Integrated Graphics............................................................... 15
2.5.4.1 Intel®945GME Analog CRT Support....................................................... 15
2.5.4.2 Intel®945GME LVDS Support................................................................. 16
2.5.4.3 Intel®945GME TV Out Support .............................................................. 16
2.5.5 Intel®945GME Direct Media Interface (DMI)................................................ 16
2.6 INTEL®ICH7-M I/O CONTROLLER HUB.................................................................. 17
2.6.1 Intel®ICH7-M Overview ................................................................................. 17
2.6.2 Intel®ICH7-M HD Audio Controller............................................................... 17
2.6.3 Intel®ICH7-M PCIe Bus: PCIe GbE Ethernet Controller.............................. 18
2.6.4 Intel®ICH7-M IDE Interface........................................................................... 19

KINO-9452 Mini-ITX SBC
Page VIII
2.6.5 Intel®ICH7-M Low Pin Count (LPC) Interface.............................................. 20
2.6.6 Intel®ICH7-M PCI Interface........................................................................... 20
2.6.7 Intel®ICH7-M Real Time Clock ...................................................................... 21
2.6.8 Intel®ICH7-M SATA Controller ...................................................................... 21
2.6.9 Intel®ICH7-M USB Controller........................................................................ 21
2.7 PCIE BUS COMPONENTS .......................................................................................... 22
2.7.1 PCIe Bus Overview.......................................................................................... 22
2.7.2 Broadcom PCI Express GbE interface............................................................. 22
2.8 LPC BUS COMPONENTS........................................................................................... 23
2.8.1 LPC Bus Overview........................................................................................... 23
2.8.2 BIOS Chipset.................................................................................................... 23
2.8.3 Super I/O chipset.............................................................................................. 23
2.8.3.1 Super I/O LPC Interface ........................................................................... 24
2.8.3.2 Super I/O 16C550 UARTs ........................................................................ 24
2.8.3.3 Super I/O Enhanced Hardware Monitor................................................... 24
2.8.3.4 Super I/O Fan Speed Controller................................................................ 24
2.8.3.5 Super I/O Keyboard Controller................................................................. 25
2.8.4 Fintek F81216DG LPC Serial Port Chipset.................................................... 25
2.9 ENVIRONMENTALAND POWER SPECIFICATIONS ....................................................... 25
2.9.1 System Monitoring ........................................................................................... 25
2.9.2 Operating Temperature and Temperature Control........................................... 26
2.9.3 Power Consumption......................................................................................... 26
3UNPACKING .......................................................................................................... 28
3.1 ANTI-STATIC PRECAUTIONS...................................................................................... 29
3.2 UNPACKING.............................................................................................................. 29
3.2.1 Unpacking Precautions.................................................................................... 29
3.3 UNPACKING CHECKLIST........................................................................................... 30
3.3.1 Package Contents............................................................................................. 30
3.3.2 Optional Items.................................................................................................. 31
4CONNECTORS AND JUMPERS......................................................................... 33
4.1 PERIPHERAL INTERFACE CONNECTORS .................................................................... 34
4.1.1 KINO-9452 Layout........................................................................................... 34
4.1.2 Peripheral Interface Connectors ..................................................................... 35

KINO-9452 Mini-ITX SBC
Page IX
4.1.3 Rear Panel Connectors.................................................................................... 36
4.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 37
4.2.1 Audio Connector .............................................................................................. 37
4.2.2 Fan Connectors................................................................................................ 38
4.2.3 Front Panel Connector .................................................................................... 39
4.2.4 Digital Input/Output Connector....................................................................... 40
4.2.5 IDE Connector................................................................................................. 41
4.2.6 LCD Backlight Connector................................................................................ 42
4.2.7 LVDS LCD connector ...................................................................................... 43
4.2.8 Mini PCI Slot ................................................................................................... 45
4.2.9 Power Connector............................................................................................. 46
4.2.10 14-Pin Serial Port Connectors....................................................................... 47
4.2.11 10-Pin Serial Port Connectors....................................................................... 48
4.2.12 SATA Drive Connectors ................................................................................. 49
4.2.13 SPDIF Connector........................................................................................... 50
4.2.14 Internal USB Connectors............................................................................... 51
4.3 EXTERNAL INTERFACE CONNECTORS....................................................................... 52
4.3.1 Audio Connectors............................................................................................. 53
4.3.2 CRT Connector ................................................................................................ 54
4.3.3 Ethernet Connectors ........................................................................................ 55
4.3.4 Keyboard/Mouse Connector ............................................................................ 56
4.3.5 Serial Port Connectors .................................................................................... 57
4.3.6 TV-Out Connector............................................................................................ 58
4.3.7 USB Connector ................................................................................................ 59
5INSTALLATION .................................................................................................... 60
5.1 ANTI-STATIC PRECAUTIONS...................................................................................... 61
5.2 INSTALLATION CONSIDERATIONS ............................................................................. 62
5.2.1 Installation Notices.......................................................................................... 62
5.2.2 Installation Checklist....................................................................................... 63
5.3 CPU, CPU COOLING KITAND DIMM INSTALLATION ............................................. 64
5.3.1 Socket 479 CPU Installation............................................................................ 64
5.3.2 Cooling Kit CF-479B-RS Installation.............................................................. 66
5.3.3 DIMM Installation........................................................................................... 68
5.4 JUMPER SETTINGS.................................................................................................... 70

KINO-9452 Mini-ITX SBC
Page X
5.4.1 AT/ATX Power Select Jumper Settings ............................................................ 70
5.4.2 Clear CMOS Jumper........................................................................................ 72
5.4.3 COM 3 Function Select Jumper....................................................................... 73
5.4.4 LVDS Screen Resolution Selection................................................................... 74
5.4.5 LVDS Voltage Selection.................................................................................... 76
5.5 CHASSIS INSTALLATION ........................................................................................... 77
5.5.1 Airflow.............................................................................................................. 77
5.5.2 Motherboard Installation................................................................................. 78
5.6 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 78
5.6.1 Peripheral Device Cables................................................................................ 78
5.6.2 IDE Cable Connection..................................................................................... 79
5.6.3 Dual RS-232 Cable Connection....................................................................... 80
5.6.4 SATA Drive Connection ................................................................................... 81
5.7 EXTERNAL PERIPHERAL INTERFACE CONNECTION................................................... 82
5.7.1 Audio Connection............................................................................................. 83
5.7.2 RJ-45 Ethernet and USB Connection .............................................................. 83
5.7.3 VGA Monitor Connection ................................................................................ 84
5.7.4 Serial Device Connection ................................................................................ 85
5.7.5 PS/2 Keyboard/Mouse Connection.................................................................. 86
5.7.6 HDTV Cable Connection................................................................................. 87
6AMI BIOS................................................................................................................ 89
6.1 INTRODUCTION ........................................................................................................ 90
6.1.1 Starting Setup................................................................................................... 90
6.1.2 Using Setup...................................................................................................... 90
6.1.3 Getting Help..................................................................................................... 91
6.1.4 Unable to Reboot after Configuration Changes.............................................. 91
6.1.5 BIOS Menu Bar................................................................................................ 91
6.2 MAIN ....................................................................................................................... 91
6.3 ADVANCED............................................................................................................... 93
6.3.1 CPU Configuration.......................................................................................... 94
6.3.2 IDE Configuration........................................................................................... 95
6.3.2.1 IDE Master, IDE Slave ............................................................................. 97
6.3.3 Super IO Configuration.................................................................................. 101
6.3.4 Hardware Health Configuration.................................................................... 104

KINO-9452 Mini-ITX SBC
Page XI
6.3.5 Power Configuration...................................................................................... 106
6.3.5.1 ACPI Configuration ................................................................................ 107
6.3.5.2 APM Configuration................................................................................. 108
6.3.6 Remote Access Configuration.........................................................................110
6.3.7 USB Configuration..........................................................................................112
6.4 PCI/PNP .................................................................................................................114
6.5 BOOT ......................................................................................................................116
6.5.1 Boot Settings Configuration............................................................................117
6.6 SECURITY............................................................................................................... 120
6.7 CHIPSET ................................................................................................................. 121
6.7.1 North Bridge Configuration........................................................................... 122
6.7.2 South Bridge Configuration........................................................................... 126
6.8 EXIT....................................................................................................................... 128
7SOFTWARE DRIVER ......................................................................................... 130
7.1 AVAILABLE SOFTWARE DRIVERS ............................................................................ 131
7.2 CHIPSET DRIVER INSTALLATION............................................................................. 131
7.3 VGA DRIVER......................................................................................................... 134
7.4 BROADCOM LAN DRIVER (FOR GBE LAN) INSTALLATION .................................. 138
7.5 REALTEK HD AUDIO DRIVER (ALC883) INSTALLATION....................................... 143
7.6 INTEL MATRIX STORAGE MANAGER INSTALLATION............................................... 148
ABIOS CONFIGURATION OPTIONS ............................................................. 151
A.1 BIOS CONFIGURATION OPTIONS........................................................................... 152
BDIO INTERFACE................................................................................................. 155
B.1 DIO INTERFACE INTRODUCTION ........................................................................... 156
B.2 DIO CONNECTOR PINOUTS ................................................................................... 156
B.3 ASSEMBLY LANGUAGE SAMPLES........................................................................... 157
B.3.1 Enable the DIO Input Function..................................................................... 157
B.3.2 Enable the DIO Output Function.................................................................. 157
CWATCHDOG TIMER .......................................................................................... 158
DADDRESS MAPPING.......................................................................................... 161
D.1 IO ADDRESS MAP ................................................................................................. 162
D.2 1ST MB MEMORYADDRESS MAP ......................................................................... 162

KINO-9452 Mini-ITX SBC
Page XII
D.3 IRQ MAPPING TABLE............................................................................................ 163
D.4 DMA CHANNELASSIGNMENTS............................................................................. 163
ECOMPATIBILITY................................................................................................ 164
E.1 COMPATIBLE PROCESSORS..................................................................................... 165
E.2 COMPATIBLE MEMORY MODULES.......................................................................... 166
FHAZARDOUS MATERIALS DISCLOSURE................................................... 167
F.1 HAZARDOUS MATERIAL DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY..................................... 168
GEXTERNALAC’97 AUDIO CODEC................................................................. 171
G.1 INTRODUCTION...................................................................................................... 172
G.1.1 Accessing the AC’97 CODEC ....................................................................... 172
G.1.2 Driver Installation......................................................................................... 172
G.2 SOUND EFFECT CONFIGURATION ........................................................................... 173
G.2.1 Accessing the Sound Effects Manager........................................................... 173
G.2.2 Sound Effect Manager Configuration Options.............................................. 174
HINDEX.................................................................................................................... 177

KINO-9452 Mini-ITX SBC
Page XIII
List of Figures
Figure 1-1: KINO-9452 Embedded SBC.......................................................................2
Figure 1-2: KINO-9452 Board Overview (Top View)...................................................4
Figure 2-1: KINO-9452 Dimensions (mm) ...................................................................9
Figure 2-2: External Interface Panel Dimensions (mm)...........................................10
Figure 2-3: Data Flow Block Diagram........................................................................11
Figure 2-4: Front Side Bus (FSB)...............................................................................13
Figure 2-5: 240-pin DDR2 DIMM Sockets..................................................................14
Figure 2-6: Integrated Graphics Interfaces...............................................................15
Figure 2-7: HD Audio Codec ......................................................................................18
Figure 2-8: PCIe GbE Connectors .............................................................................19
Figure 2-9: Mini PCI Slot.............................................................................................20
Figure 2-10: Onboard USB Implementation .............................................................22
Figure 4-1: Connector and Jumper Locations .........................................................34
Figure 4-2: Audio Connector Location......................................................................37
Figure 4-3: Fan Connector Locations .......................................................................38
Figure 4-4: Front Panel Connector Location............................................................39
Figure 4-5: GPIO Connector Location.......................................................................40
Figure 4-6: IDE Device Connector Location.............................................................41
Figure 4-7: LCD Backlight Connector Location.......................................................43
Figure 4-8: LVDS LCD Connector Location..............................................................44
Figure 4-9: Mini PCI Slot Location.............................................................................45
Figure 4-10: Power Connector Location...................................................................47
Figure 4-11: 14-Pin Serial Port Connector Locations..............................................48
Figure 4-12: 10-Pin Serial Port Connector Locations..............................................49
Figure 4-13: SATA Drive Connector Locations........................................................50
Figure 4-14: SPDIF Connector Locations.................................................................51
Figure 4-15: Internal USB Connector Locations......................................................52

KINO-9452 Mini-ITX SBC
Page XIV
Figure 4-16: KINO-9452 External Interface Connectors..........................................53
Figure 4-17: Audio Connectors..................................................................................54
Figure 4-18: VGA Connector......................................................................................54
Figure 4-19: RJ-45 Ethernet Connector ....................................................................55
Figure 4-20: PS/2 Pinouts...........................................................................................56
Figure 4-21: External Serial Port Connector ............................................................57
Figure 4-22: TV-Out Connector..................................................................................58
Figure 5-1: Make sure the CPU socket retention screw is unlocked.....................65
Figure 5-2: Lock the CPU Socket Retention Screw .................................................66
Figure 5-3: IEI CF-479B-RS Cooling Kit ....................................................................66
Figure 5-4: Cooling Kit Support Bracket...................................................................67
Figure 5-5: Connect the cooling fan cable ...............................................................68
Figure 5-6: Installing a DIMM .....................................................................................69
Figure 5-7: Jumper Locations....................................................................................70
Figure 5-8: AT/ATX Power Select Jumper Location................................................71
Figure 5-9: Clear CMOS Jumper................................................................................73
Figure 5-10: COM 3 Function Select Jumper Location ...........................................74
Figure 5-11: LVDS Screen Resolution Selection Jumper Pinout Locations.........75
Figure 5-12: LVDS Voltage Selection Jumper Pinout Locations............................77
Figure 5-13: IDE Cable Connection...........................................................................79
Figure 5-14: Dual RS-232 Cable Installation.............................................................80
Figure 5-15: SATA Drive Cable Connection .............................................................81
Figure 5-16: SATA Power Drive Connection............................................................82
Figure 5-17: Audio Connectors..................................................................................83
Figure 5-18: RJ-45 Ethernet Connector ....................................................................84
Figure 5-19: VGA Connector......................................................................................85
Figure 5-20: Serial Device Connector .......................................................................86
Figure 5-21: PS/2 Keyboard/Mouse Connector........................................................87
Figure 5-22: HDTV Cable Connector.........................................................................88
Figure 7-1: InstallShield Wizard Preparation Screen............................................ 132
Figure 7-2: Welcome Screen................................................................................... 132
Figure 7-3: License Agreement............................................................................... 133

KINO-9452 Mini-ITX SBC
Page XV
Figure 7-4: Readme Information............................................................................. 133
Figure 7-5: Restart the Computer........................................................................... 134
Figure 7-6: Starting Install Shield Wizard Screen................................................. 135
Figure 7-7: Preparing Setup Screen....................................................................... 135
Figure 7-8: VGA Driver Installation Welcome Screen........................................... 136
Figure 7-9: VGA Driver License Agreement .......................................................... 136
Figure 7-10: VGA Driver Installing Notice.............................................................. 137
Figure 7-11: VGA Driver Installation Complete..................................................... 137
Figure 7-12: Access Windows Control Panel........................................................ 138
Figure 7-13: Double Click the System Icon ........................................................... 139
Figure 7-14: Double Click the Device Manager Tab.............................................. 139
Figure 7-15: Device Manager List........................................................................... 140
Figure 7-16: Search for Suitable Driver.................................................................. 141
Figure 7-17: Locate Driver Files.............................................................................. 142
Figure 7-18: Location Browsing Window............................................................... 142
Figure 7-19: Access Windows Control Panel........................................................ 143
Figure 7-20: Double Click the System Icon ........................................................... 144
Figure 7-21: Double Click the Device Manager Tab.............................................. 145
Figure 7-22: Device Manager List........................................................................... 146
Figure 7-23: Search for Suitable Driver.................................................................. 147
Figure 7-24: Locate Driver Files.............................................................................. 148
Figure 7-25: Preparing Setup Screen..................................................................... 149

KINO-9452 Mini-ITX SBC
Page XVI
List of Tables
Table 1-1: Technical Specifications ............................................................................7
Table 2-1: Processor Features...................................................................................12
Table 2-2: Supported Processors..............................................................................12
Table 2-3: Supported HDD Specifications................................................................19
Table 2-4: Power Consumption .................................................................................27
Table 3-1: Package List Contents..............................................................................31
Table 3-2: Optional Items ...........................................................................................32
Table 4-1: Peripheral Interface Connectors..............................................................36
Table 4-2: Rear Panel Connectors.............................................................................36
Table 4-3: Audio Connector Pinouts.........................................................................37
Table 4-4: Fan Connector Pinouts.............................................................................38
Table 4-5: Front Panel Connector Pinouts ...............................................................40
Table 4-6: GPIO Connector Pinouts..........................................................................41
Table 4-7: IDE Connector Pinouts.............................................................................42
Table 4-8: LCD Backlight Connector Pinouts ..........................................................43
Table 4-9: LVDS LCD Connector Pinouts.................................................................44
Table 4-10: Mini PCI Slot Pinouts ..............................................................................46
Table 4-11: Power Connector Pinouts ......................................................................47
Table 4-12: COM3 Pinouts..........................................................................................48
Table 4-13: COM2 and COM4 Pinouts.......................................................................49
Table 4-14: SATA Drive Connector Pinouts .............................................................50
Table 4-15: SPDIF Pinouts..........................................................................................51
Table 4-16: USB3 and USB4 Pinouts.........................................................................52
Table 4-17: VGA Connector Pinouts .........................................................................55
Table 4-18: LAN1 and LAN2 Pinouts.........................................................................55
Table 4-19: RJ-45 Ethernet Connector LEDs............................................................56
Table 4-20: PS/2 Connector Pinouts .........................................................................57
Table 4-21: External Serial Port Pinouts...................................................................58

KINO-9452 Mini-ITX SBC
Page XVII
Table 4-22: TV-Out Pinouts ........................................................................................59
Table 4-23: External USB Connector Pinouts ..........................................................59
Table 5-1: Jumpers......................................................................................................70
Table 5-2: AT/ATX Power Select Jumper Settings...................................................71
Table 5-3: Clear CMOS Jumper Settings ..................................................................72
Table 5-4: COM 3 Function Select Jumper Settings................................................74
Table 5-5: LVDS Screen Resolution Selection Jumper Settings............................75
Table 5-6: LVDS Voltage Selection Jumper Settings ..............................................76
Table 5-7: IEI Provided Cables...................................................................................78
Table 6-1: BIOS Navigation Keys...............................................................................91

KINO-9452 Mini-ITX SBC
Page XVIII
List of BIOS Menus
BIOS Menu 1: Main 92
BIOS Menu 2: Advanced.............................................................................................94
BIOS Menu 3: CPU Configuration..............................................................................95
BIOS Menu 4: IDE Configuration...............................................................................96
BIOS Menu 5: IDE Master and IDE Slave Configuration..........................................98
BIOS Menu 6: Super IO Configuration................................................................... 102
BIOS Menu 7: Hardware Health Configuration...................................................... 104
BIOS Menu 8: Power Configuration ....................................................................... 106
BIOS Menu 9: General ACPI Configuration [Advanced\ ACPI Configuration]... 107
BIOS Menu 10: APM Configuration........................................................................ 108
BIOS Menu 11: Remote Access Configuration [Advanced] ................................ 111
BIOS Menu 12: USB Configuration......................................................................... 112
BIOS Menu 13: PCI/PnP Configuration.................................................................. 115
BIOS Menu 14: Boot................................................................................................. 117
BIOS Menu 15: Boot Settings Configuration......................................................... 118
BIOS Menu 16: Security........................................................................................... 120
BIOS Menu 17: Chipset............................................................................................ 122
BIOS Menu 18: North Bridge Chipset Configuration............................................ 123
BIOS Menu 19:South Bridge Chipset Configuration............................................ 127
BIOS Menu 20:Exit ................................................................................................... 128

KINO-9452 Mini-ITX SBC
Page 1
1Introduction
Chapter
1

KINO-9452 Mini-ITX SBC
Page 2
1.1 KINO-9452 Overview
Figure 1-1: KINO-9452 Embedded SBC
The KINO-9452 Mini-ITX form factor motherboard is an Intel® dual-core CPU platform.
Intel® Core™2 Duo, Core Duo and Core Solo CPU are all supported to enhance the
system processing speed. The KINO-9452 has a maximum front side bus (FSB)
frequency of 667 MHz and contains two DDR2 SDRAM DIMM sockets that support up to
4 GB system memory.
The KINO-9452 supports two audio streams through the High Definition (HD) audio codec
and supports diverse displays including one VGA display, one HDTV display and one
LVDS display. These multimedia features make the KINO-9452 a best choice for
integrating into point-of-sale (POS), kiosk or digital signage applications.
The KINO-9452 supports up to two serial ATA (SATA) hard disk drives (HDD) with
maximum transfer rates of 1.5 Gb/s and up to eight USB 2.0 devices. The dual PCI
Express (PCIe) Gigabit Ethernet (GbE) controllers provide GbE connectivity for network
communication. The KINO-9452 also has a PCI socket and a Mini PCI socket for system
expansion. Three RS-232, one RS-232/422/485 and one digital input/output (DIO) port
offer system integrators more choices of peripheral devices for the targeted application.
